Zip SEE898 User manual

© 2022 System Q Ltd
SEE898
8MP Eyeball 2.8-12mm Motorised Lens
Camera
Instruction Manual
ZipDVR.com

xSEE898
I
© 2022 System Q Ltd
ZipDVR.com
Table of Contents
Part 1 Introduction 1
1 SEE898 ............................................................................................................................ 1
Part 2 Tools & Handy Extras 1
Part 3 Connections & Dipswitches 2
Part 4 Dipswitch 4-In-1 Technology 2
Part 5 Mounting 3
1 Eyeball ........................................................................................................................... 3
Part 6 Motorised Lens 4
Part 7 OSD Menu 5
1 8MP OSD Menu Motorised .............................................................................................. 5
2 Key Menu Settings .......................................................................................................... 8
Part 8 Troubleshooting 9
1 Camera Rebooting / Turning Off ..................................................................................... 9
2 Poor Quality Images ....................................................................................................... 9
3 Image isBlack & White .................................................................................................. 9
4 NCD / No Image Displayed on Recorder ......................................................................... 9
Part 9 General Maintenance 10
Part 10 Specification 11
1 SEE898 .......................................................................................................................... 11
Part 11 Conditions 12
1 General Company Disclaimer ....................................................................................... 12
2 WEEE Declaration ......................................................................................................... 12
3 Copyright ...................................................................................................................... 12
Index 13

© 2022 System Q Ltd
1
Index
ZipDVR.com
Introduction
1.1 SEE898
The SEE898 has a motorised lens so that you canset the zoomand focus fromthe DVR. With
4-in-1 technology design means you can set the output signalto either TVI, CVI, AHD or
CVBS.
Built in twin IR arrays provide 40mof night time vision to get 24/7 performance on these new
eyeballs.
This 4K modelalso described as 8MP offers stunning Ultra-HD quality. Designed to be used
with a 4K DVR such as the new Zip Xtreme.
Tools & Handy Extras
Screwdriver
Drill
12V DC PSU
Drillbits
BNC Crimp Tool& BNCs
RG59 Coax Cable
DigitalMulti-Meter
LCD400K - CCTV Test monitor

04/04/2022
2
xSEE898
ZipDVR.com
Connections & Dipswitches
The camera has a 2.1mmsocket which requires 12V DC, use a regulated power supply rated
above the current draw of the camera.
The camera is polarity sensitive so connections must be correctly made.
The camera has a standard BNC connector for the 4-in-1 video output, the output can be
changed to AHD, CVI or CVBS ifrequired.
Dipswitch 4-In-1 Technology
Selectable HD-TVI, HD-CVI, AHD and CVBS (Analogue) Output. As default the camera is
set to HD-TVI, however the output canbe changed to AHD, CVI or CVBS ifrequired.
This output can be changed withthe dip switches on the fly-lead ofthe camera. Please note the
“Output Mode”in the menu of the DVR won’t change the format, as the dip switchoverrides the
output.
The dip switch configuration can be found below:-

© 2022 System Q Ltd
3
Index
ZipDVR.com
Mounting
5.1 Eyeball
A template is provided in the box for marking the hole positions for the fixing screws.

04/04/2022
4
xSEE898
ZipDVR.com
Motorised Lens
To access the Motorised Lens via coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ buttonat the bottomofthe screen
3. Use Zoom+ and - to zoomin and out, the camera should automatically focus when Zoom+/-
is released

© 2022 System Q Ltd
5
Index
ZipDVR.com
OSD Menu
Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as
default.
To access the Cameras Menu via coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ buttonat the bottomofthe screen
3. Click on the IRIS + / centre button to display the menu
Use the directionalarrows to move up and
down through the menu.
Use the directionalarrows left and right to
change the option.
Use IRIS + to select & enter that menu option.
7.1 8MP OSD Menu Motorised
AE
BRIGHTNESS
0 ~ 100 (Default 41)
EXPOSURE MODE
GLOBAL /
BLC
0 ~ 7 (Default 4)
RETURN

04/04/2022
6
xSEE898
ZipDVR.com
AF
AF MODE
SEMI / AUTO / MANUAL
ZOOM
- / +
FOCUS
- / +
BOOT MODE
SAVE POS / WIDE END / TELE END /
TDN AD
OPEN / CLOSE
FOCUS TRIGGER
SELECT (IRIS +)
LENS INIT
SELECT (IRIS +)
RETURN
AWB
MODE
PRO / GREY WORLD
RGAIN
0 ~ 100 (Default 44)
BGAIN
0 ~ 100 (Default 50)
DAY / NIGHT
MODE
EXT / COLOR / B/W
RETURN
IMAGE ENHANCE
CONTRAST
AUTO /
MANUAL
0 ~ 20 (Default 5)
SHARPNESS
AUTO /
MANUAL
0 ~ 20 (Default 3)
SATURATE
AUTO /
MANUAL
0 ~ 20 (Default 2)
3DNR
AUTO /
MANUAL
0 ~ 20 (Default 13)
2DNR
AUTO /
MANUAL
0 ~ 20 (Default 19)
FLIP
OFF / ON
MIRROR
OFF / ON
RETURN

© 2022 System Q Ltd
7
Index
ZipDVR.com
VIDEO SETTING
HD
NO ADJUSTMENT SEE 4-IN-1 SWITCH
STANDARD
8MP 15 / 8MP 12.5
REBOOT & APPLY
RETURN
LANGUAGE
ENGLISH / SIMPLIFIED CHINESE / TRADITIONAL CHINESE /
RUSSIAN / SPANISH / FRENCH / POLISH / ITALIAN /
PORTUGUESE
WDR
OFF / ON
FUNC
PRIVACY
MODE
OFF / ON
AREA 0
CUSTOMISE
AREA 1
CUSTOMISE
AREA 2
CUSTOMISE
AREA 3
CUSTOMISE
COLOR
RED / GREEN / BLUE
TRANSPARENCY
OFF / ON
RETURN
RETURN
RESET
SAVE – EXIT
EXIT

04/04/2022
8
xSEE898
ZipDVR.com
7.2 Key Menu Settings
Exposure Mode - AUTO / GLOBE / GLOBAL sets the required shutter speed for the current
light level. The shutter speed willautomatically detect the required length of time to keep the
digitalsensor exposed to light. FLK option sets the shutter speed to stop synchronisationwith
lighting so that pulsing effect is minimised.
White Balance - Colour adjustment ofthe camera to be set up so objects appear a natural
colour. ATW / PRO (Automatic tracking white balance) continually tracks and adjusts the white
balance, making it suitable for use in cameras in which the image content and lighting are subject
to changes.
Day & Night - The camera canbe set to colour or B&W mode or have it automatically switch
Externalis set as default, the switch betweencolour and black & white is controlled by an
externaltrigger In this a light dependent resistor.
DNR (Noice Reduction) - Noise Reduction is the process ofremoving noise fromthe video
signalby applying a digitalfilter. 2D noise reduction reduces noise in the foreground of the image
where as 3D noise reduction reduces noise in boththe foreground and the background ofthe
image.
D-WDR - Digitally adjusts the exposure in areas of the frame to maintain optimumlevels in both
the dark and bright areas ofanimage.
NOTE - Some models may not have D-WDR function.
Reset - Defaults the camera to factory settings. This setting helps when fault finding issues with
the camera to ensure allsettings are defaulted.

© 2022 System Q Ltd
9
Index
ZipDVR.com
Troubleshooting
8.1 Camera Rebooting / Turning Off
A. Check the voltage to the camera (under load) using a digitalmulti-meter, ifbelow 10.8V then
move the power supply closer to the camera.
B. For 12V DC cameras, only use regulated power supply rated above the current consumption,
so that the camera is always receiving the correct supply which is rated above the current
consumption.
C. Use thicker gauge copper cabling to reduce the voltage drop to the camera, using thicker
cable willreduce the resistance between the camera and the power supply and therefore reduce
the voltage dropped alongthe cable.
8.2 Poor Quality Images
A. Check the video format the DVR (digitalvideo recorder), thenset the camera to the relevant
video format – see the 4-In-1 Technology
B. Ifset to CVBS, thenthis is a low qualityvideo output for legacy systems (analogue - CVBS),
when usinga 2 MegaPixelDVR or above then use another video format, like HD-TVI.
C. Reset the camera menuvia Zip Coaxitron– OSD Menu
D. Check if the DVR (digitalvideo recorder) supports the resolution ofthe camera.
8.3 Image is Black & White
A. Check the video format your DVR supports, thenset the camera to the relevant video format
– see the 4-In-1 Technology
B. Reset the camera menuvia Zip CoaxitronOSD Menu
D. Check if the DVR (digitalvideo recorder) supports the resolution ofthe camera.
8.4 NCD / No Image Displayed on Recorder
A. Check the voltage to the camera (under load) using a digitalmulti-meter, ifbelow 10.8V then
move the power supply closer to the camera.
B. For 12V DC cameras, only use regulated power supply rated above the current consumption,
so that the camera is always receiving the correct supply which is rated above the current
consumption.
5
5

04/04/2022
10
xSEE898
ZipDVR.com
C. Use thicker gauge copper cabling to reduce the voltage drop to the camera, using thicker
cable willreduce the resistance between the camera and the power supply and therefore reduce
the voltage dropped alongthe cable.
D. Ensure that the BNC – BNC lead that is connected between the camera and DVR has no
shorts between the ground and the centre core (positive) or open circuits along the centre core
(positive) or open circuits along the ground.
General Maintenance
Routinely cleanthe camera to prevent dust build up as this can effect the performance ofthe
camera. It is recommended to use a damp non-abrasive microfibre cloth.
Routinely check the connections for power and data to ensure no water ingress and corrosion.
Check that the cameras are firmly attached to the wallor mounting bracket.
Check playback in the recorder to ensure the camera is recording and triggeringproperly.

© 2022 System Q Ltd
11
Index
ZipDVR.com
Specification
10.1 SEE898
Resolution
4K (8MP)
Lens Type
2.8-12mmMotorised
Image Output
1 Volt Peak-Peak 75 ohm
Min.Illumination
0 Lux IR On
Day/Night
Mechanical(True Day-Night)
IR Range
40m
Input Voltage
12V DC
Current Consumption
500mA (IR On)
IP Rating
IP66
Video Connection
BNC Socket
Power Connection
2.1mmDC Socket
Finish
White/ Grey
Build
Metal
Dimensions
135mm(Diameter) x127mm(Height)

04/04/2022
12
xSEE898
ZipDVR.com
Conditions
11.1 General Company Disclaimer
All specifications are approximate. System Q Ltd reserves the right to change any product
specifications or features without notice. Whilst every effort is made to ensure that these
instructions are complete and accurate, System Q Ltd cannot be held responsible in any
way for any losses, no matter how they arise, from errors or omissions in these
instructions, or the performance or non-performance of the equipment that these
instructions refer to.
11.2 WEEE Declaration
This symbol on the products and/or accompanying documents means that used electronic
equipment must not be mixed with general household waste. For treatment, recovery and
recycling please return this unit to your trade supplier or local designated WEE/CG0783SS
collection point as defined by your local council.
11.3 Copyright
© Copyright 2022
Zip is a registered trademark of SystemQ Ltd, Chesterfield. Derbyshire. S40 2WB
