Zektor SoloCAT Ultra 100 User manual

SoloCAT Ultra 100
HDMI Extender Set
INSTALLATION GUIDE

SoloCAT Ultra 100
Using HDBaseT™ technology, this HDMI extension solution offers
an ideal solution for custom A/V installers and Home Theatre
enthusiasts to project content over long distances without
compromising audio or video quality.
IN THE BOX
● SoloCAT Ultra 100 Receiver (RX)
● SoloCAT Ultra 100 Transmitter (TX)
● Infrared Blaster Cable Pack (TX/RX Pack)
● 48V/0.5A Power Supply
FEATURES
• Extend 1080p up to 100 meters and 4K up to 70 meters over a single
CAT cable
• Wall mountable (mount sold separately)
• Low power
• Supports UltraHD 4K transmission, 1080p@60Hz/36-bit, 720p and
VGA-WUXGA formats
• Bi-direction infra-red transmission
• HDCP and HDCP 2.2 compliant
• PoH receiver
• Low prole design (Only 13mm high)
TECHNICAL SPECIFICATIONS
Video Input:
Transmitter 1 X HDMI 2.0a
Receiver 1 X HDBaseT Class C
Video Output:
Transmitter 1 X HDBaseT Class C
Receiver 1 X HDMI 2.0a
Dimensions (WxHxD) 14.8cm / 1.3cm / 10.5cm
Chassis Material Aluminium
Colour Black
Encryption HDCP 1.4 and HDCP 2.2
Max Video Bandwidth 300MHz/10.2Gbps
Power Consumption 7.3W (TX), 8W (RX)
Power Supply 1 x 48V (TX only)
Operating Temperature 0 to +35°C (32 to +95°F)
Relative Humidity 20 to 90% RH (non-condensing)
ESD Protection
± 8kV (Air-gap discharge)
± 4 kV (Contact discharge)
Certication C
E, FCC, RoHS

IDENTIFY INFRARED RECEIVER/TRANSMITTER
IR Emitter/Receiver Pin Out AGround
B IR Signal
C 5V
IR Receiver IR Emitter
A B C
TECHNICAL
A IR Activity Indicator
B IR Emitter (TX)
C IR Receiver (RX)
D RS232 Jack Port
Adapter not included
EHDBaseT Input
F HDMI Output
G Ethernet x2
A IR Activity Indicator
B IR Emitter (TX)
C IR Receiver (RX)
RS232 Jack Port
Adapter not included
E 48V Power Input
F HDBaseT Out
G PoE Indicator
HHDMI In
IEthernet
SoloCAT Ultra 100 Receiver (RX)
SoloCAT Ultra 100 Transmitter (TX)
* The IR Emitter is to
be mounted with the
sticky pad horizontal
and the Receiver
bud vertical.
C
C
A
A
B
B
E
E
F
F
G
G H I
INSTALLATION
1Connect a single CAT5e/6/7 cable between the Receiver and
Transmitter using the HDBaseT ports
2Connect a HDMI cable* between the Transmitter’s HDMI Input and
the source device (i.e. a blu-ray player)
3Connect a HDMI cable* between the Receiver’s HDMI Output and
the receiving device (i.e. a LCD TV)
4Connect the supplied IR buds to the Transmitter and the Receiver
(Please refer to the diagram to identify the IR Emitter and IR Receiver)
The IR Emitter is to be placed on the infrared sensor of the source
device. The IR Receiver is to be placed on the TV edge using the
attached sticky pad.
5Connect the supplied power supply to the Transmitter
6 Check the LEDs on the HDBaseT ports of the Receiver and
Transmitter to ensure correct installation and connection:
The Yellow LED will illuminate when connected to a video link
The Green LED will illuminate when the device is connected to the
power supply
7 Check the IR activity on the IR Indicator LEDs (A):
The Reciever’s LED will ash Green when IR signals are being
received. The Transmitter’s LED will ash Red when IR signals are
being sent
* HDMI cables are not supplied with this extender set
D
D
D

TROUBLESHOOTING
Should you encounter installation difculties or issues with device
communication, the following checklist of common issues and causes
should help resolve your issues.
No or poor picture quality:
• Connected and powered? Double check all HDMI, Ethernet and power
cables are rmly connected into the correct ports and all devices are
correctly powered.
• Cable length? Are you approaching the maximum distance of the cable
(70m for 1080p or 40m for 4K UltraHD)? If so, adjust the picture quality or try
using an additional extender kit to go further distance. Cables bundled
together may cause cross talk and further degrade signal quality.
• Signal strength? The use of cable joins, stranded patch panels, wall
outlets and stranded patch leads as interconnects between them,
can signicantly reduce signal strength. Use solid core straight through
connections wherever possible.
• If you reduce the resolution of the source do you get a picture? If so,
this suggests a conicting resolution between source and display or a
bandwidth capacity issue with your cable. Check all inputs and outputs
share the same resolution capabilities.
• Picture ‘snow’ / HD ‘noise’ signies a failure to fully establish a signal and
can often be caused by poorly terminated RJ45 connectors or excess
cable lengths. Ensure your cable is correctly wired to 568B standards.
• Cable quality and condition - HDMI cable/connectors can easily be
damaged and the quality of material can vary, Always use good quality
leads and cables and try swapping cables that are known to be working
into the solution to see if this improves your image.
IR control:
• Are the IR emitters and receivers correctly positioned to allow infrared
signals to be transmitted and received through the extender kit? Emitters
should be xed rmly over infrared sensors of sources. Receivers should be
attached to displays ensuring a clear line of sight to the remote control
used to operate.
• Is your remote control powered and sending a signal? As IR is invisible to
the naked eye, check your remote is transmitting a signal by viewing the
remote handset sensor thought a digital camera/camera phone. The
sensor should ash when a button on the handset is held down.
• IR signal dropout can be experienced due to exterior emissions of infrared
radiation. Ensure emitters and receivers are away from direct sunlight.
Halogen lighting and plasma screens may also interfere with IR signal.
SAFETY PRECAUTIONS
Please read all instructions before attempting to
install or operate this equipment.
Please keep the following in mind as you unpack
and install this equipment:
• Always follow basic safety precautions to
reduce the risk of re, electrical shock and
injury.
• To prevent re or shock hazard, do not expose
the unit to rain, moisture or install this product
near water.
• Never spill liquid of any kind on or into
this product.
• Never push an object of any kind into this
product through any openings or empty slots
in the unit, as you may damage parts inside
the unit.
• Use only the supplied power supply unit (PSU).
Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power
cabling or allow any weight to be placed
upon it.
• To protect the unit from overheating, do not
block any vents or openings in the unit housing
that provide ventilation and allow for sufcient
space for air to circulate around the unit.
