INTRUCTION MANUAL
ZCCC-222.GX
CAMPING STOVE

GENERAL SAFETY PRECAUTION
▪For your safety, please read and follow the instructions in this manual carefully to minimize the risk of fire, explosion, or electric shock, and
to avoid property damage, injury, or death.
▪They contain important notes regarding installation, operation, and maintenance of the unit.
▪Keep all documentation for future reference.
▪This device is intended for domestic use only. This appliance is not intended for commercial use.
▪This appliance is intended for indoor use only, store it in a dry place.
▪Keep this appliance inside your home and always protected from atmospheric agents (humidity, frost, rain, hail, sun, etc.).
▪Make sure that the ambient temperature is above 0 degrees, otherwise the appliance will not work properly.
▪Do not place the appliance near or on a heat source.
▪Replace parts and accessories before restarting.
▪Use Non-inflammable cleaner.
▪Use the device only with the parts supplied to prevent any risk of injury. The use of components from other companies or non-original
spare parts may result in the risk of fire, electric shock or other accidents.
▪Never immerse the device in water or any liquid whatsoever.
▪Prevent your hand or any other part of your body from getting stuck in the removable parts of the device.
▪This device can be used by people whose physical, sensory or mental capacities are reduced or who lack experience and knowledge, But
only if they are supervised and supervised, if they have received the instructions on the use of the device. device in complete safety and if
they are aware of the dangers involved.
▪Keep the device and its cable out of the reach of children.
▪This appliance should not be used by children, as should cleaning and maintenance of the appliance. Children should not use the device as
a toy.
▪In the event of a breakdown or malfunction, the device must be repaired by a professional.
▪When installing the device, make sure that the power cord is not trapped, coiled or damaged.
▪Do not use the device:
-in the event of a leak or malfunction,
-if the device has been damaged in any way.
-if you dropped it,
▪Unplug the appliance before any cleaning operation. Use only non-corrosive or non-flammable household products. Any projection of
water or steam is to be avoided to avoid the risk of electrocution or injury.
▪To avoid any risk of damaging the appliance, transport it in its position of use, equipped with its transport blocks (depending on the model).
When unpacking it, and to prevent any risk of suffocation or accident, it is essential to keep the packaging materials out of the reach of
children.
▪In order to avoid dangerous situations, pay attention to the operating mode to follow in case of accident or breakdown.
▪To ensure the safety of the machine, use only original spare parts from the manufacturer or approved by the manufacturer.
▪Keep inflammable materials and vapors, such as gasoline, away from your unit.
▪The warranty does not include the presence & damages due to any foreign bodies (Lizards, Cockroaches, flying or crawling insects, ants,
rats, mice...) in the unit.
▪Do not touch the device with wet or damp hands.
▪Place and use the device on a flat, horizontal and stable surface.
▪When it will no longer work, do not throw the device in with household waste but rather place it in a place provided for this purpose so
that it can be recycled. By doing this you will help protect the environment.

SAFETY RULES AND RECOMMENDATIONS BEFORE & DURING USE
▪WARNING: this product must be used only for cooking. It cannot be used for different purposes.
▪Use the device only outdoors, in a well-ventilated area. Do not use it in a garage, building, covered walkway, tent or other enclosed space,
or under an overhead combustible structure.
▪Do not use the device in a vehicle, or the storage or loading space of a vehicle. This includes, but is not limited to, cars, trucks, station
wagons, vans, 4x4s, RVs, and boats.
▪This device is not intended for installation on leisure vehicles or boats.
▪Do not use this appliance if all parts are not in place and if it has not been assembled correctly, following the assembly instructions.
▪Do not install this appliance in a built-in or sliding construction.
▪Do not modify the device. LPG is not natural gas. Any conversion or attempt to use natural gas in an LPG unit or vice versa is dangerous
and will void your warranty.
▪Any item sealed by the manufacturer must not be modified by the user.
▪Before first use: Wash the new plancha and the grill by hand using mild dishwashing liquid. Wipe clean with a soft cloth.
▪WARNING: Do not strike the grill and the plancha with metallic objects. Sharp metal utensils or sharp edges can scratch the enamel surface.
▪During use, no combustible material should be within 24 inches of the rear or sides of the appliance.
▪Keep all vapors and flammable liquids, such as gasoline or alcohol, and all combustible materials away from the cooking space.
▪This appliance must be kept away from flammable materials during use.
▪In the event of a grease fire, turn off all the burners and keep the cover closed until the fire is extinguished.
▪Accessible parts can be very hot. Keep young children away.
▪The use of alcohol, prescription or non-prescription medication, or drugs may interfere with the user's ability to assemble, move, store or
operate the device correctly and safely.
▪Never leave the device unattended during preheating or operation. Use the device with caution. The entire cooking cabinet becomes hot
during use.
▪Wear heat-resistant barbecue oven mitts or gloves (conforming to standard EN 407, Contact heat level 2 or higher) when using the
barbecue.
▪Do not move the device during use.
▪Keep all power cables and the gas hose away from any heated surface.
▪Any item sealed by the manufacturer must not be modified by the user.
▪WARNING: If the LPG cylinder is not the good size to be installed in the cabinet, do not attempt to place or plug the cylinder into the
cabinet. Place and plug the bottle outside the cupboard. Failure to follow this instruction could damage the hose, resulting in serious injury
or death, as well as property damage.
▪If you smell gas:
-Turn off the gas on the appliance (barbecue).
-Extinguish any open flame.
-Open the cover.
-If the odor persists, move away from the appliance and immediately call your gas supplier or the firemen.
▪Close the gas container valve after use.
▪The device may break if dropped.
▪LPG cylinders must be stored outdoors, out of children’reach and not in a building, garage or other enclosed space.
▪After a period of storage and / or non-use, make sure that the barbecue has no gas leaks or obstructions from the burners before using it.
▪Storage of the barbecue indoors is only permitted if the LPG cylinder is disconnected and removed from it.
▪We recommend replacing the gas hose assembly on your barbecue every five years. Some countries may require that the gas hose be
replaced on a more regular basis, in which case national law prevails. For the assembly of replacement hoses, regulators and valves, contact
a professional.
WARNING :
▪During operation and after use, some parts of the device remain hot; until they cool, keep children away.
▪Do not store and use gasoline or other flammable liquids or vapors near this appliance.
▪Do not store unplugged LPG cylinders near this appliance.
▪Always wear heat-resistant barbecue oven mitts or gloves (compliant with standard EN 407, Contact heat level 2 or higher) to use the
appliance when it is hot.
▪Do not place a plancha or grill on a combustible surface, on glass or on a surface that could be damaged by heat.
▪Do not remove the plancha and the grill before they are cold.
▪Do not use cooking oil, whatever the type or quantity, on the plancha. Rather lightly oil the food before placing it on the hot plancha.
▪Never immerse your plancha or grill in water when it is hot. Thermal shock could damage the enamel.
▪Do not place two planchas side by side.

SAFETY RULES AND RECOMMENDATIONS FOR CLEANING
WARNING
▪The product must be cleaned after each use.
▪Hot surfaces can cause burns! Before starting to clean the product, wait the product cool down.
▪Before starting maintenance or cleaning, turn off the appliance, close the gas container valve and wait until the appliance is cold.
▪Soak the grill and plancha in water to remove stubborn particles, then hand wash with hot soapy water. Rinse and let dry, then store the
device in a cool, dry place.
▪Clean the rest of the device with a damp cloth after use.
▪CAUTION: Very abrasive metal pads / brushes and soaps can damage the enamel coating.
▪Donot use anycleaning product containing acid or chlorine. Clean,taking care to wipe inone directionusing liquid (non-abrasive) detergent
and a soft, soapy cloth.
▪Certain detergents or cleaning agents can damage the surface. Do not use abrasive detergents, powder / cream detergents or sharp
objects.
▪Clean the instrument panel and the control buttons with a damp cloth and wipe with a dry cloth.
▪The dashboard can be damaged! Do not disassemble the control button to clean the dashboard.
Leakage
For better safety, when the stove is not in use, close the gas cylinder.
In case of existing leakages, realizing gas odor or burn-backs, take the following steps:
1. Close the gas cylinder on the installation which supplies the stove;
2. Do not light any flames or operate tools that generate sparks;
3. Do not operate any electric switches close to the stove;
4. Open windows and doors, improving ventilation.
Contact Technical Support if the leak is in the stove and, specialized companies or gas distributors if the leak is in the supply
network or cylinder.

Dear buyer,
We thank you foryour choiceofourcamp stove/oven. Byreading the
Instructions carefully, you will be satisfiedwith the stove/oven.
Pleasere_!!d tbismanual beforeyQu light yofil'....filmliance
Once you have installed your appliance,
we recommend youtoretain this manual for futurereference.
READ THE SAFETY INFORMATION
Your safetyandthe safety of others arevery important. There are
many important safetymessages inthis manual andonyour
appliance. Always read and obeyallsafetymessages.
This isthe safety alert symbol. Recognise this symbol asan
indication of important SafetyInformation!
This symbol alertsyou to potential hazards that cankill orhurt you
and others.
Ailsafetymessageswillfollowthesafetyalertsymbolandeithertheword
"DANGER" , "WARNING" , "CAUTION" or "NOTICE" .
Thesewords mean:
Â. DANGER
Â. WARNING
Â. CAUTION
Notice:
An imminently hazardous situation that willresult in
death or serious injury.
A potentially hazardous situation that could result in
death or serious injury and/or damage toproperty.
A potentially hazardous situation that may result in
minor ormoderate injury.
Attention is called to observe a specified procedure or
maintain aspecific condition.
Â. WARNING
• If theinstructionsinthismanualarenotfollowedexactly,fireorexplosion
mayresultincausingpropertydamage,persona!injuryordeath.
• This appliance shall only beused inan aboveground open-air situation with
natural ventilation, without stagnant area, where gasleakage andproducts
ofcombustion are rapidly dispersed bywind andnatural convection
• Donotmodify this appliance
.1.

Burner
Nominal
(g/h)
Nominal
(mm)
Boiling (2off)
204
0.675
Oven
127
0.575
 DANGER
®
CARBON MONOXIDEHAZARD
THISAPPLIANCE CANPRODUCE CARBONtrlONOXIDE
WHICHHASNO ODOUR,USINGITINANENCLOSED SPACE
(FOR EXAMPLE, CARAVAN,TENT,CAR,MOBILE HOME)MAY
CAUSE DEATH.
TECHNICALREQUEST&DATA:
• Type of gas:this appliance is designed for universal L.P.Gas,look atthe
technical data label onthe stove forspecific gas information.
Working Pressure (kPa)
I3+ (28-30/37)
I3 B/P (30)
For use on Butane at 2.8-30.0 kPa
And Propane at 3.7 kPa
For use on Butane and Propane
Mixtures (LPG) at 3.0 kPa
NOTICE:
IT MAY BE HAZARDOUS TOFIT OTHER TYPES OF GAS COTAINERS
•Pressure input:2.75K.pa
gasconsumption injector size
REQUESTONREGULATOR & CONNECTION BOSE
•Before you assemble the regulator, please check the gas
type andpressure shown on the gas cylinder, andmake
surethe information on the regulator andcylinder match
•Thehose connecting the appliance andgas cylinder is
required, andthe max. length should not exceed l.Sm
•Donot twist orkink theflexiblehose
•After use, turn the gas cylinder valve off,wait for
the flame to go out,then turn the appliance control
valve(s) off
.2.

INSTALLATION:
Forthecorrect11ssemblyoftheoutb11ck campstove.Follow the
Instructions below:
• 1.Remove the paper between wire pan-grate and stovepanel. Put the wire
pan-grate in itsposition. Besurethat thewire endsfitwell in the proper
holesonthe toptoprevent the rack frommoving.
• 2. Open andclosetheburner valves: to operate the valves, you must push the
valve handle inandtum counter-clockwise to open and clockwise toclose
• 3.Be surethat the burner valves are inthe "OFF" position before you
connect the stoveto agas orpropane supply line.
Notice:This stovemay beused with a 20-LBpropane cylinder, a 1-LB
disposable cylinder.Tousewith propane, theproper low-pressure
regulator and hose must be used.
Notice:Aqualifiedinstaller,seriveagencyorthegassuppliershouldperform
installation.Forthecorrectinstallationofthestove,pleasefollowthe
stepsindicatedbelow :
• 4.Connect theinlet of the stovewith the outlet of the gas regulator. This
connecton must bemade with a specialised hose for LPgas.
• 5.Be surethat the hose isplaced correctly and isnot being stretched, tied,
orbent.
• 6.Also be surethat thehose isnot too close to heat sources, especially with the
back of the camp stove.
• 7.It isrecommended that amanual gasvalve is placed between the gas
pressure regulator and the inlet of the stoveto open or shutoffthe gas
supply.This valve must be in an easily accessible location.
• 8.Be surethat the stove iscorrectly installed.Check for any leakage,
mix some water with soap,pour someovereachconnection and lookforany
bubbles, thebubbles indicate aleak, try to tighten connection and check
again, if the leak still appears, replace the connection.
.3.

A
A
CAUTION:Followingfiguresarediagrammaticalrepresentations
of outdoors area.Rectangular areas have been used in these
Figures--the same principles apply to any other shaped area
CAUTION:Any enclosure inwhich the appliance isused shallcomply
with oneofthefollowing
Figure 1 :An enclosure
with walls on all sidcs,
but with no overhead
covcr.
Figure 2:withina
partialenclosure that
includesanovcrhcad
coverandnomore
thantwowalls
Figure 3 :within a
partial enclosure that
includesanovcrhcad
coverandno more
tbantwo walls
.4.

Open side at least
25% oftotal wall area
30 percent or more in total
of the remaining wall area
is open and unrestricted
Figure 5
-- -1- - -,- -,- - -r -
Opensideatleast
25% oftotal wall area
30percent or more intotal
ofthe remaining wall area
is open and unrestricted
 CAUTION: In the case ofbalconies 20% or more of the totalwall
area shallbeandremain openandunrestricted

.5.

CID
HOW TO LIGBT THE BURNER:
TOLIGHT YOUR STOVE INA SAFE MANNER ACCORDING TOTHE
FOLLOWING STEPS
FOR TOPBURNERS
• 1.Push the proper gas valve handle in and tum counter-clockwise to
Fully-open position to lightthe bumer.
• 2.Once the humer islit,you can adjust the intensity offlame desired.
FOR OVEN:
• 1.Lightandpull out the bottom oven tray, push the gas valve handle inandtum
Counter-clockwise to fully-openposition tolightthe humer
• 2.Keep thehandle depressed for 10seconds.
• 3.Ifthehumerdoesnotstay lit, repeatprocedures.
• 4.Before lighting orre-lighting, wait for S minutes with all gas shut off.
• 5.Toshutoff, turn allvalves to "OFF" position.
OPERATION:
Please pay attention to the/ollowing issues during operation:
• Before operation,please make surethat the appliance isput in a horizontal
position
• Keep 80cm around the item clearance and 1.Smatleast away from flammahle or
explosive materials
Â. WARNING :Obstructing combustion air opening will cause non-efficient
combustion andhigh level of exhaust gas
• After you have ignited the gas stove and/or oven, you can adjust the
controlknob,which asthe drawing shows,foryour @)
ideal flame andtemperature you want. (Drawing 1)
• When you could not ignite the flame, or the flame
becomes short, or the yellow flame occurs, please check
t.t. (\
whether there isenough gasinthe cylinder. ŒD t.
• After finishingcooking,please wear gloves andtakethe (Drawing l) pan
fromgasstoveortakefoodfromtheoven,specialattention isrequired since
theapplianceishot
• The gas humer has been setby the producer.Donottry to remove oradjust it.
• Thefood put onthe oven shelf could not exceed Skg
• Donotmove theappliance during operation
• Donot use this appliance if itisleaking, damaged, ordoes not operate properly

.6.

• Do not use this appliance if itbas been damaged or sealbas been broken.
• Change the gas container inwell ventilated area,
away from people and from ignition sources.
• Do notput anyitems ontheglass door asthe
picture shown.(Drawing 2)
• If any humer goes out during operation, turn off gas
controls on appliance and tum off cylinder valve.
Disconnect then reconnect hose tothe bottle,turn
on cylinder valve and follow ignition procedures.
If burner(s) fail to ignite, turn off gas controls on
appliance andturn off cylinder valve then disconnect
gas cylinder and retum to refuelling station for
refill asit may be empty
(Drawing 2)
• Turn allknobs to "OFF" position, close the regulator to shut off the gas supply.
If yousmellthe gas,checkwhether the gasleakage happened aspoint 8
in INSTALLATION.
 WARNING: Accessiblepartsmaybeveryhot,Keepyoungchildrenaway.
MAINTENANCE & STORAGE:
1. Keep stove area clear and free from flammable materials, gasoline and other
flammable vapours and liquids.
2. Clean your stove after use, make sure that the ventilation flow isnot blocked.
3. Check the flame of the bumers, the propane combustion colour is ablue flame,
Ifnot,thegasflowmaybe blocked, cleantheburners and checkthatthe
orifice of the valve isfree from any dirt or from any other things.
4. Clean the stovebyusing amild soapandwater.
 CAUTION: Whencleaning,donotuseanysolventorflammableor
Combustible Materials!!
Before lighting the stove again, make sure it is completely dry.
5.Please putthe appliance inthe carry bag provided, the box or otherpackage
when you donotuseit,andmake sure that the children cannot reach it.
6.Store cylinder outdoors in a well ventilated area or in storage area
compliantwithAS1596

.7.

REPAIR
Please return the appliance to seller or call the qualified person for repair and
spare parts. Do not repair it by yourself
.8.

Thanks for buying this ZERO campIing stove.
Please keep this user manual in a safe place
Updated on : JUNE 23
Specifications are subject to possible modifications without prior notice. Non-contractual pictures.
