Zte Verizon 4G User manual

This Proof Indicates Approximate Color Only. For Accurate Color Match, Use Approved Color Standard.
DO NOT USE COLOR FORMULAS ON THIS FILE.
Inks
THIS FILE MAY CONTAIN IMAGES OR ILLUSTRATIONS THAT ARE COPYRIGHT PROTECTED. CLIENT MUST OBTAIN PROPER LICENSING AND USAGE RIGHTS PRIORTO REPRODUCTION.
SUPPLIER IS RESPONSIBLE FOR CHECKING WORKING DRAWINGS BEFORE PLATES ARE MADE FOR ACCURACY IN MEASUREMENTS, PLATE TOLERANCE REQUIREMENTS,
REGISTRATION AND CONSTRUCTION DETAILING. ANY CHANGES MADE TO SUIT PRODUCTION REQUIREMENTS SHOULD BE APPROVED BY BOTHTHE CLIENT AND DESIGN DIRECTOR.
ALL COPY SHOULD BE PROOFREAD BY CLIENT AND LEGAL REQUIREMENTS CHECKED BY CLIENT’S LEGAL DEPARTMENT.
PROCESS
CYAN
PROCESS
MAGENTA
PROCESS
YELLOW
PROCESS
BLACK
NOTES: VARNISH LAYER HAS BEEN PROVIDED IN THIS FILE.
PROCESS COLOR VALUES ARE BASED ON ARTWORK PROVIDED AND HAVE NOT
BEEN ALTERED.
Project Client
Description
Designer Production Proofreader Client Services
Job Number
Produced By
Date
File Name Rev No.
Mary Salazar
11/02/11
In Box Collateral Verizon
75 x 105 User Guide
0
100035015
UG_EuFi890_CVR_75x105_NHS_V0_R2.ai
Finishes
MATTE
VARNISH
USER GUIDE
XXXX0000000(0.0) X
USER
GUIDE
GUÍA DEL
USUARIO
PLACEMENT OF LOGO
Verizon Jetpack™
4G LTE Mobile Hotspot
Model#: 890L
Global Ready™
USER GUIDE
XXXX0000000(0.0) X
USER
GUIDE
Verizon Jetpack™ 4G LTE Mobile Hotspot - 890L
LOGO: 4C PROCESS
VZW LOGO: KO TO WHITE
BACKGROUND: 4C PROCESS
TEXT: VERIZON RED
TEXT: VERIZON RED
LOGO: 4 COLOR PROCESS
10 mm
75 mm
105 mm

1
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted,
reproduced, translated or utilized in any form or
by any means, electronic or mechanical, including
photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We
reserve the right to make modifications on print
errors or update specifications without prior
notice.
Version No. : 1.0
Edition Time : 03-2012

2
CONTENTS
Welcome....................................................................4
Thank You for Choosing Verizon Wireless......... 4
Getting Started.......................................................5
Screen Indicators ....................................................... 6
Hardware Installation...........................................8
Installing the 4G SIM Card ...................................... 8
Inserting and Charging the Battery...................... 9
Removing the 4G SIM Card...................................11
Connecting to the Internet .............................. 12
Connecting Wi-Fi Enabled Devices To Your
Jetpack .........................................................................12
Follow these Steps...................................................13
Accessing the Internet............................................13
Advanced Configuration................................... 14
PIN Code Verification..............................................15
Basic Setup.................................................................16
WAN Settings.............................................................17
Router...........................................................................20
Wi-Fi Settings............................................................21
Firewall.........................................................................26
SMS ...............................................................................31

3
Navigating the Device ....................................... 32
WAN Info......................................................................33
WLAN Info...................................................................33
Settings........................................................................34
Message.......................................................................36
Usage of WPS....................................................... 36
Glossary.................................................................. 37
How to Get Help................................................... 41
Health and Safety Information ...................... 41
General Guidelines...................................................41
Aircraft Safety ..........................................................46
Hospital Safety .........................................................47
Road Safety................................................................47
Vehicles Equipped with an Airbag ......................48
Third Party Equipment............................................48
Efficient Use...............................................................49
CTIA Requirements..................................................49
Radio Frequency (RF) Exposure .........................50
FCC Compliance........................................................52
Consumer Limited Warranty........................... 55

4
Welcome
Thank You for Choosing Verizon Wireless
You’re now connected to the blazingly fast,
powerfully brilliant Verizon 4G LTE Network. This
guide will help you understand your new mobile
hotspot and all the things you can do with it at
home or abroad. So let’s get started.
This guide will show you how to unleash the
potential of your new Verizon Jetpack™. Assistance
is at your fingertips at verizonwireless.com/
support. Customer Service is at your disposal
at 1-800-922-0204 or in any Verizon Wireless
Communications Store.
Device Introduction
The Verizon Jetpack™ - 890L is a newly developed
4G LTE Mobile Hotspot. It is Global Ready™
providing flexible access for users to enjoy
high-speed internet applications around the
globe. When connected to the Verizon 4G LTE
Network, the Jetpack can support simultaneous
connections to up to 10 Wi-Fi enabled devices.
When connected in 2G or 3G mode the Jetpack
can support simultaneous connections to 5 Wi-Fi
enabled devices.

5
Getting Started
BUTTONS AND
INTERFACE DESCRIPTION
1. SCREEN Displays the menus and the
status of your Jetpack.
2. UP BUTTON Scroll up to select the
options.
3. DOWN BUTTON Scroll down to select the
options.
1
3
2
4
5 6
7

6
4. OK BUTTON

Confirm highlighted
selection.

When the Jetpack button
is locked, press once to
light up the screen, and
press again to unlock.
5. POWER SWITCH Power on/off your Jetpack.
6. MICRO USB PORT Charge your Jetpack.
7. RESET BUTTON
Press and hold to restore
your Jetpack to the factory
default settings.
Screen Indicators
Icon Description
Battery Status
4G Network
3G Network
2G Network
Data Connected

7
Icon Description
Signal Strength
and No Network Service
Roaming Signal Strength
Roaming
SMS
New SMS
SMS Full
Number of current Wi-Fi
connections
Settings

8
Hardware Installation
Installing the 4G SIM Card
If you have not already done so, please follow
these instructions for the installation of your new
4G SIM Card:
1. Remove 4G SIM Card from the outer card,
being careful not to touch the gold contacts.
CAUTION: Do not bend or scratch your 4G SIM
Card. Avoid exposing your 4G SIM Card to static
electricity, water or dirt.
2. Turn the power off. Remove the battery cover
and take the battery out. Locate the 4G
SIM card slot. Hold the card so the Verizon
Wireless logo on the card is facing you and the
gold contact points are properly aligned with
the 4G SIM Card slot.
3. Insert 4G SIM Card with the Verizon Wireless
logo facing you into the slot until it is fully
inserted.

9
NOTE: Your 4G SIM (Subscriber Identity Module)
Card is a small rectangular plastic card that stores
your phone number and important information
about your wireless service.
The 4G SIM Card MUST remain in the Jetpack
when in use.
Inserting and Charging the Battery
1. Use the thumb catch at the bottom of the
device to open the battery cover and align
the battery contacts with the terminals in
the battery compartment as shown. Push the
battery down until it clicks into place.
2. Place the battery cover over the battery
compartment ensuring that the arrow on
the device and the arrow on battery cover
are aligned. Then press the battery cover
downward until it clicks into place.
