Zippy Tech. HG2 User manual

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 1/17
User Manual
Product Type:
Switching Power Supply
Model Name:
HG2, HP2, PSM, PSL
June 18, 2003
Version 1.0
P/N ???

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 2/17
Table of Contents
Safety and Warnings ............................................................................3
Product and Accessories.......................................................................4
Pin Assignment ....................................................................................5
Specification…………………………………………………………..8
Operational Procedures ......................................................................12
Troubleshooting & Maintenance........................................................16
Technical Support ..............................................................................17

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 3/17
Safety and Warnings
IMPORTANT INFORMATION ON
SAFETY AND PROPER OPERATION OF THE POWER SUPPLY.
<< Read the information carefully before using it. >>
1. Do not attempt to take apart the power supply. There are hazardous voltages inside.
2. Do not add or remove any components from the power supply. Warranty void by doing so.
3. Only authorized technician or service center is allowed to open the power supply for product
services.
4. Never alter the power supply cord or plug. Improper modification can result in severe electrical
shock.
5. Do not expose power supply to high moisture, very dusty or extreme temperature environment.
6. Connect power supply only to designated power sources. Do not place any other materials into
the inlet of the power supply other than the power cord.
7. Do not plug or unplug the power cord with wet hands.
8. To avoid power cord damage, remove the power cord from the wall outlet by grabbing the plug
instead of the cord.
9. Make sure the power cord is properly routed so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
10. To avoid electrical shock, unplug the unit from the power source before attempting any cleaning.
Note1: For safety purposes, power cord must comply with the requirements of the National Safety Code.
Note2: All relevant registered trademarks are strictly the property of their respective companies.
Note3: No further notice will be given for any revision of the product, either modification or a newer
version.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 4/17
Product and Accessories
Please contact your local dealers if any of the following product or accessory is missing from the
package.
1. Power Supply Unit. (Refer to the Figure)
2. Screws x 4.
To prevent missing screws during shipment, screws were installed on the power
supply. When install power supply into computer, remove those four screws first,
please do not remove fan or case screws. All four screws should be installed and
fasten.
3. ATE (Auto Testing Equipment) report.
4. User manual.
5. Optional item – AC power cord.
Remark: All items listed above have been tested and approved; unauthorized accessories should
not be used on this product.
Note: The above figure is just a sample; please refer to the actual product.
Remark:
1. I/O switch on rear panel is only available for HG2 model.
2. The computer case shown above is not part of the power supply.
3. Screws and its specifications.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 5/17
Pin Assignment
Always check the socket and pin assignment (for devices such as motherboard, Hard Disk etc.) before
connecting the two heads.
PURPLE
BLACK
RED
YELLOW
ORANGE
ORANGE
10
12
11
9
8
6
7
5
3
4
2
22
24
23
21
20
BLACK
BLACK
18
19
17
GREEN
BLUE
BLACK
15
16
14
ORANGE
COLOR
1
PIN
NO.
13
NO.
PIN COLOR
BLACK
RED
BLACK
GREY
YELLOW
ORANGE
BLACK
BLACK
RED
RED
RED
WHITE
OUTPUT OUTP UT
+3.3V
+3.3V
GND
+5V
+5V
GND
PW R-OK
GND
+5VSB
+12V
+12V
+3.3V
+3.3V
+5V
+5V
+5V
GND
GND
GND
GND
-5V
-12V
PS-ON
GND
24PINS (EPS 12V)
113
12
11
10
8
9
7
5
6
4
3
2
24
23
22
21
20
19
17
18
16
15
14
OUTPUT
NO.
PIN COLOR NO. PIN COLOR OUTPUT
RED +5V
RED +5V
RED +5V
RED +5V
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
BLACK GND
YELLOW +12V
YELLOW +12V YE LLOW +12V
ORANGE +3.3V
ORANGE +3.3V
ORANGE +3.3V
ORANGE +3.3V
ORANGE +3.3V
PURPLE +5V SB
GREEN PS-ON -12V
BLUE
E
P
S
24PINS (AM D,ATX-GES)
PW R-OK
OUTPUT
11
12
PIN COLOR
YELLOW
ORANGE
ORANGE
PURPLE
BLACK
5
8
9
10
7
6
GREY
BLACK
RED
4
3
NO.
1
2
RED
BLACK
GND
+12V
+5VSB
GND
+5V
+5V
GND
+3.3V
+3.3V
PS-ON
-12V
GND
GND
GND
GND
+3.3V
OUTPUT
COLOR
PIN
WHITE
RED
RED
BLACK
ORANGE
BLACK
BLUE
GREEN
BLACK
BLACK
17
19
18
20
NO.
13
14
16
15
-5V
+5V
+5V
20PINS (AT X12V)

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 6/17
8PINS (EPS12V)
8PINS ( AMD,ATX- GES)
EPS
+12VGND
BLACK
GND
GND
GND
4
3
1
2
BLACK
BLACK
BLACK
8
6
7
5
YELLOW
YELLOW
YELLOW
YELLOW
+12V
+12V
+12V
OUTPUT
PIN
NO. COLOR PIN NO. COLOR OUTPUT
+12V
+12V
+12V
OUTPUT
PIN PIN
GND
GND
COLOR
BLACK
BLACK
NO.
2
4
3
1
6
8
7
NO.
5
COLOR
YELLOW
YELLOW
YELLOW
OUTPUT
GND
BLACK
+5V
RED
PWR-OK
GREY
OUTPUT
PIN
NO.
1
2BLACK
BLACK
GND
GND
COLOR COLOR
YELLOW
YELLOW
4
3
PIN
NO.
+12V
+12V
OUTPUT
4PINS (A TX12V,FOR P 4)
6PINS (E PS12V,OPT IO N)
4
OUTPUT
+3.3V
ORANGE
YELLOW
ORANGE
3
2
NO.
PIN
1
COLOR NO.
PIN
6
5
COLOR
BLACK
YELLOW
OUTPUT
+12V
BLACK
+3.3V
GND
GND
+12V

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 7/17
4PINS (HD／CD-ROM/RW)
GND
+12V
YELLOW
2
1
4
3
BLACK RED
OUTPUT
COLOR
NO.
PIN
NO.
PIN COLOR
+5V
OUTPUT
BLACK GND
GND
OUTPUT
+12V
GND
COLOR
BLACK
YELLOW
2
1
NO.
PIN
4
3
NO.
PIN
BLACK
RED
COLOR
+5V
OUTPUT
4PINS (FLOPPY DISK)
1~3
YELLOW +12V
BLACK
4~6 GND
PIN
NO. COLOR OUTPUT
7~9
10~12
13~15
BLACK GND
ORANGE +3.3V
RED +5V
15PINS (SERIAL ATA HD)

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 8/17
Specifications
Please refer to the specifications according to the actual product purchased.
Note: The new feature, “Prolonged Cooling” after power supply is remote-off only available on model
HG2. Under normal conditions, when power supply is at “Remote-off” mode, cooling fan will remain in
operation for the secondary heat dissipation, and will come to stop at a much lower temperature. This will
prolong the life of the power supply.
INPUT CHARACT
ERISTICS:
HG2
-
6300/
6
350/
6
400P
 VOLTAGE: 90 ~ 240 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 HZ.
 INPUT CURRENT: 6/7/8.0 A (RMS) FOR 115VAC, 3/3.5/4.0 A (RMS) FOR 230VAC.
 INRUSH CURRENT: 65A MAX. FOR 115 VAC, 125A MAX. FOR 230 VAC.
OUTPUT CHARACTERISTICS:
O U T P U T C U R R E N T(A ) R E G U LA T IO N O U T P U T
M IN .
M AX .
PEAK
LO A D LIN E
5V 3 35 ±5% ±1% 50m V
12V 2 22/26/30
+7% /-5%
±1% 120m V
-5V 0 0.8 ±5% ±1% 150m V
-12V 0 1.0 ±5% ±1% 150m V
3.3V 1 25 ±5% ±1% 50m V
+5V SB 0.1 2 ±5% ±1% 50m V
O U T P U T
V O LT AG E
R IP P LE & N O IS E
M AX . [P-P ]
REMARK: THE OUTPUT CURRENT OF 5V & 3.3V SHOULD NOT EXCEED 45A.
SPECIFICATION:
 TEMPERATURE RANGE: OPERATING 0 ℃ --- 40 ℃.
 HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE.
 DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 SECOND.
INPUT TO FRAME GROUND 1500 VAC FOR 1 SECOND.
 EFFICIENCY: 68% TYPICAL.
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms.
 OVER LOAD PROTECTION: 130 +/- 20%.
OVER VOLTAGE PROTECTION:
+5V 

5.7V ~ 6.5V, 3.3V 

3.9 ~ 4.3V, 12V 

13.6 ~ 15V.
 SHORT CIRCUIT PROTECTION: +5V, -5V, +12V, -12V, +3.3V.
 EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B.
 SAFETY: UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950.
 REMOTE ON / OFF CONTROL.
THE UNIT SHALL ACCEPT A LOGIC OPEN COLLECTOR LEVEL WHICH WILL DISABLE / ENABLE ALL
OUTPUT VOLTAGES (EXCLUDE +5V STANDBY),
AS LOGIC LEVEL IS LOW, OUTPUTS VOLTAGE WERE ENABLE,
AS LOGIC LEVEL IS HIGH, OUTPUTS VOLTAGE WAS DISABLE.
 3.3V / 5V REMOTE SENSING.
 COOLING: ONE 80mm BALL BEARING DC FAN.
 DIMENSION: 140 (D) x150 (W) x 86 (H) mm (PS/2).
 ACTIVE POWER FACTOR CORRECTION MEET IEC-1000-3-2 CLASS D.
 ADVANCE THERMAL & ACOUSTICS CONTROL FEATURES.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 9/17
Specifications
Please refer to the specifications according to the actual product purchased.
INPUT CHARACTERISTICS:
HP2
-
6460P/6500P
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 INPUT CURRENT: 8.0 A FOR 115 VAC, 4.0 A FOR 230 VAC.
 INRUSH CURRENT: 65 A MAX. FOR 115 VAC, 125 A MAX. FOR 230 VAC.
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT REGULATION OUTPUT
MIN.[A] MAX.[A] LOAD LINE
5V 2.5 40 ±5% ±1% 60m V
12V 1.0 27~32 ±5% ±1% 100m V
-5V 0 0.8 ±5% ±1% 100m V
-12V 0 1.0 ±5% ±1% 100m V
3.3V 1.0 30 +5, -5% ±1% 60m V
+5VSB 0.1 2 ±5% ±1% 60m V
OUTPUT
VO LTAGE
RIPPLE & NOISE
MAX. [P-P]
REMARK: TOTAL OUTPUT SHOULD NOT EXCEED 460W/500W FOR HP2-6460P/6500P.
*** WHEN PERFORMING CROSS REGULATION TEST, IT IS REQUESTED TO SET THE HIGHER OUTPUT
CHANNEL AT 90% MAXIMUM AND THE LOWER OUTPUT CHANNELS AT 20% MININUM OF RATED
SPEC.
 TEMPERATURE RANGE: OPERATING 0
0
C --- 40
0
C, STORAGE –20
0
C --- 70
0
C.
 HUMIDITY: 10 ~ 90 % RH.
 HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90 VAC INPUT VOLTAGE.
 DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 MINUTE,
INPUT TO FRAME GROUND 1500 VAC FOR 1 MINUTE.
 EFFICIENCY: 71% TYPICAL, AT FULL LOAD, 115VAC.
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
 OVER LOAD PROTECTION: 110 ~ 150% MAX.
 OVER CURRENT PROTECTION:
+5V 

44 A ~ 60 A, + 3.3V 

33 A ~ 45 A, 12V 

35.2 A ~ 48.0 A.
 OVER VOLTAGE PROTECTION:
+5V 

5.7V ~ 6.5V, 3.3V 

3.9 ~ 4.3V, 12V 

13.6 ~ 15V.
 EMI: MEET FCC CLASS B, CISPR22 CLASS B.
 SAFETY: UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950.
 REMOTE ON / OFF CONTROL.
 SHORT CIRCUIT PROTECTION: SHUTDOWN AND LATCH.
 BUILT-IN ACTIVE POWER FACTOR CORRECTOR.
 DIMENSION: 86(H) X 150(W) X 140 (D) mm (PS/2).
 COOLING: ONE 80 mm BALL BEARING DC FAN.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 10/17
Specifications
Please refer to the specifications according to the actual product purchased.
INPUT CHARACTERISTICS: PSM-6550P/6600P
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 INPUT CURRENT: 10.0 A FOR 115 VAC, 5.0 A FOR 230 VAC.
 INRUSH CURRENT: 65 A MAX. FOR 115 VAC, 125 A MAX. FOR 230 VAC.
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT REGULATION OUTPUTOUTPUT
VOLTAGE
MIN.[A] MAX.[A] LOAD LINE RIPPLE & NOISE
MAX. [P-P]
5V 0.5 30 ±5% ±1% 60mV
12V1 1.5 26 ±5% ±1% 100mV
12V2 0 20 ±5% ±1% 100mV
-12V 0 0.8 ±5% ±1% 100mV
3.3V 0.5 30 +5, -5% ±1% 60mV
+5VSB 0 2 ±5% ±1% 60mV
REMARK: 12V TOTAL OUTPUT 40A MAX.
REMARK: TOTAL OUTPUT SHOULD NOT EXCEED 550W/600W FOR PSM-6550P/6600P.
*** WHEN PERFORMING CROSS REGULATION TEST, IT IS REQUESTED TO SET THE HIGHER OUTPUT
CHANNEL AT 90% MAXIMUM AND THE LOWER OUTPUT CHANNELS AT 20% MININUM OF RATED
SPEC.
 TEMPERATURE RANGE: OPERATING 0
0
C --- 40
0
C, STORAGE –20
0
C --- 70
0
C.
 HUMIDITY: 10 ~ 90 % RH.
 HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90 VAC INPUT VOLTAGE.
 DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 MINUTE,
INPUT TO FRAME GROUND 1500 VAC FOR 1 MINUTE.
 EFFICIENCY: 70% TYPICAL, AT FULL LOAD, 115VAC.
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms.
 OVER LOAD PROTECTION: 110 ~ 150% MAX.
 OVER CURRENT PROTECTION:
+5V 

33 A ~ 45 A, + 3.3V 

33 A ~ 45 A, 12V1 

19.8 A ~ 25.2 A
12V2 

19.8 A ~ 25.2 A.
 OVER VOLTAGE PROTECTION:
+5V 

5.7V ~ 6.5V, 3.3V 

3.9 ~ 4.3V, 12V1 

13.6 ~ 15V
12V2 

13.6 ~ 15V.
 EMI: MEET FCC CLASS B, CISPR22 CLASS B.
 SAFETY: UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950.
 REMOTE ON / OFF CONTROL.
 SHORT CIRCUIT PROTECTION: SHUTDOWN AND LATCH.
 BUILT-IN ACTIVE POWER FACTOR CORRECTOR.
 DIMENSION: 86(H) X 150(W) X 160 (D) mm (STRETCH PS/2, EPS12V).
 COOLING: ONE 80 BALL BEARING mm DC FAN.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 11/17
Specifications
Please refer to the specifications according to the actual product purchased.
INPUT CHARACTERISTICS: PSL-6701P
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 INPUT CURRENT: 10.0 / 11.0 / 12 A FOR 115 VAC, 5.0 / 5.5 / 6.0 A FOR 230 VAC.
 INRUSH CURRENT: 65 A MAX. FOR 115 VAC, 125 A MAX. FOR 230 VAC.
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT REGULATION OUTPUT
MIN.[A] MAX.[A] LOAD LINE
5V 2.5 35 ±4% ±1% 60mV
12V 1.0 45 ±5% ±1% 100mV
-5V 0 0.8 ±5% ±1% 100mV
-12V 0 1.0 ±5% ±1% 100mV
3.3V 1.0 30 +5, -5% ±1% 60mV
+5VSB 0.1 2 ±5% ±1% 60mV
OUTPUT
VOLTAGE
RIPPLE & NOISE
MAX. [P-P]
REMARK: TOTAL OUTPUT POWER SHOULD NOT EXCEED 700W for PSL-6701P.
*** WHEN PERFORMING CROSS REGULATION TEST, IT IS REQUESTED TO SET THE HIGHER OUTPUT
CHANNEL AT 90% MAXIMUM AND THE LOWER OUTPUT CHANNELS AT 20% MININUM OF RATED
SPEC.
 TEMPERATURE RANGE: OPERATING 0
0
C --- 40
0
C, STORAGE –20
0
C --- 70
0
C.
 HUMIDITY: 10 ~ 90 % RH.
 HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90 VAC INPUT VOLTAGE.
 DIELECTRIC WITHSTAND: INPUT / OUTPUT 1500 VAC FOR 1 MINUTE,
INPUT TO FRAME GROUND 1500 VAC FOR 1 MINUTE.
 EFFICIENCY: 70% TYPICAL, AT FULL LOAD.
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms.
 OVER LOAD PROTECTION: 110 ~ 160% MAX.
 OVER VOLTAGE PROTECTION:
+5V 

5.7V ~ 6.5V, 3.3V 

3.9 ~ 4.3V, 12V 

13.6 ~ 15V.
 EMI: MEET FCC CLASS B, CISPR22 CLASS B.
 SAFETY: MEET UL 1950, CSA 22.2 NO/ 950, TÜV IEC 950.
 REMOTE ON / OFF CONTROL.
 SHORT CIRCUIT PROTECTION: SHUTDOWN AND LATCH.
 REMOTE SENSING ON 3.3 V DESIGN.
 MEET IEC-1000-3-2 CLASS D (ACTIVE PFC).
 DIMENSION: 86(H) X 150(W) X 220 (D) mm (STRETCH PS/2).
 COOLING: ONE 80 mm BALL BEARING DC FAN.
 I
2
C FEATURES (OPTIONAL).

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 12/17
INPUT CHARACTERISTICS: PSL-6720P/6800P/6850P
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 INPUT CURRENT: 5A (RMS) FOR 220 VAC
12A (RMS) FOR 110 VAC
 INRUSH CURRENT: 75A MAX. FOR 110 VAC
150A MAX. FOR 220 VAC
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT (A) REGULATIONOUTPUT
VOLTAGE
MIN. MAX. PEAK LOAD LINE
OUTPUT RIPPLE &
NOISE MAX. [P-P]
+5V 0.5 45
± 5% ± 1% 60mV
+12V 2 52/60/60
± 5% ± 1% 120mV
-5V 0 0.8
± 5% ± 1% 120mV
-12V 0 0.8
± 5% ± 2% 120mV
+3.3V 0.5 30
± 5% ± 2% 60mV
+5VSB 0 3.5
± 5% ± 1% 60mV
REMARK: 1. TOTAL OUTPUT OF +5V AND +3.3V NOT EXCEED 230W
2. TOTAL MAX.OUTPUT 720W / 800W / 850W
SPECIFICATION:
 TEMPERATURE RANGE: OPERATING 0
0
C --- 50
0
C
 HOLD UP TIME: 17mS MINIMUM AT FULL LOAD & NOMINAL INPUT VOLTAGE
 EFFICIENCY: 71% TYPICAL AT FULL LOAD
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
 OVER POWER PROTECTION
 OVER VOLTAGE PROTECTION
 OVER CIRCUIT PROTECTION
 SHORT CIRCUIT PROTECTOIN
 EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
 COOLING: 8 0mm DC FANS
 DIMENSION: 220 (D) x 150 (W) x 86 (H) mm

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 13/17
INPUT CHARACTERISTICS: PSL-6A00V
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 STEADY-STATE CURRENT: 14/7A AT ANY LOW/HIGH RANGE INPUT VOLTAGE
 INRUSH CURRENT: 20A MAX. FOR 110 VAC , 40A MAX. FOR 220 VAC (AT 25 DEGREE C AMBIENT
COLD START)
 PFC: UP TO THE TARGET OF 95% @230V, FULL LOAD
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT (A) REGULATIONOUTPUT
VOLTAGE MIN. MAX. LOAD LINE
OUTPUT RIPPLE &
NOISE MAX. [P-P]
+5V 1 25
± 250mV ± 1% 60mV
+12V1 1 50
± 600mV ± 1% 120mV
+12V2 1 50
± 600mV ± 1% 120mV
-12V 0 0.8
± 600mV ± 1% 120mV
+3.3V 1 25
± 165mV ± 1% 60mV
+5VSB 0.1 3.5
± 250mV ± 1% 60mV
REMARKS:
1. +5V AND +3.3V TOTAL MAX. POWER: 170W
2. +3.3V AND +5V AND +12V2 TOTAL MAX. POWER: 600W
3. TOTAL MAX. POWER: 1000W
SPECIFICATION:
 TEMPERATURE RANGE: OPERATING 0 ℃ -- 40 ℃ ; STORAGE TEMPERATURE: -20 ℃ – 80 ℃
 HOLD UP TIME: 18mS MINIMUM AT 90V FULL LOAD & NOMINAL INPUT VOLTAGE
 EFFICIENCY: 81%-86% TYPICAL AT 115V, FULL LOAD
 LEAKAGE CURRENT: 3.5 mA. MAX. AT NOMINAL VOLTAGE 264VAC
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
 OVER POWER PROTECTION: 110%~160%
 OVER VOLTAGE PROTECTION: +3.3V → 3.6~4.3V, +5V → 5.5~6.5V, +12V1 → 13.2~15.6V, +12V2 →
13.2~15.6V
 OVER CURRENT PROTECTION: +3.3V → 27.5~37.5A, +5V → 27.5~37.5A, +12V1 → 55~75A, +12V2 →
55~75A
 SHORT CIRCUIT PROTECTION: +3.3V, +5V, +12V1, +12V2, -12V
 SAFETY: TUV, CB, CCC, RFI/EMI STANDARDS
 EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
 COOLING: 8 0mm DC FANS
 I2C FEATURES (OPTIONAL)
 DIMENSION: 220 (D) x 150 (W) x 86 (H) mm

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 14/17
INPUT CHARACTERISTICS: PSL-6C00V
 VOLTAGE: 90 ~ 264 VAC FULL RANGE.
 FREQUENCY: 47 ~ 63 Hz.
 STEADY-STATE CURRENT: 15/7.5A AT ANY LOW/HIGH RANGE INPUT VOLTAGE
 INRUSH CURRENT: 20A MAX. FOR 110 VAC , 40A MAX. FOR 220 VAC (AT 25 DEGREE C AMBIENT
COLD START)
 PFC: UP TO THE TARGET OF 95% @230V, FULL LOAD
OUTPUT CHARACTERISTICS:
OUTPUT CURRENT (A) REGULATIONOUTPUT
VOLTAGE MIN. MAX. LOAD LINE
OUTPUT RIPPLE &
NOISE MAX. [P-P]
+5V 1 25
± 250mV ± 1% 60mV
+12V1 1 50
± 600mV ± 1% 120mV
+12V2 1 50
± 600mV ± 1% 120mV
-12V 0 0.8
± 600mV ± 1% 120mV
+3.3V 1 25
± 165mV ± 1% 60mV
+5VSB 0.1 3.5
± 250mV ± 1% 60mV
REMARKS:
1. +5V AND +3.3V TOTAL MAX. POWER: 170W
2. +3.3V AND +5V AND +12V2 TOTAL MAX. POWER: 600W
3. TOTAL MAX. POWER: 1200W
SPECIFICATION:
 TEMPERATURE RANGE: OPERATING 0 ℃ -- 40 ℃ ; STORAGE TEMPERATURE: -20 ℃ – 80 ℃
 HOLD UP TIME: 18mS MINIMUM AT 90V FULL LOAD & NOMINAL INPUT VOLTAGE
 EFFICIENCY: 81%-86% TYPICAL AT 115V, FULL LOAD
 LEAKAGE CURRENT: 3.5 mA. MAX. AT NOMINAL VOLTAGE 264VAC
 POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
 OVER POWER PROTECTION: 110%~160%
 OVER VOLTAGE PROTECTION: +3.3V → 3.6~4.3V, +5V → 5.5~6.5V, +12V1 → 13.2~15.6V, +12V2 →
13.2~15.6V
 OVER CURRENT PROTECTION: +3.3V → 27.5~37.5A, +5V → 27.5~37.5A, +12V1 → 55~75A, +12V2 →
55~75A
 SHORT CIRCUIT PROTECTION: +3.3V, +5V, +12V1, +12V2, -12V
 SAFETY: TUV, CB, CCC, RFI/EMI STANDARDS
 EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
 COOLING: 8 0mm DC FANS
 I2C FEATURES (OPTIONAL)
 DIMENSION: 220 (D) x 150 (W) x 86 (H) mm

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 15/17
Operational Procedure
1. When removing four attached screws to install this product, please make sure not removing fan or
case screws by mistake.
2. Tighten four screws onto the computer case and double check for stability. (Please refer to the
figure on page 4).
3. Before connecting the units, make sure you verify connector and pin assignment for devices such
as motherboard, hard disk etc. For example, the pin assignments of 24-pin and 8-pin connector on
AMD Athlon MP Motherboard are totally different than Intel Xeon motherboard. Severe damages
may occur by wrong connection.
4. Check product specifications and calculate actual current requirements of each DC voltage. Make
sure these requirements fall within the minimum and maximum range of power supply. If the
current requirements are below the minimum load spec., the power supply may not start up. If the
current requirements are over the maximum load spec., our over protection circuitry will latch and
shutdown the power supply.
5. Plug in power cord to the inlet of power supply.
•Only HG2 models have line power I/O rocker switch. Please set the switch to “I” or “ON”
to turn on line power. For other models, just plug the power cord into the electrical outlet
directly.
•Active Power Factor Correction (PFC) function is available for all power supply models
listed in this manual. The PFC function ensures maximum efficiency of power usage to
preserve energy and lower your electrical bills. It also automatically adapts to a very wide
range of AC line voltage: 100V to 240V AC. (There are no manual switches for you to
select AC input). This unique design ensures you can use our power supplies anywhere in
the world.
6. You can start up the power supply remotely by using “Remote on”.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 16/17
Troubleshooting & Maintenance
SYMPTOM COUNTERMEASURE
No power? After plug main connector, such as 24-pin or 20-
pin and aux. connectors
if needed, to motherboard socket, make sure AC power cord gets AC line
source that is on wall outlet, to this product
power supply. If AC power
cord gets AC line source through power bar or UPS, turn on these
devices first.
If product model is HG2, set I/O switch of power supply panel to “I”
or
“ON”. Other models HP2, PSM and PSL don’
t have line power I/O
rocker switch.
Boot system from computer case I/O.
Check product specifications and calculate
actual current requirements of
each DC voltage. Make sure these requirements fall within the minimum
and maximum range of power supply. (i) If the current requirements are
bel
ow the minimum load spec., the power supply may not start up.
Increase load. (ii) If the current requirements are over the maximum load
spec., our over protection circuitry will latch and shutdown the power
supply. Reduce load or use larger capacity power supply.
There may be a system incompatibility or
wrong connector pin out or
connection, when power supply its fan has spin for while then shutdown.
For example, (i) Use wrong pin assignments of 24-pin and 8-
pin
connectors e.g. For AMD Athlon MP Motherboard
connectors are totally
different than Intel Xeon motherboard. Severe damages may
occur by
plugging wrong connection. (ii) Plug wrong pin position on small 4-
pin
floppy drive connector to cause connection displacement.
[Action] Remove all connectors at all first, then one-by-one to
plug in
one connector at a time and
verify the operation of each device and
system function. When no problem, proceed next device.
The power supply could be latched by self-protection function (e.g.
“over
voltage”, “over current”, “overload”)
. Remove the power cord, wait for
20 seconds or more to discharge its electricity, then plug in the power
cord again, try to restart the computer.
Power is on, but no
monitor display?
Check if video card is seated properly; check the video cable connection.

Verify system and motherboard requirements. For example, some
motherboards require RAM in pairs to work properly
, such as Tyan
#S2665.

User Manual for Models HG2, HP2, PSM and PSL. Version 1.0
Page 17/17
Technical Support
To best serve our customers, there are several services available to suite your needs:
1. For detailed products specification: please visit www.zippy.com
2. For technical enquiries: please send e-mail to [e-mail]
3. For RMA service: please prepare following items before calling RMA department,
 Proof of purchase (original dated receipt)
 Product serial number (SER. NO.) (Refer to the label on product and diagram below)
 Product part number (P/N)
 Product model
 Detailed description of problems
Note:
Different distributors or resellers have their specific RMA terms and conditions; please
contact them for detailed information.
Locations of relevant information:
e.g. （ 1 ） Model HP2-6460P, （ 2 ） S/N T3240001, （ 3 ） P/N 2000370018.
Actual contents may not be the same for different models.
4. Please feel free to contact us via e-mail should you encounter any technical problems
beyond the scope of this user manual.
5. We carry more than 120 standing high quality power supply models and over six hundred
various sub-models. Please visit www.zippy.com for more detailed information.
