Zanussi Electrolux ZR 23 W User manual

A/ZE/4. (03.)200364669
GB
REFRIGERATOR
ZR 23 W
ZZAANNUUSSSSII
INSTRUCTION BOOK

2
This instruction book contains safety precautions, information on use and helpful hints and tips.
To ensure you see this appliance effectively and safely, please read this instruction book carefully
before installing or using this appliance and retain for future reference.
The symbols below help you to find thin s more easily:
Safety precautions
Warnin s and Safety information
Hints, useful information
Environmental information

Servicing
This product should be serviced by an
authorised en ineer and only enuine spare
parts should be used.
Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctionin . Contact your local
Service Force Centre.
At the end of the Appliance ife
When disposin of your appliance use an
authorised disposal site.
Remove the plu and ensure that any locks or
catches are removed, to prevent youn children
bein trapped inside.
The Appliance and the Environment
This appliance does not contain asses which
could dama e the ozone layer.
Avoid dama in the coolin unit.
The packa in used on this appliance marked with
the symbol is recyclable.
Keep this instruction book for future
reference and ensure it is passed on to any
new owner.
3
IMPOR
IMPORT TANT S ANT SAFET AFETY INS Y INSTR TRUCTIONS UCTIONS
These warnings are provided in the interests of your safety. Ensure that you understand them all
before installing or using this appliance. Your safety is of paramount importance. If you are unsure
about any of the meanings or these warnings contact the Customer Care Department.
Prior to installation
Check the appliance for transport dama e. Under
no circumstances should a dama ed appliance be
installed. In the event of dama e please contact
your retailer.
Installation
This appliance is heavy. Care should be taken when
movin it.
It is dan erous to alter the specifications or attempt
to modify this product in any way.
Ensure that the appliance does not stand on the
electrical supply cable. If the supply cable is
dama ed, it must be replaced by a cable available
from your local Service Force Centre.
Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
Parts which heat up should not be exposed.
Whenever possible, the back of the appliance
should be close to a wall, but leavin the required
distance for ventilation, as stated in the installation
instructions.
The appliance should be left for 2 hours after
installation before it is turned on, in order to allow
the refri erant to settle.
Child Safety
Do not allow children to tamper with the controls or
play with the product.
There is a risk of suffocation! Keep packa in
material away from children!
During Use
This appliance is desi ned for domestic use only,
specifically for the stora e of edible foodstuffs. It is
not intended for commercial or industrial use.
Maintenance and Cleaning
Before cleanin , always switch off the appliance
and disconnect from the electrical supply.
When unplu in always pull the plu from the
mains socket, do not pull on the cable.

4
CONTENT
CONTENTS S
Instructions for the User
Guide to use the instruction book 2
Important Safety Instructions 3
Instructions for the User 5
Description of the Appliance 5
Using the Appliance 6
Before Use 6
To Start the Appliance 6
Thermostat Control 6
Hints for stora e 6
Stora e Shelf 7
The Ice-makin Compartment 7
Hints and Tips 7
Food Stora e 7
Frozen food stora e 7
Ener y Savin Advice 7
Storage time chart 8
Maintenance and Cleaning 9
Internal cleanin 9
External cleanin 9
When the appliance is not in use 9
Something Not Working 10
Service and Spare Parts 11
Customer Care 11
Guarantee Conditions 12
Instructions for the Installer
Technical Data 13
Location 13
Installing the Appliance 13
Transportation, Unpackin 13
Location 13
Ventilation Requirements 14
Door Reversal 14
Electrical Connection 15

5
Ins
Instr tructions f uctions for the User or the User
General information
This appliance is desi ned for the refri eration of food
in a domestic home. It also has an ice-makin
compartment.
To ensure correct operation, this appliance should
be located where the ambient temperature is
between 12-32 °C
Description of the appliance
1. Ice-makin compartment
2. Data plate
3. Ice tray
4. Wire shelf
5. Drip tray
6. Feet
7. Door asket
8. Door compartment
9. Thermostat with knob
10. Condenser
11. Air circulation
12. Compressor
13. Spacer

6
Hints for storage
Su ested stora e locations for different types of
food produce:
1. Storin frozen foods, makin ice and ice-cream.
2. Confectionery, ready-cooked foods
3. Foods in dishes
4. Opened cans
5. Milk, dairy products
6. Fresh meat, cold cuts, sausa es, etc.
7. Fruits, ve etables, salads
8. Cheese, butter
9. E s
10. Yo hurt, sour cream
11. Bottles, drinks
Using the Appliance
Before Use
Remove all securin tapes.
Wash the inside of the appliance with lukewarm water
with a little bicarbonate of soda added (5 ml to 0,5 litre
of water). Do not use soap or deter ent as the smell
may lin er. Dry the appliance thorou hly.
Do not use detergents, abrasive powders,
highly perfumed cleaning products, wax
polishes or products containing alcohol.
FFTo Start the Appliance
1. Allow the appliance to stand for 2 hrs after
installation.
2. Plu in the appliance and switch on at the mains
supply.
3. Turn the thermostat control knob to the required
settin . A settin of 4 is usually suitable for normal
operation (see thermostat control).
4. Leave the appliance for approximately 4 hours for
the correct temperature to be reached before
placin food inside.
Thermostat Control
The thermostat control knob situated inside the
refri erator re ulates the temperature of the
refri erator and ice-makin compartment. Thermostat
control knob is marked from 1-7 the hi her the
number, the colder the settin .
Position 0 - Off
Position 1 - Cold
Position 7 - Coldest

7
Storage Shelf
The shelf inside the appliance has a flap on the
left side that makes storin lar e sized bottles
possible.
The door shelves taken out of appliance can be used
for servin foods (fruit, salads, etc.)
The Ice-making Compartment
This compartment is suitable for the storin of
commercially frozen food and for makin and storin
ice cubes.
Hints & Tips
Food Storage
To obtain the best results from your appliance
neither hot foods nor liquids which may evaporate,
should be placed in the refri erator.
Keep the time between buyin chilled food and
placin it in your frid e as short as possible.
Do not push food to ether too much, try to allow air
to circulate around each item.
Do not store food uncovered.
Remove suspect food from your refri erator and
clean, refer to Cleanin and Maintenance.
Frozen food storage
Storin ready-frozen foods is quite strai htforward.
The packs can be placed beside each other or on top
of each other.
You are stron ly advised to place ready-frozen food in
the compartment as quickly as possible after
purchase and we therefore recommend that you buy
them last. Also ensure that the external packa in is
intact.
Packa in which is swollen or has traces of
refrozen water droplets on the pack could indicate
that the product has not been kept at a suitable
temperature and that it may have lost its ori inal
quality.
Partially thawed food must not be refrozen, it must
be consumed within 24 hours.
Never exceed the stora e times indicated.
Do not open the ice-makin compartment door too
often and do not leave open lon er than necessary.
Important
In the event of a power cut the food in the ice-
makin compartment will not be affected if the
power cut is short and if the compartment is full. Do
not open the door. Should the food be in to thaw,
it must be consumed quickly and must not be
refrozen.
Energy Saving Advice
Do not install the cabinet close to sources of
heat, such as a cooker, dishwasher or radiator.
Locate the appliance in a cool well ventilated
room and make sure that the air openin s of the
cabinet are not obstructed.
Always leave warm food to cool down to room
temperature before placin in the frid e.
Try to avoid keepin the door open for lon
periods, or openin the door too frequently as
warm air will enter the cabinet, and cause the
compressor to switch on unnecessarily often.
Ensure there are no obstructions preventin the
door from closin properly.
It is advisable to periodically clean the
refri eration system at the back of the appliance
with a duster or vacuum cleaner.

8
S
St tor orage time char age time chart t
Time and method of stora e of fresh foods in the refri erator
Foods Storage time in days Method of packaging
1234567
Raw meat XXx x x clin film, airti ht
Cooked meat XXXx x x dish covered
Roasted meat XXXx x dish covered
Raw minced meat Xdish covered
Cooked minced meat XXx x dish covered
Cold cuts XXx x clin film, cellophane, rease-
proof paper
Fresh fish Xx x clin film, airti ht
Cooked fish XXx x dish covered
Tinned fish, open Xx x dish covered
Fresh chicken XXXx x x clin film, airti ht
Fried chicken XXXx x x dish covered
Fresh duck, oose XXXx x x clin film, airti ht
Roasted duck, oose XXXXx x x dish covered
Butter unopened XXXXXXXori inal packa in
Butter opened XXxxxxxoriinal packa in
Milk XXXx x ori inal packa in
Cream XXx x plastic box
Sour cream XXXXx x x plastic box
Cheese (hard) XXXXXXXaluminium foil
Cheese (soft) XXXXx x x clin film
E XXXXXXX
Spinach, sorrel XXx x clin film
Green peas, reen beans XXXXx x x clin film
Mushroom XXx x x clin film
Carrot XXXXXXXclin film
Tomato XXXXXXXclin film
Cabba e XXXXXx x clin film
Strawberry, raspberry, etc. XXXx x clin film
Tinned fruits opened XXXx x dish covered
Cakes filled with cream XXx x dish covered
Notation:
Xrecommended stora e time
x maximum recommended stora e time

9
Maint
Maintenance & Cleaning enance & Cleaning
Before any maintenance of cleaning work is
carried out DISC NNECT the appliance from
the ELECTRICITY SUPPLY.
Internal Cleaning
Clean the inside and accessories with warm water and
bicarbonate of soda (5 ml to 0.5 litre of water). Rinse
and dry thorou hly.
NEVER use detergents, abrasive powders,
highly perfumed cleaning products or wax
polishes to clean the interior as these will
damage the surface and leave a strong
odour.
External Cleaning
Wash the outer cabinet with warm soapy water.
When the appliance is not in use
When the appliance is not in use for lon periods,
disconnect from the electricity supply, empty all foods
and clean the appliance, leavin the door open to
prevent unpleasant smells.
Defrosting
While the appliance is in operation the ice-makin
compartment becomes pro ressively covered with
frost.
This frost, acts as an insulator and prevents the
cold from reachin the insulator food. The frost
should be removed whenever the thickness of the
frost exceeds 6 mm (¼). To carry out complete
defrostin proceed as follows.
Pull out the plu from the wall socket or turn the
thermostat control knob to the 0 position.
Leave the frid e and ice-makin compartment
doors open, when defrostin is completed, dry the
appliance thorou hly. Remove any defrost water
collected in the tray.
Replace the plu in the socket or return the
thermostat to the initial position and, after lettin
the appliance run for at least an hour, place the
food in the refri erator.

10
Problem
No power to the
appliance
The temperature in the
appliance is too hi h
The temperature in the
appliance is too low
Excessive frost and ice
has built up
The appliance is noisy.
Possible Cause
No power at the socket.
There is a power cut.
The fuse has blown.
Thermostat control knob is set at 0.
The appliance is located in an unsuitable position.
The thermostat control knob is set too low.
The thermostat control knob is set too hi h.
The door has been left open.
Somethin is obstructin the door.
The door asket is dirty.
The appliance is not level.
Solution
Check there is power at the socket.
Check there is not a power cut by checkin the
household li hts.
Check the fuse has not blown.
Check the thermostat control knob settin .
Check the ambient temperature is within the
appliances operatin limits of 12 °C to 32 °C.
Check that the thermostat control knob is turned
to the correct settin relative to ambient
conditions.
Set the thermostat control knob to a lower
position.
Check the door has not been left open.
Check nothin is preventin the door from closin .
Check the door asket is intact and clean.
Check if the appliance stands stable.
Some
Something N thing No ot W t Wor orking king
If the appliance is not workin correctly, please carry out the followin checks before contactin
your local Service Force Centre.
If after the above checks your appliance still does not
operate correctly, contact your local Service Force
Centre.
Please note that it will be necessary to provide proof
of purchase for any in- uarantee service calls.
In-guarantee customers should ensure that the
above checks have been made, as the
engineer will make a charge if the fault is not a
mechanical or electrical breakdown.

11
Cus
Cust tomer Car omer Care Depar e Department tment
For eneral enquiries concernin your Zanussi Electrolux appliance or for further information on Zanussi
Electrolux products, please contact our Customer Care Department by letter or telephone at the adresses
below or visit our website at www.zanussi.co.uk
Customer Care Department
Zanussi Electrolux
55-77 Hi h Street
Slou h
Berkshire
SL1 1DZ
08705 727727 (*)
*calls to this number may be recorded for trainin purposes.
Ser
Service and Spar vice and Spare P e Par arts ts
In the event of your appliance requirin service, or if you wish to purchase spare parts, please contact your
local Service Force Centre by telephonin :-
08705 929929
Your telephone call will be automatically routed to the Service Force Centre coverin your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit
the website at www.serviceforce.co.uk
Before callin out an en ineer, please ensure you have read the details under the headin "Somethin Not
Workin ."
When you contact the Service Force Centre you will need to ive the followin details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the ratin plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee
service calls.

12
Guar
Guarant antee Conditions ee Conditions
We Zanussi Electrolux undertake that if within 12
months of the date of the purchase this ZANUSSI
ELECTROLUX appliance or any part thereof is proved
to be defective by reason only of faulty workmanship
or materials, the company will, at our option repair or
replace the same FREE OF CHARGE for labour,
materials or carria e on condition that:
The appliance has been correctly installed and
used only on the electrical supply stated on the
ratin plate.
The appliance has been used for normal domestic
purposes only, and in accordance with the
manufacturer's instructions.
The appliance has not been serviced, maintained,
repaired, taken apart or tampered with by any
person not authorised by us.
All service work under this uarantee must be
undertaken by a Service Force Centre.
Any appliance or defective part replaced shall
become the Company's property.
Home visits are made between 8.30am and 5.30pm
Monday to Friday. Visits may be available outside
these hours in which case a premium will be char ed.
EXC USIONS
This Guarantee does not cover:
Dama e or calls resultin from transportation,
improper use or ne lect, the replacemet of any li ht
bulbs or removable parts of lass or plastic.
Costs incurred for calls to put ri ht an appliance
improperly installed or calls to appliances outside
the United Kin dom.
Appliances found to be in use within a commercial
environment, plus those which are the subject of
rental a reements.
Products of Zanussi Electrolux manufacture which
are not marketed by Zanussi Electrolux.
The uarantee is in addition to your statutory and le al
ri hts.
EUROPEAN GUARANTEE
If you should move to another country within
Europe then your uarantee moves with you to your
new home subject to the followin qualifications:
The uarantee starts from the date you first
purchased your product.
The uarantee is for the same period and to the
same extent for labour and parts as exists in the
new country of use for this brand or ran e of
products.
This uarantee relates to you and cannot be
transferred to another user.
Your new home is within the European
Community (EC) or European Free Trade Area.
The product is installed and used in accordance
with our instructions and is only used
domestically, i.e. a normal household.
The product is installed takin into account
re ulations in your new country.
Before you move please contact your nearest
Customer Care Centre, listed below, to ive them
details of your new home. They will then ensure that
the local Service Or anisation is aware of your
move and able to look after you and your
appliances.
France Senlis [phone]
Germany Nurenber [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slou h [phone]

13
Ins
Instr tructions f uctions for the Ins or the Inst taller aller
Technical data
ZR 23 W
Ice-makin comp.: 5
Fresh food comp.: 65
Ice-makin comp.: 5
Fresh food comp.: 62
525
520
587
0,53
193
B
55
24
Model
Gross capacity (l)
Net capacity (l)
Width (mm)
Hei ht (mm)
Depth (mm)
Ener y consumption (kWh/24h)
(kWh/year)
Ener y class, accordin to EU standards
Rated power (W)
Wei ht (k )
Installing the appliance
Transportation, unpacking
The appliance and the interior fittin are protected
for transport.
Remove all packa in and any adhesive tape.
Any remnants of adhesive can be removed usin
white spirit.
After transportation the appliance must not be
switched on for 2 hours. This is to allow the
refri erant to settle.
Cleaning
Clean the accessories and the inside of the
appliance with warm water and bicarbonate of soda
(5 ml to 0.5 litres of water). Rinse and dry
thorou hly.
Do not use detergents, abrasive powders, highly
perfumed cleaning products, wax polishes or
cleaning products containing bleach or alcohol.
ocation
The appliance should be positioned in a well
ventilated, dry room.
Ener y use is affected by the ambient temperature.
The appliance should therefore:
not be installed next to radiators, cookers or other
sources of heat
only be installed at a location where the ambient
temperature corresponds to the climate
classification, for which the appliance is desi ned.
The climate classification can be found on the data
plate.
The followin table shows which ambient temperature
is correct for each climate classification:
Climate Classification Ambient Temperature
SN +10 to +32 °C
N +16 to +32 °C
ST +18 to +38 °C

Ventilation Requirements
The appliance must have adequate ventilation to
ensure correct operation.
Dia ram shows the ventilation requirements when
installed:
A* Under a worktop, or cupboard.
* The clearance space of 10 cm above the appliance
may be reduced to 5 cm providin a clearance
space 2.5 cm is left on either side of the appliance.
B When freestandin
Door Reversal
If required the openin direction of the door can be
chan ed as follows:
To reverse the hin e assembly proceed as follows:
Disconnect the appliance from the electricity
supply.
Remove the top hin e cover.
Unscrew the 2 retainin screws, and remove the
hin e from the appliance.
Take the door off.
Unscrew the lower hin e retainin screws, and
remove the hin e accordin to the dia ram.
Fit the lower hin e on the opposite side.
Fix the door onto the lower hin e pin.
To fit top door hin e, remove the plastic blankin
plu s carefully, and refit them in the holes left by the
hin e retainin screws.
Refit the top hin e usin the 2 retainin screws,
takin care that the ed e of the door is parallel with
side of the cabinet.
Replace the hin e cover.
Remove screw covers (if fitted) and handle retainin
screws. Remove blankin plu s on the opposite
side.
Relocate the handle to the opposite side and refit
retainin screws (covers if fitted), and replace the
blankin plu s.

Electrical connection
Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
This appliance must be earthed.
The manufacturer declines any liability should
these safety measures not be observed.
Electrical Requirements
Before switchin on, make sure the electricity supply
volta e is the same as that indicated on the appliance
ratin plate.
The appliance is supplied with a 13 amp plu fitted. In
the event of havin to chan e the fuse in the plu
supplied, a 13 amp ASTA approved (BS 1362) fuse
must be used. Should the plu need to be replaced
for any reason. The wires in the mains lead are
coloured in accordance with the followin code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured reen and yellow must be
connected to the terminal marked with the letter E or
by the earth symbol or coloured reen and yellow.
The wire coloured blue must be connected to the
terminal N or coloured black.
The wire coloured brown must be connected to the
terminal marked L or coloured red.
Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must be
secure over the outer sheath.
This appliance complies with the followin
E.E.C. Directives:
73/23 EEC of 19.02.73 (Low Volta e Directive)
and subsequent modifications,
89/336 EEC of 03.05.89 (Electroma netic
Compatibility Directive) and subsequent
modifications.

Rev.: 2003. 04. 01.Printed by Xerox Hun ary Ltd.
From the Electrolux Group. he worlds No.1 choice.
The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux
Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of
approx. USD 14 billion in more than 150 countries around the world.
E ECTRO UX HOME PRODUCTS OPERATIONS EUROPE
© Electrolux plc 2003
