Zip SEE608 User manual

Mini Eyeball 3.6mm 8MP (4K)
SEE608
ZipDVR.com
© 2021 System Q Ltd

ZIP TVI Camera Range
I
© 2021 System Q Ltd
ZipNVR.com
Table of Contents
Part 1 Introduction 1
1 SEE608 ............................................................................................................................ 1
Part 2 Tools & Handy Extras 1
Part 3 Connections 2
Part 4 4-In-1 Technology 3
Part 5 Mounting 3
1 All-in-one ........................................................................................................................ 3
Part 6 OSD Menu 4
1 8MP OSD Menu ............................................................................................................... 4
2 Key Menu Settings.......................................................................................................... 6
Part 7 Troubleshooting 7
1 Camera Rebooting / Turning Off ..................................................................................... 7
2 Poor Quality Images ....................................................................................................... 7
3 Image isBlack & White .................................................................................................. 7
4 NCD / No Image Displayed on Recorder ......................................................................... 7
Part 8 General Maintenance 8
Part 9 Specification 8
1 SEE608 ............................................................................................................................ 8
Part 10 Conditions 9
1 General Company Disclaimer ......................................................................................... 9
2 WEEE Declaration ........................................................................................................... 9
3 Copyright ........................................................................................................................ 9
Index 10

Introduction
1
© 2021 System Q Ltd
ZipNVR.com
1 Introduction
1.1 SEE608
Long range IR reach ofup to 60M and a 2.8-12mmvarifocallens make this a great choice for
covering larger areas with CCTV. Use it on a 12mm setting to capture vehicles entering a
gateway even in low light when the high powered IR beamkicks into action. The motorised lens
option can even make use of an alarm trigger such as a break beamto capture this and
automatically emailit to you.
The mechanicalday-night filter retracts at night to let the camera see to its best levels whilst it
moves back during the day to give great colour reproduction that isn’t overwhelmed by the IR
rays ofthe sun.
4K Resolution - Also described as 8MP offers superb qualityimages that’s idealifyour footage
might end up in court as evidence. Good choice ifyou’re fittinga 4K DVR such as the new Zip
Xtreme DVR.
2 Tools & Handy Extras
· Screwdriver
· Drill
· Hammer
· POW151 - 12V DC 500mA Plug-in PSU
· Drillbits
· BNC Crimp Tool& BNCs
· RG59 Coax Cable
· DigitalMulti-Meter
· LCD400K - CCTV Test monitor

ZIP TVI Camera Range
2
© 2021 System Q Ltd
ZipNVR.com
3 Connections
The camera is provided with a fly lead with a 2.1mm DC socket and standard BNC connector
It is recommended to use a power supply that is rated higher than the current consumption of the
camera
The camera is polarity sensitive so connections must be made correctly

4-In-1 Technology
3
© 2021 System Q Ltd
ZipNVR.com
4 4-In-1 Technology
Selectable HD-TVI, HD-CVI, AHD and CVBS (Analogue) Output. The default is set to HD-
TVI however the output canbe changed to AHD, CVI or CVBS ifrequired.
This output can be changed either with the dip switches onthe fly-lead ofthe camera. Please
note the “Output Mode” in the menuof the DVR won’t change the format, as the dip switch
overrides the output.
The dip switch configuration can be found below:-
5 Mounting
5.1 All-in-one

ZIP TVI Camera Range
4
© 2021 System Q Ltd
ZipNVR.com
6 OSD Menu
Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as
default.
To access the Cameras Menu via coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ button at the bottomofthe screen
3. Click on the IRIS + button to display the menu
Use the directionalarrows to move up and
down through the menu.
Use the directionalarrows left and right to
change the option.
Use IRIS + to select & enter that menu option.
6.1 8MP OSD Menu
LENS
MANUAL(No Adjustment)
EXPOSURE
SHUTTER
AUTO / FLK
AGC
0 ~ 15 (Default 12)
BRIGHTNESS
0 ~ 100 (Default 40)
D-WDR
OFF/ AUTO
BACKLIGHT
OFF/ BLC
BLC
LEVEL
LOW / MIDDLE/
HIGH
AREA
POSITION & SIZE
DEFAULT
(Defaults the above)
RETURN / SAVE& END
RETURN / SAVE& END
WHITEBAL
ATW
AWC SET
(Sets Automatic White Balance Control)
DAY& NIGHT
EXT
D – N (DELAY)
0 ~ 15 (Default 0)
N – D (DELAY)
0 ~ 15 (Default 2)
RETURN / SAVE& END
AUTO
D – N (AGC)
0 ~ 216 (Default 220)
D – N (DELAY)
0 ~ 15 (Default 0)

OSD Menu
5
© 2021 System Q Ltd
ZipNVR.com
N – D (AGC)
0 ~ 215 (Default 25)
N – D (DELAY)
0 ~ 15 (Default 2)
RETURN / SAVE& END
COLOR (Permanently in colour)
B/W
IRSMART
ON / OFF
LEVEL
0 ~ 15 (Default 0)
AREA
POSITION & SIZE
RETURN
IRPWN
0 ~ 100 (Default 100)
RETURN / SAVE& END
ADJUS
NR
2 DNR
LOW / MIDDLE/ HIGH / OFF
3 DNR
LOW / MIDDLE/ HIGH/ OFF
RETURN / SAVE& END
SHARPNESS
LOW / MIDDLE/ HIGH
COLOR GAIN
BLUEGAIN
0 ~ 10 (Default 6)
RED GAIN
0 ~ 10 (Default 6)
RETURN / SAVE& END
LSC
ON / OFF
MIRROR
OFF/ MIRROR / V-FLIP / ROTATE
DPC
LIVEDPC
ON / OFF
RETURN / SAVE& END
LANGUAGE
ENG/ CHN 1 / CHN 2 / GER/ FRA / ITA / SPA / POL/ RUS / POR/
NED / TUR/ JPN
OUTPUT MODE
FORMAT***
THD / CVBS / AHD / CHD
RESOLUTION
8 MEGA
FRAMERATE
NRT
VIDEO. OUT
NTSC / PAL
APPLYSET
RETURN / SAVE
RETURN / SAVE& END
Exit
SAVE& END
RESET
NOT SAVE

ZIP TVI Camera Range
6
© 2021 System Q Ltd
ZipNVR.com
6.2 Key Menu Settings
Exposure Mode - AUTO sets the required shutter speed for the current light level. The shutter
speed willautomatically detect the required length oftime to keep the digitalsensor exposed to
light. FLK option sets the shutter speed to stop synchronisation with lighting so that pulsing effect
is minimised.
White Balance - Colour adjustment ofthe camera to be set up so objects appear a natural
colour. ATW (Automatic tracking white balance) continually tracks and adjusts the white
balance, making it suitable for use in cameras in which the image content and lighting are subject
to changes.
Day & Night - The camera can be set to colour or B&W mode or have it automatically switch
Externalis set as default, the switch between colour and black & white is controlled byan
external trigger In this a light dependent resistor. Delay can be set which willinstruct the camera
to wait for a set length of time before switching. This accommodates for any temporary drops in
light
DNR (Noice Reduction) - Noise Reductionis the process ofremovingnoise fromthe video
signalby applying a digitalfilter. 2D noise reduction reduces noise in the foreground ofthe image
where as 3D noise reduction reduces noise in both the foreground and the background ofthe
image.
D-WDR - Digitally adjusts the exposure in areas of the frame to maintain optimumlevels in both
the dark and bright areas ofanimage.
Reset - Defaults the camera to factory settings. This setting helps when fault finding issues with
the camera to ensure allsettings are defaulted.

Troubleshooting
7
© 2021 System Q Ltd
ZipNVR.com
7 Troubleshooting
7.1 Camera Rebooting / Turning Off
A. Check the voltage ofthe camera (under load) ifbelow 10.8V then move the power supply
closer to the camera.
B. For 12V DC cameras only ever use regulated power supply rated at above 750mA, 1A
would be recommended. So that the camera is always receiving the correct supply.
C. Use thicker gauge copper cabling to reduce the voltage drop.
7.2 Poor Quality Images
A. Check the fly-lead is set to the correct output – see 4-In-1 Technology
B. Ifset to CVBS, then this is a low qualityvideo output for legacy systems (Analogue), when
using a 2 MegaPixelDVR or above then use another video format, like HD-TVI.
C. Reset the camera menuvia Zip Coaxitron – OSD Menu
D. Check ifyour recorder supports the resolution of the camera.
7.3 Image is Black & White
A. Check the video format your DVR supports, thenset the camera to the relevant video format
– see the 4-In-1 Technology
B. Reset the camera menu via Zip Coaxitron OSD Menu
C. Check the recorder supports the resolution ofthe camera.
7.4 NCD / No Image Displayed on Recorder
A. Test that the camera has the correct voltage supplyingit, this must be done with the camera
connected so that there is load onthe PSU. A 12V DC camera should have at least 10.5V DC
connected to it.
B. The camera cannot functionwithout the correct power supply. For 12V DC cameras only
ever use regulated power supplies to ensure that the camera is always receivingthe correct
voltage.
C. Ensure that the BNC – BNC lead that is connected betweenthe camera and DVR has no
shorts or open circuits.
3
4
3
4

ZIP TVI Camera Range
8
© 2021 System Q Ltd
ZipNVR.com
8 General Maintenance
· Ensure that nothingis obscuringthe field of view, position the camera to ensure the Lens can
see clearly.
· Routinely cleanthe camera to prevent dust build up as this caneffect the performance ofthe
camera. We recommend a damp non-abrasive microfibre cloth.
· Check that the cameras are firmly attached.
· Check playback in the recorder to ensure the camera is recording properly.
9 Specification
9.1 SEE608
Resolution
4K (8MP)
Lens Type
2.8-12mmVarifocal
Image Output
1 Volt Peak-Peak 75 ohm
Min.Illumination
0 Lux IR On
Day/Night
Mechanical(True Day-Night)
InfraRed LEDs
2 High Powered LEDs
IR Range
60M
Input Voltage
12V DC
Current Consumption
500mA (IR On)
IP Rating
IP66
Video Connection
BNC Socket
Power Connection
2.1mmDC Socket
WDR
Yes
Bracket
Wall& Ceiling Available
Finish
White/ Black
Build
Metal
Dimensions
(H)88.5mmx (W)88mmx (D)141mm(ex bracket)

Conditions
9
© 2021 System Q Ltd
ZipNVR.com
10 Conditions
10.1 General Company Disclaimer
All specifications are approximate. System Q Ltd reserves the right to change any product
specifications or features without notice. Whilst every effort is made to ensure that these
instructions are complete and accurate, System Q Ltd cannot be held responsible in any
way for any losses, no matter how they arise, from errors or omissions in these
instructions, or the performance or non-performance of the equipment that these
instructions refer to.
10.2 WEEE Declaration
This symbol on the products and/or accompanying documents means that used electronic
equipment must not be mixed with general household waste. For treatment, recovery and
recycling please return this unit to your trade supplier or local designated WEE/CG0783SS
collection point as defined by your local council.
10.3 Copyright
© Copyright 2021
Zip is a registered trademark of SystemQ Ltd, Chesterfield. Derbyshire. S40 2WB
