ZICSD355Installation & Instruction Manual
en

Please read these instructions first before using your
appliance
Thank you for choosing a zenith appliance.
Please take some time to read this user manual before using your appliance,
to ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the
appliance is correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this
user manual, and store in a safe location close to the appliance for easy
future reference.
This user manual may also be applicable for several other models.
Differences between models will be listed.
Explanation of symbols used throughout this user manual
C-The earth/ground terminal in the plug is marked with the symbol.
-The freezer compartment is marked with the symbol.
-Some installation steps in furniture are marked with the symbol of
attention.
-Important information or useful usage tips.
-Symbol for waste electrical and electronic equipment.
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses
a completely environmentally friendly refrigerant the R600a (flammable only
under certain conditions) you must observe the following rules:
••••
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, other
than the ones recommended by the manufacturer.
Do not damage the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other
than those that might have been recommended by the manufacturer.

EN
2CONTENTS1 Your refrigerator 32 Warnings 4Electrical requirements .......................5Warning! This appliance must be earthed ..............................................5Energy saving tips .............................6Compliance with WEEE Directive and
Disposing of the Waste Product: .......6
Compliance with RoHS directive: .......6Package information ..........................63 Installation 7Disposing of the packaging ...............7Disposing of your old refrigerator .......7Placing and Installation ......................7Transportation instructions .................8
Installation instructions ......................9
Replacing the interior light bulb ..........9Reversing the doors .........................10
4 Before operating 18Final Check .....................................185 Using your refrigerator 19
Temperature control and adjustment...19
Suggested arrangement of food in the fridge/freezer .........................20
Storing frozen food .........................21
Freezing fresh food .........................21
Making ice cubes .... ........................21Defrosting ...... ..................................226 Maintenance and cleaning 237 Do’s and Don’ts 24Installation instructions
detailed step by step ........................11
Problem solving ...............................25
8 Installation of high levelling foot26
Guarantee .....................................29
How to obtain service ..................32

EN
31 Your refrigerator C Some items mentioned in this instruction manual are generic and may notcorrespond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.10111. Fridge compartment door shelf2. Bottle Shelf3. Deep-freeze compartment4. Fast-freeze compartment5.Crisper6. Defrost water collection channel7. Adjustable body shelves8. Interior light9. Thermostat control10. Fridge compartment11. Freezer compartment1987776543332Congratulations on your choice of a zenith quality appliance which has been
designed to give you service for many years.

4 EN
2 Warnings•
Do not connect your appliance to the electricity supply until all packing and transit protectors have been removed.
• If transported horizontally leaveto stand upright for at least 4 hours before switching on to allow compressor oil to settle.
• If you are discarding an old refrigerator with a lock or latch fitted to the door, disable the lock/latch, ensure that it is left in a safe condition to prevent the entrapment of young children.
• This fridge/freezer must only be used for its intended purpose i.e. the storing and freezing of edible foodstuff.
• Do not dispose of the applianceon a fire. At zenith, the care and protection of our environment is an ongoing commitment. This appliance which is among the latest range introduced is particularly environment friendly. Your appliance contains non CFC / HFC natural substances in the cooling system (Called R600a) and in the insulation (Called cyclopentane) which are potentially flammableif exposed to fire. Therefore, take care not to damage, the cooling circuit /pipes of the appliance in transportation and in use. In case of damage do not expose the appliance to fire or potential ignition source and immediately ventilate the room where the appliance is situated.
• We suggest you contact your local authority for disposal information and facilities available.
• See Installation Instructions on page 9 for information on suitable location.
•To obtain the best possibleperformance and trouble freeoperation from your appliance it isvery important to carefully read theseinstructions.•On delivery, check to make sure thatthe product is not damaged and thatall the parts and accessories are inperfect condition.•Ensure that the plug remains readilyaccessible. Do not use multipleadapter or extension cable.•Failure to observe these instructionsmay invalidate your right to freeservice during the guarantee period.•Keep ventilation openings, in theappliance enclosure or in the built-instructure, clear of obstruction.•Do not use mechanical devicesor other means to accelerate thedefrosting process, other than thoserecommended by the manufacturer.•Do not damage the refrigerantcircuit.•Do not use electrical appliancesinside the food storagecompartments of the appliance,unless they are of the typerecommended by the manufacturer.•We suggest you keep theseinstructions in a safe place for easyreference.•This appliance can be used bychildren aged from 8 years andabove and persons with reducedphysical, sensory or mentalcapabilities or lack of experienceand knowledge if they have beengiven supervision or instructionconcerning use of the appliance in asafe way and understand thehazards involved.

EN
5
FITTED WITHBS 1362 13A FUSE ALWAYSFIT BS 1362 REPLACEMENTCARTRIDGE FUSE
GREEN &YELLOWORGREENNBLUEORBLACKLBROWNORRED22mm.
6mm.
6mm.
6mm.32mm.12mm.FUSE
CORD GRIP•Children shall not play with theappliance. Cleaning and usermaintenance shall not be made bychildren without supervision.•Children should be supervised toensure that they do not play with theappliance.Electrical requirements
Before you insert the plug into the wall socket make sure that the voltage and the frequency shown on the rating plate inside the appliance corresponds to your electricity supply.Rating label is on the left hand side of fridge inner liner.We recommend that this appliance be connected to the mains supply via a Suitable switched and fused socket. The appliance must be positioned so that the plug is accessible. WARNING: When positioning the appliance ensure the supply cord is not trapped or damaged.Should the mains lead of the appliance become damaged or should it need Replacing at any time, it must be replaced by a special purpose made mains lead which can only be obtained from a zenith authorised service agent.
Warning! This appliance must be earthedIf the fitted moulded plug is not suitable for your socket, then the plug should be cut off and an appropriate plug fitted. Destroy the old plug which is cut off as a plug with bared cord could cause a shock hazard if inserted into a socket elsewhere in the house. The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse needs to be replaced an ASTABEAB approved BS 1362 fuse of the same rating must be used. Do not forget to refit the fuse cover. In the event of losing the fuse cover the plug must not be used until a replacement fuse cover has been fitted.Colour of the replacement fuse cover must be the same colour as that visible on the pin face of the plug. Fuse covers are available from any good electrical store.Important! Fitting A Different Plug As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: (see diagram).1. Connect the green-yellow or green(Earth) wire to the terminal in the plugmarked ‘E’ or with the symbol orcoloured green and yellow or green.2. Connect the blue (Neutral) wire tothe terminal in the plug marked ‘N’ orcoloured black.3. Connect the brown (Live) wire to theterminal in the plug marked ‘L’ orcoloured red.With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor or in the main fuse box. If in doubt contact a qualified electrician.

Energy saving tips1. Ensure your appliance is installed in awell ventilated area.2. Ensure the time between buyingchilled/frozen food and placing themin your appliance is kept at minimum,particularly in summer. Werecommend you use a cool bag or aspecial carrier bag to carry perishablefood.3. Do not leave the door (s) of yourappliance open longer thannecessary and ensure they areclosed properly after each opening.4. Defrost frozen food in the fridgecompartment, so that frozen foodacts as an ice pack to assist coolingin the fridge.5. Energy consumption of thisappliance is measured while freezercompartment is loaded without useof top shelf lid and the drawersexcept the bottom drawer. It isadvised that freezer compartment isloaded without use of drawersexcept the bottom drawer in order toachieve maximum loading capacity.Compliance with WEEE Directive and Disposing of the Waste Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its service life. Take it to the collection center for the recycling of electrical and electronic equipment. Please consult your local authorities to learn about these collection centers.Compliance with RoHS directive:The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.Package informationPackaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.EN
6

EN
73 InstallationDisposing of the packagingThe packing materials may be dangerous for children. Keep the packing materials out of the reach of children or dispose of them by classifying them in accordance with the waste instructions. Do not dispose of them along with the normal household waste.The packing of your refrigerator is produced from recyclable materials.Disposing of your old refrigeratorDispose of your old refrigerator without giving any harm to the environment.• You may consult your authorised dealeror waste collection center of yourmunicipality about the disposal ofyour refrigerator.Before disposing of your refrigerator, cutoff the electric plug and, if there areany locks on the door, make theminoperable in order to protect childrenagainst any danger.Placing and Installation1.Install your refrigerator to a place thatallows ease of use.2.Keep your refrigerator away from heatsources, humid places and directsunlight.3.
There must be appropriate airventilation around your refrigerator inorder to achieve an efficient operation.
4.Place your refrigerator on an even floorsurface to prevent jolts.5. Do not keep your refrigerator inambient temperatures under 10°C.WARNING: Do not locate extension sockets or charging transformers / power supplies or Lithium-Iron battery operated products adjacent to the compressor as they could overheat.

Transportation instructions1. The appliance should be transportedonly in a vertical upright position. Thepacking as supplied must be intactduring transportation.2. If during the course of transport, theappliance has to be transportedhorizontally, it must only be laid on itsright hand side when standing in thefront of the appliance. After bringingit to upright position, it must not beoperated for at least 4 hours to allowthe system to settle.3.
Failure to comply with theabove instructions could result indamage occurring to the appliance. Themanufacturer will not be held responsibleif these instructions are disregarded.
4. The appliance must be protectedagainst rain, moisture and otheratmospheric influences.5. When positioning your appliancetake care not to damage your flooring,pipes, wall coverings etc. Do not movethe appliance by pulling by the door orhandle.6. Empty any water in the draintray before moving. See section‘Defrosting’ and ‘Maintenance andcleaning’ for further information.7. Make sure that the defrost waterpipe at the back of the product is fixedto the plastic evaporating pan on thetop of the compressor, to avoid defrostwater spillage on the floor.IMPORTANT: Care must be taken while cleaning / carrying the appliance to avoid touching the bottom of the condenser metal wires at the back of the appliance as you might injure your fingers and hands.Do not attempt to sit or stand on top of your appliance as it is not designed for such use. You could injure yourself or damage the appliance. IMPORTANT: Make sure that mains cable is not caught under the appliance during and after carrying / moving the appliance, to avoid the mains cable becoming cut or damaged.
Do not allow children to play with the appliance or tamper with the controls. Zenith declines to accept any liability should the instructions not be followed.
EN
8

EN
9Installation instructions1. The space in the room where the appliance is installed must not be smaller than 10 cubic meters. Minimum ambient temperature is 5°C, if used in colder conditions the freezer may not operate effectively.2. Do not place the appliance near cookers, radiators or in direct sunlight as this will cause your appliance to work harder. If installed next to a source of heat or freezer, maintain the following minimum side clearances: From Cookers 50 mm (2”)From Radiators 300 mm (12”) From Freezers 25 mm (1”)3. Refer to "Maintenance and cleaning" section to prepare your appliance for use.4. A special receptacle is supplied to store the mains plug during transit. The receptacle is fixed at the back of the cabinet, on the side of the compressor (see diagram). Gently remove the plug from the receptacle. Never pull the mains cord, you may damage the appliance. In the case of transportation, ensure you locate the plug in the receptacle provided to avoid transit damage. Replacing the interior light bulb To change the Bulb/LED used for illumination of your refrigerator, call your Authorised Service. The lamp(s) used in this appliance is not suitable for household room illumination. The intended purpose of this lamp is to assist the user to place foodstuffs in the refrigerator/freezer in a safe and comfortable way. The lamps used in this appliance have to withstand extreme physical conditions such as temperatures below -20°C.

Reversing the doors Proceed in numerical order.






1

9
1
19
17
20
14
16
13
12
15
11
Top Door
1. Unscrew top hinge (1).
2. Carefully remove the top door (2).
3. Unscrew lower hinge (3).
4. Remove plastic plugs (7 & 8).
5. Refit top hinge (1) as lower hinge
(16) on the left hand side.
6. Replace top door (17).
7. Refit lower hinge (3) as top hinge
(18) on the left hand side.
Lower door
1.
Unscrew top hinge (4).
2. Carefully remove the lower door (5).
3. Unscrew lower hinge (6).
4. Remove plastic plugs (9 &10).
5. Refit hinge (4) as lower hinge (11)
on the left hand side.
6. Replace lower door (12).
7. Refit lower hinge (6) as top hinge
(13) on the left hand side.
Refit plastic plugs (7, 8, 9 & 10) into
the screw holes on the right hand
side (14, 15, 19 & 20).
EN
10

EN
11The back wall of the wooden cabinet must be left open completely to kitchen wall in order to allow
sufficient air circulation to cool down the condenser unit for energy efficiency.
1775 mm
855 mm
32 mm
1778-1788 mm
No wooden
back wall
71 mm
540 mm
545 mm
40 mm
775 mm
1775 mm
855 mm
Installation instructions
detailed step by step
555 mm
mm
Adjusting the legs
If your refrigerator is unbalanced:
You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where
the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the
opposite direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.

EN
12
775 mm
40 mm 71 mm
855 mm
1778-1788 mm

EN
1390 o
2
1
3
5
1
a
4
b
PS
PS
≤ 17
Torx
(T)
x6
Wood
(W)
x15
Plastic Sheet
(PS)
x12
Wood
(1TW)
x3
Note: Installation step for 2, screws for connecting top plastic part should not be screwed very hard, because
of moving the plastic part easily left or right side.
5
* Spares included
42 mm
Top
view
*
* If the subject parts are not
included in the product you
have purchased, then it is valid
for other models.

EN
1423
6(T)7
1
5
44 mm

EN
158
10
9
11 (T)
42.0 mm
42.0 mm
(1TW)12
42
.
0 mm
42.0
mm

EN
1614
13 (T)(1TW)15
17
16
(1TW)
42
.
0 mm
42.0 mm
(W)2.0 mm
18

EN
1720
19
22 90o
21 mm
(W)
21 W2 mm
2 mm
2 mm
23
4 mm
4 mm

EN
184 Before operating Final CheckBefore you start using the fridge/freezer check that:1.The feet have been adjusted forperfect levelling.2.The interior is dry and air cancirculate freely at the rear of thecabinet.3.Clean the interior as recommendedunder “Maintenance and cleaning.”4.Insert the plug into the wall socketand switch on the electricity supply.• When the door is open, the fridgeinterior light will come on.5.You will hear a noise as thecompressor starts up. The liquid andgases sealed within the refrigerationsystem may also give rise to noise,whether the compressor is running ornot which is quite normal.6.Set the thermostat knob half waybetween 1 and 5.7.Front edges of the cabinet may feelwarm. This is normal. These areas aredesigned to be warm to avoidcondensation.8.Do not load the applianceimmediately it is switched on. Wait untilthe correct storage temperature hasbeen reached. We recommend thatyou check the temperaturewith an accurate thermometer (seeTemperature control and adjustment).
