ZIGBEE ATC-3200 User manual

Model ATC-3200
Zigbee to RS232/422/485 Converter
User’s Manual
Introduction
The ATC-3200 is a cost effective and highly integrated
Serial-to-Zigbee wireless Converter. Built on ZigBee technology,
the ATC-3200 is ideal for a range of applications from simple
RS-232 cable replacement to sophisticated multi-drop RS-485
networks and everything in between. Available in
RS-232/RS-422/RS-485.
ZigBee is the global wireless language connecting dramatically
different devices to work together and enhance everyday life.
The ZigBee Alliance is a non-profit association of more than
280 member companies driving development of ZigBee
wireless technology. The Alliance promotes world-wide
adoption of ZigBee as the leading wirelessly networked,
sensing and control standard for use in energy, home,
commercial and industrial areas.
Features:
• Utilizes globally available 2.4 GHz ISM band
• Control and Configuration with UART commands.
• 65535 unique node addresses, IDs allow multiple large
networks to coexist.
• Programmable Transmit Power Output, max. 12 dBm
• Complete IEEE 802.15.4 spec compliant
• Typical Receiver Sensitivity –102 dBm
• Typical Throughput rate 250,000 bps
• Obstructed signal range to 500 meters @ 12dBm/PA and
-102dBm/LNA
• Multiple Low Power Operating modes
• 3-in-1 RS-232/422/485 interface Max.115.2Kbps Serial
interface and zigbee.
• Supports 4- and 2-wire RS-485 with AUTO-SEND™ and
built-in terminator
• Supports industrial 24 VDC power input and optional Power
over Serial
• Terminal block accessories for easy RS-422/485 serial wiring
• Easy and powerful configuration program
• Approval CE, RoHS
Hardware Description
1. RS-232 Pinout：（DB9 Male）
2. RS-422/485 Pinout：（six Terminal from left）
Terminal
No 1 2 3 4 5 6
RS-422 T+ T- R+ R- VIN GND
RS-485 485+ 485- - - VIN GND
3. Power Supply：
ATC-3200 Zigbee converter can adopt the product’s 9V power
adapter for power supply or adopt power from other DC power or
device.(+9--+24V@500-100mA)。
4. ATC-3200 LED indication：
SET Indication Zigbee Link ，yellow on Zigbee Link
established。
LINK Data Sending/Receiving between Serial and the
Zigbee
PWR Indication Power
5. Connection Diagram
RS-232 Connection
RS-422 Connection
RS-485 Connection
（DB9Male）Signal I/O
PIN2 RXD IN
PIN3 TXD OUT
PIN5 GND -

Applications
• Wireless remote control
• Building automation
• Personal area network
• Industrial control
• OEM equipment
• PC peripherals
Configuration and Operation
1. ATC-3200 default Settings
Master Com Port No: com1
Slave Com Port No: com1
Pan ID: 5152
Channel: 01-2410MHz
Baud rate: 9,600
Parity Check: Unknow
Encryption:01-Encry
Encryption Key:ffff
Check Time:Unknow
2. Configure ATC-3200
Step1. Use a connector or converter to make a connection
between the ATC-3200 and PC.
Step2. With a fine needle through the small hole next to the
power plug inside the set by holding down the switch for 5
seconds, the red light flashes. Equipment belonging to the state
can be set.
Step3. Start software QR RS232 1 to N, selected using a
computer to connect the Master module serial port
Step4. Click the “Next” button to read the ATC-3200 firmware
configuration. Select Master module parameters.
Selection is complete, click "Write To", began to set
parameters.
Step5. When the screen appears the following screen, on
behalf of parameters are set.
Step6. Click the "Setup Slave", enter the Slave matching
process.
Step7. Remove Master module, COM Port connection Slave
module.

Step8. Press the pairing button Slave module until the
matching light flashes.
Step9. Click "Next", enter the Slave matching images.
Setp10. Click the "Write To Slave", set the Slave parameters
start
Setp11. When the screen appears the following screen, on
behalf of parameters are set.
Step12. If the remaining Slave modules required settings, click
the "Other Slave". Starting from step 7 to reset.
