User Manual
ZOB343X
EN User Manual
Oven

Welcome to Zanussi! Thank you for choosing our appliance.
In our drive to be sustainable, we are reducing paper assets and provide full user
manuals online. Access your full user manual at zanussi.com/manuals
Get usage advice, brochures, trouble shooter, service and repair information at
zanussi.com/support
1. PRODUCT DESCRIPTION
1.1 General overview
1 43 52 6
7
8
9
10
4
3
2
1
11
1Control panel
2Knob for the heating functions
3Power lamp / symbol
4Display
5Control knob (for the temperature)
6Temperature indicator / symbol
7Air vents for the cooling fan
8Heating element
9Lamp
10 Fan
11 Shelf positions
2. CONTROL PANEL
2.1 Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
2 ENGLISH

2.2 Display
A B
A. Clock functions
B. Timer
3. BEFORE FIRST USE
3.1 Before first use
The oven can emit an odour and smoke during preheating. Make sure that the room is
ventilated.
Step 1 Step 2 Step 3
Set the clock Clean the oven Preheat the empty oven
1. , - press to set the time.
After approximately 5 sec., the
flashing stops and the display
shows the time.
1. Remove all accessories from
the oven.
2. Clean the oven and the acces‐
sories with a soft cloth, warm
water and a mild detergent.
1. Set the maximum temperature
for the function: .
Time: 1 h.
2. Set the maximum temperature
for the function: .
Time: 15 min.
Turn off the oven and wait until it is cold. Place the accessories in the oven.
4. DAILY USE
4.1 How to set: Heating function
Step 1 Turn the knob for the heating functions
to select a heating function.
Step 2 Turn the control knob to select the tem‐
perature.
Step 3 When the cooking ends, turn the knobs
to the off position to turn off the oven.
4.2 Heating functions
Heating function Application
Off position
The oven is off.
Heating function Application
Light
Oven lamp
True Fan Cooking
Even baking, tender‐
ness, drying
Moist Fan Baking
Baking
Defrost
Defrosting
Grill
Toasting, grilling
ENGLISH 3

4.3 Notes on: Moist Fan Baking
This function was used to comply with the
energy efficiency class and ecodesign
requirements. Tests according to BS EN
60350-1.
The oven door should be closed during
cooking so that the function is not interrupted
and the oven operates with the highest
energy efficiency possible.
For general energy saving recommendations
refer to "Energy Efficiency" chapter, Energy
Saving.
This function is designed to save energy
during cooking. When you use this function,
the temperature in the cavity may differ from
the set temperature. The heating power may
be reduced.
5. CARE AND CLEANING
5.1 Notes on cleaning
Cleaning Agents
Clean the front of the oven with a soft cloth with warm water and a mild detergent. Clean and
check the door gasket around the frame of the cavity.
Use a cleaning solution to clean metal surfaces.
Clean stains with a mild detergent.
Everyday Use
Clean the cavity after each use. Fat accumulation or other residue may cause fire.
Moisture can condense in the oven or on the door glass panels. To decrease the condensa‐
tion, let the oven work for 10 minutes before cooking. Do not store the food in the oven for
longer than 20 minutes. Dry the cavity with a soft cloth after each use.
Accessories
Clean all accessories after each use and let them dry. Use a soft cloth with warm water and
a mild detergent. Do not clean the accessories in a dishwasher.
Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects.
6. TROUBLESHOOTING
6.1 What to do if...
In any cases not included in this table please
contact with an Authorised Service Centre.
Problem Check if...
The oven does not heat
up.
The fuse is blown.
Problem Check if...
The door gasket is dam‐
aged.
Do not use the oven.
Contact an Authorised
Service Centre.
The display shows
"12.00".
There was a power cut.
Set the time of day.
The lamp does not work. The lamp is burnt out.
4 ENGLISH

6.2 Service data
If you cannot find a solution to the problem yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is on the rating plate. The rating plate is on the front
frame of the oven cavity. Do not remove the rating plate from the oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
7. ENERGY EFFICIENCY
7.1 Product Information Sheet according to UK Ecodesign and Energy
Labelling Regulations
Supplier's name Zanussi
Model identification ZOB343X 944064891
Energy Efficiency Index 94.8
Energy efficiency class A
Energy consumption with a standard load, fan-forced mode 0.73 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 53 l
Type of oven Built-In Oven
Mass 28.6 kg
BS EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐
ods for measuring performance.
7.2 Energy saving
The oven has features which
help you save energy during
everyday cooking.
Make sure that the oven door is closed when
the oven operates. Do not open the oven
door too often during cooking. Keep the door
gasket clean and make sure it is well fixed in
its position.
Use metal cookware to improve energy
saving.
When possible, do not preheat the oven
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes at
one time.
Cooking with fan
When possible, use the cooking functions
with fan to save energy.
Residual heat
When the cooking duration is longer than 30
min, reduce the oven temperature to
minimum 3 - 10 min before the end of
ENGLISH 5

cooking. The residual heat inside the oven
will continue to cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a meal
warm.
Moist Fan Baking
Function designed to save energy during
cooking.
8. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put
the packaging in relevant containers to
recycle it. Help protect the environment and
human health by recycling waste of electrical
and electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
