Zocon Z 300 Operator's manual

INSTRUCTION MANUAL AND
SAFETY MEASURES
Z 300 SEEDER

Manual Zocon Z300 Seed drill
1. INTRODUCTION
This instruction manual is intended for people who work with the machine or who perform
daily maintenance on the machine.
It must be read carefully before performing work with or on the machine for the first time.
This instruction manual describes how to use the Z300 Seeder, which safety measures to
take and how to service and transport the machine.
This instruction manual may include components that are optional extras.
Any deviations between the text and/or diagrams in this instruction manual and your
machine may, therefore, result from a difference in design. They may also stem from
changes as a result of continuous development and innovation.
Note
Not observing the following instructions may result in a dangerous situation
and the manufacturer's warranty may become invalid.
Explanation of the warning symbols
•Read the instruction manual before using the machine.
•Caution. Rotating parts.

Manual Zocon Z300 Seed drill
2. TECHNICAL NOTICE
•Chassis epoxy painting
•Dimensions 670 large x 1000 long x 800 high, weight 60kgs (300 Liter)
•The blower works with an electric 12 volts motor
•The rotor rolls by an electric motor, five sorts of rotor exist
- White: slug pellet, insecticide (very small flow)
- Green: rape, alfalfa, clover, mustard, luzern (small flow)
- Yellow/stainless: phacelia, radish, mixing seeds (medium flow)
- Red: rye grass, corn (big flow)
- Black: cereals (very big flow)
•An electronic control box is included with three switches:
- To start or stop the blower
- To start or stop the rotor
- A handling button with a 0 to 30 graduated scale for the flow, set directly in cabin
•And a green light for working
•The blower blasts the seeds through the flexible pipes of 30 mm
•Two Motors: 12 volts
•Blower motor: 140 watts
•Rotor motor: 100 watts
3. FITTING
•Fit the Z300 on the tool chassis, it should be placed on the stubble middle
•Check the solidity of your installation. Position the machine so that there is no danger
for the operator being injured while it is being filled
•When fitting the machine on the tool it is essential to install a guard rail
•Install a platform with a handrail and access stairs to allow the hopper to be filled in
complete safety
•Use perforated anti-slip metal
•The spreader plates should be fitted so that the seeds fall just behind the
ploughshare of the stubble or the discs and before the roll between 30 and 70cm.The
spreader plates spread the seeds at a distance between 50 to 1.40m. Small
seedsshould be covered by the roll of the stubble. It is necessary to have a slope
down for the hoses and avoid reverse slope
•Before working, check that the machine is not electronically connected

Manual Zocon Z300 Seed drill
4. CONNECTION
•Electric thread and control command are included with the Z300
•N°1513 (on technical doc): for starting the blower system
•N° 1514 (on technical doc): for starting the rotor
•The handle button N° 1512 graduated from 0 to 30 to set the electric flow
•Supply protected connection of 30 amperes is necessary
•Connect the red thread with the positive plug + (brown thread) and the blue one with
the negative plug -
•Check the blower rolls in the right direction (arrow direction)
5. SECURITY RULES
After fitting the Z300 on the tool, check the different points of fixation, all the fixation holes of
the chassis should be used to insure a good stability of the Z300 on the tool. Depending on
the highness of the fitting you should provide a “passerelle” to access easily to the Z300 with
no slipping steps large from 28 to 35cm and high from 50 to 55cm from the ground. To
prevent any respiratory problems, please fill and empty the tank with adapted protection
(mask…) Before any manual work on the machine plug it off.
6. FITTING THE FLOW
The flow is regulated by a rotor working with an electric motor combined with an electronic
control command fitted in the cabin which permits the kg/hour set.
A graduated scale regulates the flow. A switch is used for the stop/go set.
As the Z300 is checked, the rotor motor and the blower system work in the right direction.
As the hopper is under pressure, use the Z300 with closed hopper.
EMPTYING THE HOPPER: a trap at the rotor end is dedicated for emptying.*
CHANGING THE ROTOR: unscrew the two buttons, take off the trap, pull the rotor, put in
the new rotor with the square side first, then close the trap, and screw the buttons.
STOCK THE DRILL COVERED..
7. FLOW SET:
The table set is given in flow/hour:
Working width x speed x weight/hectare

Manual Zocon Z300 Seed drill
8. USE:
Set flow: the Z300 can be used with any drills or stubbles, it is necessary to have a
slope down for the rolls and avoid reverse slope.
Start with the N°1514 + green light.
The set flow is done by the handle button N°1512 on the electronic command box in cabin.
The blower works with the N° 1513.
At the end of the field stop the sow with the button in cabin N°1514 (let the blower works).
The Z300 is an electric tool, the flow is calculated by hour. Width work multiplied by the
speed equal to an hour sowing surface. Take the hour sowing surface and multiply it to the
weight per hectare.
Take the table set.
Examples:
N°1: sowing density 0.95: green rotor.
For a 6 row drill, width work 4.80 metres, distance between spreader plates 80 cm, and a
sowing speed of 4km/hour:
4.80m x 4 km/hour =1.92 ha/hour.
Weight per hectare wanted: 10 kg
Sowing surface: 1.92 ha x 10 kg/ha = 19.2 kg per hour.
Take table set, fit 19.2 kg = number
N°2: sowing density 0.95: green rotor.
For an 8 row drill, width work 6.40 metres, distance between spreader plates 80 cm, and a
sowing speed of 5 km/hour:
6.40m x 5 km/hour = 3.20 ha/hour.
Weight per hectare wanted: 9 kg.
Sowing surface: 3.20 ha x 9 kg/ha = 28.8 kg per hour.
Take table set, fit 28.8 kg = number
N°3: sowing density 0.65: yellow /stainless rotor.
For mustard sowing on stubble, width work 5 metres, speed of 7 km/hour for a 10kg/hectare
sowing. 5m x 7000m/hour = 35000m²/hour = 3.5 ha x 10 kg = 35 kg/hour.
Take table set, fit 35kg/hour 6 issues, number
N°4: sowing density 0.95: yellow /stainless rotor.
For mustard sowing on stubble, width work 6 metres, speed of 8 km/hour for a 12kg/hectare
sowing. 6m x 8000m/hour = 48000m²/hour = 4.8 ha x 12 kg = 57.6 kg/hour.
Take table set, fit 57.6kg/hour, number
Before any sowing, calculate the flow by hour, divide it by 60 minutes and check the
flow/minute before sowing. You can do the check in fix position with the seeds spread in a
bucket.

Manual Zocon Z300 Seed drill
9. HOW TO CHANGE ROTOR DISTRIBUTION
Right fitting of the string.
1) Take the string off: Right fitting of the down string :6H00
Right fitting of the up string : 12H00
2) The string does not press the strips rotor anymore.
3) Unscrew the both buttons to take off the greasing rotor. *
The greasing rotor and its two buttons.
Take off the rotor and change it, be careful with the axe distribution motor
connect it well.
The right fitting of the both strips is very important to prevent any problems
of flow in the tank. Fit again the greasing rotor, its both buttons and the string

Manual Zocon Z300 Seed drill
10. SENSOR CONTROL
Before using your captor system, please calculate you flow according to the right table sets.
Put on the both switches flow
and fane and begin driving at
constant speed.
Calculate with the
table sets your flow
and indicate it with the
right number on the
potentiometer.
After few meters
driving at constant
speed, press the
« vitesse memorisee »
switch to record it, the
green light should
work.
If any problem appears
during the spreading, the red
light will work, then
please make the necessary
check.
At the end of the field, to
fill your tubes with seeds
use the switch
« amorçage » during
sufficient time.
Der Fahrzeuggeschwindigkeitssensor
sollte in einem Abstand von 0,5 bis 1 cm
des Rades montiert werden

Manual Zocon Z300 Seed drill
GREEN ROTOR YELLOW ROTOR
Speed 1 Speed 2 Speed 1 Speed 2
Kg /Hour
Kg /Hour
Kg /Hour
Kg /Hour
N°4
5.31Kg
N°4
6.90Kg
N°4
6.64Kg
N°4
8.95Kg
N°5
7.44Kg
N°5
9.67Kg
N°5
7.08Kg
N°5
9.74Kg
N°6
8.50Kg
N°6
11.04Kg
N°6
7.97Kg
N°6
10.63Kg
N°7
9.72Kg
N°7
12.63Kg
N°7
9.74Kg
N°7
12.40Kg
N°8
11.96Kg
N°8
15.55Kg
N°8
11.51Kg
N°8
15.94Kg
N°9
14.27Kg
N°9
18.56Kg
N°9
13.28Kg
N°9
17.71Kg
N°10
17.43Kg
N°10
22.65Kg
N°10
15.94Kg
N°10
21.25Kg
N°11
20.40Kg
N°11
26.52Kg
N°11
18.60Kg
N°11
24.79Kg
N°12
23.99Kg
N°12
31.18Kg
N°12
22.14Kg
N°12
29.22Kg
N°13
29.44Kg
N°13
38.27Kg
N°13
25.68Kg
N°13
34.53Kg
N°14
32.87Kg
N°14
42.74Kg
N°14
29.22Kg
N°14
39.85Kg
N°15
37.79Kg
N°15
48.62Kg
N°15
33.65Kg
N°15
45.16Kg
N°16
39.85Kg
N°16
51.80Kg
N°16
37.19Kg
N°16
50.47Kg
N°17
43.93Kg
N°17
57.11Kg
N°17
40.73Kg
N°17
54.90Kg
N°18
47.73Kg
N°18
62.09Kg
N°18
45.16Kg
N°18
60.21Kg
N°19
50.44Kg
N°19
65.58Kg
N°19
48.70Kg
N°19
65.53Kg
N°20
52.02Kg
N°20
67.63Kg
N°20
52.24Kg
N°20
69.95Kg
N°21
53.13Kg
N°21
69.07Kg
N°21
55.79Kg
N°21
74.38Kg
N°22
53.97Kg
N°22
70.16Kg
N°22
58.44Kg
N°22
77.04Kg
N°23
54.55Kg
N°23
70.90Kg
N°23
61.10Kg
N°23
81.46Kg
N°24
56.45Kg
N°24
73.38Kg
N°24
63.75Kg
N°24
85.89Kg
N°25
57.56Kg
N°25
74.32Kg
N°25
68.18Kg
N°25
91.20Kg
N°26
59.22Kg
N°26
76.98Kg
N°26
70.84Kg
N°26
96.52Kg
N°27
60.32Kg
N°27
78.42Kg
N°27
76.15Kg
N°27
101.83Kg
N°28
63.76Kg
N°28
82.88Kg
N°28
79.69Kg
N°28
107.14Kg
N°29
64.20Kg
N°29
83.46Kg
N°29
84.12Kg
N°29
112.02Kg
N°30
65.89Kg
N°30
85.62Kg
N°30
89.43Kg
N°30
119.54Kg

Manual Zocon Z300 Seed drill
RED ROTOR BLACK ROTOR
Speed 1 Speed 2 Speed 1 Speed 2
Kg /Hour
Kg /Hour
Kg /Hour
Kg /Hour
N°4
15.50Kg
N°4
18.82Kg
N°4
26.56Kg
N°4
38.74Kg
N°5
19.92Kg
N°5
23.24Kg
N°5
30.99Kg
N°5
44.27Kg
N°6
24.35Kg
N°6
28.77Kg
N°6
38.74Kg
N°6
56.45Kg
N°7
28.77Kg
N°7
34.31Kg
N°7
43.16Kg
N°7
63.09Kg
N°8
33.21Kg
N°8
39.85Kg
N°8
48.70Kg
N°8
69.73Kg
N°9
37.63Kg
N°9
44.27Kg
N°9
58.66Kg
N°9
84.12Kg
N°10
42.06Kg
N°10
49.81Kg
N°10
69.73Kg
N°10
99.62Kg
N°11
46.49Kg
N°11
55.34Kg
N°11
79.69Kg
N°11
115.11Kg
N°12
50.92Kg
N°12
60.88Kg
N°12
90.76Kg
N°12
130.61Kg
N°13
54.79Kg
N°13
64.19Kg
N°13
101.83Kg
N°13
146.10Kg
N°14
58.66Kg
N°14
69.73Kg
N°14
112.90Kg
N°14
161.60Kg
N°15
62.53Kg
N°15
74.16Kg
N°15
123.97Kg
N°15
177.10Kg
N°16
66.41Kg
N°16
79.69Kg
N°16
133.93Kg
N°16
192.59Kg
N°17
70.28Kg
N°17
81.91Kg
N°17
145.00Kg
N°17
208.10Kg
N°18
74.16Kg
N°18
87.44Kg
N°18
156.07Kg
N°18
223.59Kg
N°19
77.48Kg
N°19
89.65Kg
N°19
166.00Kg
N°19
327.98Kg
N°20
80.80Kg
N°20
95.19Kg
N°20
174.88Kg
N°20
251.26Kg
N°21
84.12Kg
N°21
98.51Kg
N°21
184.85Kg
N°21
264.54Kg
N°22
87.44Kg
N°22
68.62Kg
N°22
193.70Kg
N°22
277.82Kg
N°23
90.76Kg
N°23
105.15Kg
N°23
199.24Kg
N°23
284.46Kg
N°24
94.08Kg
N°24
109.58Kg
N°24
212.52Kg
N°24
304.39Kg
N°25
97.40Kg
N°25
112.90Kg
N°25
221.37Kg
N°25
317.67Kg
N°26
100.72Kg
N°26
117.33Kg
N°26
230.23Kg
N°26
329.85Kg
N°27
104.04Kg
N°27
120.65Kg
N°27
237.98Kg
N°27
340.92Kg
N°28
107.36Kg
N°28
125.07Kg
N°28
236.87Kg
N°28
350.88Kg
N°29
110.68Kg
N°29
129.50Kg
N°29
251.26Kg
N°29
359.73Kg
N°30
114.00Kg
N°30
132.82Kg
N°30
257.90Kg
N°30
368.59Kg

Manual Zocon Z300 Seed drill
Thickness Wire 2.5
3-Pin Plug
7-Pin Plug
7-Pin Plug
7-Pin Plug
Motor Rotor
Speed 1
3-Pin Plug
Control box
Motor Rotor
Speed 2
Fan
