Zte A002ZT User manual

A002ZT
User Guide

1
A002ZT
A002ZT User Guide Contents
Introduction
Introduction.........................................................................2
Getting Started
Parts & Functions.............................................................. 6
USIM Card............................................................................ 7
Setup (Windows PC)
Device Recognition/Removal on Windows PC..................10
Installing/Uninstalling Driver (Windows PC).................. 11
Connecting with Windows Dialup....................................13
Setup (Mac)
Device Recognition/Removal on Mac...............................16
Installing/Uninstalling Driver (Mac)................................16
Settings (Using WEB UI)
Overview of WEB UI.........................................................20
WEB UI Layout on Computer........................................... 23
Connecting/Disconnecting Communication......................27
Data Traffic Settings...................................................... 29
Mobile Network Settings................................................. 32
Device.................................................................................60
Checking Notifications.....................................................97
Checking USB Modem Information.................................101
Show Support Website...................................................103
Appendix
Troubleshooting.............................................................. 106
Specifications..................................................................107
Warranty & Service........................................................ 109
Customer Service............................................................109
Safety Precautions
Safety Precautions.........................................................112
General Notes................................................................. 118
Specific Absorption Rate (SAR) Information for this
Product............................................................................ 119

2Introduction
Introduction
Before You Begin
Read "Safety Precautions" thoroughly for proper usage.
Accessible services may be limited by contract conditions.
Guide Usage Notes
Most operation descriptions are based on default settings.
Other Notations
This product is referred to as "USB modem" in this guide.
Operating Environment (Compatible
OSs)
Use USB modem in any of these operating environments.
Use outside these environments may affect performance.
Operating environment (hardware, connected peripherals,
installed applications, etc.) may also affect performance.
・For computer support, OS version upgrade information,
etc., see corresponding manufacturer's product support
documentation.
・The information for operating environment (compatible OSs)
listed here is information for August 2020.
Item Description
Compatible
Operating
Systems
Windows 8.1 / Windows 8.1 Pro /
Windows 8.1 Enterprise (32-bit/64-bit)
Windows 10 Home / Windows 10 PRO /
Windows 10 Enterprise / Windows 10
Education (32-bit/64-bit)
Mac OS X 10.10 to 10.15
Japanese and English editions supported.
* Modem mode unavailable for Mac
operating systems.
Memory
Requirements
Windows 8.1: 1 GB+ (32-bit)/2 GB+ (64-
bit)
Windows 10: 1 GB+ (32-bit)/2 GB+ (64-
bit)
Mac OS X: 512 MB+ (1 GB+ recommended)
Available Hard
Disk Capacity
400 MB+ recommended (200 MB+
required) (common to all operating
systems listed above)
Interface USB 2.0
Compatible
Browser
Microsoft Internet Explorer 8 or later
Firefox 45.0 or later
Safari 6.0 or later
Opera 40.0 or later
Google Chrome 45.0 or later
Microsoft Edge
Package Contents
The following items are included in the package. Please
confirm package contents before use. Contact SoftBank
Customer Support for missing items.
Keep accessories in a safe place.
・A002ZT (USB modem)
・クイックスタート(Japanese)
・お願いとご注意(Japanese)
Getting Started
・USB modem accommodates software updates. Use the latest
software.
・Note that connection speeds may drop or connections
may be disabled depending on line traffic or connection
environments.
・With an enterprise subscription contract, functions may be
restricted by an administrator. Depending on how functions
are restricted, some settings or operation as described may
be unavailable.
・A network connection that supports a flat-rate plan is
preset on USB modem beforehand (at time of shipping). The
network connection is subject to band restrictions of the
SoftBank network.
・Communication using USB modem may be disrupted if moving
between a base station and a femtocell or other smaller
base station.
If USB modem is set to automatically reconnect a network
connection, the IP address may change after reconnecting.
For details on network connection settings, see "Changing
Network Connection Settings."
・USB modem has a "NORMAL MODE" mode and a Windows
dialup connection "MODEM MODE." Change the mode using
"Modem Switch Tool." Download from the URL below.
https://www.ztedevices.com/jp/?soft=a002zt-tool-
download
・For details on creating a PC profile, see "A002 User Guide
~ Kitting Tool & Profile Generate Tool ~" supplied with the
tool provided separately to enterprise administrators.

3
Introduction A002ZT
Trademarks
・SoftBank, SoftBank's equivalent in Japanese and the
SOFTBANK logo are registered trademarks or trademarks of
SoftBank Group Corp. in Japan and other countries.
・ZTE, ZTE 中興 and logo are trademarks or registered
trademarks of ZTE Corporation in China and other countries.
Copyright © 2020 ZTE Corporation. All rights reserved.
・Microsoft®, Windows®, Internet Explorer, and Microsoft
Edge are trademarks or registered trademarks of US
Microsoft Corporation in the United States and other
countries. Microsoft Windows Operating System is indicated
in its abbreviated form as Windows.
・Apple, the Apple logo, Mac, Macintosh, and Safari are
trademarks of Apple Inc. registered in the United States and
other countries.
・TM and © 2020 Apple Inc. All rights reserved.
・Google and Google Chrome are trademarks of Google LLC.
・Firefox is a trademark or registered trademark of US Mozilla
Foundation in the United States and other countries.
・Opera is a trademark or registered trademark of Opera
Software ASA.
For details on Opera, go to http://www.opera.com/ja/.
・The names of the companies, products and services used in
this guide are registered trademarks or trademarks of the
respective companies.

4

Getting Started
Parts & Functions.............................................................. 6
USIM Card............................................................................ 7

6
Parts & Functions
Front/Top/Bottom
Part Description
USB
Connector Connect to computer USB port.
LED Status
Lamp
Check USB modem status from color and
flashing pattern.
Strapholder Attach a strap here.
USIM Card
Slot Install USIM Card
USB Connector
Raise and lower as shown.
USB Connector Precautions
Do not use forcefully bent at any direction or angle.
LED Status Lamp
Lights/flashes to indicate communication activity or errors.
LED Color
and Pattern Communication Activity
Red, lit
- Activating
- Searching for network
- Saving network
- Out of service area
Red, flashing
(rapidly and
evenly)
- Overheated at above 70°C
Red, flashing
(evenly)
- Waiting for PIN code entry
- Waiting for PUK code entry
- USIM Card completely locked
- USIM Card problem
Blue, lit 4G/LTE data in use
Blue, flashing
(rapidly and
evenly)
4G/LTE data in use, and overheated at
above 60°C
Blue, flashing
(evenly)
4G/LTE standby (other than in data
communication, and in service area)
Green, lit GSM/3G data in use
Green,
flashing
(rapidly and
evenly)
GSM/3G data in use, and overheated at
above 60°C
Green,
flashing
(evenly)
GSM/3G standby (other than in data
communication, and in service area)
Three colors
(red, green,
blue), flashing
Software updating
Removing Back Cover
Technical conformity mark indicating that USB modem
conforms to technical regulations pursuant to the Radio Law
and the Telecommunications Business Law can be viewed under
Back Cover.
Raise USB Connector, insert a flat-tipped stick (non-metal,
such as plastic tweezers) in the notch for removing the cover
( ○ ), and pry open as shown.
Back Cover lifts away.

7
Getting Started A002ZT
USIM Card
USIM Card is an IC card that contains customer information
including phone number.
Handling USIM Card
For USIM Card handling, see the following items.
IC chip
For USIM Card handling, see SoftBank Website.
https://www.softbank.jp/mobile/support/protect/usim/
・Always keep the IC chip clean.
・Wipe clean with a dry, soft cloth.
・Avoid applying labels. May damage USIM Card.
USIM Card Cautions
Observe the following when using USIM Card.
・Customer is responsible for any damage caused by
inserting USIM Card in an other-brand IC card reader, etc.
SoftBank Corp. is not responsible in such case.
・USIM Card is the property of SoftBank Corp.
・USIM is replaceable (at cost) in case of loss/damage.
・Return USIM Card to the company when cancelling
subscription.
・Returned USIM Cards are recycled for environmental
purposes.
・Note that USIM Card specifications and performance may
change without notice.
・It is recommended that you keep a separate copy of
information that is stored on USIM Card. SoftBank Corp.
is not responsible for damages from stored information
that is lost.
・Always follow emergency procedures to suspend service
if your USIM Card or USB modem (USIM Card inserted) is
lost/stolen. For details, contact Customer Service.
・Power off USB modem before installing/removing USIM
Card. Removing USIM Card while USB modem is operating
may cause USB modem to malfunction.
・USB modem requires a special USIM Card. The special USIM
Card cannot be used in a smartphone.
Installing USIM Card
Be sure USB modem is disconnected from the computer.
Open USIM Card Slot Cover
・With your finger(nail) in the notch on top of the cover, pull
as shown.
Insert USIM Card in USIM Card Slot
・Push and click into place, noting orientation of USIM Card
(notch/IC (gold) chip facing up).
・Be careful not to touch or scratch the IC chip when
installing USIM Card.
Close USIM Card Slot Cover
USIM Card is inserted.
・Align Cover with Slot, and press gently.

8
Removing USIM Card
Be sure USB modem is disconnected from the computer.
Open USIM Card Slot Cover
・With your finger(nail) in the notch on top of the cover, pull
as shown.
Remove USIM Card from USIM Card Slot
・Press inward until USIM Card clicks and pops out.
・Be careful not to touch or scratch the IC chip when
removing USIM Card.
Close USIM Card Slot Cover
USIM Card is removed.

Setup (Windows PC)
Device Recognition/Removal on Windows PC..................10
Installing/Uninstalling Driver (Windows PC).................. 11
Connecting with Windows Dialup....................................13

10
Device Recognition/Removal on
Windows PC
Device Recognition (Windows)
Turn on PC first.
When connecting USB modem to a PC for the first time,
install (set up) the driver.
Connect to PC’s USB port.
PC should recognize USB modem within a few seconds.
Device Removal (Windows)
Stop the connection, and check that data uploading/
downloading is completed before removing USB modem.
Stop the connection, and check that data uploading/
downloading is completed.
Remove USB modem
USB modem is removed.
Cautions for Removing USB Modem
Standby/Hibernation
USB modem may malfunction if PC enters standby
(suspend/resume) or hibernation with it connected. Be
sure to remove USB modem before leaving PC unattended,
etc. USB modem may malfunction if connected before PC
starts/restarts. Remove USB modem before starting/
restarting PC.
WEB UI
Exit WEB UI before removing USB modem. Do not remove
USB modem during transmissions.

11
Setup (Windows PC) A002ZT
Installing/Uninstalling Driver
(Windows PC)
When connecting USB modem to a PC for the first time,
install (set up) the driver.
Screenshots and steps described here are for Windows 10.
Depending on your operating system or environment, shown
screens and messages may differ.
Cautions for Installation/Uninstallation
Removing USB Modem
Do not remove USB modem during installation/
uninstallation. May cause installation/uninstallation
failure, system malfunction, or other system errors.
Administrator Privileges
Log in to an account with administrator privileges.
User Account Control
User Account Control dialog box may appear depending
on the settings of your operating system. Select "Yes" or
"Allow" and continue.
Installing the Driver in Windows
Turn on PC first.
Connect to PC’s USB port.
ZTEMODEM
Run AutoRun.exe
Once "A002ZT Hostless Modem" appears in start menu,
driver is installed.

12
Installing the Driver in Windows
Manually
If installation does not begin automatically or a screen is not
displayed for selecting installation options, install with the
following steps.
In start menu, Windows System File Explorer
This PC ZTEMODEM
Double-click AutoRun.exe
Once "A002ZT Hostless Modem" appears in start menu,
driver is installed.
Uninstalling Driver (Windows)
Remove USB modem from PC first.
Right-click start menu Apps and Features
A002ZT Hostless Modem Uninstall Uninstall
Yes Yes
Uninstallation starts.

13
Setup (Windows PC) A002ZT
OK
Once "A002ZT Hostless Modem" no longer appears in start
menu, driver is uninstalled.
Connecting with Windows Dialup
To set up a new dialup connection, phone number and
account information for the connection are necessary.
Use "*99#" or "*99***1#" as the phone number, and you
should check account information from SoftBank Website
(https://www.softbank.jp/biz/mobile/lineup/data/a002zt/
support/), the Internet service provider (ISP), or the network
administrator.
Screenshots and steps described here are for Windows 10.
Depending on your operating system or environment, shown
screens and messages may differ.
Set USB modem in "MODEM MODE" to make a dialup
connection. Change the mode using "Modem Switch Tool."
Download from the URL below.
https://www.ztedevices.com/jp/?soft=a002zt-tool-download
Connecting with Windows Dialup
Turn on PC first.
Click start menu Windows System Control Panel
Network and Internet Network and Sharing Center
Set up a new connection or network
Select connection option Connect to the Internet Next
・If confirmation window appears for using existing
connection, select "Set up a new connection anyway."
Dial-up
・If modem or TA other than USB modem is installed, screen
for device selection appears. Select USB modem ("Modem -
ZTE Proprietary USB Modem #2").
Enter phone number and account information you checked,
Create

14
In connecting screen, Skip Close
In "Network and Sharing Center," Change adapter settings
Right-click created connection icon Propaties
In properties screen and each Option / Security /
Networking / Sharing tab, make settings for obtained
connection
In properties screen, General tab, check that "Connect using"
is "Modem - ZTE Proprietary USB Modem #2 (COMXX)" /
"Phone number" is phone number obtained in step
Checkmark "Using dialing rules," Dialing Rules
Save/edit location information OK In properties
screen, OK
At bottom right of desktop, Click created setting
Dial-up Connection Connect
In connection screen, Dial
Dialup connection is established.

Setup (Mac)
Device Recognition/Removal on Mac...............................16
Installing/Uninstalling Driver (Mac)................................16

16
Device Recognition/Removal on
Mac
Device Recognition (Mac)
When connecting USB modem to a Mac for the first time,
install (set up) the driver.
Connect to Mac’s USB port.
Mac should recognize USB modem within a few seconds.
Device Removal (Mac)
Stop the connection, and check that data uploading/
downloading is completed before removing USB modem.
Stop the connection, and check that data uploading/
downloading is completed.
Remove USB modem from Mac
USB modem is removed.
Cautions for Removing USB Modem
Before Entering Sleep Mode
USB modem may malfunction if Mac enters Sleep mode
with it connected. Be sure to remove USB modem before
leaving Mac unattended, etc. USB modem may malfunction
if connected before Mac starts/restarts. Remove USB
modem before starting/restarting Mac.
WEB UI
Exit WEB UI before removing USB modem. Do not remove
USB modem during transmissions.
Installing/Uninstalling Driver
(Mac)
Screenshots and steps described here are for Mac OS X
10.15.4.
Depending on your operating system or environment, shown
screens and messages may differ.
Installing the Driver in Mac
Connect to Mac’s USB port
"ZTEMODEM" icon appears on desktop and "A002ZT
Hostless Modem" folder automatically opens.
・If no icon appears click ZTEMODEM.
Double-click A002ZT Hostless Modem
Enter user name and password OK
Driver is installed.

17
Setup (Mac) A002ZT
Uninstalling Driver (Mac)
If no longer using WEB UI, uninstall (delete) driver from Mac
with the following steps.
Applications Uninstall A002ZT Hostless Modem
Uninstall
Enter user name and password OK
Uninstallation starts.
Close
Once "A002ZT Hostless Modem" no longer appears in
application folder, driver is uninstalled.
Cautions for Installation/Uninstallation
Removing USB Modem
Do not remove USB modem during installation/
uninstallation. May cause installation/uninstallation
failure, system malfunction, or other system errors.
Administrator Privileges
Log in to an account with administrator privileges.
Language while Installing
Language while installing is according to the Mac operating
system settings. Change language before installation.

18
