Z3 Technology CIB-BOS-0 Series User manual

Hardware Specification
FLIR® Boson®Camera to Z3 Encoder Interface
Model Name: CIB-BOS-0x
DOC-USR-0197-01
Manual Version 1.1
June 7, 2019
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2019 Z3 Technology, LLC. All rights reserved.
Sony is a trademark of Sony Corporation.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.
Z3 Technology, LLC incorporates HDMI® technology. The terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

2
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
REVISION HISTORY
Version
Date
Change Note
Author
1.0
05/21/2018
Original Document
BM
1.1
06/07/2019
Updated images
SI

3
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
TABLE OF CONTENTS
GENERAL DESCRIPTION.................................................................................................. 6
FEATURES ................................................................................................................. 7
PHYSICAL.................................................................................................................. 8
CONNECTIONS ............................................................................................................ 8
4.1 Connection to the FLIR®Boson®2, J1............................................................................... 8
4.2 Connection to the DCK encoder, J3 and J4 ....................................................................... 9
4.3 USB jack, J4 ..........................................................................................................10
4.4 Composite video jack, J5 ...........................................................................................11
SPECIFICATIONS .........................................................................................................11

4
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
LIST OF FIGURES
Figure 1: CIB-BOS board Dimensions .................................................................................... 6

5
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
LIST OF TABLES
Table 1: pin assignments of J1 on the CIB-BOS board: ................................................................. 8
Table 2: shows the pin assignments for J2: .............................................................................. 9
Table 3: shows the pin assignments for J3: .............................................................................10
Table 4: Specifications .....................................................................................................11

6
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
GENERAL DESCRIPTION
The CIB-BOS board provides a seamless interface between the FLIR®Boson®infrared camera and the Z3
Technology DCK system encoders. The CIB-BOS board allows for one of two possible interface styles, the
proprietary FlexIO interface system present on some DCK encoder models using a 30-pin JST connector, or a
30-pin KEL ribbon cable. The CIB-BOS board enables a single cable from the DCK encoder to provide power
and control to the Boson camera while transmitting digital LVDS digital video from the camera to the
encoder.
The CIB-BOS board also provides a Micro-USB port that can be used to access the Boson® configuration from
a computer using a standard USB cable.
The CIB-BOS board plugs directly into the body of the Boson®camera, without extensions, to convert the
board-to-board connector system used by the FLIR®Boson®into either a wire-to-board connector compatible
with the FlexIO system or a KEL micro-coaxial cable. This allows a short cable connected between the
encoder and the camera to power the camera and to enable the full functionality of the Boson®.
Figure 1: CIB-BOS board Dimensions
26 mm
21 mm

7
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
FEATURES
▪Direct connection to the FLIR®Boson®infrared camera
▪Single cable connection between DCK encoder system and Boson®camera
▪Provides power, control, and digital video paths
▪Allows for offline configuration of the Boson®via USB jack
▪Mounts directly to the body of the Boson®camera, no interface cards from FLIR® required

8
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
PHYSICAL
The CIB-BOS board is 21x26mm. It mounts directly onto the body of the FLIR®Boson®camera with J1 facing
the camera.
The CIB-BOS interface board should be secured to the body of the FLIR®Boson®by 4 screws through the
screw holes located on each corner of the board.
CONNECTIONS
4.1 Connection to the FLIR®Boson®2, J1
The J1 connector on the CIB-BOS interface board is a 80-pin high density Hirose connector which will
mate directly with the Primary I/O Connector on the FLIR®Boson®camera. In addition to retrieving
digital and analog video from the camera, this connector provides the FLIR® Boson® with power and
serial connectivity.
Please refer to the “FLIR®Boson®Engineering datasheet” document for the pin assignments on the Boson
camera. The FLIR document is available directly from the FLIR®support web site.
Table 1: pin assignments of J1 on the CIB-BOS board:
Pin #
Signal Name
Pin #
Signal Name
1
GND
2
+3.3V
3
GND
4
+3.3V
5
GND
6
+3.3V
7
GND
8
+3.3V
9
USB_DN
10
GND
11
USB_DP
12
-
13
GND
14
-
15
USB_VBUS
16
-
17
USB_ID
18
-
19
GND
20
GND
21
DATA_14
22
DATA_17
23
-
24
RESETn
25
DATA_08
26
-
27
DATA_04
28
DATA_05
29
GND
30
GND
31
DATA_07
32
DATA_06
33
UART_SIN
34
DATA_16
35
DATA_22
36
DATA_23
37
DATA_19
38
DATA_15
39
GND
40
GND
41
DATA13
42
DATA_18
43
UART_SOUT
44
-
45
DATA_10
46
DATA_09
47
DATA_12
48
DATA_11

9
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
49
GND
50
GND
51
DATA_02
52
DATA_20
53
VSYNC
54
DATA_21
55
PCLK
56
DATA_03
57
-
58
GPIO_2
59
GND
60
GND
61
-
62
DATA_01
63
-
64
-
65
-
66
-
67
-
68
-
69
GND
70
GND
71
-
72
EXT_SYNC
73
HSYNC
74
-
75
-
76
-
77
DATA_00
78
DATA_EN
79
GND
80
-
4.2 Connection to the DCK encoder, J3 and J4
The CIB-BOS board connects to the Z3 Technology DCK encoder system via connector J3 or J4.
The J3 connector header placed on the CIB-BOS board is a 30-pin header from JST, part number BM30B-
SRDS-G-TF. It is designed to connect to the same connector on multi-channel capable versions of the Z3
DCK encoder product line, such as the FV2K-DCK-13 and FV4K-DCK-15.
The J4 connector is a KEL micro-coaxial connector part number USL00-30L. It is meant to connect to the
KEL connector on HD versions of DCK systems.
This connection mode is NOT COMPATIBLE WITH 4K ENCODER SYSTEMS.
Please be sure to ONLY USE KEL CABLES PROVIDED OR APPROVED BY Z3 TECHNOLOGY.
NOTE:Connecting J4 to a 4K capable encoder will likely cause permanent damage to the encoder,
Boson camera and CIB-BOS board.
NOTE: Connecting J4 to the encoder using a non-approved KEL cable will likely cause permanent
damage to the encoder, Boson camera and CIB-BOS board.
Both J3 and J4 connectors carry LVDS digital and video from the camera to the encoder, power from the
encoder to the camera and bi-directional serial communication for camera control.
Table 2: shows the pin assignments for J2:
Pin #
Signal Name
Pin #
Signal Name
1
FLEX_VCC
2
ENC_SERIAL_TX
3
FLEX_VCC
4
ENC_SERIAL_RX
5
GND
6
n/c
7
GND
8
GND
9
FLEX_D9P
10
FLEX_D0N
11
FLEX_D8N
12
FLEX_D0P

10
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13
FLEX_D8P
14
FLEX_D1N
15
GND
16
FLEX_D1P
17
FLEX_D6N
18
FLEX_D2N
19
FLEX_D6P
20
FLEX_D2P
21
FLEX_D5N
22
FLEX_CKN
23
FLEX_D5P
24
FLEX_CKP
25
FLEX_D4N
26
FLEX_D3N
27
FLEX_D4P
28
FLEX_D3P
29
GND
30
CVBS
Table 3: shows the pin assignments for J3:
Pin #
Signal Name
Pin #
Signal Name
1
FLEX_VCC
2
ENC_SERIAL_TX
3
FLEX_VCC
4
ENC_SERIAL_RX
5
GND
6
n/c
7
GND
8
GND
9
FLEX_D9P
10
LVDS_SYNC_N
11
FLEX_D8N
12
LVDS_SYNC_P
13
FLEX_D8P
14
LVDS_DATA1_N
15
GND
16
LVDS_DATA1_P
17
EXT_SYNC
18
LVDS_DATA2_N
19
FLEX_D6P
20
LVDS_DATA2_P
21
FLEX_D5N
22
LVDS_CLK_N
23
FLEX_D5P
24
LVDS_CLK_P
25
FLEX_D4N
26
FLEX_D3N
27
FLEX_D4P
28
FLEX_D3P
29
GND
30
CVBS
▪FLEX_VCC is power coming from the encoder, used to power the circuits in the CIB-FT2 board and the
Tau®2 camera. The CIB-FT2 expects clean DC power with voltage between 6.5V and 16V.
The DCK encoder system will provide +12V power on these pins.
▪ENC_SERIAL_TX and ENC_SERIAL_RX are the serial port connections for camera control. The TX is the
serial output from the encoder to the camera, and the RX is the input to the encoder from the
camera.
The CIB-FT2 board drives the ENC_SERIAL_RX pin with 5V TTL level, and expects H level of the
ENC_SERIAL_TX signaling to be anywhere between 3.0V and 5.25V.
▪CVBS is the analog video signal, NTSC or PAL compliant.
4.3 USB jack, J4
The CIB-FT2 board has a micro-USB jack that allows a USB computer to power and access the camera
controls. This is used, for example, to configure the Tau®2 camera using the FLIR®control GUI software
running on a PC.

11
CIB-BOS-0x
HARDWARE SPECIFICATION
CONFIDENTIAL DOC-USR-0197-01
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
When there is power on the USB bus the CIB-FT2 board switches the control of the Tau®2 camera to the
USB bus. The CIB-FT2 board will appear to the host computer as a serial port implemented by a Silicon
Labs CP2104 USB to Serial Converter chip. After loading the proper driver, pointing the FLIR®GUI to the
assigned COM port will enable communication.
Power from the USB bus is also used to power the Tau®2 camera, so no additional power sources are
required.
The source of control for the camera is determined by the presence of power on the USB bus.
When power is not present on the USB bus the CIB-FT2 board will power itself and the camera from the
FlexIO bus via J2 or J3. Serial communications for camera control are also routed to J2 or J3.
When power is present on the USB bus, the CIB-FT2 will route the serial communications to the USB host,
and therefore the communications path though J2 or J3 will not be active.
4.4 Composite video jack, J5
The J5 jack on the CIB-FT2 board is a composite video output, with NTSC or PAL video as selected by the
camera configuration.
J5 is a MCX type jack.
Because the Tau®2 camera only provides one video stream, the same signal that is used to drive J5 is
also connected to the CVBS pins of J2 and J3. Since analog video requires a 75 Ohm termination, only
one of the three outputs can be connected at any given time.
SPECIFICATIONS
Table 4: Specifications
Parameter
Min
Typ
Max
Notes
Input Power Voltage
6.5V
12V
16V
From encoder, via J2 or J3
4.5V
5V
5.25V
From USB host, via J4
Power Consumption
25mA
Power consumption by CIB-FT2 board
excluding camera.
Video Output
1Vpp
Composite video on MCX jack, J5
Serial Port, TX to encoder
5V
TTL level
Serial Port, RX from
encoder
3.0V
5V
5.25V
Operating Temperature
-40 °C
85 °C
Open air, unobstructed air flow
Storage Temperature
-40 °C
120 °C
25% to 80% RH, non-condensing
