USB Smart Cable
User Manual
UM018112-0908

USB Smart Cable
User Manual
UM018112-0908 Revision History
ii
Revision History
Each instance in the Revision History table reflects a change to this docu-
ment from its previous revision.
Date
Revision
Level Description
Page
Number
September
2008
12 Updated Connecting to the
Target Board
6
April 2008 11 Updated USB Smart Cable
Firmware Compatibility. Updated
Installing the USB Smart Cable
and Driver
2and 3
December
2007
10 Added ZLF645, Windows Vista-
32, and USB Smart Cable
firmware compatibility
information. Put contents into the
latest template. Changed ZiLOG
to Zilog
All

USB Smart Cable
User Manual
UM018112-0908 Table of Contents
iii
Table of Contents
USB Smart Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Supported Host Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installing the USB Smart Cable and Driver . . . . . . . . . . . . . . . . . . . 3
Windows Vista-32/64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Windows 98 SE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting to the Target Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power-On Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USB Smart Cable Not Recognized . . . . . . . . . . . . . . . . . . . . . . 7
Host Does Not Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Customer Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
1
USB Smart Cable
Zilog’s USB Smart Cable, ZUSBSC0100ZACG, allows you to connect
ZLF645, Z8 Encore!®, Z8 Encore! XP®, ZNEO®, or eZ80Acclaim!®
development board to a high-speed or full-speed USB port on Zilog
Developer Studio II (ZDS II) host system.
This user manual provides instructions for installing USB Smart Cable
hardware and the associated drivers. When the USB Smart Cable is con-
nected and the driver installed, you can proceed with debugging as
described in the development kit documentation.
Kit Contents
The kit contents for the USB Smart Cable include:
• USB Smart Cable
• Six-conductor ribbon cable
• User manual
Supported Host Environments
The supported host environments are:
• A host PC with ZDS II v4.9.0 or later version for Z8 Encore! and
eZ80Acclaim!, or ZDS II v4.10.0 for ZNEO, or ZDS II v4.11.0 for
ZLF645. For ZDS II host system requirements refer to the develop-
ment kit quick start guide.
• One USB high-speed or full-speed port on the host chassis or a pow-
ered Hub.

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
2
The USB Smart Cable cannot operate properly on an unpowered Hub
(that is, a Hub without a separate AC adapter).
Windows NT hosts are not supported by the USB Smart Cable.
Table 1. Supported Target Environments
Table 2. USB Smart Cable Firmware Compatibility
Development
Board
System Clock Power Supply Current
Minimum Maximum Minimum Maximum
Z8 Encore!®,
Z8 Encore! XP®,
ZLF645
32 kHz 20 MHz 2.7 V 3.6 V 2 mA
ZNEO®10 kHz 20 MHz 2.7 V 3.6 V 2 mA
eZ80Acclaim!®5 MHz 50 MHz 3.0 V 3.6 V 2 mA
CPU Family Firmware
Z8 Encore!®, Z8 Encore! XP®, ZNEO®, eZ80Acclaim!®1.6
ZLF645 1.7
Z8 Encore!®, Z8 Encore! XP®, ZNEO®, eZ80Acclaim!®,
ZLF645
1.8
Note:

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
3
Installing the USB Smart Cable and Driver
Before connecting the USB Smart Cable to your system, Windows loads
the appropriate driver from the ZDS II installation directory or CD-ROM.
You can download ZDS II software for a specific device family at
www.zilog.com. Alternatively, if you have an applicable Zilog develop-
ment tool, use the CD-ROM provided. The installation procedure depends
on your Windows operating system version.
Zilog no longer includes CD-ROMs with USB Smart Cable kits
built August 2006 or later.
Windows Vista-32/64
1. Connect the USB Smart Cable to the host PC. The Found New
Hardware dialog box is displayed.
2. Select Locate and install driver software (Recommended). The
Driver Software Installation window is displayed, and then the
Found New Hardware-USB Smart Cable dialog box is displayed.
3. Select I don’t have the disc. Show me other options.
4. Select Browse my computer for driver software (Advanced).
5. Browse to one of the following driver directory:
For 32-bit Vista:
<ZDS II Installation Directory>
\device drivers\USB\x32
<ZDS II Installation CD>\device drivers\USB\x32
For 64-bit Vista:
<ZDS II Installation Directory>
\device drivers\USB\x64
<ZDS II Installation CD>\device drivers\USB\x64
Note:

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
4
The Windows Security dialog box is displayed.
6. Select Install this driver software anyway.
7. When the software has been installed, click Closed.
Windows XP
1. Connect the USB Smart Cable to the host PC for the first time. The
Found New Hardware Wizard should activate automatically.
2. In the Wizard, select Install from a list or specific location
(Advanced); then click Next.
If the Windows Logo testing dialog appears, select Continue
Anyway.
3. Select Search for the best driver in these locations and Include this
location in search.
4. Browse one of the following to the driver directory:
<ZDS II Installation Directory>
\device drivers\USB\x32
<ZDS II Installation CD>\Device Drivers\USB\x32
5. Click Next, and then click Next again after the appropriate driver is
found.
6. Click Finish to complete the installation.
Windows 2000
1. Connect the USB Smart Cable to the host PC for the first time. The
Found New Hardware Wizard should activate automatically.
2. In the Wizard, click Next.
3. Select Search for a suitable driver for my device (Recommended);
then click Next.
Note:

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
5
4. Select Specify a location; then click Next.
5. Browse to one of the following driver directory:
<ZDS II Installation Directory>
\device drivers\USB\x32
<ZDS II Installation CD>\Device Drivers\USB\x32
6. Click OK, and then click Next after the appropriate driver is found.
7. Click Finish to complete the installation.
Windows 98 SE
1. Connect the USB Smart Cable to the host PC. The Found New Hard-
ware Wizard should activate automatically.
2. In the Found New Hardware Wizard, click Next.
3. Select Search for the best driver for your device (Recommended).
Click Next.
4. Select Specify a location. Browse one of the following to the driver
directory:
<ZDS II Installation Directory>
\device drivers\USB\x32
<ZDS II Installation CD>\Device Drivers\USB\x32
5. Click Next, and then click Next again after the appropriate driver is
found.
6. Click Finish to complete the installation.

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
6
Connecting to the Target Board
Power-On Sequence
Follow the steps below before connecting to target:
1. Connect the USB Smart Cable to the Host PC.
2. Connect the USB Smart Cable six-pin connector to the target board.
3. Apply power to the target board.
If the target is not connected properly, remove the USB Smart Cable from
the host PC and repeat the above steps. If the connection issues are still
there, see Troubleshooting Tips on page 7.
Attach one end of the six-conductor ribbon cable to the Smart Cable six-
pin DBG connector (see Figure 1). Attach the free end of the ribbon cable
to the connector on the target board. Ensure that pin 1 on the ribbon cable
(indicated by the dark stripe) is aligned with pin 1 on the target connector.
For further information on connecting the USB Smart Cable to your target
board, refer to either eZ80Acclaim! Design for Debug Technical Note
(TN0035) or Z8 Encore!®Design for Debug Technical Note (TN0036).
Figure 1. Connecting the Six-Conductor Ribbon Cable to the USB Smart Cable

USB Smart Cable
User Manual
UM018112-0908 USB Smart Cable
7
Troubleshooting Tips
If a hardware failure is suspected, contact a local Zilog representative for
assistance. Before submitting a problem report to Zilog Customer Sup-
port, follow the instructions in this section.
USB Smart Cable Not Recognized
Disconnect all other USB devices (including keyboard and mouse if you
can use PS2 ports instead). Ensure that USB Smart Cable is plugged in
directly with no intervening Hub. If this corrects the issue, reconnect
devices one at a time to isolate the conflicting device.
Host Does Not Boot
Systems with one or more USB devices connected may not boot properly
after you connect the USB Smart Cable. This issue is being investigated.
The workaround is to connect the USB Smart Cable, after the system
starts.

USB Smart Cable
User Manual
UM018112-0908
8
Customer Support
For answers to technical questions about the product, documentation, or
any other issues with Zilog’s offerings, visit Zilog’s Knowledge Base at
http://www.zilog.com/kb.
For any comments, detail technical questions, or reporting problems, visit
Zilog’s Technical Support at http://support.zilog.com.
