SDS-1 Phone Configuration Guide
Step 1: Set a Static IP Address on Your Windows 10 Computer
To access the web interface, your computer must be in the same subnet range as the station. There is a video about this on
the config file download site you were just on.
1. Click Start, and type Control in the search field, then select Control Panel.
2. Click on Network and Internet.
3. Click on Network and Sharing Center.
4. On the left pane, click the Change adapter settings link.
5. Right-click on your computer’s Ethernet network adapter and select Properties.
6. Select the Internet Protocol Version 4 (TCP/IPv4) option.
7. Click the Properties button.
8. Select the Use the following IP address option.
9. Set the IP address (e.g., 169.254.1.90).
10. Set the Subnet mask. (e.g., 255.255.0.0).
11. Click OK.
12. Click Close again to close the network adapter properties.
Step 2: Connect the PC, POE Switch, TCIS-2, and Phone
1. Plug the PC and the Turbine TCIS-2 into the Ethernet POE switch. DO NOT plug in the phone yet. Make sure to turn
off WiFi on your laptop if you can’t access the TCIS-2 in the steps below.
2. Allow for about 60 seconds for the Turbine to boot up. The light on the Red call button will be flashing yellow. Now
plug in the phone.
Step 3: SDS-1 Phone Configuration
Network settings
1. Press the round Menu button.

Page 2 v1.0
2. Scroll down to System and press the Menu button to select it.
3. Scroll to Network > IPv4 Settings and change to Static IP. Press the Back Button.
4. Under Network, scroll down to Static IP Settings, Select Static IP, and add the phone IP address of 169.254.1.101 (Or
that address of the phone you are programming). Use the *key on the keypad to enter periods. Press OK button
5. Reboot phone if asked.
6. Press Menu button and scroll down to Phone and press the Menu button to select it.
7. Select SIP > Account 1.
8. Set SIP Proxy to 169.254.1.100 (the Edge Controller). Use the *key on the keypad to enter periods. Press the OK
softkey once entered.
9. Press the down arrow to get to the following two settings. Ignore all the rest.
10. Set User ID to 301 (or the extension of the phone you are programming). Press the OK softkey once entered.
11. Set Auth ID to the same as the last step. Press the OK softkey once entered.
12. Press the SAVE button and Reboot the phone if asked.
13. Press the Menu button again and scroll to System > Network > IPv4 Settings > Static IP Settings and change to the IP
address of 169.254.1.101 as done above (or the address of the phone you are programming).
14. Save and Reboot the phone if asked. The phone may start working without rebooting.
Setting the Two Phone Programmable Buttons
1. Enter the address of the phone to be programmed (169.254.1.101) in your web browser address bar
2. Login using the admin name of user and the password of 123
3. Go to SETTINGS > Programmable Keys
4. Under LINE2, change MODE to Speed Dial
5. Type the name of the device to be called in the Description field (ie Scale 1) and enter its phone
number in Value (ie 300).
6. Under SOFTKEY1, change the Mode to Speed Dial.
7. Type the name of the device to be called in the Description field (ie Scale 2) and enter its phone
number in Value (ie 302).
8. Click Save and Apply.
Example IP Address Usage for a system with 4 scales and 4 scale house phones:
Directory Number
Name
IP Address
300
Scale 1
169.254.1.100
301
Scale House 1
169.254.1.101
302
Scale 2
169.254.1.102
303
Scale House 2
169.254.1.103
304
Scale 3
169.254.1.104
305
Scale House 3
169.254.1.105
306
Scale 4
169.254.1.106
307
Scale House 4
169.254.1.107
