Zetronix HADES HPSmartIPC User manual

SPEAKER ♦CHARGER ♦CAMERA
USER MANUAL
HPSmartIPC

Contents
In the Box Page 1
Diagram Page 2
Page 4
Mobile App Setup
Advanced Features Page 10
Camera Name and Password Page 11
Bluetooth Speaker Setup
Page 12
Recording Localy to Memory Card Page 13
Viewing Recorded Media Page 15
Motion Alarm Notifications
Page 16
Formatting on PC Page 18
Formatting on Mac Page 20
Product Specifications Page 22
Warranty Page 23
Additional Help Page 25
Page 9
Romote Video Stream
Troubleshooting Page 17

IN THE BOX
Page
1
B
E
D
C
A
G
F
D
A. Speaker Camera
B. Audio headphone jack cable
C. Driver CD
D. Reset Pin
E. Micro USB adapter
F. This manual
G. USB AC Wall Charger

DIAGRAM
Page 2

DIAGRAM

Camera Sensor

Infra-red emitter

Bluetooth Indicator

Lower Volume / Previous

Increase Volume / Next

Pause / Pickup phone
Press and hold: Celsius / Fahrenheit

Bluetooth Speaker On/Off

Time setup
Press and hold: 12 hour / 24 hour format

Alarm setup

Snooze

Wireless charging platform

Charging indicator light

Bluetooth Mic

Bluetooth Speakers

USB Charging Port

Audio Auxiliary Input

12V DC Power Input Connector

WiFi Camera Mic

Reset Button

MicroSD Card Slot

WiFi Camera On/Off

Power Indicator Light

Speakers
Page 3

Page 4
MOBILE APP SETUP
1. Download the App
Download and install the HDSmartIPC app
from Google Play or the App Store.
2. Power up the device
If your device uses a battery, esure that it is
charged, else ensure that is connected to
power or powered on.
3. Turn on the WiFi
Some devices will have a WiFi switch, if so
please identify it and make sure its turned
on.
Google Play App Store

MOBILE APP SETUP
Page 5
4. Connect to the device camera’s WiFi
Open your smartphone settings, search and
connect the to device's wiress network name
starting with the letters "LM..." or "AI...",wait
for Wi-Fi to connect, and phone status bar to
shows the Wi-Fi symbol in blue.
____________ ███████
LM065-A7X2430009

MOBILE APP SETUP
Page
6
zWeatherStation-500w
Enter the App, and the app will add just the
connected camera automatically.
if you dont see any listed press the plus sign
(+) to add a new camera. On the next screen
hit LAN search device, then you will be shown
a list of all detected cameras. You should see
at least one. Hit Add to add the camera
____________
________
5.Connect the phone to the camera device.

MOBILE APP SETUP
Page 7
6. Add the camera
Back on the App's main screen you will see a
video preview display of the added camera.
Press the gear icon to open settings then
select Device settings.
_____ ___
_______ ____

MOBILE APP SETUP
Page
8
Quit and restart the App, and the device will
start up with the WiFi connected within 30
secods.
You can now go back to your phone settings
as in the previous section and connect your
phone back to your local Wifi network.
The app will now stream live videos from
anywhere as long as your phone has internet
access.
Select Wi-Fi Config (Network configuration on Andoid
phones) then look for your local WiFi network name
(SSID). You will be prompted for your local network
Password. The App will now connect to the camera.
_____________

Page 9
LIVE STREAM
Camera UID / Name
Camera status
Recorded videos in memory card
Camera setting
Message: Alarm messages
(Please insert micro sd card to
get alarm pictures)
Files: Snapshots and Recorded
videos

ADVANCED FEATURES
Page 10
TIPS: Each setting in Device Settings, please scroll
down and press ok to save the setting.
Set name: Set camera name like, Office. Living
room. Kids room...
Set new password: Set camera new password
Wi-Fi config: Set camera to other Wi-Fi
Video setting: Set SD card record mode /
Resolution /File length …
Motion alarm config: Set motion detection
sensitivity
Camera info: Camera ip address, Mac address,
Reboot...

CAMERA NAME AND PASSWORD
The Default (old) password is 8888. Enter your
desired password, and hit OK.
___________
Hit the gear icon below the camera view,
then select Modify Device, you will be
prompted to Set name, choose a new camera
name, then set the Set new password.
Page 11

MOTION ALARM RECORDING
Alarm rnotification will sent you a notification
and record a snapshot when the camera
detects motion. Under Device settings choose
set Motion Alarm config and set Motion
detection to ON.
Alarm interval is the time it should continue
to record after motion was initially triggered.
To record the video on Alarm, please refer to
the Alarm video on the next section.
___________
Page 12

LOCAL MEMORY CARD RECORDING
Media can be recorded to a memory card
installed on the device. First make sure that
you have a MicroSD memory card installed
in the CRESENDO.
Hit the gear icon below the camera view to
go into Device Stttings, then select MicroSD
Card Config on Android phones and look for
TF card set.
You have the option
to format the memory
card, record at all
times, record at
specified intervals, or
stop the recording.
Recording Lengh is
the maximum video
file segments lengh.
Alarm video will
record locally when
motion is detected
and alert you on your
phone. Please refer to
the next section on
this manual to set up
alarm notifications.
Page 13

LOCAL RECORDING
Page 14
Fulltime recording: records indefinitely.
Stop record: no recording is done.
Alarm Video: records when motion is detected. Note
that motion activation needs to be set for this to
work, please refer to Page 12.
Recording lengh refers to how long the video files
will be segmented into. The HADES records video
into file segments of up to 20 minutes in length.
Format MICRO SD card: this will wipe all media and
files recorded on the MicroSD card

MEDIA PLAYBACK
Playback with WinCam Pro app
You can use the app toreview the media recorded to
the card; from the main menu, tap onthe Files icon on
the bottom of the screen.
Playback from computer.
You can also connect the memory card to your computer
and view it there.
You may have to use the included adapter
(E). It will come up as a
removable drive and all the
files can be accessed by opening the folder.
We recommend using the free VLC Media player to play
back media in your computer. Download from
http://www.videolan.org
Page 15

BLUTOOTH SETUP
Press the
Bluetooth Clock power button to turn on
Bluetooth on the HADES to start the search.
Under your phone Settings, ensure Blutooth is
turned on, wait for it to search then select the 019T
device.
All media played on your phone will be played out
though
HADES ’s speaker.
Page 16

TROUBLESHOOTING
Most issues can be solved by formatting the memory
card, restarting the HADES, or resetting the HADES’s
WiFi.
Formatting the memory:
WARNING: formatting the memory will wipe out all the
recorded media previously stored.
Formatting the memory will clean up any file corruption
that may exist preventing the device from operating
correctly.
Please refer toPage 18or 20 on how to format the
memory card.
Restart the HADES
Restart the app, disconnect the power from the HADES,
turn off the power ,for about 30 seconds and wait 1
minute.
Reset the HADES’s WiFi:
While the power is on, using the included reset pin (D),
press and hold the reset switch for about 10 seconds.
You may need to remove the camera from the app, and
add it again. See page 6.
Page 17
