Zonet ZEW1505 User manual

Page 1 of 9
1 About This Guide
This Quick Installation Guide only provides you some basic instructions. For more detailed
information, please refer to the User Manual.
Before you begin, you must have following at least:
A notebook /desktop pc with an available 32-bit Cardbus/PCI slot
At least a 300MHz processor and 32MB of memory
Cardbus/PCI controller properly installed and working in the computer
An 802.11g or 802.11b Access Point (for infrastructure Mode) or another 802.11g or
802.11b wireless adapter (for Ad-Hoc; Peer-to-Peer networking mode.)
2 Install Driver and Utility
Insert the Driver and Utility CD-ROM into the CD-ROM driver.
The Wizard should run automatically, and Figure 2-1 should appear. If it dose not,
Browse CD and double-click setup.exe . The wizard will run and install all necessary
files to your computer automatically.
Figure 2-1
 Select the installing language from the screen.

Page 2 of 9
Figure 2-2
Figure 2-3

Page 3 of 9
Figure 2-4
 Follow the Install Shield Wizard steps, and click Finish when done.
Figure 2-5
 Now turn off your PC or notebook

Page 4 of 9
3 Install Wireless adapter
3.1 ZEW 1505
 Power on your notebook, let the operating system boot up completely, and log in as
needed.
 Hold the adapter with the LOGO facing up and insert it into a Cardbus slot.
Figure 3-1
 If the Found New Hardware Wizard displays, choose i nstall the software
automatically (Recommended) , and click Next button. The driver will be installed
automatically.
Figure 3-2

Page 5 of 9
3.2 ZEW1605
 Open your PC case and locate an available PCI on the motherboard.
 Slide the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the
slot’s contacts. You may have to apply a bit of pressure to slide the adapter all the way in.
after the adapter is firmly in place, secure its fastening tab to your PC’s chassis with a
mounting screw. Then close your PC.
 Attach the external antenna to the adapter’s antenna port.
 Power on the PC.
Figure 3-3
 If the Found New Hardware Wizard displays, choose i nstall the software
automatically (Recommended) , and click Next button. The driver will be installed
automatically.
Figure 3-4

Page 6 of 9
3.3 ZEW1605A
 Open your PC case and locate an available PCI on the motherboard.
 Slide the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the
slot’s contacts. You may have to apply a bit of pressure to slide the adapter all the way in.
after the adapter is firmly in place, secure its fastening tab to your PC’s chassis with a
mounting screw. Then close your PC.
 Attach the extended antenna to the adapter’s antenna port.
 Power on the PC.
Figure 3-5
 If the Found New Hardware Wizard displays, choose i nstall the software
automatically (Recommended) , and click Next button. The driver will be installed
automatically.
Figure 3-6

Page 7 of 9
4 Configuration your wireless adapter
 The Wireless Client Configuration Utility screen will appear automatically.
Figure 4-1
 Click the Set Wizard(S) tab to start connecting to Wireless-AP.
Figure 4-2

Page 8 of 9
 Select Station(infrastructure), click Next
Figure 4-3
 To connect to one of the networks on the list, select the wireless network and click Next
Figure 4-4

Page 9 of 9
 Click OK (if the wireless network have network key, you should import the network key,
please refer to Wireless network adapter –user manual)
Figure 4-5
 Select Obtain an IP address automatically, Obtain DNS server address
automatically, and then Click Finish to complete configuration.
Figure 4-6
Congratulations! You’ve successfully configured your wireless adapter!
