Zhejiang Luqi Intelligent Technology Co. I5 User manual

1
Content
1 User’s Manual Summary............................................................................................................................................................................................................................. 2
2 Product......................................................................................................................................................................................................................................................... 3
3 Surreal Scooter Riding.................................................................................................................................................................................................................................6
4 Other Information about the Battery..........................................................................................................................................................................................................11
5 Maintenances............................................................................................................................................................................................................................................. 13

2
1User’s Manual Summary
1.1 About This Manual
Please read this manual and instruction video carefully before riding Surreal Scooter for your safety.
Make sure you have a good Understanding of the safety warnings, attentions and notices, which will all be helpful to improve your riding experience.
This manual only applies to Surreal Scooter.
1.2 Riding Risks
Surreal Scooter is an automatic, systematic and intelligent transportation and entertainment aid. It has been put through strict tests in the manufacture stages,
however, you could be injured if the warnings listed in the manual are ignored.
Warnings:
You may get injured if the scooter is out of control and you crash, also when you fall off the scooter, and when you disregard the notices and warnings included
in the manual. You must read this manual and watch relevant videos carefully, in order to decrease risks and avoid injuries.
1.3 Preparatory Work
It is important to do a safety check. Please check if the tyre’s have been damaged and if the accessories are loosening. This is to be done before riding the scooter.
Please contact the authorized agents or aftersales department to repair, if something is defective.

3
1.4 Relevant Documents and information
The instructions below can supply to the manual, please pay attention to the relevant “warning”, “attention” and “notices”.
Warning: indicates that your activities will leads to physical injury.
Attention: indicates that your activities may lead to product damaging.
Notices: indicates some functional tips and information, which users should pay attention to.
2Product
2.1 Serial Number
It is the only marking of the product, please keep it for quality tracking, aftersales service, insurance claims and missing confirmation.
It is made up of twelve letters with a barcode.
You can get the serial number from exterior packing and Protection to Fix Card.
2.2 Product Parameter
Parameters
Parameter values
Notices
Model No.
Surreal Scooter
①Max mileage speed can be allocated through
relevant application. But actual riding speed may
faster than mileage speed in short time and be
steady ultimately, due to Scooter having dynamic
and stable system.
②Mileage result got based on specific
environment: temperature 25℃; loading 70Kg. It
Max riding speed
10Km/h①
Max mileage
20Km②
Max climbing capability
15°
Net weight
9.5Kg③

4
also can be affected by different factors, such as
riding habit, temperature, pavement and loading
and so on.
③Net weight refers to the weight of battery
applied 4.4A. Product weight maybe has a
difference, according to different models and
materials. The weight of Surreal Scooter is
9.5KG approximately.
④Width 185mm measured for Scooter, 360mm
measured when pedal opening.
⑤Standard configuration of Scooter is Battery of
4.4Ah.
⑥Charging time maybe diverse, according to
different environment and battery capability.
Load weight
20～100Kg
Min turning radius
0m
Size
580*185*180mm④
Battery
36V 24.4Ah Lithium Battery⑤
Charging requirements
AC110～240v 50～60Hz
Charging time
1～2hrs⑥
Tyre
Pneumatic tyre
The best working environment
15～30℃
Notices:
The detail of information of loading, please refer to the following section.
Regarding how to improve riding mileage, please refer to following section.
2.3 Operational Principle of Scooter
The Balance system works similar to the human owned. For example, for ensuring your balance, you have to walk along when your body is moving forward;
similar to when your body is moving backwards, you lean back. When riding the wheel of the Scooter instead of your feet, likewise, the system will auto sense and
drive the wheel forward accurately to keep balancing; the wheel will drive backwards when your body is leant back.
Surreal Scooter adopts dynamic principle, utilizing gyroscope and the accelerator sensor to test the Scooter changes. It also uses servo-control system to make
the relevant adjustments accurately for keeping the system balance.

5
The System will control the speed difference of left and right to realize which way you want to turn, this happens when your body’s gravity is adjusted. When
riding, you should adjust your body weight to the direction of forward, then the Scooter will follow your direction system, and will then drive ahead, when your
body’s gravity is leant back the system will drive backwards.
2.4 Main Components of Scooter

6
2.5 The vehicle working pattern
Beginner
Superior
Senior
Balancing Feature
Stable
Relatively stable
Flexible
Steering Sensitivity
Low
Medium
High
Mode Indicator
Blue
Blue
Red
Notice:
The Superior as default mode and steering sensitivity is high when you turn on the Scooter. Please pay attention to safety for the first time riding.
2.5.1 Switching in different modes
Check current mode and method of switching.
Step 1. Please put your Scooter straight up, Power Indicator will change to Mode Indicator.
Step 2. Pressing the Power button will switch the mode, every press can switch one mode.
3Surreal Scooter Riding
3.1 Riding
Surreal Scooter is a travel tool with high technology; it may lead to unpredictable injuries when you drive before understanding the operation manual. Here
below is a detailed introduction of notices, and a list of matters that needs attention during riding. Please read carefully and drive as requested, to avoid any injuries.

7
3.1.1 Matters That Needs Attention before Riding
Please check components of Surreal Scooter are securely installed and do not have any damage.
You should practice in a spacious and flat ground (4m*4m at least, interior and outdoor, either is fine).
You should fully understand your surroundings, and make sure there is no other disturbances, such as another Scooter, pedestrians, pets, bicycles and so on.
You need to be accompanied by a skilled assistant, who can operate skillfully and a have a full understanding of this manual.
Please do not practice on smooth and wet ground, as this can cause slipping, which could lead to an injury.
Please wear a helmet and protective padding to avoid any damages caused.
For ensuring body flexibility, please wear comfortable clothing and flat shoes.
3.1.2 Start Riding
Step 1. Put Surreal Scooter on the ground vertically, then press the power switch button, the indicator will then light up, riding can be started after the beep.
Step 2. The Pedal indicator will light up after the power has been triggered by your foot stepping on the pedal, then the system enters self-balancing state.
Another foot can then step on the other pedal after keeping yourself and the scooter balanced.
Step 3. After succeeding to stand up, continue to keep your body balance, the scooter will then be in a state of rest. Gently adjust your weight, make your body
lean forwards or backwards to easily control scooter to go forward or draw back.
Step 4. Controlling the scooter to turn left and right, left foot lean forward as turning right, right foot lean forward as turning left.
Step5. Please keep scooter in state of rest and balancing once you have stopped riding, take one foot away from the pedal then another one.
Notice：
Please don’t start riding until the Scooter auto-corrects to vertical, if the Scooter is tilting forward and back, when power switch been pressed do not
step on.

8
3.1.3 Speed Limit Protection
In order to prevent injuries caused by over speed, we have to set maximum riding speed. So when the speed reaches over the maximum riding speed, the pedal
will warp to restrict speed up, and the speed of the scooter will decline.
Attention：
Please do not force speed up, when it is close to limitation.
3.1.4 Tilt Protection
If the Scooter tilts over 15°, the hub will stop rotating and the system will temporarily switch off.
Notice:
Turn off power switch then restart Scooter to unlock protection.
3.1.5 Power Capability
The capability awarded by LED lights, which is comprise of 5 LED bulbs. All of them will light up, when the capability is over 85% approximately, and
extinguish as the capability decreases. In order to avoid ‘no driving back’ because of long distance, please check the capability before riding. And we advise that
you give enough time to charge your scooter.
5 LED lights will continue to flash, if the capability is less than 10%. And a buzzer will continuously “beep”, at the same time, the front pedal will start to upturn,
forcing the drivers speed to cut and stop. Please do not restart Scooter, in case you fall off due to the power running out.
Mileage may decrease in the winter, because the lithium battery is released faster in low temperature environment.

9
3.1.6 Ingress Protection
Ingress protection of Surreal Scooter is IP54, please don’t ride on the road with water-logging.
3.2 The Impacts from Environment
3.2.1 The Mileage
Riding habits and environment will affect mileage dramatically. Here below are listed some conditions that cause great influences.
Impact Factors
Reasons
Road Conditions
Mileage will improve, riding on the flat ground, on the contrary, it will decrease significant, on the mountain field and bumpy
ground.
Speed And Riding Habit
Riding in constant and stable speed, will improve mileage, but speed decelerate very frequently will reduce mileage.
Loading
Light loading increases mileage significantly.
Temperature
Temperature has a great influence towards mileage, mileage is larger as close to the best riding temperature. And if the
temperature is lower, the mileage will decrease noticeable.
Battery
Fair charging and maintenance of battery will extend mileage. Meanwhile, mileage decreased, if it is old, over load and never
maintained battery.
Wind Direction
Mileage increased riding with the wind, decreased against wind.
3.2.2 Riding at High Temperatures
The temperature of the electric motor, battery and riding system and any other components increase observably, which will influence the parameter and lifetime.

10
Riding speed will decrease, if components’ temperature is over 50℃. Decreased scope relates to actual temperature, which means, the higher the temperature, the
lower the decreased scope. Please stop riding and turn off the power button to let the Scooter cool, when the warning system is auto-activated by 80℃or over.
3.2.3 Riding at Low Temperature
It will increase resistance by inter components lack of lubrication, and discharge and the capability of the battery will reduce dramatically. Therefore, please do
not do strenuous exercise with Scooter at low temperature (under -5℃), that will lead to the Scooter being out of control.
3.2.4 Uphill
It means that Scooter will continue to work with heavy loading, thus, temperatures of internal components rise fairly rapidly when the battery has reached the
over loading weight. Long time climbing will result in lifetime and capability being reduced. Therefore, please avoid to drive the Scooter for a long time climbing.
Moreover, system will auto reduce the maximum riding speed for security, due to heavy loading, reduced scope depends on loading and the slope.
3.2.5 Downhill
According to the difference of the slope and the carrying capacity weight, also the system being under energy recycle mode, the electric motor will turn to be a
generator, part of the kinetic energy change to electric energy, and reserve back to the battery. Therefore, continue running downhill good for extending mileage.
However, if you continue running downhill it will result in the battery being over charged, and damage the battery, when capability of battery is full. Based on
this condition, the system will automatically reduce maximum running mileage to decrease the opportunity of the battery being over charged. But the scope of
decrease depends on the loading and the slope.

11
4Other Information about the Battery
This section will show how to charge, maintain and the safety regulations of the battery use.
4.1 Using Battery Safely
Warning:
Please obey regulations contained in this manual for you and others safety and extend the battery lifetime.
Here below indicates safety regulations of battery using.
Please do not connect any two output terminal connectors of battery.
Please place it out of reach of children and pets, exposed battery and electrode may lead to a casualty.
Cell of battery contains some chemistry materials, so please open the battery and do not insert any foreign matter into the battery. It may causes shock or even a
fire and explosion.
Please charge by using the standard charger, which is offered by us.
Please obey local laws and regulations to dispose and transport of the battery.
4.2 Charging
Please charge once a month or two days after riding for maximum extended battery lifetime.
Please charge in an appropriate environment and temperature.
4.2.1 Charging Interface and Notices
Excluding shows current electric capability, electric indicator lights flashing shows continue charging (For example, 3 indicator lights is current electric

12
capability, charging shows 4 lights flashing, then 5 lights.)
Warning:
Battery maybe damaged, if it does not charge in time. As time goes by, battery capacity will run out, finally result in battery over discharged.
Please charge using the charger offered by us.
Warning:
Charging time of Surreal Scooter is approximately 1 ½ hours, electricity will auto cut when fully charged.
Normal battery lifetime is 500 times of charging, because of limit lifetime. If you have used the battery over its lifetime, you may find the riding time
shorten significantly, even it been fully charged.
Please charge battery fully, because of storage and transportation it can lead to the battery not been used for a long time, it will discharge slowly.
This battery does not need charging until discharging is complete and exhaust.
Although fully charged, mileage will shorten under frigid environment.
Please keep environment of charging tidy and dry, and do not charge if the charger terminal is wet.
Please charge and store according to the regulations, otherwise, the battery will be damaged and lifetime will influence.
Do not remove or change the structure privately.
Warning:
Ingress protection of Surreal Scooter is IP54, it means that it is spill and dust resistance. However, please do not soak in the water that will lead to
forever damage.
Do not use water cannon to wash.

13
5Maintenances
5.1 Cleaning
Steps:
Ensure power has been turned off, pull the plug and close the charger port.
Use suds or water to wipe the cover of Scooter.
Please do not let water into the charge port during cleaning process.
5.2 Storage
Please store it indoor where it is dry and a reasonable temperature. Please charge fully, and once at least every 3 months if you do not use it for a long period.

14
Warranty Card
Product
Information
Item Name：
Model：
Serial number:
User Info
Name：
Phone：
Postcode：
Address：
Information
of Distributer
Name：
Phone：
Sale Date：
Sales Address：
Maintenance Record
Submission
Date
Maintenance description
Maintenance Result
Completion
Date
Signature

FCCCaution
Thisdevice complieswithpart15 oftheFCCRules. Operation issubjecttothe
followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)
thisdevice mustacceptanyinterferencereceived, including interferencethatmay
causeundesired operation.
AnyChangesormodifications notexpresslyapprovedbythepartyresponsiblefor
compliance could void theuser's authorityto operatetheequipment.
Note: Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15 oftheFCCRules. Theselimitsare designedto
providereasonableprotection againstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesand canradiateradiofrequencyenergyand, ifnot
installedand usedinaccordancewiththeinstructions, maycauseharmfulinterference
toradiocommunications. However,there isno guaranteethatinterference will not
occurinaparticular installation. Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevision reception, whichcanbedeterminedbyturning theequipmentoff
and on, theuser isencouragedtotrytocorrecttheinterferencebyoneormore ofthe
followingmeasures:
-Reorientorrelocatethereceivingantenna.
-Increasetheseparation between theequipmentand receiver.
-Connecttheequipmentintoanoutleton acircuit differentfromthattowhichthe
receiver is connected.
-Consult thedealer oranexperienced radio/TVtechnician forhelp.
