Zip DEX Mounting instructions
Zip InLine
Electronically Controlled Instantaneous
Water Heaters
Models: DEX & DBX
Issued August 2014
Installation, Maintenance and User Instructions
Please read these instructions carefully before commencing installation of the InLine water heater.
Please leave these instructions with the end user after installation.
Zip Heaters (UK) Ltd
14 Bertie Ward Way
Dereham
Norfolk
NR19 1TE
Telephone: 0845 6 005 005
Mobile: 0345 6 005 005
Fax: 01362 692448
Web: www.zipheaters.co.uk
The terms ‘Zip’ and ‘InLine’
are registered trademarks
9120-34136 August 2014 V1.05
Description 1
Approvals 1
Safety information 2
WARNING 2
CAUTION 3
Dimensions 3
Technical Data 4
Spare parts 5
Installation
Requirements 6
Installation site 6
Installing the wall bracket 7
Installing the connection pieces 7
Installing the appliance 8
Surface mounted installation 9
Electrical connection 9
Load shedding relay (DEX) 10
Electrical connection from below 10
Electrical connection from above 11
Commissioning 11
Maintenance and cleaning 13
Operation (Model DEX only) 14
Fault nding 16
Warranty 17
Contents
Please read these instructions carefully before commencing installation of the
DEX - DBX Electronically controlled Instantaneous Water Heaters.
Please leave these instructions with the end user after installation.
To ensure you have the latest revision of this instruction manual, please visit
www.zipheaters.co.uk to download the latest copy.
In order to preserve our environment we ask that you dispose of this product
correctly. Please contact Zip Customer Service for advice on 0845 6 005 005 or
0345 6 005 005.
August / 2014 Page 1 DEX & DBX Installation, Maintenance and User Instructions V1.05
Description
Zip InLine DEX and DBX instantaneous water heaters are micro-processor controlled, pressure
resistant water heaters suitable for supplying hot water to one or more outlets.
The heating element switches on automatically when the hot water tap is opened and
switches off automatically when the hot water tap is closed.
The electronic control system automatically regulates the power consumption
temperature within the power limit of the appliance.
Power consumption is also regulated based on outlet temperature to ensure the required
water pressure.
For DEX the required outlet temperature can be entered on a keypad within the range 20°C to
60°C (DEX12 range is 20°C to 55°C) and can be read off the digital display.
For type DBX the factory set outlet temperature is 50°C and can be adjusted inside the appliance
within the range 30°C to 60°C.
For DEX (*excluding DEX12) a maximum inlet temperature of 70°C is suitable for use with
preheated water from solar heating systems.
*For DEX12 the maximum inlet temperature is 25°C.
Approvals
Zip InLine DEX and DBX are VDE approved to the LVD and EMC directives and are CE endorsed.
comply with the requirements of the United Kingdom Water Regulations / Byelaws (Scotland).
The products are listed under the WRAS (Water Regulations Advisory Scheme) Water Fittings
and Materials Directory.
WARNING: Situations that could cause injury to yourself or others.
CAUTION: Situations that could cause damage to your appliance or other equipment.
NOTE: Notes, usage tips or additional information.
IMPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY.
NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS PRODUCT
CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY.
RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 2 August / 2014
Safety Information
WARNING
• Installation, commissioning and maintenance of this appliance must only be carried
out by a competent installer who will then be responsible for adhering to all relevant
standards and regulations.
• The front cover of the appliance must never be opened before disconnecting the appliance
from the mains power supply.
•
nominal current of the appliance.
• The appliance must be permanently connected to the supply through an isolating switch with a
contact separation of at least 3mm in all poles and be protected by a suitably rated RCD.
• The cross sectional area of the connection cable must be appropriate for the power rating and
location of the appliance. See Technical Data.
• The connecting cable must be adequately secured.
• This appliance must be earthed at all times.
• Check that the power supply is switched off prior to electrical connection.
•
• In case of malfunction isolate the power supply immediately. In case of leaks also isolate the
water supply. Repairs must only be carried out by Zip Heaters (UK) Ltd or an authorised Zip
service engineer.
• Temperatures in excess of approximately 43°C are perceived as hot, especially by children, and
may cause a feeling of burning.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning the use of the appliance in a safe way
and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
•
• If inlet temperature is up to 70°C (eg. fed from a solar supply) mixing with cold water will be
required to ensure a safe temperature at the outlet.
August / 2014 Page 3 DEX & DBX Installation, Maintenance and User Instructions V1.05
•
appliance must not be subjected to pressure exceeding 1.0 MPa (10 bar).
• The appliance must only be used when correctly installed and in perfect working order.
• The appliance must be installed in a frost-free room and must never be exposed to frost.
• The DEX and DBX range is not intended for use with thermostatic mixing valves or taps.
•
•
work on the plumbing system or maintenance), the appliance must be vented by opening
and closing the hot water tap until all air has been eliminated from the water heater and
no more air emerges before re-connecting to the electrical supply.
•
must not fall below the required value indicated on the rating plate. The appliance must
not be used for any other purpose.
• Incoming water temperature must not exceed that stated in Technical data.
• The Zip InLine is intended for connection to mains supply only. In any other case please
contact Zip on 0845 6 005 005 or 0345 6 005 005 for advice.
• Zip Heaters (UK) Ltd cannot be held liable for any damages caused by failure to
observe these instructions.
CAUTION
Dimensions
231
170
466
56
100
32 1
363
97
231
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 4 August / 2014
Model
DEX(1)
DEX12(1) DBX18 DBX21 DBX24 DBX27
Nominal supply voltage 1/N/PE 230V~ 3/PE 380-400V~ 3/PE 400V~
Power Rating (kW) 8.8 / 11.0(1) 18.0 21.0 24.0 27.0
Rated Current (A) 38 (8.8kW)
48 (11.0kW) 26 30 35 39
Element type Bare wire
Rated pressure 1 MPa (10 bar)
Temperature adjustment range
DEX 20°C - 55°C 20°C - 60°C
DBX 30°C - 60°C
Maximum inlet temperature
DEX 25°C 70°C
DBX 30°C
2.5
DEX 5.0 8.0
DBX 7.0 8.0 8.0 9.0
Flow rate @ 38°C (l/min)(2) 4.8 (8.8kW)
6.1(3) (11.0kW) 9.8(3) 11.4(3) 13.0(3) 14.8(3)
Flow rate @ 50°C (l/min)(2) 3.3 (8.8kW)
4.1 (11.0kW) 6.8 7.9 9.0(3) 10.2(3)
Pressure loss @ 2.5 l/min 0.2 bar
@ 9.0 l/min 1.3 bar(4)
°C
DEX >1300 ohm.cm >1100 ohm.cm
DBX >1300 ohm.cm
Dimensions H x W x D (mm) 466 x 231 x 97
Maximum weight (kg) 3.7
Rated volume (litres) 0.4
Water connections (BSP) 1/2”
Protection class IP25
(1) Power rating selected at time of installation
(2) At 12°C incoming water temperature
(3) Mixed with cold water at the outlet
(4)
All data quoted at nominal supply voltage. Standard European voltage tolerances of -6% to + 10%
may be applied.
A minimum water pressure of 0.2 MPa (2 bar) is recommended for optimum performance.
The appliance must not be subject to more than 1 MPa (10 bar).
Technical data
August / 2014 Page 5 DEX & DBX Installation, Maintenance and User Instructions V1.05
When ordering spare parts, please always specify the appliance model and serial number.
Spare Parts
Non-return valve
IN82246
Flow sensor
IN82526
Thermal sensor
IN82851
Thermal sensor
IN82851
DEX / DEX12
Control Panel
IN82550
IN82162
Flow limiter
IN89111 - DBX18
IN89110 - DBX21 & 24
IN89109 - DBX27
IN89110 - DEX
IN89108 - DEX12
Service kit comprising
Heating Element,
Pressure and Safety Switch,
PCB
DEX12 Heating element,
Pressure and Safety Switch
IN82728
PCB IN82726
DBX18 IN83118
DBX21 IN83121
DBX24 IN83125
DBX27 IN83127
DEX IN83227
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 6 August / 2014
Installation
Requirements
• These instructions must be read and fully understood before commencing the installation. If in
doubt, or in need of further guidance please ring Zip on 0845 6 005 005 or 0345 6 005 005.
• Zip InLine water heaters must be installed by a competent person familiar with electric
instantaneous water heaters.
• Installations must comply fully with UK Water Regulations and any Local Authority
requirements.
• The electrical installation including earthing and cross bonding should comply with current
IEE regulations and any Local Authority requirements.
•
•
nominal current of the appliance. (See Technical Data Section on page. 4).
• The appliance must be permanently connected to the supply through an isolating switch with
a contact separation of at least 3mm in all poles and be protected by a suitably rated RCD.
• The cross sectional area of the connection cable must be in accordance with the power
cable size of 10mm2.
• Take care to protect the wiring from damage during installation and ensure that any
uninsulated wiring is not directly accessible after installation.
• Check that the power supply is switched off prior to electrical connection.
• Installation site
• The installation site must be free from frost at all times.
• For maintenance work a shut off valve should be installed in the water supply line to the
heater.
• The unit should be positioned as close as possible to the outlet to minimise heat loss. The
recommended maximum distance is 2 meters.
• The appliance complies with protection type IP25 and may therefore be installed in protection
zone 1.
• When considering the location of the heater, consideration should be given to
the safe and visible disposal of any water resulting from leaks and seepage.
This is particularly relevant when the heater is located in a cupboard or any concealed location.
For guidance please call Zip Heaters (UK) Ltd on 0845 6 005 005 or 0345 6 005 005.
• Hot and cold water connecting pipes should be WRAS approved and of copper or steel
construction. Plastic pipes may only be used if conforming to DIN 16893 Series 2. The hot
water pipes must be thermally insulated.
August / 2014 Page 7 DEX & DBX Installation, Maintenance and User Instructions V1.05
Installing the wall bracket
before installation to remove any water
borne debris.
2. Using a 12mm hexagon key, screw the screw
in nipples into the wall connections. After
tightening the double nipples must protrude
by 12mm.
3. Hold the mounting template on the wall and
over the connections. Use the template to
locate the drilling positions and drill them with
a 6mm bit, ensuring that there are no hidden
cables or pipe-work. Attach the wall bracket
4. Offset tiling or uneven surfaces can be
compensated for by up to 30mm with the aid
between the wall and the wall bracket.
Installing the connection pieces
1. Screw the cold water connection piece (A)
with the union nut and the ½” seal onto
the cold water connection.
2. Screw the hot water connection piece
(B) with the union nut and the ½” seal
onto the hot water connection.
Fig 1
Fig 2
A
B
•
15°C. for type DEX, and at least 1,300 ohm.cm 15°C for type DBX and DEX12.
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 8 August / 2014
Installing the appliance
removing the fascia panel then
2. If the power supply cable is to be
connected in the upper part of the
appliance follow instructions 1 to 3 for
“Electrical Connection From Above”
on page 11. This is not applicable to
model DEX12.
3. Place the appliance on the wall
bracket with the threaded stud
back plate.
If necessary the threaded stud can
be carefully bent through a maximum
of approximately 30° to allow it to
However, it must be ensured
that the water connection pipes can
be connected to the appliance without
applying force.
4. Screw the two 8” union nuts on the
appliance’s water connection pipes,
8” seal, onto the
5. Screw the plastic knurled retaining nut
onto the threaded stud of the wall
bracket.
6. Open the water supply to the
appliance and slowly open the shut-off
valve (see Fig 5) in the cold water
connection piece to position 1.
Check all connections for leaks.
7. Ensure that all air is eliminated from
the water heater by opening and
closing the hot water tap until no more
air emerges.
Fig 3
Fig 4
Fig 5
(3-phase model shown)
August / 2014 Page 9 DEX & DBX Installation, Maintenance and User Instructions V1.05
Surface mounted installation
1. For surface mounting, the two
½”screw-in nipples and the ½”
seals must be screwed into
the ½” union nuts of the hot
water and cold water connectors.
The two ½” caps of the side outlets
of the hot water and cold water
connectors must be removed and
screwed into the open end of the
screw-in nipples. The hot water
and cold water connectors must then
8” union nut of
the appliance and delivery pipe,
8” seals.
2. When surface mounting, it is
advisable to install the appliance
at a distance from the wall as
illustrated in Fig 6 using the spacer
sleeves supplied. In this case the two
connections should also be used.
screwed into the ½” side outlets of
the hot water and cold water
connectors with ½” union nuts and
½” seals. The holes required for the
pipes must then be broken out of the
housing using a blunt implement.
4. Ensure the line strainer is inserted
into the cold water connection.
Electrical connection
Prior to commencing electrical
connection take time to re-read the
‘Installation Requirements’ listed on
page 6 and ensure that all requirements
pertaining to electrical installation are
observed.
Wiring Diagram
1. Circuit board
2. Heating element
3. Safety thermal cut-out
4. Terminal block
Fig 6
Fig 6
3-phase
Single phase
1
3
4
2
2
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 10 August / 2014
Load shedding relay (Model DEX only)
If further 3-phase appliances are connected, a load
shedding relay (IN82250) can be connected to phase
conductor L2. (3-phase models only).
A special operating mode must be selected on
the appliance by pressing the four function keys
simultaneously until the required mode (0, 1 or 2) is
shown on the display then releasing the keys.
First select mode 1 to check correct operation of the
load shedding relay at low appliance output (35° set
1. Remove inner and outer insulation from the
connecting cable to the lengths shown in Fig 7.
2. With the smaller opening foremost, slide the
water splash protection sleeve over the
with the wall. This prevents any water leaks
from coming into contact with the electrical
leads. The protection sleeve must be
used and free from damage.
3. Open the control panel to the right.
4. Fit the connecting cables into the terminal
block according to the wiring diagrams on
page 9. Ensure all connections are fully
tightened and secure.
5. The appliance must be earthed.
6. Pull the protection sleeve over the connecting
intermediate panel.
7. Close the control panel.
Note: If required, the terminal block can be
re-positioned in the upper part of the appliance. In
this case the instructions in the following
section should be followed.
Mode Description
0
Normal operation,
manufacturer’s
setting.
1
Operation with
normal load
shedding relay.
2
Operation with
sensitive load
shedding relay.
Fig 7
Electrical connection from below
WARNING
Check that the power supply is switched off prior to electrical connection!
Fig 8 (3-phase model shown)
(3-phase wiring)
(single-phase wiring)
180mm
60mm
8mm
August / 2014 Page 11 DEX & DBX Installation, Maintenance and User Instructions V1.05
Commissioning
To prevent damage to the appliance, the instantaneous water heater must be
purged of air before using it for the rst time.
PURGING
Before connecting the electrical supply, open and close the hot water tap until the water
runs smoothly and no more air emerges.
NOTE! Every time the appliance is drained (e.g. after work on the plumbing system,
if there is a risk of frost or following repair work), the heater must be purged in
this way before reconnecting the power supply.
WARNING! This appliance must be earthed.
Model DEX only
• The maximum power rating of the appliance can be selected from 18, 21, 24 or
27kW (8.8 or 11.0kW for DEX12) at the time of installation. The maximum power
rating should only be selected with reference to the technical data on page 4, after
ensuring that correct cable sizing and fuse protection is in place and with regard to
local site conditions and electrical regulations.
• This should only be carried out by a competent person familiar with instantaneous
water heaters.
1. Switch on the power supply to the appliance. The digital display will light up.
Fig 9
(3-phase model shown)
S
CAUTION
Electrical connection from above (not applicable to model DEX12)
Check the power supply is switched off prior to electrical
connection!
1.Open the prepared breaking point (S) in the upper part of the
appliance by pressing with a blunt instrument (e.g. Screwdriver)
2.Open the cable grommet to slightly smaller than the cable size to
ensure optimum protection against water ingress. Fit the grommet
into the cable opening. N.B. The cable grommet must be used.
3. Strip the cable 6cm above the point where it emerges from the wall.
Support the appliance while the cable is routed through the grommet.
5.Fit the connecting cables into the terminal block according to
the wiring diagram on page 9. Ensure all connections are fully
tightened and secure.
6.The appliance must be earthed.
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 12 August / 2014
2.
on the display. If not, please refer to the section below “Reinstallation”.
3. Use the arrow up and down function keys to select the required maximum
power rating. N.B. DEX at 27kW for connection only to 3/PE 400V AC supply.
4.
start to operate.
5. Mark the set power rating on the product rating plate.
6. After selecting the maximum power rating, the heating element will activate
7. Open the hot water tap and check the appliance is functioning correctly.
8. Explain operation of the appliance to the end user and leave the operating
instructions for their reference.
9. Complete the product registration card and return it to Zip Heaters or
register the product on line at www.zipheaters.co.uk
DEX Reinstallation
If the appliance is to be re-commissioned under different installation conditions
it may be necessary to alter the maximum power rating.
To re-set the maximum power rating use a
BS EN 60900 rated screwdriver to short circuit
the two pins as shown in Fig 10. Value ‘21’ (“12”
maximum power rating has been selected.
Model DBX only
N.B. DBX27 for connection only to 3/PE 400V AC
supply.
1. Switch on the power supply to the appliance.
2. Open the hot water tap and check the appliance is functioning correctly.
3. Explain operation of the appliance to the end user and leave the operating
instructions for their reference.
4. Complete the product registration card and return it to Zip Heaters or
register the product on line at: www.zipheaters.co.uk
DBX Temperature Adjustment
The appliance is factory set to deliver hot
water at 50°C.
The hot water temperature can be adjusted
between 30°C and 60°C by turning the
potentiometer with a 2mm blade screwdriver
as shown in Fig 11.
Turning clockwise increases temperature and
turning anti-clockwise decreases temperature.
Fig 10
Fig 11
August / 2014 Page 13 DEX & DBX Installation, Maintenance and User Instructions V1.05
A B
Maintenance and cleaning.
N.B. Maintenance work must only be carried out by a competent person
familiar with instantaneous water heaters.
General cleaning
Do not use strong, corrosive spray or abrasive cleaners / chemicals.
soft cloth and mild soap and water.
Do not spray water over the tap as it may damage the low-voltage electronics.
cleaners with a PH level less than 4, hypochlorite, hydrogen peroxide or any other
aggressive chemical the affected component must be replaced immediately.
Undersink units must never be located near, or cleaned with water jets. Avoid
using airborne pesticides near the undersink unit.
The electrical and plumbing components should be inspected regularly by a
competent person to ensure proper functioning and operational safety. Water
quality should be considered when determining the frequency of inspection.
Cleaning and replacing the lter strainer
from the unit.
The strainer should be cleaned or replaced as follows:
1. Isolate the electrical supply to the unit.
2. Remove the appliance cover and close the
shut-off valve (see Fig 12) in the cold water
connection piece to position II.
3. Unscrew the plug (A) from the cold water
connection piece and take out the strainer (B)
(see Fig 13).
4. The strainer can now be cleaned or replaced.
6. Slowly open the shut-off valve in the cold water
connection piece to position I.
7. Vent the unit by opening and closing the hot
water tap several times until all air has been
eliminated from the water heater and no more air
emerges.
the unit.
Fig 12
Fig 13
II
I
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 14 August / 2014
Operation (Model DEX only)
Temperature setting
The required hot water temperature can be
increased or decreased in increments of 1°C
arrow function keys.
Depressing the function key for a longer
time changes the temperature continuously.
The temperature can be adjusted between
20°C and 60°C. (DEX12 20°C and 55°C)
Note. Reducing the temperature below 20°C
displays ‘- -’ and the heating function will
not operate.
Program buttons
The two program keys allow a preset
temperature to be selected quickly.
The factory setting is 35°C for program 1
and 48°C for program 2.
The preset temperature can be changed to
the current temperature setting by prolonged
pressing of the program key.
The display changes from ‘P1’ or ‘P2’ to
the new temperature value which becomes
available each time the corresponding
program key is pressed.
Temperature limitation
Units are supplied with the temperature
limitation function deactivated.
To activate, select the limit temperature then
press the program 1 and up arrow function
keys simultaneously for at least 3 seconds.
To deactivate, press the program 1 and
down arrow function keys simultaneously for
at least 3 seconds.
Note. Programmed temperature settings will
need to be reset after deactivating
temperature limitation.
Set temperature
-1°C +1°C
Select preset temperature
A2
A1
B1 B2
Temperature limitation on
Press > 3
seconds
+
12
Temperature limitation off
Press > 3
seconds
+
Conrmation of
deactivation
12
Store temperature
Press > 3 seconds
Set required
temperature
12
3
4
August / 2014 Page 15 DEX & DBX Installation, Maintenance and User Instructions V1.05
Reset to factory setting
To reset to factory settings press
the up arrow and down arrow
function keys simultaneously.
The display will count backwards
from ‘10’ to ‘00’ in one second
intervals.
The appliance is reset when the counter reaches ‘00’.
Releasing the function keys earlier will cancel the process.
Energy saving
Set the required hot water temperature on the appliance.
If the water is too hot reduce the temperature on the appliance instead of
mixing with cold water.
Note! Adding cold water wastes the energy used to heat it up.
Also, any cold water added is not controlled by the electronic circuitry meaning
that precise temperature control can no longer be guaranteed when supplying
more than one outlet.
Power limit
volume of hot water being drawn off to the required temperature, this will be
indicated by the LCD decimal point on the display.
indicated by the decimal point remaining solid.
Operation with solar systems
Type DEX (excluding DEX12*) are suitable
for use with solar heating systems providing
appropriate controls are in place to ensure that
the temperature of the water entering the unit
does not exceed 70°C.
If the inlet temperature exceeds the set point,
switched off.
*Note! DEX12 has a maximum inlet temperature of 25°C.
Press + hold
Reset complete
Reset to factory settings
12
3
DEX & DBX Installation, Maintenance and User Instructions V1.05 Page 16 August / 2014
Fault nding
Repairs should only be carried out by competent persons familiar with electric
instantaneous water heaters.
All service work should be performed by an authorized Zip service
engineer – for details of the full range of services available call Zip Service on
0845 6 005 005 or O345 6 005 005.
When calling for service, please always specify the appliance model and serial
number.
The following table will be helpful in determining the causes of some common
problems and their solutions.
Problem Cause Solution
Water stays cold (DEX / DBX)
Digital display does not light
up (DEX)
Circuit breaker tripped Reset circuit breaker
STDB tripped (DEX) Contact Zip Service to
reset STDB (DEX)
message ‘Er’ (DEX)
Control system has
switched off
Switch power supply
off and on. If ‘Er’ still
Service
(DEX / DBX)
Clean shower head or
tap nozzle
Line strainer dirty or
Contact Zip Service to
Selected temperature not
achieved (DEX / DBX)
rate at the outlet
Selected temperature not
achieved and decimal point
Cold water has been
added at the outlet
Set for required
temperature and tap
hot water only
Inlet temperature
exceeding set point
Reduce inlet
temperature
Delivered temperature
perceived to be too cold
(DBX)
Set temperature too low
Contact Zip Service to
increase set
temperature
Delivered temperature
perceived to be too hot (DBX) Set temperature too high Contact Zip Service to
reduce set temperature
No response to keypress
(DEX)
correctly
correctly
August / 2014 Page 17 DEX & DBX Installation, Maintenance and User Instructions V1.05
Warranty
available and should give many years of trouble free service.
Certain warranties may be implied by law into your contract with Zip.
The warranty provided below is additional to these implied warranties and
nothing set out below shall limit your statutory rights or rights at law.
Zip Heaters (UK) Ltd warrants that, should any part fail within 12 calendar
months of installation, that part will be repaired or replaced free of charge by
Zip or its Distributor or Service Provider, except as set out below, provided the
appliance is installed and used strictly in accordance with the instructions
supplied, and that failure is not due to accident, misuse, abuse, unsuitable
expressly nominated by Zip.
No costs are payable by the customer other than any mileage or
travelling-time charges incurred by a Zip Service Provider or the cost of
removal, cartage and re-installation of any component of the appliance if it
needs to be returned for repair to Zip or its Distributor.
This warranty does not cover damage resulting from non-operation of the
appliance or consequential damage to any other goods, furnishings or property.
Zip does not exclude, restrict or modify any liability that cannot be excluded,
applicable.
Furthermore, this warranty does not displace any statutory warranty, but, to
the extent to which Zip is entitled to do so, the liability of Zip under any
statutory warranty will be limited at Zip’s option to the replacement of the
appliance or supply of equivalent appliance, the payment of the cost of
replacing the appliance or acquiring an equivalent appliance, or the payment
of the cost of replacing the appliance or acquiring an equivalent appliance, or
the payment of the cost of having the appliance repaired or the repair of the
appliance.
The use of this crossed out wheeled bin logo indicates that this
product needs to be disposed of separately to any other household
waste.
Within each of the European Union member countries, provisions
have been made for the collection and recycling of unwanted
electrical and electronic equipment.
In order to preserve our environment we ask that you dispose of
this product correctly. Please contact Zip Customer Service for
advice on 0845 6 005 005 or 0345 6 005 005
Other manuals for DEX
1
This manual suits for next models
1
Table of contents
Other Zip Water Heater manuals
Zip
Zip HydroTap Miniboil MB1BA User manual
Zip
Zip Aquapoint III AP3/30 User manual
Zip
Zip AP3/05 Mounting instructions
Zip
Zip Varipoint II VP103 Mounting instructions
Zip
Zip Aquapoint III AP3/100 Mounting instructions
Zip
Zip CEX-O Mounting instructions
Zip
Zip VP103 User manual
Zip
Zip Tudor II P4/52 Mounting instructions
Zip
Zip AQUAPOINT III Eco Manual
Zip
Zip VP303 Mounting instructions
Zip
Zip InLine ES3 Mounting instructions
Zip
Zip Varipoint III Assembly Instructions
Zip
Zip HydroTap 801621 User manual
Zip
Zip VP103 Mounting instructions
Zip
Zip HydroTap G4 User manual
Zip
Zip AquaFlo II AF3090 Mounting instructions
Zip
Zip VARIPOINT II Series Manual
Zip
Zip Tudor Manual
Zip
Zip Autoboil 315052 User manual
Zip
Zip Tudor Manual
Popular Water Heater manuals by other brands
Riello
Riello START AQUA 28/60 BI installer and user manual
A.O. Smith
A.O. Smith ST-300 User and service manual
Vaillant
Vaillant electronicVED E ../7 INT II Series installation instructions
SYRIUS
SYRIUS TS-INOX STO installation guide
Bosch
Bosch Tronic 5000C Technical service bulletin
Kenmore
Kenmore MISER 153.336333 owner's manual
Hubbell
Hubbell BWXSS-3775 Installation, operation and maintenance manual
State Water Heaters
State Water Heaters T-H3M-DV Installation manual and owner's guide
DeDietrich
DeDietrich TWH Split WH 150 E user guide
Eldom Invest
Eldom Invest E41 TECHNICAL DESCRIPTION MANUAL FOR INSTALLATION, OPERATION AND MAINTENANCE WARRANTY AND WARRANTY CONDI
Noritz
Noritz IHK-NRCP Installation and instruction manual
Siemens
Siemens DO 3670D3 Usage and installation instructions
