Zhuoyi ZYT11-WK User manual

Timer Switch User Manual (ZYT11-WK)
●Be sure to read the manual carefully before using.
●Please safekeeping the manual.
I. Function and Application
groups on/off,output time reach to 168 hours
2. Ice-out when temperature below 2
3.Automatic adjust when temperature below 30 or above 60
4.LED display and DIN mounting
5.Chargeable battery
6.Overload protective device inside
. Operation instructions
1. Adjust Clock
zBefore using this product, please check the clock display to follow the current time, and
calibrate it.
zHold down the "CLOCK" key, meanwhile adjust respectively the key “HOUR”, “MINUTE”,
“WEEK” is accord with the current time.
2. Time setting
step key Setting content
①Press the key "TIMER" The first switch-on setting（display 1ON ）
②Press the key "HOUR" and
"MINUTE"
Setting switch-on time （hour, minute）
③Press the key "WEEK" Working Mode: set the switch-on working days
④Press the key "TIMER" again The first switch-off setting（display 1OFF）
⑤Press the key "HOUR" and
"MINUTE" again
Setting switch-off time （hour, minute）
⑥Press the key "WEEK" again set the switch-off working days
⑦Repeat step ①to ⑥Set other 2ON and 2OFF, 3ON and 3OFF until 16ON
and16OFF（if no, pls make it display “— — ：— —” )
⑧Press the key "CLOCK" End the timing setting and enter to the state of clock
display.
⑨Press the key "AUTO/ MANU" Adjust the switch sign “ ”to the current state ("on"
or "off"),and adjust to the state of “auto”.
Notice: ■When make an error or cancel the settings, press "RESET/RECALL "key to make it
display “— — ：— —” ( it means no timing program, not "00:00").
■Working mode: everyday cycle, MO, WEand FR; TU, THand SA; SA, SU; MO, TUand
WE; TH, FRand SA, MO., TU, WE, TH, FR; MO, TU, WE, TH, FR. and SA;
■If you set the switch-on time, you must set the switch-off time to correspond.
3. For example
Some electrical equipment needs to switch on 19:00, and switch off 08:00 next day.
A. Follow the steps ①, ②, ③, and make it display as Figure 1a;
B. Follow the steps ④, ⑤, ⑥, and make it display as Figure 1b;
C. Follow the step ⑦, and make each group 2ON and 2OFF, 3ON and 3OFF until 16ON and 16OFF
display as“— —：— —”.
D. Follow the steps ⑧, ⑨, and adjust the work mode to the state of "AUTO".

This device could be conjoin manual and automatic based on the temperature change
1. Controller will be shuted when temperature above 45,and on when below 35.
2. jin g
3. Freeze protaction function
The controller will boiler until the temperature up to 7,when detecting
Ⅳ. Dimension and installation（unit：mm）
V. Wring diagram
VI. Maintenance
■Do not use the timer on the equipments which will cause the accident to affect the safety of life
or harm to society with misoperation, such as medical equipment and large equipment, etc.
■When timer switch is used in equipments (large heater, or refrigerator, etc.) which will cause
great property damage with misoperation, make sure the features and performance values
have adequate margin. If necessary, take 2-circuit security measure and etc.
■Do not self-repair, decomposition or reconstruction the products. Please commit the repair,
inspection work to the agency or the construction enterprises.
■Do not touch the terminals after connect to the power.
■Make it work under the environment where is isolated from moisture, corrosion and high
content of metal gas. Do not make it contaminate with oil or water.
VI. Remove trouble
1. When the timer switch can not ON or OFF by auto some day, pls check the setting time on
WEEK is correct or not.
2. After make sure the setting time is correct, but it still be ON or OFF at the wrong time, pls
check other unnecessary groups and make sure them on the sate of display “— — ：— —”.
3. After be sure step 1& 2, there is still some problems on the timer switch, pls check and make
sure the mark “▼” on the “AUTO” state.
4. If there is still any problem after you check the step 1, 2 &3, you are kindly asked to get help
from our company or the agency.
