Zennio ALLinBOX 1612 v2 User manual

➢
ALLinBOX 1612 v2
Multifunction device with power supply, KNX-IP Interface, 16
outputs, 12 inputs and logical module
ZPR1612V2
USER MANUAL
Application program version: [1.4]
User manual edition: [1.4]_a
www.zennio.com

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
2
CONTENTS
Contents........................................................................................................................................ 2
1 Introduction .......................................................................................................................... 3
1.1 ALLinBOX 1612 v2 ............................................................................................................ 3
1.2 Installation........................................................................................................................ 5
1.3 Start-Up and Power Loss.................................................................................................. 7
1.4 LED Indicators................................................................................................................... 8
1.5 Hard Reset to Factory Defaults ...................................................................................... 10
1.6 Hard Reset power supply............................................................................................... 11
2 Configuration....................................................................................................................... 12
2.1 KNX to IP Interface ......................................................................................................... 12
2.2 Programmer ................................................................................................................... 13
2.2.1 Parallel Downloads................................................................................................. 14
2.3 Addicional Individual Addresses (Tunneling Addresses)................................................ 16
2.4 General........................................................................................................................... 17
2.5 Inputs ............................................................................................................................. 20
2.5.1 Binary Input............................................................................................................ 20
2.5.2 Temperature Probe................................................................................................ 20
2.5.3 Motion Detector .................................................................................................... 20
2.6 Outputs........................................................................................................................... 21
2.7 Thermostats ................................................................................................................... 23
2.8 Master Light ................................................................................................................... 24
2.9 Logic Functions............................................................................................................... 27
2.10 Scene Timing .................................................................................................................. 28
2.11 Manual Control Through IR Remote Control ................................................................. 30
ANNEX I. Communication Objects............................................................................................... 34

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
3
1INTRODUCTION
1.1 ALLinBOX 1612 V2
ALLinBOX 1612 v2 is a versatile KNX actuator featuring a wide variety of functions:
16 relay outputs, configurable as:
➢Up to 8 independent shutter channels (with or without slats),
➢Up to 16 individual ON/OFF outputs,
➢Up to 2 1 fan coil modules,
➢A combination of the above.
12 multi-purpose inputs, configurable as:
➢Temperature probes (possibility to parameterise a personalised probe),
➢Binary inputs (i.e., pushbuttons, switches, sensors),
➢Motion detectors.
20 customisable, multi-operation logic functions.
Up to 4 standard thermostats and 4 Hospitality thermostats.
2 master light control instances for an easy, out-of-the-box control of a set
of luminaires (or functionally equivalent devices) one of which acts as a
general lamp and the others as secondary lamps.
Manual operation / supervision of the 16 relay outputs through infrared.
Scene-triggered action control, with an optional delay in the execution.
Relay switches counter.
Heartbeat or periodical “still-alive” notification.

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
4
IP interface
➢Up to 5 parallel connections from ETS for programming and monitoring.
➢High capacity buffer
6 light indicators (LEDs): two state indicators for the power supply (power
and overload), one power supply factory reset indicator, two state indicators
for the lines (bus and Ethernet), one more IP factory reset indicator, and one
additional indicator for the programming mode.
Power supply 29V –1.4 A (40W). It is divided between an auxiliary output of
29V and a bus output with KNX coil include. The nominal input of the power
supply must be universal 110/230V ~ 50/60Hz.

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
5
1.2 INSTALLATION
Figure 1. ALLinBOX 1612 v2 elements scheme.
Figure 1 shows a scheme of ALLinBOX 1612 v2 with all the LED indicator and required
connections. ALLinBOX 1612 v2 has its own power supply, so it does not need an
additional one and it serves to supply the rest of the devices through the KNX bus.
The couple LNX twisted-pair (TP) line and LAN network, the KNX bus (12) and
Ethernet (18) cables must be connected. After the connection, the device can be
conveniently mounted on the DIN rail by the usual procedure.
The main elements of the device are described next.
Test/Prog. Pushbutton (13): a short press on this button sets the device into
the programming mode, making the associated LED (14) light in red.
Note: if this button is held while plugging the device into the KNX bus, the
device will enter into safe mode. In such case, the LED will blink in red every
0.5 seconds.
9
2
5
4
8
1
6
7
3
10
16
11
12
13
14
15
16
17
18
19
1. Main Power Supply.
2. Overload Status LED.
3. Power Supply Status LED.
4. Reset Button.
5. Reset Status LED.
6. IP Factory Reset Button.
7. IP Factory Reset LED.
8. Ethernet LED.
9. KNX Bus LED.
10. Analog/Digital Inputs.
11. Auxiliary Power Output.
12. KNX Connector.
13. Programming/Test Button.
14. Programming/Test LED.
15. Fixing Clamp.
16. Outputs.
17. IR Input.
18. Ethernet Connector.
19. Remote Control (not included).

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
6
Outputs (16): output ports for the insertion of the stripped cables of the
systems being controlled by the actuator (see section 2.6). Please secure the
connection by means of the on-board screws.
Inputs (10): input ports for the insertion of the stripped cables of external
elements such as switches / motion detectors / temperature probes, etc. One
of the two cables of each element need to be connected to one of the slots
labelled “1” to “12”, while the other cable should be connected to the slot
labelled as “C”. Note that all the external input devices share the “C” slot for
one of the two cables. Please secure the connection by means of the on-
board screws.
LEDs (2, 3, 5, 7, 8 y 9) and reset buttons (4 y 6): the behaviour will be
described in section 1.4.
Main Power Supply (1): slots for the connection of the voltage wires (phase,
neutral and ground).
To get detailed information about the technical features of this device, as well as on the
installation and security procedures, please refer to the corresponding Datasheet,
bundled with the original package of the device and also available at www.zennio.com.

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
7
1.3 START-UP AND POWER LOSS
During the start-up of the device, the Test/Prog. LED will blink in blue colour for a few
seconds before ALLinBOX 1612 v2 is ready. External orders will not be executed
during this time, but afterwards.
Depending on the configuration, some specific actions will also be performed during
the start-up. For example, the integrator can set whether the output channels should
switch to a particular state and whether the device should send certain objects to the
bus after the power recovery. Please consult the next sections of this document for
further details.
On the other hand, when a bus power failure takes place, ALLinBOX 1612 v2 will
interrupt any pending actions, and will save its state so it can be recovered once the
power supply is restored.
For safety reasons, all shutter channels will be stopped (i.e., the relays will open) if a
power loss takes place, while the individual outputs and fan coil contacts will switch to
the specific state configured in ETS (if any).

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
8
1.4 LED INDICATORS
ALLinBOX 1612 v2 incorporates 7 LED lights on the top of the device that make it easy
to monitor the status of the buses and to detect typical communication problems, as
detailed next.
Figure 2. LEDs
KNX Line Status LED (TP): shows the status of the primary bus.
➢OFF: error or KNX line not connected or not powered.
➢ON (green) = TP connection OK.
Note: the update of the LED status can be delayed a few seconds after the
trigger event, e.g., after the disconnection of the main line.
Ethernet Line Status LED (IP): shows the status of the secondary bus.
➢OFF: error or IP line not connected.
➢ON (green): Ethernet connection OK
Power Supply Status LED (POWER): shows the status of the power supply.
➢OFF: free-voltage device.
➢ON (green): voltage device (power supply OK).
➢BLINKING (green): short circuit in the power supply / “Reset” button press.

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
9
Overload LED (OVERLOAD): notifies a high consumption in the power
supply.
➢OFF: device with low power consumption.
➢ON (red): device with too high consumption.
➢BLINKING (green): short circuit in the power supply.
Programming LED:
➢OFF = normal operation.
➢ON (red) = programming mode active.
IP Factory Reset LED:
➢OFF: normal operation.
➢ON (red): IP restored by DHCP.
➢ON (green): static IP (of ETS configuration) restored.
➢ON (yellow): IP restored by APIPA.
Note: Please refer to section 1.5 for further details.
Reset LED:
➢OFF: normal operation.
➢ON (red): while the button is pressed (power supply is reset) and short
circuit in the power supply.

ALLinBOX 1612 v2
http://www.zennio.com Technical Support: http://support.zennio.com
10
1.5 HARD RESET TO FACTORY DEFAULTS
By pressing the "IP Factory Reset" button for three seconds:
The device will adopt an IP address via the DCHP server.
➢If the DHCP client does not obtain a valid IP address (after several
attempts), then the device will be assigned an IP address via the AutoIP
(APIPA)
1
protocol.
The factory reset indicator LED will light up in red.
If a second-long press is made on the "IP Factory Reset" button
The device will adopt a static IP address.
➢If "Use a static IP address" has been chosen in the ETS configuration, the
device will have the configured IP.
The factory reset led will light up in green.
➢If, on the other hand, in the ETS configuration "Obtain an IP address
automatically" has been chosen, the device will obtain an IP by means of
AutoIP (APIPA).
The factory reset indicator LED lights up yellow.
The factory IP setting and the colour of the factory reset LED will remain until the
device is restarted.
The following table summarizes the above:
Press
ETS Configuration
IP Configuration
LED
1st long press
(3s)
Obtain an IP automatically
IP obtained by DHCP.
(If a valid IP is not obtained 
IP by APIPA)
Red
Use a static IP address
2nd long
press (3s)
Obtain an IP automatically
IP obtained by APIPA
Yellow
Use a static IP address
Static IP of ETS configuration
Green
1
Random static IP configuration in the range 169.254.1.0 - 169.254.254.255
