Z-TRAUQ ESM 7750 User manual

1-877-798-7287 P.1
ESM 7750 v10R7
2.1 GENERAL DESCRIPTION:
2.2 DIMENSIONS:
2.3 PANEL CUT-OUT:
2.4 PANEL MOUNTING:
Please read the following information before using and
thank you very much for buying Emko products.
The safety requirements are classified as "warning" or
"caution" according to the following explanations:
WARNING: Suggests that the user' s mishandling can
result in personal death or serious injury.
CAUTION: Suggests that the user' s mishandling can
result in personal injury or damage to the property.
Packing List: One unit.
Two fixing clamps.
One owner’s manual.
1. INTRODUCTION:
ESM series process controllers can be adapted easily to all applications and automation
systems to control heating, cooling or any process parameters. They are mainly used in the
glass, plastics, petrochemical, textile, automotive and machine production industries.
ESM series products are highly developed offering sensitive control schemes by means of
selectable control forms including ON/OFF, P, PI, PD, PID, Auto-tune and Self-tune.
2. INSTALLATION:
WARNING: A visual inspection of this product for possible damage during shipment is
recommended before installation. It is your responsibility to ensure that qualified mechanical
and electrical technicians install this product.
If there is danger of serious accident resulting from a failure or defect in this unit, the user
shall provide the unit with an appropriate external protective circuit.
The unit is normally supplied without a power switch or a fuse. Use power switch and fuse as
required (fuse rating is 1A@250VAC)
Be sure to use the rated power supply voltage to protect the unit against damage and to
prevent failure.
Keep the power off until all of the wiring is completed so that electric shock and trouble with
the unit can be prevented.
Never attempt to disassemble, modify, or repair this unit. Tampering with the unit may result
in malfunction, electric shock, or fire.
Do not use the unit in combustible or explosive gaseous atmospheres.
During installation into a metal panel, care should be taken to avoid injury from metal burrs
which might be present. The equipment can loosen from vibration and become dislodged if
installation parts aren't properly tightened.
WARNING: Before beginning installation of this product:
Disconnect all electrical power to the machine.
Make sure the machine cannot operate during installation.
Follow all safety warnings of the machine manufacturer.
CAUTION: Forbidden Conditions: Corrosive and explosive atmospheres, Home application.
This unit is for industrial applications, only.
Carefully read and follow all installation instructions.
Remove power from unit. Firmly grip the facia, push
Œ
the locking tabs top and bottom and pull the unit
from its case.
Insert the module(s) into the cavity(ies as shown).

Carefully reinsert
Ž
the unit into its
housing. Make
certain that the
communications
port lines up with
the hole at the back
of the housing and
snap into place.
Terminal cover
Label
Mounting Clamp
Front Panel
Enclosure max 5mm thick
69mm (2.72in)
69mm (2.72in)
97mm (3.82in)
(97mm 3.82in)
Inserting into Panel:
WARNING: During installation into
a metal panel, care should be taken to
avoid injury from metal burrs which
might be present. The equipment can
loosen from vibration and become
dislodged if installation parts aren't
properly tightened.
!Prepare panel cut-out.
!Check front panel gasket position.
!Insert the device through the cut-
out.
Installing the Fixing Clamps:
The unit is designed for panel
mounting. Fixing is by mounting
clamps top and bottom.
Insert the unit in the panel cut-out
from the front.
Insert the mounting clamps from the
rear side of the device and tighten the
fixing screws to secure the unit
against the panel.
Removing from panel:
1) Loosen screws.
2) Pull the fixing clamps, both top and bottom, from the device while
holding the unit in place.
3) Pull the unit through the front of the panel.
ESM 7750 OWNER’s MANUAL
Installing / Replacing I/O Modules
Plug-in ModulesProduct Code
SSR Output 20mA@18Vdc
Transistor Output 40mA@18Vdc
Volt/Current Out (0 to 20mA, 0 to 10V)
Digital Input (5-30Vcc)
0 to 20 mA Current Input
0 to 5Aac CT Input
TC Input
RTD Input
EMO-700
EMO-710
EMO-720
EMO-730
EMI-700
EMI-710
EMI-720
EMI-730
EMI-740
72mm/2.83in
72 m/2.8 nm 3i
Relay Output 5A@250Vac

17 18
output 3

Front Panel Description
Entering Process Set Value and Parameters
Setting the process values:
When the button is pressed, the SV LED, next to the process value on the bottom
!
display, flashes. Adjust the desired process set value using the and buttons.
!!
Press the button again to save the new value to memory. If, instead, the
!!
button is pressed, the new set value isn’t saved to memory and the unit exits the
setting mode. You can't change the SV value when the AT LED is lit.
Setting the alarm values:
All outputs on the device can be configured as alarms. Alarm set values are shown
as ALr1, ALr2 and ALr3 in the SET LIST menu. To access the Set Lıst menu press the
button then the button. Pressing the button agaın allows you to
!! !
access and change the values of PSEt, ALr1, ALr2 and ALr3.
Observing and changing parameter values:
The parameters have been divided into three groups: Operator, Technician and
Calibration. The calibration parameters can be accessed by the manufacturer only.
The operator can not access the parameters for running mode and configuration.
Whenever you want to enter either the operator’s or technician’s parameter groups,
the device will require a password. The default value of the user-changeable
passwords ıs “0”. To enter new passwords, you must first access the technician’s
parameters and scroll to “PASS ConF”. After entering the password press the
!
button to save it to memory.
You can access the main titles of the menu by using the and buttons. Press
!!
the button to move to the next level of any menu. Change the value of your
!
chosen parameter by using and buttons. The new value is saved to
!!
memory by using the Button.
!
°C
OP1
SV
°F
OP2
OP3
AT
AUTO
MAN
RAMP
REM
Output1(Process or Alarm) LED
An LED indicator for units other than °C and °F
Output2(Process or Alarm) LED
Output3(Process or Alarm) LED
Automatic operation LED (for process output)
Manual operation LED (for process output)
LED for Ramp&Soak operations
LED for operation with remote set value
Process set value LED
Autotune LED
Display & Indicators
°F unit LED
°C unit LED
Parameters
Table-1 (Process Input Type and Scale selection)
0
1
2
4
6
8
10
12
14
16
18
3
5
7
9
11
13
15
17
19
L(FeConst DIN43710)
L(FeConst DIN43710)
J(FeConst IEC-584)
K(NiCrNi DIN/IEC)
R(Pt13%RhPt DIN/IEC)
S(Pt10%RhPt DIN/IEC)
T(CuConst DIN/IEC)
B(Pt18%RhPt DIN/IEC)
E(CrConst DIN/IEC)
N(NicrosilNisil DIN/IEC)
C(... DIN/IEC)
R(Pt13%RhPt DIN/IEC)
S(Pt10%RhPt DIN/IEC)
T(CuConst DIN/IEC)
B(Pt18%RhPt DIN/IEC)
E(CrConst DIN/IEC)
N(NicrosilNisil DIN/IEC)
C(... DIN/IEC)
J(FeConst IEC-584)
K(NiCrNi DIN/IEC)
-100°C
-100.0°C
-200°C
-200°C
0°C
0°C
-200°C
-200°C
-150°C
-200°C
0°C
-199.9°C
-199.9°C
0.0°C
0.0°C
-199.9°C
-199.9°C
-150.0°C
-199.9°C
0.0°C
-148°F
-148.0°F
-328°F
-328°F
32°F
32°F
-328°F
-328°F
-238°F
-328°F
32°F
-199.9°F
-199.9°F
32.0°F
32.0°F
-199.9°F
-199.9°F
-199.9°F
-199.9°F
32.0°F
850°C
850.0°C
900°C
1300°C
1700°C
1700°C
400°C
400°C
700°C
1300°C
2300°C
900.0°C
999.9°C
999.9°C
999.9°C
400.0°C
400.0°C
700.0°C
999.9°C
999.9°C
1562°F
999.9°F
1652°F
2372°F
3092°F
3092°F
752°F
752°F
1292°F
2372°F
4172°F
999.9°F
999.9°F
999.9°F
999.9°F
752.0°F
752.0°F
999.9°F
999.9°F
999.9°F
Process Input Type(TC) Scale(°C) Scale(°F)
0
1
PT 100
PT 100
-200°C
-199.9°C
-328°F
-199.9°F
650°C
650.0°C
1202°F
999.9°F
Process Input Type(RTD) Scale(°C) Scale(°F)
0
1
2
3
4
0...50 mV
0...5 V
0...10 V
0...20 mA
4...20 mA
Configurable
Process Input Type(DC Voltage and Current) Scale
Configurable
Configurable
Configurable
Configurable
SET
Keyboard
Access all menus and to move
up to another menu.
Access process set value and OK
button when in the program mode.
Increase the parameter values
and access the program menus.
Decrease the parameter values
and access the program menus.
There are three options: you can have two independent 4 segment processes (essentially
giving you two recipes) or one 8 segment process.
If you want only one Ramp, use the Stra parameter. You do not have to use the Pu, Tr and
TS parameters.
By using the Stra you are defining the amount of time the controller will take to get the
temperature to the Set Value (time becomes the overriding factor).
If you want more than one R & S, make sure that Stra = 0.
Then choose rsty according to the number of segments desired.
If you want the controller to shut down after it has gone through all the R & S segments, it
must be running in the Manual Mode (Operator Parameters – Run List).
If this parameter is defined as AUTO, then, at the end of the final segment, the controller
will work to keep the temperature at the final target value.
To run the R & S, Rssl in the Operator’s Parameters must be set to RUN via the front
mounted touch pad
OR
via an input module, EMI-700, which can be plugged into the controller. This is further
explained on page 4.
Notes on Ramp and Soak
ESM 7750 Programming Guide Abbreviations
Parameters are listed in the left hand column in bold lettering followed by its
description and available choices. Some abbreviations are defined as follow:
AT
Full Scale (or Max. Scale)
Autotune
HYS
FS
Process Value
Hysteresis
PV
P.3
1-877-798-7287
Minimum Operating Value
Maximum Operating Value
Self Tune
Process Set Value or PSET
SV
Su-u
Su-L
ST
PSET
ALr1
ALr2
ALr3
This is the device’s process set value. If there isn’t any extra module in the device,
this parameter is used for Output-3.
Process and Alarm Set Value Parameters (SET LIST)
OPERATOR PARAMETERS
Module-1’s alarm set value when installed & configured as an alarm output.
Tuning and Operating methods (RUN LIST) see p5 for explanation of tuning methods
tUnn This parameter defines the tuning type.
NO =Tuning is inactive. ATUN=Only Autotune is active.
STUN=Only Selftune is active. AT.ST=Autotune and selftune are active.
attn NO= Autotune is inactive.YES= Autotune is active.
rSSL Ramp-Soak Function.
oFF=ramp-soak inactive run=Ramp-Soak is active hold=ramp-soak is paused
bpLtBumpless Transfer
NO=bumpless transfer is inactive. YES=Bumpless Transfer is active.
Display Parameters (DISP LIST)
Module-2’s alarm set value when installed & configured as an alarm output.
Output-3’s alarm set value when configured as an alarm output.
AUtO AUTO= Auto process mode. MAN=Manual process mode.
Ramp / Soak Parameters (rmP SoA)
StrA From 0 to 99h 59min. (Inactive if 0.0)
rStO From 0 to 50% of SV. (Inactive if 0). If rSto or ramp & soak functions have
been selected, then (set value-rSto)<starting temp<(set value+rSto). The
unit operates within this range for the duration selected.
rSty Ramp-Soak type 0=1-4 segment 1= 5-8 segment 2=1-8 segment
PU-1to 8 Target SV (SU-L to SU-U)
Tr-1 to 8 Ramp segment time (from 0 to 99h 59min.)
TS-1 to 8 Soak segment time (from 0 to 99h 59min)
ULSL If output module 1 is a relay output, then this parameter can be used to define the
motorized valve control form. Output 1 to open and Output 3 to close the valve:
No=inactive HEAt=operates with heating PID CooL=operates with cooling PID
LtCC High Limit Latch Cancelling. If an Alarm output was configured as a latched
output and that output is not in the latched condition, it can be returned to a
non latching alarm output by entering YES. Once cancelled LtCC=NO
SET
°C
AUTO
°C
AUTO
SET
°C
AUTO
see operator
parameters
see technıcıan
parameters
factory settıngs
Programming Mode - Main Menus
ESM 7750 v10R7
Process &
Parameter
Display
Process Set Value,
Alarm Set Value &
Parameter display
tdSP Defines the function of the top display.
0=PV , 1= SV-PV, 2=2nd analog input’s measured value (if unit is fitted with this option)
bdSP Defines the function of the bottom display.
Note: If device is running in manual mode, the bottom display shows % Power.
0=SV 1=%power 2=ramp-soak dısplay
3 = 2nd sensor’s measured value 4 = CT input measured value

P.4
1-877-798-7287
ESM 7750 v10R7
Parameters
Parameters
PID parameters (cont’d)
oLLC Min. control output for cooling.(0.0%- ouLC). Inactive in Heating/Cooling mode.
ouLC Maximum control output for cooling. (oLLC - 100.0%).
oLtC Minimum output time for cooling. (0.0 to Ct-C or 50 miliseconds if value is 0.0)
ArAnti-Reset Windup (0% to 100% of FS). During PID operation if PSEt -
Ar#PSEt#PSEt+Ar then an integral value is calculated otherwise the last
calculated integral value is used. See p6 for graphic example.
If ot.Ar is selected, then proportional band is used in PID process instead of Ar
value.
SuoF Offsets the proportional band from the SV in the PID calculations ("50% of FS)
PoFS PID output offset. Added to PID output. -100.0 to 0 for cooling PID
0.0 to 100.0 for heating PID
-100.0 to 100.0 for heating/cooling PID.
Strn Stability value. Adjustable from 1 to max scale. If tunn=no or Stun, oscillation might
occur. PSEt-Strn#PSEt#PSEt+Strn
O-dbProportional band shifting. Adjustable from +50.0% of FS. This value is added to
PSET value for cooling. If SV for heating =PSEt+SuoF then SV for
cooling=PSEt+SuoF+o-db
Sbou Control output value for duration of Sensor break error
-100.0 to 0 for cooling PID
0.0 to 100.0 for heating PID
-100.0 to 100.0 for heating/cooling PID
To continue controlling the process if sensor breaks, enter a value. Inactive if 0.0
Parameters
Parameters
SV offset for PID. A ed to PID output (PoSS * PSET / FS)
-100.0 to 0 for cooling PID
0.0 to 100.0 for heating PID
-100.0 to 100.0 for heating/cooling PID.
dd
PoSS
Technician’s parameters (PınP)
Decimal point position on the displays
0=0000 1=000.0 2=00.00 3=0.000
dPnt
Dual or multi-point calibration 0=Lol is -1999 & Upl is 9999)
1=Dual point (adjust Lol & Upl to suit)
2=Multi-point (up to 16 points P000 to P016)
UCAL
Calibratiton points for multi-point configuration
Used for non-linear calibration
P000
to
P016
Configuration for unit of measure
°C=Centigrade °F=Fahrenheit U=other - =none
unıt
Minimum value of operating scale
Lol
Maximum value of operating scale
Upl
Process offset ±10% of FS. Added to process value & expressed in degrees.
Puof
Input signal filtering time (display refresh rate 0.0 to 900.0 seconds) .
ıFLt
D C V o t a / e i s l = 2 )l g e C u r r n ( s
UASL Input type selection for voltage and current (Table-1)
ıSSL Configuration for process input type.
0=TC, 1=RTD, 2=DC Voltage/Current
I is
TC nput ( sl=0)
R p ( s 1TD In ut is l= )
P-Ht Proportional band for heating (0.0% to 999.9% of FS.)
I-Ht Integral time for heating (0 to 3600 seconds)
D-Ht Derivative time for heating (0.0 to 999.9 seconds)
Ct-H Control period for heating (1 to 150 seconds)
For Relay module: 30 seconds
For SSR driver module: 1 or 2 seconds.
oLLH Min. control output for heating.(0.0 to ouLH).Inactive ın Heating/Cooling mode.
oULH Maximum control output for heating. (oLLH to 100%).
oLtH Min. output time for heating. (0.0 to Ct-H or 50 miliseconds when = 0.0)
CCoE Cooling proportional band coefficient. (0.0% to 100.0%). If heating and cooling
PID are used, tunning is performed by the heating output. Therefore (P-CL=P-
HT * CCoE/100) eg. If P-Ht=10.0% and CCoE=50 then P-CL=
10.0*50/100=5.0%. If value is 0.0, coefficient is inactive.
Recommendation: CCoE=100 when cooling with air; 80 with oil; 40 with water
P-CL Cooling proportional band. (0.0% to 999.9% of FS.) eg. If uPL= 1000EC,
LoL=0EC and P-CL=50% then in temperature P-CL=(1000-0)*50/100=500EC
I-CL Integral time for cooling. (0 to 3600 seconds)
d-CL Derivative time for cooling. (0.0 to 999.9 seconds)
Ct-C Cooling control period. (1 to 150 second)
Recommendation: Use an SSR output for control periods shorter than 30s.
These are much better suited for frequent on/off operation than relay outputs.
PID parameters
Input/Output Modules Configuration (MODULE-1/MODULE-2) ıoP1 & ıoP2
out1 / out2 Output configuration (heat, cool, Lout)
Con1 / Con2 Control type (ON/OFF or PID)
HYS1 / HYS2 Hysteresis value 0% to 50% of FS (expressed in degrees)
HYn1 / HYn2Mode of Hysteresis [0=SV+(HYS/2) and SV-(HYS/2)]
[1=SV and SV+HYS or SV and SV-HYS]
tm1 / tm2 Minimum OFF time (0.0 to 100.0 Seconds)
oAt1 / oAt2 Output scale 0= 0...20mA (connect parallel 500 ohm for 0-10VDC)
1= 4...20mA
0=Alarm output 1=Manual/Automatic 2=Sensor break alarm
3=PV is out-of-range 4=Ramp/Soak finished
5=Sensor break alarm for analogue input module
6=PV is out-of-range for analogue input module
Lou1 / Lou2
(Loutputs)
0=Process high alarm 1=Process low alarm
2=Deviation high alarm 3=Deviation low alarm
4=Deviation band alarm 5=Deviation range alarm
6=Heater failure alarm (CT input module must be installed)
ALt1 / ALt2
(alarm types)
Alarm hysteresis 0% to 50% of FS (expressed in degrees)
ALH1 / ALH2
Output type: Heat / Cool / Retransmission
oua1 / oua2
Rt.pr=Retransmission of PV Rt.er=Retransmission of error
Rt.pu=Retransmission of SV
ret1 / ret2
If Module 1 or 2 is EMO-430
If Module 1 or 2 is EMI-400
LIN1 / LIN20=Manual / Automatic when logic input closed, changes AUTO program
parameter, if MAN changes to AUTO, if AUTO changes to MAN
1=Start Stop the AT when logic input closed, changes ATTN program
parameter, if NO changes to YES, if YES changes to NO
2=Run / off Ramp/Soak RSSL program parameter,when logic input is closed,
changes RUN or HOLD to OFF, if OFF changes to RUN)
3=Run / hold Ramp/Soak RSSL program parameter when logic input is closed,
changes RSSL program parameter, if RUN changes to HOLD, if HOLD
changes to RUN)
4=Cancel Alarm Latching when logic input is triggered, unless the alarm
condition still exists.
If Module 1 or 2 is EMI-410, EMI-430, EMI-440 or EMI-450
ISL1 / ISL2 Configuration for second sensor input type: 0=TC 1=RTD 2=DC volt/current
L = 0If IS 1 or ISL2=
tSL1/2 TC input type selection for thermocouple and scale (ref. Table-1)
UNT1/2 °C=Centigrade °F=Fahrenheit
LoL1/2 Minimum value of second sensor input range
uPL1/2 Maximum value of second sensor input range
IPu1/2 Module’s display offset value ±10% of Fs1. Added to process value in degrees.
iFL1/2 Module’s input signal filtering time. (From 0,0 to 900,0 seconds)
CJn1/2 Analogue input Module’s cold junction compensation setting
NO = cold junction compensation is inactive YES = active
rES1/2 Analogue input remote selection. Determines whether the measured value is the
result of the input on terminals 1,2, 3 or from the input module. Visible only when
decimal point and unit parameters are the same for both inputs.
ALS1 / ALS2 Alarm sensor selection 0 = Process input sensor (on terminals 1,2,3)
1 = Analogue module (1 or 2) sensor
CoEF Input coefficient. Used to scale input. eg. If sensor input = 40mV, a coefficient
of 1.25 (50mV÷40mV) is used to get a Full Scale deflection (Upl).
Alarm delay from fault 0.0 to 9999 seconds
Aon1/ Aon2
Alarm reset from fault 0.0 to 9998 seconds. For high limit with manual reset
only, select 9999. Display will read LtCH to indicate latch feature selected.
AoF1/ AoF2
Current transformer ratio can be adjusted from 0 to 100.
eg. For a 100:5A CT this parameter would read 0020 (100/5)
Ctr1 / 2
Heater break alarm set value = (Amps without failure + amps with heater failure)/2
For correct measurements, heating output must be active for at least 0.2 sec.
Hb1 / 2
If Module 1 or 2 is EMI-420
tCSL TC input type selection for thermocouple and scale (ref. Table-1)
unıt Configuration for unit of measure (°C, °F)
LPAd Low point adjustment used together with uPAd to correct sensor error.
eg. reading is 26 (low) and 320 (high) but should read 25 and 325
LPAd = -1 and uPAd=5
uPAd Upper point adjustment
LOL Minimum value of operation scale
UPL Maximum value of operation scale
PUOF Process offset ±10% of FS. Added to process value & expressed in degrees.
ıFLt Input signal filtering time. (0.0 to 900.0 seconds)
CjnC NO = cold junction compensation is inactive. YES = active.
rtdS
unıt Configuration for unit of measure (°C, °F)
LPAd Low point adjustment used together with uPAd to correct sensor error.
eg. reading is 26 (low) and 320 (high) but should read 25 and 325
LPAd = -1 and uPAd=5
uPAd Upper point adjustment
LOL Minimum value of operation scale
UPL Maximum value of operation scale
PUOF Process offset ±10% of FS. Added to process value & expressed in degrees.
ıFLt Input signal filtering time. (0.0 to 900.0 seconds)
RTD input type selection for thermoresistance and scale (Ref. Table-1)
(connect parallel 500 ohm for 2-10VDC)

Passwords (PASS ConF)
opps Operator password (0 to 9999).
Tcps Technician password (0 to 9999).
SAdr Slave Address from 1 to 247
Communication Configuration (Comm Conf)
BAudBaud Rate:0- 1200 1- 2400 2- 4800 3- 9600 4- 19200
Prty Parity 0- none 1- ODD 2-EVEN
StPb Stop Bit 0- 1 stop bit 1- 2 stop bit
Manufacturer’s Calibration Page (PASS CAL) - Factory Set
Explanations
Firstly, the control form must be PID in order for this tuning method to operate.
PID coefficients
save to
memory.
parameter is
changed t
PID coefficients
save to
memory.
parameter is changed
t
If the tunn parameter is
Stun or At.St, step response
tuning is selected. When
the device is first
energized, the actual value
is compared to the set
value. If the set value is
greater than the actual
value, the process output is
enegized until the
start value+((set value)/2)
is reached. The process
output is reduced to 0% and
the device ensures that the
temperature has begun to
fall. The
are calculated and d
If the tuning is
completed successfully,
the tunn
from Stun to NO or At.St o Atun depending on the original choice.
If the set value is less than
the actual value and the
cooling PID is selected, the
process output is energized
until the
start value-((set value)/2)
is reached. The process
output is reduced to 0% and
the device ensures that the
temperature has begun to
rise. The
are calculated and d
If the tuning is
completed successfully, the
tunn
from Stun to NO or At.St o
Atun depending on the
original choice.
During tuning, the set value
can not be changed. Step
response is canceled without changing the PID set values when any of the following conditions
applies: the heating PID is canceled during Heating step response; when the cooling PID is canceled
during Cooling step response; when there is a sensor break error or when the step response tuning
operation can not be completed within 8 hours (the AT LED flashes. The error can be cleared with the
“SET” button). If the power to the device is removed and reapplied, the device carries out step
response tuning again.
Firstly, the control form must be PID in order for this tuning method to operate.
The user can decide at any
time to use this tuning
method by selecting Atun
or At.St for the tunn
parameter in the run list.
After changing the set
value, if the difference
between the newly defined
and former set values is
greater than the
proportional band
+/-(scale x P-Ht)/1000 if
heating or heating/cooling
or +/-(scale x P-CL)/1000
if cooling, the contoller
will automatically start this
function.
In the event that the actual value moves outside the set value by +/-Strn 3 times while the device is
executing the PID control, the Attn parameter becomes YES and tuning is started.
If the Attn parameter is YES, the device begins tuning from the point where it stands at that moment. If
the heating and cooling PIDs are selected together, or if only the heating PID is selected, Heating Limit
Cycle is performed; if only the cooling PID is selected Cooling Limit Cycle is carried out. If the Limit
Cycle operation can not be completed within 8 hours, tuning is cancelled and the Attn parameter
becomes NO. The PID parameters remain as they were before this failed session.
If Heating Limit Cycle is being done, tuning is performed according to set-((set temperature)/4), if
cooling Limit Cycle is being done, tuning is performed according to set+((set temperature)/4) .
At the end of tuning the Attn parameter becomes NO and the PID parameters are saved to memory.
If a sensor break error occurs, the tuning operation is paused until the sensor connection is re-
established. When the sensor connection returns to normal, the tuning operation is recommenced. If
the Limit Cycle tuning operation can not be completed within 8 hours the tuning operation is cancelled
(the AT LED flashes. The error can be cleared with the “SET” button).
While the tuning operation is under way, the Process Set Value (PSEt) can not be changed.
P.5
1-877-798-7287
Process
Value
Time
During
Atun
operation
100%
Process
Output
Control is
unstable
PID coefficients are
determined and system
becomes stable.
Process Set
Value ( )
Time
LIMIT CYCLE TUNING (Auto Tune)
Process
Value
Time
100%
Process
Output
Stun
Start
Value
PID coefficients are determined
and system becomes stable.
Start Value + [ ( Set Value) ]
2
Process Set
Value ( )
Time
STEP RESPONSE TUNING (Self Tune)
Process
Value
Time
100%
Process
Output
Stun
Start
Value
Process Set
Value ( )
Start Value - [ ( Set Value) ]
2
PID coefficients are determined
and system becomes stable.
Time
ESM 7750 v10R7
SU-L SV min. limit. Adjustable from min. scale to SU-u value . It’s the minimum value of
the operation scale.
out3 Output configuration (heat, cool, Lout)
Con3Control type (ON/OFF or PID)
HYS3 Hysteresis value 0% to 50% of FS (expressed in degrees)
tm3 Minimum OFF time (0.0 to 100.0 seconds). Active in on.off control
Lou30=Alarm output 1=Manual / Automatic data output
2=Sensor break alarm 3=Output active when PV is outside operating range
4=Output activates at end of R/S 5=Analog input module sensor break alarm
6=PV of second input is <LoL1 / 2 or >uPL1 / 2
aLt3 Alarm type:
0-Process high alarm 1-Process low alarm 2-Deviation high alarm
3-Deviation low alarm 4-Deviation band alarm 5-Deviation range alarm
6=Heater failure alarm (CT input module must be installed)
NOTE: 2,3,4,5,are not available if Lou3 … 0.
aLH3 Alarm hysteresis. Active if output 3 is alarm output. If ALS3=0 or there is no second
sensor input, adjustment is 0 - 50% of process input scale (uPL-LoL).
If ALS3=1and an analogue input is present, then it can be adjusted from 0 to 50% of
the input module’s scale.
If a CT input module is installed and ALt3=0006, adjust from 0.0 to 20.0A.
SU-u SV max. limit. Adjustable from SU-L value to max. scale. It’s the maximum
value of the operation scale.
HYn3 Mode of Hysteresis 0=SV+(HYS/2) and SV-(HYS/2)
1=SV and SV+HYS or SV and SV-HYS
Output - 3
If Module 1 or 2 is EMI-410, EMI-430, EMI-440 or EMI-450 (continued)
RTS1 / 2 Selection of sensor type and scale (see Table 1)
UNT1 / 2 °C=Centigrade °F=Fahrenheit
LoL1 / 2 Minimum value of second sensor input range
uPL1 / 2 Maximum value of second sensor input range
IPu1 / 2 Module 1 / 2 PV offset ±10% of FS1. Added to the input reading in degrees
iFL1 / 2 Module 1 / 2 Input signal filtering time. (From 0,0 to 900,0 secs)
rES1 / 2 Determines whether the measured value is the result of the input on
terminals 1,2, 3 or from the input module. Visible only when decimal point
and unit parameters are the same for both inputs. If YES, then analogue
input module’s value is used as the Set Value. If NO, then SV=PSET
Parameters
UAS1 / 2 Selection of sensor type and scale. (See Table1)
DPN1 / 2 Analogue input module decimal point position
0 = 9999 1 = 999.9 2 = 99.99 3 = 9.999
ICA1 / 2 Analogue input module calibration type
0 = None 1 = Dual point
ICL1 / 2 Minimum value for dual point calibration
ICH1 / 2 Maximum value for dual point calibration
uNT1 / 2 °C=Centigrade °F=Fahrenheit U=Other units
LoL1 / 2 Minimum value of second sensor input range
uPL1 / 2 Maximum value of second sensor input range
Ipu1 / 2 Module 1 / 2 PV offset ±10% of FS1. Added to the input reading.
iFL1 / 2 Module 1 / 2 Input signal filtering time. (From 0.0 to 900.0 secs)
rES1 / 2 Determines whether the measured value is the result of the input on
terminals 1,2, 3 or from the input module. Visible only when decimal point
and unit parameters are the same for both inputs. If YES, then analogue
input module’s value is used as the Set Value. If NO, then SV=PSET
I SL1 or I L2= 1
f I S
If I L L2=  S 1= or IS 2
General Configuration (Genn ConF)
Su-L2Second sensor SV min. limit. Adjustable from min. scale to SU-u2 value .
It’s the minimum value of the operation scale.
SU-u2Second sensor SV max. limit. Adjustable from SU-L2 value to max. scale.
It’s the maximum value of the operation scale.
ALS3 Alarm sensor selection. If output 3 is an alarm output and an analogue module is
installed: 0 = Alarm in accordance with input sensor (on terminals 1,2,3)
1 = Alarm in accordance with analogue input module (1 or 2)
Alarm delay from fault 0.0 to 9999 seconds
Aon3
Alarm reset from fault 0.0 to 9998 seconds.
For high limit with manual reset only, select 9999. Display will read LtCH to indicate
latch feature has been selected.
AoF3
ULtt Motorized valve travel time can be adjusted from 5 to 600 sec.
ULHY Min. activation time of motorized valve and is adjustable from 0.1 to 5.0%.
eg. If ULtt=100s and ULHY=1.0% then the minimum activation time is (100s*1%) or
1 second.

PROPORTIONAL BAND SHIFTING o-db ALARM OPTION and OUTPUT FORMS
P.6
HYS
ON
OFF
Alarm
Set
Alarm
Output
Process Value
HYS
ON
OFF
Alarm
Set
Alarm
Output
Process Value
Process high alarm
Process low alarm
HYS
ON
OFF
Process
Set Process Set + Alarm Set
Alarm
Output
Process Value
Deviation High Alarm
HYS
ON
OFF
Process
Set
Process Set - Alarm Set
Alarm
Output
Process Value
Deviation Low Alarm
HYS
Process Set - Alarm Set
HYS
ON
OFF
Process
Set Process Set + Alarm Set
Alarm
Output
Process Value
Deviation Band Alarm
HYS
Process Set - Alarm Set
HYS
ON
OFF
Process
Set Process Set + Alarm Set
Alarm
Output
Process Value
Deviation Range Alarm
Process
Output
100%
50%
0%Process
Value
Cooling Set
Value ( + )
Heating Set
Value ( )
Process
Output
100%
50%
0%Process
Value
Heating Set
Value( )
Cooling Set
Value( - )
If > 0 (Dead Band) If < 0 (Overlap Band)
1-877-798-7287
Process
Value
Time
Ar Value
Ar Value
New
Integral
Value is
not calculated
Set Value
New
Integral
Value is
calculated
New
Integral
Value is
not calculated
ANTI-RESET WINDUP AR
PID OUTPUT OFFSET POFS
Added to Output % which is calculated at the end of the PID.
500
PoFS = %5.0
PoFS = -%5.0
Process
Output
100%
50%
0%Process
Value
%5
%5
Added to the process output calculated at the end of the PID according to the process set
value. * / ( - )
eg: PSET = 500°C , uPL = 1000°C , LOL = 0 , PoSS = 5.0%
then 5.0 * 500 /(1000-0) = 2.5%
500
Process
Output
with Offset
Process
Output
100%
50%
0%Process
Value
2.5%
OUTPUT OFFSET RELATED TO PID SET POSS
ESM 7750 v10R7

Operator Parameters
SET
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET SET
SET SET
SET SET
SET
SET
SET
°C
AUTO
SET
Current transformer ratio for Module-1
can be adjusted from 0 to 100.)
eg : For 100:5A type current
transformer the Ctr 1 parameter would
be 100/5 or 20
Current Transformer
Calculating set value for heater failure
Set Value = [(Current value without failure +
Current value with heater failure )] / 2
eg. A 200V system with three1KW heaters
would normally draw 15 amps
[1000 / 200 ]*3 = 5A *3 = 15A
If one of the heaters is out of order, the current
draw is now 5A*2 or 10A. The Set Value must
be adjusted to (15+10) /2 or12.5A
HEATER BREAK ALARM
to Module 1
PNEUMONIC REPRESENTATION
1-877-798-7287 P.7
MOTORIZED VALVE CONTROL
SET
°C
AUTO
°C
AUTO
°C
AUTO
AUTO
SET
SET
SET
°C
ESM 7750 v10R7
°C
AUTO
°C
AUTO
SET
°C
AUTO
SET
°C
AUTO
SET
°C
SET
°C
AUTO
SET
°C
SET
°C
SET
process
set
value
alarm 1
set
value
alarm 2
set
value
alarm 3
set
value
tune
auto
tune
Operation
type
ramp/soak
control
motorized
valve
control
bumpless
transfer
alarm
latch
cancelling
top
display
bottom
display
soft
start
ramp/
soak
tolerance
ramp/
soak
steps
PU=RS nbr.
tr=ramp time
tS=soak time
up to 8 R/S
steps
Ramp/Soak
menu
EMO-700 relay output
module must be plugged
into Module-1 socket.
100 ... 240 V
Opening
Relay
N L
Supply
Switch
Closing
Common
Opening
Valve
Supply
Input
~
M
~
~
V
n nOpe i g Closing
MOTORIZED VALVE
50/60 Hz
1A T
Fuse
~
Max. 3A T
Fuse
~
10
Input/Output
Module-2
MODULE-2
Output-3
Closing
Relay
1
11
2
13
3
14
4
17
5
18
6
NO C
3A@250V
NO
C
5A@250V
EMO-700
MODULE-1
~
~
Communication
Module
(RS-232(standard)/
RS-485(optional))
7
NC
Control Output
200V
1kW*3
Heater
~
10 11
CT
MODULE-1
In the RUN LIST grouping of the
OPERATOR’s section, select HEAT or
COOL for parameter ULSL.
The parameter can be adjusted
from 5 to 600 seconds. It defines the time
required to open the valve completely.To
determe this parameter correctly, close the
valve manually. Be sure the valve is fully
closed; then reopen it manually without
stopping and measure how long it took to
reopen it completely. Add 5% to this value
and enter it for this parameter.
The parameter determines the
increments as a percentage of the Ultt
parameter and can be adjusted from 0.1 to
5.0 %. If the valve oscillates while opening
or closing, INCREASE this parameter’s
value!
Graphic representation of Ramp and Soak function
Process
Set value
PU-3
Time
Start
tr_1 tS_1 tr_4 tS_4
PU-1
PU-2
PU-4
PU-5
PU-6
PU-7
PU-8
tr_2 tS_2 tr_3 tS_3
4 ramp soak ( = ) 4 ramp soak ( = )
8 ramp soak ( = )

°C
REMOTE RAMP MAN AUTO
°C
AUTO
°C
AUTO
SET
°C
AUTO
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET SET SET
SET
SET SET
SET
SET
SET
SET SET
SET
SET
SET SET
SET
SET
SET
SET SET
SET
SET
SET
SET SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET SET
SET SET
SET SET
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET
SET
SET
Technician Parameters
Process Input Configuration
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
see operator parameters
SET SET SET SETSETSETSET
°C
AUTO
SET
see Tech
PID control
parameters
°C
AUTO
SET
see Tech
I/O-1
module
config.
°C
AUTO
SET
see Tech
I/O-2
module
config.
°C
AUTO
SET
see Tech
output 3
config.
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
°C
AUTO
°C
AUTO
SET
SET
P.8
°C
AUTO
°C
AUTO
SET
1-877-798-7287
ESM 7750 v10R7
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
SET

°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
Technician Parameters
PID Control Parameters
Technician Parameters
Input / Output-1 Module Configuration
P.9
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET
SET
SET SET SET SET
SET SET SET
SET
SET
SET
°C
AUTO
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
SET
1-877-798-7287
ESM 7750 v10R7
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET
SET
SET
SET
°C
AUTO
SET

Technician Parameters
Input / Output Module-2 Configuration
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET
SET SET SET
SET SET
SET
SET
°C
AUTO
SET
Technician Parameters
Output-3 Configuration
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
°C
AUTO
SET
SET
SET SET SET SET
SET SET SET SET
SET SET
SET
SET
P.10
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
°C
AUTO
SET
SET
°C
AUTO
SET
1-877-798-7287
ESM 7750 v10R7
