Zartek ZA-442-5W User manual
Dual LED Portable Floodlight with Stand
ZA-442-5W ZA-442-10W
USERS MANUAL
Thank you for purchasing this Zartek floodlight. This portable floodlight was
engineered and manufactured to give you many years of dependable operation.
Please take a few moments to read through the manual to have full usage from
this new innovative product.
Included items: 2 x LED Floodlights (5 Watt or 10 Watt as indicated on box)
Tripod stand with arm and bolts
Vehicle adaptor with 5m cable
FEATURES:
• Extreme Bright LED COB Globes
•Low Heat Emitter with High Efficiency
• Reflector for Uniform Light Dispersion
•Individual Switch on Each Light
• 5m Heavy-Duty Detachable Cable
•Operates from Vehicle 12V DC
• Horizontal & Vertical Beam Adjustment
• Easy to Setup and Reposition
• Height Extendable Tripod Stand
• Foldable Stand for Easy Handling & Storage
• Suitable for Indoor and Outdoor Use
• Shockproof & Rainproof
• 1 Year Limited Warranty
• Ideal for Handymen, Contractors, Construction, Campers,
Workshops, Emergency Services, Mining, Outdoor/Indoor Events,
Concerts, Parties etc
DID YOU KNOW?
LED lighting technology is well suited for spotlights and floodlights. Their durable
and efficient bulb provides intense light using less battery power. LED floodlights
are far more shockproof than halogen lights. LED bulbs have a very long
operating life so the bulb never needs replacing.
HIGH BRIGHT BEAM
Avoid direct eye exposure or serious eye injury could result.
To prevent damage to eyesight, never look directly into light when it is on.
Do not shine in any face.
This item is not a toy. Keep out of reach of children
SPECIFICATIONS:
• 2 x 5 Watt LED Globe 450 Lumens each (Part # ZA-442-5W)
or 2 x 10 Watt LED Globe 900 Lumens each (Part # ZA-442-10W)
• Colour Temperature 6500K
• Beam Angle 120 Degrees
• Globe Life span > 50,000hours
• Single Ceramic LED Array (COB)
• Input Voltage: 12v DC 1A(5W), 1.5A(10W)
• Operating Current / each light: 0.5A(5W), 0.75A(10W)
• Toughened Glass Cover
• Height Adjustable 80cm to 170cm
• Working Environment -20°C to 65° C
• Rating IP65
• Weight: 3.5kg
Setup:
The Zartek ZA-442 floodlight is equipped with a rugged tripod stand. Flatten the
3 legs and position on a horizontal flat surface. Extend the pole to the required
height and tighten all points. Ensure that the stand is stable. Attach the lights to
each end of the top arm with the hand bolts provided. Swivel and tilt both lights to
the intended direction and fasten hand bolts.
Operation:
This floodlight can be powered with the included vehicle adaptor either from a
vehicle’s 12V socket or separate car battery. A 5m detachable heavy-duty cable
has twin plugs for each of the lights. The power socket is located beneath each
light next to the ON/OFF switch. Gently lift the rubber socket protector and insert
the plug into each light. Lead the cable from the light to a power source and
ensure the wire is not damaged or broken. Press the ON/OFF switch to operate.
CAUTION!
This light uses significant amounts of power. If powered from a vehicle that
is OFF and not running ensure that the light is not left on for long periods or
a flat car battery may result. A standard, fully-charged car battery will
power the light for about 30 hours and then go flat. It is therefore only
recommended to use the light for a few hours on battery power alone and
then recharging the battery.
Small Car Battery 40AH: 40hrs (5W), 26hrs (10W)
Medium Car Battery 60AH: 60hrs (5W), 40hrs (10W)
Large Car Battery 80AH: 80hrs (5W), 53hrs (10W)
The dual LED Zartek ZA-442 portable floodlight has an Aluminium lightweight
housing for the lights with powder coated steel tripod stand for firm positioning on
flat surfaces. Beam direction can be adjusted individually per light by 360°
horizontally and 90° vertically. Fix the floodlight head position by tightening the 3
hand screws.
•Beam Angle 120 Degrees per Light
•Wide Area Flood Beam Distance approx. 50 meters for 5 Watt &
80 meters for 10 Watt
This floodlight is ideal for caravan parks, events, repair work, construction,
automotive, roadside assistance, outdoor, industrial and general use. LED
globes are shockproof and never need replacing. The light casings and tripod
stand are durable and lightweight and this portable floodlight is easy to setup and
reposition wherever temporary light is required. Applications include handymen,
contractors, campers, mining, workshops, parties, concerts etc.
WARNING!
•Do not power this floodlight with any other adaptors other than those
supplied with the unit.
•Do not operate the floodlight in high temperature, hazardous or explosive
environments.
•Do not subject the light to strong impacts.
•Do not disassemble or modify the floodlight as it contains protective
devices which, if damaged, may cause the light to get very hot.
Maintenance & Storage:
If the unit gets dirty, gently clean the outer surface of the floodlights with a soft
cloth moistened with a mild solution of water and detergent.
The tripod stand is foldable and the lights can be removed for compact storage.
Ensure that the light housings are well protected during transit. The 5m cable is
fully detachable for easy setup and convenient storage.
Store in a cool, dry place.
Warranty:
This product is warranted by Zartek against manufacturing defects in materials
and workmanship under normal use for a 12 month period from date of purchase
via our authorized appointed dealers.
