ZoomSwitch ZMS20-UC User manual

Set-Up Guide for ZoomSwitch™ Model ZMS20-UC
Unplug the cable that is currently
connected to the left side or left
underside of your telephone set (the
other end will remain connected to
your headset base or amplier.)
Plug the cable you just pulled out in
Step 1 and plug it into the into the
accessory port (port B) of the Zoom
Switch.
Take the black phone cable that comes
with the Zoom Switch and plug the end
labeled Port A into Port A of the Zoom
Switch.
Plug the other side of the black phone
cable (labelled phone) into your
telephone.
Plug the included USB cable into the
Zoom Switch USB port.
Plug the other end of the USB cable
into your computer’s USB port.
Once connected, the device will
be installed as ‘ZoomSwitch USB
Adapter’.
1
4
2
5
3
6
A
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e
USB
Phone
(RJ9 Jack)
Accessory
(Headset/Handset)
A B
R
e
d
f
o
r
U
S
B
G
r
e
e
n
f
o
r
P
h
o
n
e

Set-Up Guide for ZoomSwitch™ Model ZMS20-UC
Testing:
Now that the Zoom Switch is set up, test it
by making regular phone calls, listening, and
talking through your computer.
To operate the Zoom Switch and move
between the USB and phone lines, just push
the large button in the center of the Zoom
Switch. You will see the indicator light change
accordingly.
Mute:
If you cannot hear, verify that the Zoom
Switch is not muted. A muted Zoom Switch is
indicated by a ashing light.
Volume:
You can also adjust the volume using the dial
located on the left side of the Zoom Switch.
If you are using a Cisco phone,
make sure the switch located on
the right side of the Zoom Switch is
set to “Cisco”. For all other phone
models, make sure the switch is set to
“Normal”.
Troubleshooting:
If you have trouble being heard on the USB
side, you may need to change the position of
the A/B polarity switch on the bottom of the
Zoom Switch.
7
Model:
ZMS20-UC
For support go to:
zoomswitch.com
