Zipato ZXT-120 User manual

This guide
describes
how to install,
program and
operate Zipato
IR Extender.
How can I
manage all
security issues
with one
easy, intuitive
and efficient
solution?
USER
GUIDE
V1.0
IR
EXTENDER
Infrared

COPYRIGHT
© 2015 Tri plus grupa d.o.o. All Rights Reserved. Copyright by Tri plus grupa d.o.o.
No part of this manual may be reproduced or transmitted in any form without the
expressed, written permission of Tri plus grupa d.o.o.
TRADEMARKS
Zipato and the Zipato logo are registered Trademarks.
All other product names mentioned herein may be trademarks or registered
trademarks of their respective companies.
NOTICE
Although Zipato has attempted to ensure the accuracy of the content of this manual,
it is possible that this document may contain technical inaccuracies, typographical,
or other errors. Zipato assumes no liability for any error in this publication, and
for damages, whether direct, indirect, incidental, and consequential or otherwise,
that may result from such error, including, but not limited to loss of data or profits.
Zipato provides this publication “as is” without warranty of any kind, either express
or implied, including, but not limited to implied warranties of merchantability or
fitness for a particular purpose. The published information in the manual is subject
to change without notice.
Zipato reserves the right to make changes in the product design, layout, and driver
revisions without notification to its users.
03
IR EXTENDER
QUICK INSTALLATION GUIDE
02 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

IMPORTANT SAFETY INFORMATION
To avoid contact with electrical current:
Never install an Ethernet connection in wet locations unless that connector is
specifically designed for wet locations.
Do not place Ethernet wiring or connections in any conduit, outlet or junction box
containing electrical wiring.
Installation of inside wire may bring you close to electrical wire, conduit, terminals
and other electrical facilities. Extreme caution must be used to avoid electrical
shock from such facilities. Avoid contact with all such facilities.
Ethernet wiring must be at least 2 m from bare power wiring or lightning rods and
associated wires, and at least 15 cm from other wire (antenna wires, doorbell
wires, wires from transformers to neon signs), steam or hot water pipes, and
heating ducts.
ELECTROMAGNETIC COMPATIBILITY
In proper state and when operated properly, the product complies with all the
requirements in respect of interference radiation according to EN 300 220-2 and
EN 301 489-3. The connections conducting HF signals must neither be manipulated
nor damaged.
03
IR EXTENDER
QUICK INSTALLATION GUIDE
02 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

INTRODUCTION 05
IR EXTENDER OPERATIONS 08
INSTALLATION 20
TROUBLESHOOTING 25
SPECIFICATIONS 27
IR EXTENDER CODE LIST 34
LIMITED PRODUCT WARRANTY 40
DECLARATION OF CONFORMITY 46
CONTENTS
05
IR EXTENDER
QUICK INSTALLATION GUIDE
04 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

The ZXT-120 is a Z-Wave to IR extender for air-conditioner (AC), (Figure 1), it works
with any Z-Wave compliant gateway or controller by translating Z-Wave Thermostat
Commands to AC IR control code. User can select the IR code from the built-in
code library of ZXT-120, or use learning function, by using Z-Wave Configuration
Commands according to the parameter table. ZXT-120 is also with built-in
temperature sensor which allows gateway or controller to get the current room
temperature.
ZXT-120 can be configured as either “Frequently Listening Routing Slaves” (FLiRS)
or “Always Listening” node after exclusion process (before inclusion process).
FLiRS node type is for battery operated applications and it will enter sleep mode
frequently in order to conserve battery consumption that can provide the flexibility if
there is out of 5Vdc power source. Also, user can place the unit in anywhere at home.
INTRODUCTION
Figure 1 ZXT-120
05
IR EXTENDER
QUICK INSTALLATION GUIDE
04 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

Always Listening node type is for the needs of fast response application. It works
with 5Vdc power source. Always Listening node can act as a repeater, which will re-
transmit the RF signal to ensure that the signal is received by its intended destination
by routing the signal around obstacle and radio dead spots.
ZXT-120 supports Network Wide Inclusion (NWI) and Explore Frames. It also
supports Z-Wave networks with multiple gateways and controllers. Like every
Z-Wave accessory, user will need to include the 4 ZXT-120 into their Z-Wave network
using the primary controller. Then, the user can use either the primary controller
or secondary controller to configure and setup the ZXT-120 using Z-Wave’s
configuration command class. Once the configuration and setup is complete, the
controller can use Z-Wave “Thermostat commands class” to control their IR-
controlled air-conditioner through the ZXT-120.
CONTROLLER AND GATEWAY REQUIREMENTS
The ZXT-120 can work with any Z-Wave compliant controller or gateway supporting
the following Z-Wave commands.
- Configuration Command Class
- Multilevel Sensor Command Class
- Thermostat Command Class
• Thermostat Mode Command Class
• Thermostat Fan Mode Command Class
• Thermostat Set-point Command Class
07
IR EXTENDER
QUICK INSTALLATION GUIDE
06 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

BUILTIN IR CODE LIBRARY
The Built-in IR code library supports most of the popular air conditioner brands in the
market. Z-Wave gateway and controller does not need to have any IR control code knowledge.
User can use ZWave controller or gateway to select the IR code according to the ZXT-120 code
list separately provided through Z-Wave configuration
command.
GLOSSARY
DEVICE OR
NODE
Devices and nodes are all terms to describe anindividual Z-Wave device. These are
allinterchangeable when setting up your Z-Wavenetwork.
INCLUSION Add a Z-Wave device to the network.
EXCLUSION Delete a Z-Wave device from the network.
REMOVE To take a device out of a group, scene or association group while that device still exists in the same
Z-Wave network.
ZWAVE
NETWORK
A collection of Z-Wave devices is controlled by primary and secondary controllers operating on the
same system. A Z-Wave network has its own unique ID code so that controllers not in the network
cannot control the system.
PRIMARY
CONTROLLER
The first controller is used to set up your devices and network. Only the Primary Controller can be
used to include or delete devices from a network. It is recommendedthat you mark the primary
controller for each network for ease in modifying your network.
SECONDARY
CONTROLLER
A controller containing network information about other devices within the network and is used
for controlling devices. Secondary controller is created from the Primary Controller and cannot
include or delete devices to the network.
INCLUSION
CONTROLLER
A controller containing network information about other devices within the network and is used for
controlling devices. Inclusion controller is created from the Primary Controller in a SIS enabled Z‐
Wave network. Inclusion Controllers have the ability to add and remove devices from the network.
07
IR EXTENDER
QUICK INSTALLATION GUIDE
06 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

Before using the ZXT-120, please read the [INSTALLATION] if you need to mount
the ZXT-120 to a wall. Power up the ZXT-120 by the USB Power 5Vdc or Dry battery
AAA x 3pcs.
• Plug-in 5Vdc power into the USB socket if operated at Always Listening
mode. Or
• Install 3xAAA batteries if operated at FLiRS mode.
• Please refer to the section of [MOUNTING PROCEDURE].
• Remove the battery cover on the back of your ZXT-120 battery chassis.
• Mount the battery cover into the main unit with 2 screws.
• Check the polarity of the batteries and the “+/-” marks inside the
• battery compartment.
• Insert the batteries.
• Push the battery cover and main unit back in place.
IR EXTENDER
OPERATIONS
CAUTION (battery and power adaptor safety)
• Use new batteries of the recommended type and size only.
• Never mix used and new batteries together.
• To avoid chemical leaks, remove batteries from the ZXT-120 if you do not intend to use the remote for an extended period of time.
• Dispose of used batteries properly; do not burn or bury them.
09
IR EXTENDER
QUICK INSTALLATION GUIDE
08 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

PRODUCT OVERVIEW
03
01 02
05 04
01 “PROG” Button, Learning
andLED indication
02 Temperature
sensor
03 Battery
Chassis
04 USB Power
5V DC
05 External
IR port
06 Surround IR Output for top
and 4-directions
06
09
IR EXTENDER
QUICK INSTALLATION GUIDE
08 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

ZWAVE REMOTE CONTROL
01 | Select your operation mode; please refer to “Listening Mode” section.
02 | Include or Exclude the unit from the existing Z-Wave home
control network with your primary controller.
• Refer to your primary controller instructions to process
the inclusion / exclusion setup procedure.
• When prompted by your primary controller, click once
on the PROG button.
• The primary controller should indicate that the action
was successful. If the controller indicates the action was
unsuccessful, please repeat the procedure.
03 | User can use either primary controller or secondary controller
(should support configuration command class) to setup the ZXT-
120 AC code by the parameter 27 (IR code number for built-in
code library), please refer to code list for the parameter value
then setup your AC control code.
04 | Once the configuration and setup were completed, the
controller can use Z-Wave “Thermostat commands class” to
control their IR-controlled air-conditioner with the ZXT-120.
05 | You can record down your device code under the below table for
future reference after setting up the ZXT-120 correctly.
CODE NUMBER:
11
IR EXTENDER
QUICK INSTALLATION GUIDE
10 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

ZXT120 INFORMATION
How to get the NIF “Node Information Frame” on ZXT-120 (Inclusion)
Step Setup Key LED Indication Status on ZXT-120
1Press the PROG button on
the ZXT-120 LED flashes once then stays off (ZXT-120 will
report the supported command class)
Parameter No. and Parameter Value of configuration command
Parameter Number Definitions Parameter Value
25 0X19 Indicate a location for IR code
learning and start learning 0-22 (0x00 0x16)
26 0X1A
Learning status register
Note:
The status value 0x01 and
0x04 will be reset to 0 when
the ZXT-120 receive a get
command to this parameter
0(0x00): Idle - this IR channel is idle
(default)
1(0x01): OK - the latest learning
process successful and completed
2(0x02): Learning - the ZXT-120 is
busy processing previous learning
request
4(0x04): Failed - the latest learning
request failed
27 0X1B IR code number for built‐in
code library Refer “Code list” for details
28 (0x1C) External IR Emitter power
level
0(0x00): normal power mode
255(0xFF): high power mode (default)
11
IR EXTENDER
QUICK INSTALLATION GUIDE
10 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

32 (0x20)
Surround IR control
-to avoid the IR interference
by disabling the surrounding
IR emitter if 2 air-
conditioners in a room are
used
- extend the battery life by
disabling the Surround IR
Emitters
0(0x00): disable Surround IR Emitters
255(0xFF): enable Surround IR
Emitters (default)
33 (0x21) AC function “SWING” control 0(0x00): SWING OFF
1(0x01): SWING AUTO(Default)
35 (0x23) Learn location status Bit mask = 1, learn location has learn
data. Otherwise, Bit mask = 0
See figure “Learn location” as below
76543210
10000010
76543210
00010001
76543210
0000001
76543210
Bit Mask Byte 1
Location 0-7
Bit Mask Byte 2
Location 8-15
Bit Mask Byte 3
Location 16-22
Bit Mask Byte 4
[Reseved]
13
IR EXTENDER
QUICK INSTALLATION GUIDE
12 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

37 (0x25)
Sensor temperature
compensation
(This parameter is used to
compensate the temperature
error at temperature sensor)
Temperature offset
value.
Formula:
Display temperature
= sensor reading
value + offset value
(unit = degree C)
0x00 = 0°C (Default)
0x01 = 1°C
0x02 = 2°C
0x03 = 3°C
0x04 = 4°C
0x05 = 5°C
0xFF = -1°C
0xFE = -2°C
0xFD = -3°C
0xFC = -4°C
0xFB = -5°C
Mapping Information
• BASIC Set Value 0x00 will map to Thermostat mode Off 0x00.
• BASIC set Value 0xFF will map to Thermostat mode Resume 0x05.
LISTENING MODE CHANGE DEFAULT MODE IS FLIRS
ZXT-120 can be configured as either “Frequently Listening Routing Slaves” (FLiRS) (if you
are using battery ) or “Always Listening” (if you are using 5Vdc adaptor) before inclusion
process. Refer to Glossary for definition of “FLiRS” and “Always Listening” node.
Important:
It is not allowed to changing ZXT-120 listening mode without exclusion process (do not
change ZXT-120 listening mode while ZXT-120 is included in a network).
13
IR EXTENDER
QUICK INSTALLATION GUIDE
12 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

How to switch ZXT-120 listening mode from “Always Listening” to
“FLiRS” (or vice verse)
Step Setup Key LED Indication Status
on ZXT-120
1Press and hold the PROG
button on the ZXT-120 for
around 5 seconds
LED turns ON after PROG key hold
for 5 seconds
2Release the button and then
press the PROG button 3
times within 2 seconds
LED flashes twice then stays off
(ZXT-120 set in FLiRS mode)
OR
LED flashes four times then stays off
(ZXT-120 set in Always Listening
mode)
Inclusion/Exclusion
Step Setup Key LED Indication Status on ZXT-120
1
Refer to your primary controller
instructions to process the
inclusion/ exclusion setup
procedure.
-
2When prompted by your
primary controller, click once
on the PROG button
LED flashes once then stay off (ZXT-120 will
report the supported command class)
The primary controller should indicate that the action was successful. If the controller
indicates the action was unsuccessful, please repeat the procedure.
15
IR EXTENDER
QUICK INSTALLATION GUIDE
14 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

IR Code Selection
ZXT-120 is with built-in IR AC code library, user may select the IR code using
Configuration Command Class.
Step Setup Key LED Indication Status on ZXT-120
1After included ZXT-120 to Z-Wave
controller or Gateway, go to device setup for
configuration on gateway or controller. -
2
Input parameter number “27” and
parameter value (please look up the code
list of ZXT-120 according to your AC brand).
Then complete the configuration process.
-
3
Press the PROG button on the ZXT-120.
(this step apply when using ZRC-100 or
other portable controller for set up, if using
gateway, user can skip this step)
LED flashes once when ZXT-120
receives the configuration setting.
4
Go back to the control page of ZXT-120 on
the gateway and try the function such as
(cool, temperature set).
If the air conditioner does not respond to the
command you set on Gateway (Cool, Heat,
Auto, Temperature set etc.), repeat step 2
and 3 to select the next code on code list.
LED flashes once every time it
receives a command from
gateway.
Important Information
• Different brand or model of air conditioner has different function. For example, some air conditioner only support temperature set
from 18°C-30°C, if user set 17 °C on gateway, ZXT-120 will not respond.
• There are more than 1 code for each brand, some does not support heat, if user selected a code that does not support heat but the
original air conditioner supports heat function, please continue to try next code until the correct one is selected.
• If none of the code works on the target air conditioner, or the air conditioner brand is not shown on the code list, please select
code “000” for IR code learning (refer to instruction of IR Code Learning)
15
IR EXTENDER
QUICK INSTALLATION GUIDE
14 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

IR CODE LEARNING
In case none of the code on the code list works for the targeted air conditioner, user
can use IR code learning function using configuration according to below steps:
Step Setup Key LED Indication Status
on ZXT-120
1
Go to configuration setting
page on the gateway or ZRC-
100 and input parameter
number “27” and parameter
value “000” to select the
dedicated AC code number
“000” for learning.
LED flashes twice when ZXT-120
receives the configuration setting.
2
Look up below mapping table
(value 0-22) for learning,
and decide the IR setting
you intent to learn next. For
example “22°C, cool” which
matches value “5” (IR code
to be learnt will locate at “5”
in ZXT-120). Set your original
air conditioner remote at
“22°C, cool” and turn it off.
(Besides temperature and
mode, you may set other
desired settings, such as
Fan, Swing etc.)
-
3
Go to configuration setting
page on the gateway or ZRC-
100 and input parameter
number “25” and parameter
value “5” (in this case).
-
17
IR EXTENDER
QUICK INSTALLATION GUIDE
16 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

4
Press the PROG button on
the ZXT-120. (this step apply
when using ZRC-100 or other
portable controller for set up,
if using gateway, user can
skip this step)
LED flashes once
when ZXT-120 receives the
configuration setting.
ZXT-120 flashes once again to start
learning
5
Aim the original air
conditioner remote at ZXT-
120 from distance within 1-3
inches.
Press “power on” button on
the original air conditioner
remote.
If the learning is failed,
repeat step 3 to step 5.
To learn next IR code, repeat
step 2 to step 5.
LED flashes twice if
learning is successful.
LED flashes 6 times if
it’s failed.
When you encounter problem, check followings:
• Make sure your original remote is switched to power off.
• Press the key on original remote before learning mode timeout.
• Keep away from incandescent light and direct sunlight during learning.
• Make sure IR Transmitter of your original remote alight with learning diode of ZXT-120, you may also slight adjust closer or
further away the distance of two devices. Some of remotes the IR transmitter in hidden behind lens and may not installed center
of remote.
• Make sure the power is good on both devices, especially the original remote. Use fresh batteries.
IR LEARNING MAPPING TABLE PARAMETER NUMBER 25
Parameter Value
(Storage Location)
Thermostat command & IR setting
Storage in Celsius unit Storage in Fahrenheit unit
0 OFF OFF
17
IR EXTENDER
QUICK INSTALLATION GUIDE
16 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

1 ON (resume) ON (resume)
2 19 °C cool 67 °F cool
3 20 °C cool 68 or 69 °F cool
4 21 °C cool 70 or 71 °F cool
5 22 °C cool 72 or 73 °F cool
623 °C cool 74 or 75 °F cool
7 24 °C cool 76 °F cool
8 25 °C cool 77 or 78 °F cool
9 26 °C cool 79 or 80 °F cool
10 27 °C cool 81 or 82 °F cool
11 28 °C cool 83 or 84 °F cool
12 19 °C heat 67 °F heat
13 20 °C heat 68 or 69 °F heat
14 21 °C heat 70 or 71 °F heat
15 22 °C heat 72 or 73 °F heat
16 23 °C heat 74 or 75 °F heat
17 24 °C heat 76 °F heat
18 25 °C heat 77 or 78 °F heat
19
IR EXTENDER
QUICK INSTALLATION GUIDE
18 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

Important Information
After all learning completed, user can go back to the ZXT-120 control page on the gateway for normal operation.
• On the gateway UI, user can only use the temperature range from the mapping table, OFF, ON(RESUME), COOL, HEAT, DRY, If
user press the button of FAN, or other function on the gateway UI which is not listed in above table, ZXT-120 will not respond.
• If user only learnt ON, OFF, or part of the settings according to the above table, ZXT-120 will send the learnt data to the
air conditioner only. For example, user only learnt ON, OFF, 22°C Cool, 24°C Heat, ZXT-120 will not send IR data to air conditioner if
user set 27°C Cool on the gateway.
• ZXT-120 has been pre-defined default cool at 26°C, default heat at 22°C, when user press Cool on gateway without setting
temperature, ZXT-120 will send the learnt data of 26°C Cool to air conditioner. When user press Heat on gateway without setting
temperature, ZXT-120 will send the learnt data of 22°C Heat to air conditioner.
• There is only one code for dry mode, user can set it at any preferred temperature.
• User can still use gateway to set up scene and schedule with ZXT-120, for example, to have AC turn on at 23°C every day at 7pm,
25°C at 11pm. Just make sure the set code is learnt.
• The learning mapping table is for split air conditioner which remote control is with LCD display. For window type air conditioner
(which remote control is without LCD display), the mapping table with temperatures do not apply, due to different type of IR control
protocol. However, user may still use the OFF, or ON/RESUME, DRY key for learning. (Because the POWER key on the original
remote without LCD display is toggle, user can choose either ON key, or OFF key to learn Power key, after learning is done, press
once to turn on the air conditioner if the air conditioner is OFF, press once to turn off if the air conditioner is ON)
19 26 °C heat 79 or 80 °F heat
20 27 °C heat 81 or 82 °F heat
21 28 °C heat 83 or 84 °F heat
22 Dry mode Dry mode
RESET ZXT120 TO FACTORY DEFAULT
Press and hold “PROG” button for 10seconds on ZXT-120. During the key hold period,
RED LED lights up at around 5 seconds, then, it will flash twice until reset process is
completed at around 10 seconds.
Information
• If you are using Gateway or other Z-wave controllers to operate ZXT-120, Please follow the instruction from the gateway or other
controller.
• You can check either the specifications in the manual of your ZXT-120 or also check online at www.zipato.com for a full list of
products that can be used with your ZXT-120.
19
IR EXTENDER
QUICK INSTALLATION GUIDE
18 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com

MOUNTING THE ZXT120 TO A WALL
MOUNTING LOCATION PRECAUTIONS
• Before mounting, check the material and structure of the mounting location. If
the location does not have the proper material or structure, the ZXT-120 can fall
and cause injuries.
• Use commercial items that best match the wall structure and material for the
screws and other fixtures.
• Do not mount near a kitchen counter, humidifier, or other location in which it can be
exposed to smoke or steam. Doing so could cause a fire or electrical shock.
• Do not mount in locations with high humidity or large amounts of dust. Doing so
could cause a fire or electrical shock.
• Do not mount to locations subject to high temperatures, high humidity, or exposure
to water. Doing so could cause a fire or electrical shock.
• Do not mount to locations subject to large amounts of vibration, large jolts, or
large forces. These could cause an injury if the ZXT-120 falls and breaks.
MOUNTING PROCEDURE PRECAUTIONS
• Do not modify parts or use the ZXT-120 in ways other than its intended use. Doing
so could cause the ZXT-120 to fall and result in an injury.
INSTALLATION
21
IR EXTENDER
QUICK INSTALLATION GUIDE
20 IR EXTENDER
QUICK INSTALLATION GUIDE
www.zipato.com
www.zipato.com
Other manuals for ZXT-120
2
Table of contents
Other Zipato Extender manuals
Popular Extender manuals by other brands

SmoothTalker
SmoothTalker Mobile X6 Series Quick install guide

Winegard
Winegard ConnecT 2.0+ Installation & operation manual

D-Link
D-Link DAP-1330 Technical Support Setup Procedure

weBoost
weBoost DRIVE 4G-X FLEET user manual

Intercoax
Intercoax ECP-2601T installation guide

AFi
AFi MTM-300S instruction manual
