Zanussi DCH 327 X User manual

1
Model No. DCH 327 X
Product No 949 600 131
Serial No.
32587-6516Rev. 1-842
INSTRUCTION BOOK
ZANUSSI IRE

2
Contents Page no
I portant to know........................................................................................... 3
Operating instructions ..................................................................................... 6
Maintenance And Cleaning ............................................................................ 8
Tips on the use of the cera ic hob unit ........................................................ 10
Mounting .................................................................................................. 12
Electrical installation ..................................................................................... 14
Technical data ............................................................................................... 15
If the hob does not work ............................................................................... 16
Deep fat frying.............................................................................................. 17
It is i portant to know how the hob works, for which reason we would ask you to
read these instructions carefully before using it. Only then can we quarantee that
"your new kitchen aid" will fully eet your expectations and require ents that you
had when you chose your Zanussi syste .
Sincerely
Zanussi

3
Service and repair may only be
performed by the distributor, or by a
service organization approved by the
distributor. Only repair parts delivered
by the distributor may be used.
Please read the warranty.
Avoid pinching the cable.
The hob unit is intended for ordinary
household cooking purposes. Any
other use can result in damage to the
unit as well as personal injury.
Use only pots and pans with a rigid,
even contact surface - uneven contact
surface results not only in poor heat
conduction, but also increases the risk
of dangerous spills.
During deep-fat frying, sauteeing,
melting of butter, etc., one must always
remain near the unit, due to the danger
of fire. In the event of fire the unit
must be shut off immediately (and the
cooker hood as well, if in use).
Make sure that the unit is shut off
when not in use - the knob should rest
at “0”.
The unit becomes dangerously hot
during use, and remain so for a period
of time. They should therefore be
treated with due respect. Keep children
at a distance.
For safety's sake, turn pots and pans so
that handles do not protrude, thus
inviting accidents.
Never place plastic or paper, etc., on
the unit. If the unit should be switched
on by accident, the paper could burn,
plastic melt, etc.
For hygienic and safety reasons the
unit must be kept clean. Grease, oil
and food spills create unpleasant
odours when burnt, and can in some
cases result in open flames.
Read - and adhere to - the users
instructions, as well as any instructions
and warnings printed on the labels of
the cleaning agents used.
Help to avoid accidents; if the unit
should ever be discarded, render it
useless by removing the cable, or by
cutting the cable as close to the unit as
possible.
Areas if use
The hob is only intended for normal
household use. It is important that you
follow the advice given in these
instructions in order to avoid any risk
of damage to persons and objects.
Used for any other purpose invalidates
the guarantee as well as product
liability.
Important to know

4
Product liability
Our liability is limited to that which is
stipulated by law, and covers only
damage to persons and property, which
results from defects in materials and
workmanship of the unit itself.
This liability extends for a period of 10
years from the date of purchase as a
factory-new unit.
Reservations
Our liability does not apply in the
event that the damage in question is
due to any of the following conditions:
The unit has not been installed in
accordance with the instructions set
forth in this pamphlet.
That the safety rules in the instructions
have not been complied with.
That repair has been made by others
than an authorized service technician.
The unoriginal spare parts have been
used. That the damage is caused by
transport at a later date, for instance
during removal or resale.
That the damage is caused by any form
of use contrary to common sense.
Positioning
It is advisable to place the unit near an
out-of-the-way, or closed, corner, with
space on either side on which to rest
hot cooking utensils. The unit should
not be placed at a heavily-trafficked or
open corner, nor in at passageway.
Unpacking
Check to see whether the unit is
damaged.
Distribution damages
Any damages due to transportation by
us or by our representative must be
reported to the dealer not later than
one week after receipt of the unit.
Installation
Electrical installation must be
performed by an authorized electric
company. Electrical installation by a
novice can result in damage to persons
or to the unit.
Electrical parts must not be tampered
with.
Caution: In order to avoid a hazard this
appliance must be installed according
to these instructions for installasion.
Check
If you make a note of the model,
product and serial numbers on receipt
you will always have this information
to hand (See front page).
These numbers will be needed for any
service visits.
The model number plate is situated on
the bottom of the hob.

5
Before use
Before using the hob unit it is advised
to clean the ceramic surface with the
enclosed cleaning agent.
Use a clean, damp cloth or tissue. Dry
with a clean cloth.
The decorative pattern on the ceramic
surface can become scratched and
marred with use, depending upon how
one uses and maintains the unit, but
does not adversely affect performance.
Note! The warranty does not cover
such blemishes.

6
Operating instructions
pilot light
Switch symbols (to the left)
Switch for regulating the double
plate at the rear
Switch for regulating the small
plate at the front.
Regulating
The regulating of heat is graduation-free
for all plates on a scale from 1 to 12.
“1” Represents lowest heat
“12” Represents maximum heat.
“0” Represents “OFF”.
Small circle: When you switch on the
cooking section it will always be the
small circle that is switched on. Choose
the wanted temperature.
From small to big circle (both circles
are on): Turn the button past “12” to
stop. Turn back to the wanted
temperature.
From big to small circle: Turn the
button back to “0”. Switch on again and
choose the wanted temperature.

7
Pilot light
Pilot light is activated when either of
the zones are turned on, and will
remain on until the cooking zones are
switched off.
Residual-Heat indicator
Each plate has a residual heat
indicator which remains on as long as
the temperature of the cooking zone
exceeds 80˚C, even if the cooking zone
is switched off.

8
Maintenance and cleaning
Use Proper Cooking Utensils
Make the most of your new ceramic-
top hob unit by using proper utensils
of a good quality.
Only pots and pans which are
expressly intended for use on ceramic-
top hob units may be used. Utensils
must, as a minimum, cover the entire
circle which represents a given burner.
The underside, or bottom, of the
utensil must form a flat, even surface.
Ensure that both contact surfaces - the
utensil as well as the hob unit’s - are
absolutly dry.
Utensils with enamelled bottoms cause
excessive wear on the decorative
pattern of the ceramic surface. Utensils
with painted bottoms must not be used,
as the paint can be transferred to the
ceramic surface, where it will stick
permanently, causing a pocked surface.
Warning!
Utensils with aluminium bottoms can
cause light spots on the ceramic
surface. These can be removed with
the cleaning agent supplied with the
unit.
Cleaning of the ceramic
surface
The ceramic surface must be cleaned
each time that the unit has been in use.
Use a clean cloth, which has been
dipped in warm, soapy water

9
(use liqud AJAX or other diswashing
liquid), and well wrung.
All spills must be cleaned up
immediately, while the burner is still
warm. Use the cleaning agent supplied
with the unit.
Remove spots caused by utensils with
aluminium bottoms, or burned grease,
by polishing with the cleaning agent
supplied with the unit. In extreme
cases polishing may have to be
repeated several times in order to
remove the blemish entirely.
After clean-up of any of the burners,
the entire ceramic surface should be
polished, using the cleaning agent
supplied with the unit.
Cleaning of borders and edges
All borders and edges, including the
front control panel, should be cleaned
in the same manner, and with the same
cleaning agent for example, liquid
AJAX, as the ceramic surface.
Warning!
Never use scouring powder, scouring
sponges, steel wool, or any other
cleaning agent, which can scratch the
ceramic surface.

10
Tips on the use of the
ceramic ho unit
Do not slide saucepans across the
surface of the hob - always lift the pan
when placing it on, or removing it
from the ceramic surface.
Wipe the bottom surface of the pots
and pans with a clean dry cloth before
placing them on the ceramic surface.
This helps to reduce cleaning and
prevents scratching the hob glass.
Wipe off spills whilst the hob is warm.
Select the highest setting for the
cooking zones until the food is brought
to the boil, then reduce the setting.
Use saucepans with an even base. An
uneven based saucepan may increase
the electricity consumption by up to
50%.
The saucepan should match the
cooking zone or be slightly larger.
Use a tightly fitting lid on the saucepan
to reduce electricity consumption.

11
The decorative pattern on the ceramic
surface can become scratched and
marred with use, depending upon
maintenance, but does not adversely
affect performance.
Such blemishes are not covered by the
warranty and do not affect the
operation of the hob.
Spills and melts must be removed
immediately, while the surface is still
warm, using the scraper supplied with
the unit. Especially damaging are melted
plastic, aluminum, or any foodstuff
containing sugar, including natural sugar,
as these can create permanent
“pockmarks”and craters on the ceramic
surface. After scraping polish thoroughly
with the cleaning agent supplied with the
unit.
Utensils which have been in contact with
the above-mentioned melted materials
must be cleaned throughly before used
again on the ceramic-top hob unit.
Defects in the ceramic surface which can
be related to the above are not covered
by the warranty.
Warning:
Aluminum foil and plastic utensils are
not to be placed on hot surfaces.
The surface may not be used for storage.
Do not stare at the heating units when
in operation.

12
Mini u distance
to wall:
150
Mini u distance
to wall (non-
fla able aterial):
150
Reinforce ent
bea s
Mounting
Caution: In order to avoid a hazard this
appliance must be installed according to
these instructions for installation
The appliance unit can be mounted in
any type of kitchen with a work top
whose thickness is between 28 mm and
40 mm.
Clearance
The distance between the top side of the
work top and the carpentry underneath
must be at least 47 mm.
Fixing
Screw the fixing brackets out to such an
extent that they can be turned in under
the work top. Tighten the brackets on to
the work top with an ordinary
screwdriver.
Cut-out measurements
One rectangular hole is sawn out for the
appliance combination chosen.
The depth of the cut-out for any unit is:
490 mm
Length of hole = sum of all units`
externally measured length, less 20 mm.
Mounting of Reinforcement
Beams
A reinforcement Beam, with supporting
flanges at each end, is included with
each two-burner unit. For unit
combinations, a reinforcement beam
must be used between each unit.
Min. 47 mm

13
It is not necessary to attach the
reinforcement beam to the table
surface, as it is held in place by a
specially designed moulding, which is
incorporated in the hob unit´s flanges.
The unit´s externally
measured length
145 mm:
Cooker hood
290 mm:
Two-burner standard electric hob
Two-burner ceramic-top electric hob
Two-burner gas hob
Grill
580 mm:
Four-burner ceramic-top electric hob
Four-burner gas hob
Installation of a single unit
When mounting a single unit, be it a
half-or full size unit, in a table surface
which is thicker than 30 mm, it is
necessary to make a special notch in
both sides of the cut-out hole, as
shown in the adjacent drawing.
The purpose of these notches is to
create space for the electrical cables.
Glass cover
For units with a glass cover, ensure
that the cover always remains open
while the unit is operating (operation
indicator lamp on).

14
The electrical connection may only be
performed by a qualified electrician/
competent person. The electrical
connection must be carried out in
accordance with prevailing regulations
for appliances using heavy current.
The connection must comply with any
specific requirements specified by the
local electricity supply authority.
There must be no interference with
any of the unit’s electrical parts.
The cable is mounted in the pegs as
shown.
Unscrew the cover while connecting
the cables.
A unit led directly to the power point
or the outlet rose.
More units may be connected via one
or more junction boxes.
The cable must be connected via an
external switch with a contact
separation of at least 3 mm in each
pole.
Please observe these instructions,
otherwise the warranty will not
cover any damage that may occur.
Single-phase zero-earth
Cable type 1,5 mm²HO5VV-F.
The cable outside diameter must be
between 7,5 and 10,5 mm.
Cover
Electrical installation

15
Two-phases zero-earth (max. 10A)
Cable type 1 mm²HO5VV-F.
The cable outside diameter must be
between 7,5 and 10,5 mm.
Technical data
Cell Voltage 230 V
Electrical connection
230V - 50Hz
Total wattage 2900W
Instant heat effect 12/18 cm 750/1700 W
Instant heat effect 14 cm 1200 W
This unit is labelled to indicate
conformity with the lowvoltage directive
(73/23/EEC) and the EMC directive
(89/336/EEC).

16
Check to see whether a fuse has
blown.
Check to see whether the relay is
switched off.
If the problem is not with the fuse or
relay, do not attempt to correct it
yourself.
Instead, contact our service network -
all repairs must be performed by our
service personnel.
Warranty
This unit is warranted against defects
in materials and workmanship, when
used as intended, for a period of one
year from the date of purchase. The
warranty covers both parts and service,
as well as necessary transportation
costs. Keep your proof of purchase.
Reservations
The warranty does not cover damages
which are not due to defects in
materials or workmanship. Repair, or
attempted repair, by any party other
than our authorized service network
will invalidate the warranty. The
warranty does not cover an unjustified
house-call by our service network.
Service and spare parts
Service and repair of this unit must be
carried out by our service personnel, or
by an alternative service organisation,
approved by the distributor. Only spare
parts delivered by the distributor may
be used. Spare parts and service are the
domain of our service network.
If the unit does not work

17
Deep fat frying
For safety purposes, when deep fat
frying, fill the pan 1/3 full of oil. Do
not cover the pan with a lid and do
not leave the pan unattended.
In the event of a fire, switch off at the
electricity supply and cover the pan
with a lid or damp cloth to assist in
smothering the flames.
Do not use water on the fire. Leave the
pan to cool for at least 30 minutes
before moving it.
Do not leave the fat or oil in the frying
pan on the hob to store it in case the
hob is inadvertently switched on.
1. Preparing the food
Seal the food by coating with flour,
egg and bread crumbs or batter. Do not
use a basket with batter coated foods
as they will stick.
2. Quantity of oil
For safety purposes, fill the pan only
1/3 full of oil.
3. Testing the temperature of the oil
It is advisable to use a thermometer to
test the temperature of the oil.
Alternatively, drop a small cube of
bread into oil which should brown in
just under a minute if the oil is at the
correct temperature, or 190˚C.
4. Cooking the food
Lower the food gently into the oil. Do
not add too much food at once or the
temperature of the oil will be reduced
and may result in soggy, greasy food.
Turn the food if necessary, doughnuts
float to the surface so they will not
brown on the upper side if not turned.
Once cooked, drain the food on
absorbent paper.
5. Frying temperatures
Temp in ˚C
First frying of potatoes 170
175
180
Second frying of potatoes 190
Frying chicken and fish 195
200
Preserving
1. Pan size
Do not use a pan that overlaps the
perimeter of the hob trim.
2. Filling the pan
To allow for a full rolling boil, the pan
should be no more than 1/3 full when
all the ingredients have been added.

18
It is better to use two pans rather than
overfill one, or use half quantities.
3. What to use
Use firm fruit or vegetables and wash
well before using.
4. Types of sugar
Preserving sugar gives clear jam,
however granulated sugar is cheaper
and gives equally good flavour.
5. Crystallization
Crystallization may be caused if sugar
is not completely dissolved before
bringing the jam to the boil. Over
boiling will affect the flavour, setting
properties and colour of the jam.
6. To test jam for setting.
If a jam thermometer is available, boil
the jam to 140˚C. Marmalade should be
boiled to 106˚C.
If no thermometer is available, remove
the pan from the heat, place a sample of
jam on a cold dish and cool quickly (i.e.
in a freezer or frozen food compartment
of a refrigerator). When cold, and if it is
ready, it should crinkle and hold the
mark of a finger run through it.
7.
The scum should be removed as soon as
possible after setting, but marmalade
should be allowed to cool before
decanting into jars to prevent the peel
rising.

20
ZANUSSI
