Speed Dome/Keyboard Controller
EVC300D
Colour Dome Camera
!Please unpack all boxes carefully and identify that all the parts are present.
!Make sure you use only the recommended power supplies. Damage caused to the
camera or controller by incorrect voltage or wiring is not covered by the
warranty.
!Cutting the camera cable will void the warranty.
Before you begin
EVC22ZSD/EVC2KB
Speed Dome/Keyboard Controller

Index
Camera Instructions
Cautions...........................................................................................................3
Camera-Overview..............................................................................................4
Camera-Features..............................................................................................4
Camera-Contents..............................................................................................5
Camera installation............................................................................................6
Camera- Wiring Diagrams.................................................................................8
Camera- Communication Settings.....................................................................9
Preset Functions..............................................................................................11
Camera Testing..................................................................................................12
Troubleshooting...............................................................................................13
Camera Specifications.....................................................................................14
Keyboard Controller Instructions
Cautions..........................................................................................................15
Controller-Overview..........................................................................................15
Controller-Features..........................................................................................15
Controller-Contents..........................................................................................15
Controller-Keyboard Panel...............................................................................16
Controller-Keyboard Operation.........................................................................16
Controller-Wiring Diagram................................................................................19
Controller-Specifications....................................................................................20
2

1. Please read this manual carefully before beginning the installation work.
2. This dome camera operates using a 24V AC power supply, the voltage input
rating marks can be found at the bottom of the dome.
3. This dome camera is manufactured using precision optics and electrical
components; high pressure, heavy vibration or other improper handling during
transportation and installation may cause damage to the equipment.
4. Do not disassemble the internal components of the dome camera.
5. Each electrical safety standard must be complied with during the operation of
this equipment. Use only the recommended power supply for this product. Keep
an adequate distance between the RS-485, video signal transmission cable and
any high voltage equipment or cables. We recommend that you take measures to
prevent any damage to this unit in the event of a lightning strike or power surge.
6. The dome camera stated in this manual is for indoor use only, if you want to site
the camera in a position where it may be exposed to the elements, please use an
external dome camera.
7. Do not use the equipment beyond the stated temperature, humidity and voltage
ratings.
8. The camera must be positioned so that it will not point directly into the sun (sunrise and sunset) or any bright
light, as this may cause damage to the camera. Also, avoid viewing areas where half the area is in bright sunlight
and the other half is dark, such as in the shadow of a building. All types of cameras have difficulty in ‘seeing’ with
such a large lux level variation.
9. Do not clean the equipment with an abrasive cleaning agent, use a dry cloth to remove any dirt from the
surfaces of the camera.
10. Make sure the final fixing position of the camera can support enough load to
carry the combined weight of the bracket and camera.
11. Use a professional lens cloth for cleaning the lens.
Cautions
3

The EVC22ZSD Colour Speed Dome Camera is designed for use in high risk applications and can be panned,
tilted and zoomed in seconds to the view you require. Features pan tilt speeds of up to 100° per second, a 22x
Optical Zoom Lens, and operation down to 0.5 lux. It offers 480 TVL images from its Sony 1/4" Super HAD CCD
sensor and can be controlled by Pelco D or P compatible DVRs and Camera Controllers. The camera is designed
for wall mounting externally as supplied.
1. Integrated multi-protocol decoder
a. Built-in decoder consists of multi-protocol and can integrate up to 9 communications protocols. The
communication baud rate is adjustable. Using the simple dip switch located inside the camera body, the product
can be made compatible with most domestic and foreign systems.
b.RS485 serial control, address of Speed Dome device is from 0-255.
2. Integrate full-view rotary PAN/TILT:
a. Horizontal 0-360º unlimited continuous rotation and rotation rate that can be adjusted from 0.1-100°/s
continuously. Vertical rotation range is 0-90º and rotation rate can achieve 90°/s.
b. Built in image stabilizer for low speed operation.
c. Auto flip function eliminates blind spots when following a person or object.
3. Intelligent power-off memory operation
a. Provides 128 preset points (including pan-tilt positions and lens focus preset points) and information power-off
memory.
b. The Speed Dome can scan between two points horizontally and the scanning speed can be changed and
selected.
c. Provides setting of scanning track and selects cruise track function. The Self-test facility will allow you to store
and edit information for power-off memory. (Depending on user’s keyboard controller or DVR function)
4. New-added functions
A. Long-focus speed-limited function: Speed dome can auto adjusts its manual control speed according the current
focus length of video camera. When the user zooms in to make the image larger, its manual control speed
becomes slower, which ensures that video camera can scan the object quickly and correctly.
B. Flexible and convenient to use: The Speed Dome uses multiple communication protocols including Pelco P and
Pelco D, and baud rate is selectable from 2400bps to 19200bps.
C. Line-scanning position freely selectable: This device can scan between any two selected points within less than
180°, and the scanning speed is adjustable continuously.
D. Six programmable Guard Tour presets: Each Guard Tour has 16 preset points and the dwell time and call speed
for each preset position can be set.
E. Intelligent power loss memory retains current setting and state: If the camera is line scanning or in Guard Tour
mode when there is a power loss, the current settings and work states were be saved. When the camera is
powered on there will be no need to reset any of your presets.
Camera-Overview
Camera-Features
4

F. Home position: The home function is available when it is set to ON, namely, this means that the speed dome
camera will return the home position (Preset Number 1) if there is no activity in a period of time, additionally the
user can adjust the Dwell time. The dome camera will not return the home position if it is in scan mode. If no home
function is needed when the dome camera is stopped, set the option to OFF.
G. Intelligent manually pan continuous scanning: When the user uses a joystick for pan scan monitoring, in certain
settings, the dome can continue with the pan scan automatically.
H. Tilting and Zooming while scanning: Tilting and zooming while line scanning or manually pan continuous
scanning.
Camera-Features
Code Description
1Manual
2 Acrylic Dome Cover
3 Dome Housing
4Wall mount bracket
5 12V DC Power Supply
6Black inner cover
7BNC cable
8 Screws pack
Camera-Contents
5

Dome Shield Cover Installation
Tighten up the screws
Fig 1.1
Fig 1.2
Camera- Installation
Step1- Align the dome core black cover open cut out with the camera lens, then align the four holes on the shield
cover with the fours screw holes of the dome camera.
Step2-Tighten up the 4x half thread screws.
Step 3- Align the dome cover to the dome lock position, rotate clockwise to tighten.
6

Dome Camera Bracket Installation
Fig 1.3
Fig 1.4 Fig 1.5
Step1- Use the diagram shown below to measure out the distances between the four holes required, then drill 4
holes in the chosen mounting location.
Step 2- Feed the dome connection cable into the bracket hollow pipe. Caution! Before attaching to the wall, check
that there is nothing left inside the bracket aperture. As shown in Fig 1.4.
Step 3- Fix the bracket and connection cable to the wall using the fixing screws supplied. As shown in Fig 1.5.
Step 4- Connect the dome connection cable to connector located in the aperture at the top of the dome housing,
as shown in Fig 1.6.
Fig 1.6
Connect the dome cable
connectors
7

Step 5- Fix the dome to the wall bracket, by tightening the screws, as shown in Fig 1.7.
Cautions- Remember to use the washers supplied, with the screws during this step.
Fig 1.7
Fig 1.8
Note: Complete all the wiring connections before you power up the speed dome camera.
This section explains how to wire a single speed dome camera, making it simple to install, test and demonstrate
the camera. When using this product for the first time, please read carefully and follow this electric wiring drawing
as incorrect wiring may lead to permanent damage of the speed dome device or damage to other equipment.
Make the electrical connections to power the camera and the RS485 connections if you are using this camera with
the EVS2KB controller (see Page 15 onwards for details).
Single Speed Dome
Installation Tip
Before fixing the speed dome permanently in position make sure that the baud rate, protocol and camera ID
are all set. Connect to a controller and test that the main camera functions are working correctly. See Camera
Testing on Page 11
Camera- Wiring Diagrams
8

When connecting multiple speed domes, the user can expand the system with additional devices such as a
capture device, video matrix, DVR or an alarm box.
AC24V: The camera’s power supply, will convert 110V/60HZ or 220V/50HZ input to a AC 24V output.
RS-485 Bus: The RS485 signal output from the controller connects to the RS485 wires from each of the cameras,
allowing one controller to control many speed domes.
Video: The video signal from each speed dome can directly output to video equipment such as monitor or video
matrix. !!T
ake care to match up the impedance!!
Before installation and use, set the communication protocol and transmission speed (baud rate), as shown
below.
1. Setting protocol and baud rate of the camera
Multiple Speed Domes
Fig 1.9
When setting the communication protocol of the camera, the
first 4 characters on the dip switch are used to set default
serial transmission rate of the protocol. If the default baud rate
of the protocol does not match with baud rate of host, reset
the default baud rate of the protocol consistent with default
baud rate of host (See table on page 10). The table lists
protocols that are suitable for this camera. Normal operations
of these protocols are compatible with domestic and foreign
main systems.
Attention: The protocol and baud rate of the camera should
comply with those of controller, which needs to be restarted
after making changes to the settings. (Page 15)
Camera- Communication Settings
9

1st digit 2nd digit 3rd digit 4th digit 5th digit 6th digit
PELCO D ON ON OFF OFF ** **
PELCO P OFF OFF ON OFF ** **
AUTO OFF OFF OFF OFF ** **
IQS ON ON ON ON ** **
ON/OFF
Status
Protocol
5th digit 6th digit
2400 OFF OFF
4800 OFF ON
9600 ON OFF
19200 ON ON
ON/OFF
Status
Protocol
This dip switch in this example is
set to PELCO D protocol and
baud rate of 2400
2. Setting the address of the camera
Setting address for dome device (this figure shows the address of
camera No 1).
Setting Method
The sum of switch numbers when in the ON position is the address of dome device, see diagrams below.
Calculation example of the camera address:
(2+4+16=22)The camera address is 22.The camera address range is 0-255.
