ZETTLER P80SB User manual

1/6 Doc. version 1.0
Visual Indicator Sounder Beacon Series
Summary of the range
Performance characteristics
The Visual Indicating Device (VID) Sounder Beacons and Sounders are
loop powered units that are driven from an addressable controller
panel.They are available in ceiling and wall mounted variants, including an
outdoor wall version.
The ceiling mounted variants provide a base for fitting a fire detector.
Alternatively, a blanking cap is fitted.
The beacons are not EN54-23 compliant and are not suitable for
applications that require a VAD (Visual Alarm Device).
All VID Sounder Beacons and Sounders have a built-in two port loop short
circuit isolator.
Settings for tones, volume, beacon flash and status monitoring are
configurable using the control panel.
Selectable flash rates are:
1Hz (one flash every second)
0.5Hz (one flash every two seconds)
Product Details Order number In scope/fitted
Base variant
P80SB Addressable Base Sounder 576.080.002 □
P80AIB Addressable Base Sounder Beacon VID 576.080.010 □
Wall variant
P80SW Addressable Wall Sounder White 576.080.003 □
P80SR Addressable Wall Sounder Red 576.080.004 □
P85SR Addressable Wall Sounder Weatherproof 576.080.005 □
P80AIW Addressable Wall Sounder Beacon VID White 576.080.011 □
P80AIR Addressable Wall Sounder Beacon VID Red 576.080.012 □
P85AIR Addressable Wall Sounder Beacon VID Weatherproof 576.080.013 □
Accessories
B-CAP Blanking Cap For Sounder/VID/VAD Bases 557.080.001 □
A-CON Conduit Adaptor For Sounder/VID/VAD Bases 557.080.002 □
S-BOXR Shallow Surface Back Box For Indoor Wall Sounder/VAD/VID Red 557.080.007 □
S-BOXW Shallow Surface Back Box For Indoor Wall Sounder/VAD/VID White 557.080.008 □
A-BOX Flush Backbox Adaptor For Indoor Wall Sounder/VAD/VID 557.080.010 □
D-BOXR Deep Surface Back Box for Indoor Wall Sounder/VAD/ VID Red 557.080.011 □
D-BOXW Deep Surface Back Box for Indoor Wall Sounder/VAD/ VID White 557.080.012 □
P80SB P80AIB P80SW P80SR P85SR P80AIW P80AIR P85AIR
Mounting orientation Ceiling Wall
Indoor type A/outdoor type B Indoor Outdoor Indoor Outdoor
Weight (g) 146 154 182 182 358 194 194 372
Housing material PC-ABS PC PC-ABS
Housing colour White Clear White Red White Red
Operating temperature (°C) -25 to +70 -10 to 55 -25 to +70 -10 to 55 -25 to +70
Storage temperature (°C) -25 to +70
Humidity Up to 95% non-condensing
Pressure Sounder SPL output quoted for 1000 mBar
Sounder volume settings 4 2
EN54-17 isolator Yes
EN54-3 sounder Yes
Visual indicator No Yes No Yes
Vibration, shock, corrosion, EMC Complies with EN54 series requirements
Beacon flash rates -0.5 and 1 Hz - - - 0.5 and 1 Hz
Ingress protection IP21C IP55 IP21C IP55
Sounder output at 1 metre
High volume 90 dBA 100 dBA
Mid High volume 80 dBA -
Mid Low volume 70 dBA -
Low volume 60 dBA* 90 dBA
Flash colour -Red -Red
*Not EN54-3

2/6 Doc. version 1.0
Address programming
Default address = 255. Set the address before installation using either the 850EMT or 801AP service tool with its ancillary lead. Remove the front cover to access the
programming port on wall devices.
Isolator characteristics
Sounder tones and performance
Note 1: If the pulse pattern is assigned by the control panel, then only continuous tones can be configured.
Note 2: The conventional bell is a simulated tone with limited bandwidth. It is not advisable to mix conventional bells with electronic sounders producing a simulated bell tone.
Loop loading
Note: Please refer to the loop loading calculator for these units.
Parameter Isolator
Vmin, Vmax, Vnom Line voltage range 20V-40V, 35V nominal
VSO min.VSO max Isolator trip threshold range 18.5V - 21V
VSC min, VSC max Isolator recovery threshold 2.9V, 3.5V
IC max Maximum rated continuous current 1.1A
IL max Leakage current into short circuit (isolated tripped) 10 mA
IS max Maximum rated switching current 1.1A non-inductive
ZC max Maximum series impedance 0.5
ZC typ Typical series impedance 0.25
Tone name Tone description Configurable/monitored (only if volume
is 80 dB or above)
Pattern Frequency Rate Wall Ceiling
Dutch Slow Whoop Sweep 500 to 1200 Rising over 3.5 s, 0.5 gap Yes/Yes Yes/Yes
7 Hz Fast Sweep Sweep 800 to 970 142.8 ms ramp 7 Hz Yes/Yes Yes/Yes
BS 1 Hz Sweep Sweep 800 to 970 1 Hz Yes/Yes Yes/Yes
2 Tone Alternating 660 / 880 500 ms per tone Yes/Yes Yes/Yes
Temporal 4 Intermittent 880 500 ms On 500 ms Off x 4 then 1 second gap Yes/Yes Yes/Yes
Temporal 3 Intermittent 880 500 ms On 500 ms Off x 3 then 1 second gap Yes/Yes Yes/Yes
March Time Beep Intermittent 880 500 ms On 500 ms Off Yes/Yes Yes/Yes
Continuous 970 Continuous 970 Steady Yes/Yes Yes/Yes
Continuous 850 Continuous 850 Steady Yes/Yes No/No
DIN 1 Hz Sweep Sweep 1200 to 500 Falling over 1 s Yes/Yes Yes/Yes
Banshee LF Buzzer Sweep 800 to 950 120 Hz Yes/Yes Yes/Yes
3 Hz Banshee Sweep 800 to 950 3 Hz Yes/Yes Yes/Yes
9 Hz Banshee Sweep 800 to 950 9 Hz Yes/Yes Yes/Yes
Alternating Alternating 554/440 554 Hz for 100 ms and 440 Hz for 400 ms Yes/Yes Yes/Yes
Yodalarm Alternating 800/1000 250 ms for each frequency Yes/Yes Yes/Yes
Conventional Bell Continuous 1450 Steady Yes/Yes Yes/Yes
Sounder volume Beacon flash rate
(if applicable)
Wall sounder
P80SW/P80SR/P85SR
Wall VID
P80AIW/P80AIRP85AIR
Base sounder
P80SB
Base VID
P80AIB
OFF OFF 0.35 mA 0.35 mA 0.35 mA 0.35 mA
LOW OFF 3.1 mA 3.1 mA 2.45 mA 2.45 mA
HIGH OFF 8.45 mA 8.45 mA 4.32 mA 4.32 mA
HIGH 0.5 Hz - 10.85 mA - 6.71mA
HIGH 1 Hz - 13.0 mA - 8.8 mA

3/6 Doc. version 1.0
Sounder performance - ceiling devices
Sounder performance - wall devices
Volume HIGH Ceiling devices - sound performance horizontal (dBA at 1 m) Ceiling devices - sound performance vertical (dBA at 1 m)
Angle 15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
Tone
Dutch Slow
Whoop
40V > 95 > 87 > 83 > 82 > 80 > 80 > 94 > 87 > 82 > 81 > 84 > 87
20V > 93 > 86 > 82 > 80 > 78 > 78 > 92 > 83 > 80 > 79 > 82 > 87
7 Hz Fast Sweep 40V > 93 > 85 > 81 > 79 > 77 > 78 > 92 > 85 > 81 > 80 > 81 > 87
20V > 91 > 83 > 79 > 77 > 76 > 76 > 90 > 82 > 79 > 78 > 80 > 86
BS 1 Hz Sweep 40V > 94 > 86 > 82 > 81 > 78 > 79 > 93 > 86 > 82 > 80 > 83 > 88
20V > 92 > 85 > 81 > 79 > 77 > 77 > 91 > 83 > 79 > 79 > 82 > 86
2 Tone 40V > 94 > 86 > 83 > 82 > 76 > 80 > 94 > 86 > 82 > 80 > 84 > 88
20V > 93 > 85 > 82 > 80 > 76 > 78 > 91 > 83 > 79 > 79 > 82 > 85
Temporal 4 40V > 98 > 90 > 87 > 85 > 80 > 84 > 97 > 89 > 84 > 84 > 88 > 92
20V > 93 > 87 > 84 > 82 > 77 > 81 > 95 > 87 > 79 > 79 > 82 > 89
Temporal 3 40V > 98 > 90 > 87 > 85 > 80 > 84 > 97 > 90 > 84 > 84 > 88 > 92
20V > 95 > 87 > 84 > 82 > 77 > 81 > 95 > 88 > 82 > 82 > 85 > 89
March Time beep 40V > 98 > 90 > 87 > 85 > 80 > 84 > 97 > 90 > 84 > 84 > 87 > 91
20V > 95 > 87 > 84 > 82 > 77 > 81 > 96 > 88 > 81 > 81 > 87 > 91
Continuous 970 Hz 40V > 92 > 82 > 79 > 77 > 77 > 74 > 92 > 83 > 79 > 76 > 79 > 83
20V > 91 > 79 > 77 > 75 > 75 > 72 > 90 > 81 > 79 > 75 > 79 > 83
DIN 1 Hz Sweep 40V > 94 > 86 > 81 > 79 > 78 > 78 > 93 > 86 > 81 > 81 > 82 > 87
20V > 91 > 83 > 79 > 77 > 75 > 75 > 91 > 83 > 80 > 79 > 81 > 86
Banshee LF Buzzer 40V > 94 > 86 > 81 > 79 > 77 > 77 > 93 > 85 > 81 > 80 > 82 > 87
20V > 91 > 84 > 78 > 75 > 75 > 73 > 91 > 84 > 79 > 79 > 80 > 85
3 Hz Banshee 40V > 94 > 86 > 82 > 82 > 77 > 78 > 93 > 85 > 81 > 80 > 82 > 87
20V > 91 > 83 > 79 > 77 > 75 > 76 > 91 > 83 > 79 > 78 > 81 > 86
9 Hz Banshee 40V > 94 > 85 > 81 > 78 > 76 > 77 > 92 > 85 > 81 > 80 > 81 > 87
20V > 92 > 83 > 79 > 76 > 74 > 75 > 90 > 83 > 79 > 78 > 80 > 85
Alternating 40V > 95 > 86 > 82 > 80 > 78 > 79 > 94 > 87 > 81 > 81 > 84 > 87
20V > 91 > 84 > 79 > 76 > 76 > 76 > 92 > 85 > 79 > 79 > 82 > 86
Yodalarm 40V > 94 > 85 > 81 > 78 > 76 > 78 > 93 > 86 > 81 > 80 > 81 > 87
20V > 90 > 82 > 78 > 76 > 75 > 75 > 90 > 83 > 79 > 79 > 80 > 85
Conventional Bell 40V > 91 > 83 > 78 > 79 > 76 > 77 > 91 > 83 > 81 > 79 > 81 > 86
20V > 89 > 81 > 78 > 77 > 75 > 76 > 89 > 82 > 80 > 78 > 79 > 84
Volume HIGH Wall devices - sound performance horizontal (dBA at 1 m) Wall - sound performance vertical (dBA at 1 m)
Angle 15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
Tone
Dutch Slow
Whoop
40V > 91 > 95 > 95 > 95 > 95 > 91 > 91 > 95 > 95 > 95 > 95 > 91
20V > 89 > 93 > 93 > 93 > 93 > 89 > 89 > 93 > 93 > 93 > 93 > 89
7 Hz Fast Sweep 40V > 87 > 94 > 94 > 94 > 94 > 87 > 87 > 94 > 94 > 94 > 94 > 87
20V > 85 > 92 > 92 > 92 > 92 > 85 > 85 > 92 > 92 > 92 > 92 > 85
BS 1 Hz Sweep 40V > 91 > 95 > 95 > 95 > 95 > 91 > 91 > 95 > 95 > 95 > 95 > 91
20V > 87 > 93 > 93 > 93 > 93 > 87 > 87 > 93 > 93 > 93 > 93 > 87
2 Tone 40V > 88 > 94 > 94 > 94 > 94 > 88 > 88 > 94 > 94 > 94 > 94 > 88
20V > 87 > 93 > 93 > 93 > 93 > 87 > 87 > 93 > 93 > 93 > 93 > 87
Temporal 4 40V > 89 > 95 > 95 > 95 > 95 > 89 > 89 > 95 > 95 > 95 > 95 > 89
20V > 87 > 94 > 94 > 94 > 94 > 87 > 87 > 94 > 94 > 94 > 94 > 87
Temporal 3 40V > 89 > 96 > 96 > 96 > 96 > 89 > 89 > 96 > 96 > 96 > 96 > 89
20V > 87 > 94 > 94 > 94 > 94 > 87 > 87 > 94 > 94 > 94 > 94 > 87
March Time beep 40V > 89 > 96 > 96 > 96 > 96 > 89 > 89 > 96 > 96 > 96 > 96 > 89
20V > 87 > 94 > 94 > 94 > 94 > 87 > 87 > 94 > 94 > 94 > 94 > 87
Continuous 970 Hz 40V > 87 > 90 > 90 > 90 > 90 > 87 > 87 > 90 > 90 > 90 > 90 > 87
20V > 84 > 88 > 88 > 88 > 88 > 84 > 84 > 88 > 88 > 88 > 88 > 84
Continuous 850 Hz 40V > 89 > 94 > 94 > 94 > 94 > 89 > 89 > 94 > 94 > 94 > 94 > 89
20V > 88 > 92 > 92 > 92 > 92 > 88 > 88 > 92 > 92 > 92 > 92 > 88
DIN 1 Hz Sweep 40V > 89 > 94 > 94 > 94 > 94 > 89 > 89 > 94 > 94 > 94 > 94 > 89
20V > 88 > 92 > 92 > 92 > 92 > 88 > 88 > 92 > 92 > 92 > 92 > 88
Banshee LF Buzzer 40V > 89 > 94 > 94 > 94 > 94 > 89 > 89 > 94 > 94 > 94 > 94 > 89
20V > 87 > 92 > 92 > 92 > 92 > 87 > 87 > 92 > 92 > 92 > 92 > 87
3 Hz Banshee 40V > 89 > 94 > 94 > 94 > 94 > 89 > 89 > 94 > 94 > 94 > 94 > 89
20V > 87 > 92 > 92 > 92 > 92 > 87 > 87 > 92 > 92 > 92 > 92 > 87
9 Hz Banshee 40V > 88 > 93 > 93 > 93 > 93 > 88 > 88 > 93 > 93 > 93 > 93 > 88
20V > 86 > 91 > 91 > 91 > 91 > 86 > 86 > 91 > 91 > 91 > 91 > 86
Alternating 40V > 89 > 94 > 94 > 94 > 94 > 89 > 89 > 94 > 94 > 94 > 94 > 89
20V > 87 > 92 > 92 > 92 > 92 > 87 > 87 > 92 > 92 > 92 > 92 > 87
Yodalarm 40V > 89 > 93 > 93 > 93 > 93 > 89 > 89 > 93 > 93 > 93 > 93 > 89
20V > 87 > 91 > 91 > 91 > 91 > 87 > 87 > 91 > 91 > 91 > 91 > 87
Conventional Bell 40V > 86 > 90 > 90 > 90 > 90 > 86 > 86 > 90 > 90 > 90 > 90 > 86
20V > 84 > 88 > 88 > 88 > 88 > 84 > 84 > 88 > 88 > 88 > 88 > 84

4/6 Doc. version 1.0
Installation information
Dimensions
Cabling and wiring
Wiring notes
All wiring must comply with local installation regulations and local fire system design requirements.
Ensure all conductors are free of earths.
Verify correct wiring and wiring polarity before connecting the devices to the addressable loop.
Weatherproof wall units Indoor wall units Base units
Wall variant wiring Base variant wiring Contact Function
L Not used
L1 Positive line in and
out
L2 Negative line (isola-
tor in or out)
M Negative line (isola-
tor in or out)
R Remote LED out,
wired only if a
remote indicator is
required
105 97
153
32
39
60
65
39
32
5
146
Fig. 1: Sounder Beacon VID
89 40
138
60.3
135
Fig. 2: Sounder
45
114
70
50
12
Fig. 3: Base unit
1– Temporary park plunger and indicator
(yellow) for short circuit isolator.
2– Address flag holder.
+
-
+
-
Loop in Loop out
Screen
Fig. 4: Wall variant wiring
Loop Positive Loop Positive
Loop Negative Loop Negative
L1
L
R
M
L2
Optional Remote Indicator
Fig. 5: Base variant wiring

5/6 Doc. version 1.0
Mounting and fixing instructions
Weatherproof wall units Indoor wall units Base units
These units are supplied with their own back box
and special front cover. A sealing ring is supplied
fitted on this front cover. See item 1 in Fig 6.
1 Fix the back box to the wall. Drill positions
for glands on the top, bottom, and sides,
see item 2 in Fig 6.
2 Slide the wall unit into place in the front
cover as shown and then push down until it
clips in.
3 Secure the front cover (including the wall
unit) to the back box with the four supplied
screws (M3.5 hex head) using the supplied
Allen key.
Note: To maintain the IP rating, use suitably
rated cable glands and sealant as required.
1 Unclip the front cover from the wall unit. using the screw-
driver slot on the top.The front cover is hinged at the bottom
of the unit.
2 Use the two supplied screws to either fix the unit to the
optional back box (with knockouts for conduit connections)
or to the optional adaptor plate or to a back box with suitable
mating fixings.
3 Refit the front cover, engaging the clips on the bottom first.
4 Secure the front cover with either the supplied self-tapping
screw or nylon plug.
Note: If using the adaptor plate, a suitable recess is required for
the connector block protruding from the rear of the wall unit.
These units either fit directly to the ceiling or to an optional
ceiling adaptor.The ceiling mounted variants provide a base
for fitting a fire detector. Alternatively, a blanking cap is fit-
ted.See Fig 8.
See Fig 10 for fitting the locking pin. To remove a detector
from a base with a locking pin, complete these steps:
1 Insert a suitable tool into the access hole to depress
the locking pin in the detector cover.
2 Rotate the detector to remove.
These units can be used with the Ceiling Tile Adapter (CTA)
kit (517.050.060) by using the CTA Adaptor Plate, CTA-AP
(517.050.058).
2
1
Fig. 6: Fitting weatherproof wall units
1
4
3
6
2
5
7
Fig. 7: Indoor wall units
1– Single gang flush back
box
2– A-BOX
3– S-BOX
4– D-BOX
5– M3.5 screw x 2
6– Self-tapping screw
7– Nylon plug
A-CON
B-CAP
Fig. 8: Fitting base units
1
2
3
4
Fig. 9: Checking the gasket
1 Check that the gasket (item 1) is seated correctly before fitting the front cover.
2 Note “v”notch (item 2) on the upper side and gasket retained by the hooks on both sides
(items 3).
3 Item 4 is the programming port.
Fig. 10: Fitting the locking pin

120.515.395_MZX-D-VID-DS. Doc. version 1.0. 17. August 2018.
© 2018 Johnson Controls.All rights reserved. All specifications and other information shown were current as of
document revision date and are subject to change without notice.
www.zettlerfire.com
Tyco Fire & Security GmbH, Victor von Bruns-Strasse 21, CH-8212 Neuhausen am Rheinfall, Switzerland
Approvals
All required Declarations and certificates are publically available on the website www.zettlerfire.com and are searchable by number or model name.
The above fire detection products are components designed for use in Addressable Systems exclusively available to registered partners only. They are intended for installation by
trained registered personnel only. Systems should be installed and configured according to local regulations.
18
0832
TYCO FIRE & SECURITY GMBH
NEUHAUSEN AM RHEINFALL 8212
SWITZERLAND
CPR APPROVAL EUROPEAN TYPE APPROVALS
INTERNATIONAL
LISTINGS
EN54-3
EN54-23
EN54-17
MED
LPCB
VDS
AFNOR
FNO
SBSC
FPANZ
HKFSD
TFTF
P80SB DoP-2017-4234 / 0832-CPR-F2061
P80AIB DoP-2017-4234 / 0832-CPR-F2062
P80SW DoP-2017-4234 / 0832-CPR-F1673
P80SR DoP-2017-4234 / 0832-CPR-F1674
P85SR DoP-2017-4234 / 0832-CPR-F1824
P80AIW DoP-2017-4234 / 0832-CPR-F1675
P80AIR DoP-2017-4234 / 0832-CPR-F1676
P85AIR DoP-2017-4234 / 0832-CPR-F1825
This manual suits for next models
15
Table of contents
Other ZETTLER Security Sensor manuals
