Zip SEE040 User manual

Quick Start Guide - qSEE040 Copyright 2021 System Q Ltd
1
RoomWatch Camera - 2 Way Audio & PIR
Zip is a registered trademark of System Q Ltd
SEE040 - Quick Start Guide
www.systemq.com/PDF
/manual/xSEE040.pdf
The SEE040 RoomWatch camera can used standalone with the ZipVision Pro app, ZipVision Windows
Client Software or with a ZIP NVR or DVR. With built in audio and PIR, plus PoE, H265 and H264 codec.
Powering the camera
The camera takes approximately 2 minutes to
boot.
Option 1 - Power the camera from 12V DC (via the
2.1mm DC Socket), the current consumption is
300mA.
The camera is polarity sensitive so connections
must be made correctly.
Option 2 - Power the camera using a PoE 48V RJ45 Socket. When connecting to a ZIP PoE NVR plug the
camera directly into the NVRs built in PoE switch.
Default login details are:-
Default IP
192.168.10.1
User Name
admin
Password
777777

Quick Start Guide - qSEE040 Copyright 2021 System Q Ltd
2This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
RoomWatch Camera - 2 Way Audio & PIR
Zip is a registered trademark of System Q Ltd
All specifications are approximate. System Q Ltd reserves the right to change product specificationsor features without notice. Whilst every effort is
made to ensure that these instructions are complete andaccurate, System Q Ltd cannot be held responsible for any losses,no matter how they arise,
from errorsor omissionsin these instructions,or the performance or non-performance of the equipment refered to.
Wireless to Router
1. Go to the ZipVision Pro App > Menu > Device List > Add >
RoomWatch
2. Scan the QR Code on the Base of the RoomWatch
3. The camera should already have power connected, if not
then connect power now (the camera takes approximately 2
minutes to boot)
4. Enter the Wi-Fi connection details
5. Select the RoomWatch camera that you wish to add to
your network
6. Enter Default login details for the camera - User Name
7. Wait for the WiFi connection to the camera
8. Enter new password for security
9. Once complete, "connected" will show in Device Manager
Adding to a ZIP NVR / DVR
If adding the camera to a ZIP NVR /
DVR using a separate PoE switch or
via WiFi, the camera needs to be
manually added, scan the QR code
below for the "how to guide"
www.zipdvr.com/howto/TIP459
-How-To-Add-IP-Cameras.html
Resetting to Default
The camera has a default button on
the back (recessed in).
Press and hold for 10 seconds to
default.
Searching via Windows PC
Use the ZipFinder tool to search for ZIP IP cameras on a network via a Windows PC.
www.softcctv.com/store/Item/Zip-Finder-IP-CCTV-Security-Camera-Discovery-Tool
Image Sensor
1/ 2.7” Progressive CMOS
Viewing Angle
103 Degrees
Resolution
HD 1080P, 1.3MP (960H) & 720P @ 25fps
Lens Type
2.8mm Fixed Lens
Shutter
1/5 ~ 1/20000s
Video Compression
H265 / H264
Onvif
2.6
WiFi Frequency
2.4GHz
WiFi Range
10m
Bit Rate
8K ~ 8Mbps
Audio
2-Way Built-in
Memory Card Slot
Micro SD (128GB Max)
Day/Night Function
Mechanical (True Day/Night)
Backlight Control
BLC / DWDR
Voltage
12V DC or PoE (PSU Required)
Current Consumption
280mA (IR On) / 150mA (IR Off)
Power Connection
2.1mm DC Socket (12V) or RJ45 (PoE )
Operating Temperature
From -10 to 45 deg C
Use
Internal
Bracket
Supplied
Dimensions
(H)106mm x (W)63mm x (D)34mm
