Zultys BPS12 User manual

BPS12
Battery Power Supply
Manual Part Number 90-18020
Hardware Manual
Zultys Technologies
771 Vaqueros Avenue
Sunnyvale, CA 94085
USA
tel: [phone]
fax: [phone]
http://www.zultys.com

Notice
The information contained in this document is subject to change without notice.
Zultys Technologies makes no warranty of any kind with regard to this material, including, but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Zultys Technologies shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
Zultys Technologies assumes no responsibility for the use or reliability of interconnected
equipment that is not furnished by Zultys Technologies.
This document contains proprietary information which is protected by copyright. The contents of
this manual and the associated software are the property of Zultys Technologies, and all rights are
reserved. No part of this document may be photocopied, reproduced, stored in any computer
format, translated to another language, or publicly displayed without the prior written consent of
Zultys Technologies.
The information contained herein has been prepared by Zultys Technologies solely for use by
Zultys’s employees, agents, and customers. Dissemination or use of the information or concepts
contained herein to or by other parties is prohibited without prior written consent from Zultys
Te c h n o l o g i e s .
Zultys, the Zultys logo, ZIP2, ZIP4x4, ZIP4x5, MX250, MX1200, MXIE, BPS12, and “Enterprise
Media Exchange” are trademarks of Zultys Technologies and may be registered trademarks in
certain countries. All other names may be trademarks or registered trademarks of their respective
owners.
Revision History
Release Release Date
1.0.5 06 July 2004

BPS12 Hardware Manual i
Contents
Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Scope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Documentation Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Forms of Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Colophon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2 Warranty, Service, and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3 Receiving the Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Initial Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Shipment Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 In Case of Damage or Malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Returning Items for Repair or Replacement . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 4 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 BPS12 Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 5 Installing the BPS12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.2 Preparation for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chapter 6 Powering and Connecting the BPS12. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 Connecting the BPS12 to an ac power source . . . . . . . . . . . . . . . . . . . . . 29
6.3 Connecting the BPS12 to an MX250 or MX1200 . . . . . . . . . . . . . . . . . . . 31
6.4 Connecting Multiple BPS12 Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

ii BPS12 Hardware Manual
Contents
Chapter 7 Maintenance and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 Servicing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Appendix A Regulatory and Safety Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
A.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
A.2 EMC Emission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
A.3 EMC Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

1
Chapter 1
Introduction
1.1 Scope
1.1.1 Audience
This manual is intended for properly trained service personnel and technicians who need to
install the BPS12 Battery Power Supply. The manual assumes you are familiar with electronic
circuitry and wiring practices.
1.1.2 Installation and Use
1. Unpack the product and verify the items as described in chapter 3, starting on page 11.
2. Prepare the site as described in chapter 5, starting on page 21.
Warning The BPS12 is designed to be installed by qualified personnel only. Installation by
unqualified individuals may result in injury and damage to the BPS12 and
surrounding equipment.
Warning This equipment is to be installed and maintained by service personnel only as
defined by AS/NZS 3260 Clause 1.2.14.3 Service Personnel.
Warning The BPS12 must be installed in a secure location that has access restricted to
qualified personnel only. Placing the BPS12 in a location accessible by unqualified
individuals may result in bodily injury and damage to the BPS12 and surrounding
equipment.
3. Install the BPS12 as described in chapter 5, starting on page 21.
4. Connect the devices that are to be powered by the BPS12.

2
BPS12 Hardware Manual
Warning Read and understand the installation instructions before you install the equipment
or connect it to its power source.
1.1.3 What this Manual Includes
This manual provides detailed information and instructions on the hardware and proper
installation of the BPS12 Battery Power Supply. It provides ordering numbers and descriptions for
parts that are sold directly by Zultys.
The manual describes how you should receive the product, how to obtain service and support,
warranty information on the BPS12, a description of the front and panels, installation procedures,
and maintenance instructions.
1.1.4 What this Manual Does Not Include
This manual does not describe the features and functionality of the BPS12. The manual does not
discuss technology details, pricing, names of sales representatives, or names of distribution
channels.
Access the Zultys web sites for all further information. Zultys is very open about its products and
most of the manuals are available on line at:
http://www.Zultys.co.uk UK and Ireland
http://www.Zultysau.com Australia
http://www.Zultys.co.nz New Zealand
http://www.Zultys.com.cn China
http://www.Zultys.com USA, Canada, and all other countries
1.2 Ordering Information
Figure 1-1 shows the ordering numbers for BPS12 hardware.
Figure 1-2 lists the accessories included with the BPS12.
Zultys
Part Description
90-05020 BPS12 with Battery Power Cable and power cord for North America, Taiwan, and Japan
90-05021 BPS12 with Battery Power Cable and power cord for UK and Hong Kong
90-05022 BPS12 with Battery Power Cable and power cord for continental Europe (Schuko plug)
90-05023 BPS12 with Battery Power Cable and power cord for Australia and New Zealand
90-05024 BPS12 with Battery Power Cable and power cord for Israel
90-21004 Battery Power Cable
35-10008 10 Amp Fuse
35-10009 16 Amp Fuse
Figure 1-1 Ordering Numbers for BPS12 Hardware

1. Introduction
3
1.3 Documentation Overview
1.3.1 Organization
This user’s manual describes:
•how to select a site for the BPS12
•how to unpack the equipment
•how to mount the equipment in a rack
•how to wire the system to other peripherals
1.3.2 Special Paragraph Styles
The following are the notices that are used to attract special attention to certain items. They set
text off from the main body of the manual. These notices also appear in other languages where
required by certain regulatory bodies:
Important This notice contains special information that should not be ignored.
Caution This notice calls attention to a condition or procedure which, if not observed, could
result in damage to the BPS12.
Warning This notice indicates that if a specific procedure or practice is not correctly
followed, permanent damage to the BPS12 and personal injury may result.
Danger This notice warns you of imminent hazard to yourself and others if proper
procedures are not followed.
Zultys
Part Description
80-05010 Rack mount brackets
58-20002 Rack mount bracket screws
58-20003 Equipment mounting screws – metric (M6x10)
58-20004 Equipment rack screws (#12-24)
Figure 1-2 Ordering Numbers for BPS12 Hardware

4
BPS12 Hardware Manual
1.4 Forms of Documentation
1.4.1 Printed
The printed version of this manual is updated as required.
1.4.2 PDF
This manual is available in PDF format. You can download the PDF file from the Zultys web site
at:
http://www.zultys.com
You can obtain old versions of the manual that may describe the hardware that you have, the
manual that was used to produce the most recently printed manual, or the latest manual that
describes all the latest features of the product. You can identify the version of the manual from
the title page, opposite the table of contents (page 2 of the PDF file).
When you use the PDF file, you can click on any reference in the text. This powerful feature
allows you to follow the references in the text very easily. Using Acrobat, you can then return to
the page you were previously reading. This is a huge benefit to you if you want to study a small
area of the product.
1.5 Colophon
This document was produced on personal computers using Adobe’s FrameMaker for Windows.
The printed book is printed by an offset process.
The headings are set in Swiss 721, Bitstream’s version of the Helvetica™ typeface; the copy is set
in Zapf Calligraphic, Bitstream’s version of the Palatino™ typeface; notices are set in Swiss 721 or
News Gothic, Bitstream’s version of the Kingsley-ATF Type Corporation typeface. The drawings
were produced using Adobe Photoshop, Adobe Illustrator, and Microsoft Visio.
1.6 Documentation Feedback
Zultys appreciates any constructive feedback on all our documentation. If you have comments or
error reports on any Zultys documentation, please submit your feedback to:
Technical Publications Department
Zultys Technologies
771 Vaqueros Avenue
Sunnyvale, California 94085 USA
[e-mail]

5
Chapter 2
Warranty, Service, and Support
2.1 Introduction
Zultys wants you to get the most out of the product you have purchased. To that end, we offer
you:
•hardware warranty (for failure of the hardware)
•technical support (in case of difficulty)
Zultys makes each of these available to you under different terms and conditions. This chapter
describes what is offered and the conditions of the coverage.
2.2 Installation
Warning The BPS12 is designed to be installed by qualified personnel only. Installation by
unqualified individuals may result in injury and damage to the BPS12 and
surrounding equipment.
You can install the BPS12 yourself or arrange for someone else to install it for you. Zultys does not
offer installation. If you purchased the BPS12 from a VAR or distributor they will be able to offer
you installation services. If you bought the product from Zultys directly you may be able to obtain
installation services from a third party contractor.
If you have purchased the BPS12 from Zultys and now think that you need assistance to install
and configure the system, you should obtain that assistance. You should not proceed with the
installation and configuration. Zultys may be able to help you locate a suitable third party to help
you, but Zultys and the technical support at Zultys cannot assist you directly with the installation.

6
BPS12 Hardware Manual
2.3 Warranty
2.3.1 General
Zultys Technologies (Zultys) provides a warranty to the purchaser of its products as outlined
below. For purchases made in the USA, Canada, the UK, China, and Australia, the purchaser is
the end user. For all other sales, the purchaser is Zultys’ reseller or distributor, who has sold you,
the end user, the product.
2.3.2 Products Sold in the USA to USA Customers
This section represents Zultys’ standard warranty at the time that this manual was produced.
These terms apply to sales made in the USA to USA customers.
2.3.2.1 Products Covered and Period
1. Zultys hardware products are warranted against defects in material and workmanship. If
Zultys receives notice of such defects during the warranty period, Zultys shall at its option
either repair or replace hardware products that prove to be defective. Some newly
manufactured products purchased may contain selected re-manufactured parts equivalent
to new in performance.
2. Zultys software and firmware products which are designated by Zultys for use with a
hardware product, when properly installed on that hardware product, are warranted not to
fail to execute their programming instructions due to defects in materials and workmanship.
If Zultys receives notice of such defects during the warranty period, Zultys shall repair or
replace software media and firmware which do not execute their programming instructions
due to such defects. Zultys does not warrant that the software, firmware, or hardware will
meet your requirements or that their operation shall be uninterrupted or error free.
3. If Zultys is unable, within a reasonable time, to repair or replace any product to a condition
as warranted, Buyer shall be entitled to a refund of the purchase price upon return of the
product to Zultys.
2.3.2.2 Supplemental Statements
Supplemental statements setting forth the duration and implementation of warranty and
installation applicable to purchased products are incorporated herein.
2.3.2.3 Duration and Commencement of Warranty Period
Unless otherwise agreed to in writing, the warranty period is three years. The warranty period
begins on the date you received the product.
2.3.2.4 Confirmation of Delivery Date
If you request warranty, Zultys may require proof of your date of purchase of the system. You
will need to provide Zultys with a copy of your invoice showing the date that you bought the
product and the name and address of the distributor that sold you the product. Zultys will not
ask you for this information if you bought the product directly from Zultys.

2. Warranty, Service, and Support
7
2.3.2.5 Obtaining Warranty Service
For warranty service or repair, this product must be returned to a service facility designated by
Zultys. Zultys may repair on-site at the option of the Buyer. The Buyer is then responsible for
travel charges and applicable additional expenses for such services.
Buyer shall prepay shipping charges to Zultys and Zultys shall pay shipping charges to return the
product to Buyer. However, Buyer shall pay all shipping charges, duties, and taxes for products
returned to Zultys from another country.
2.3.2.6 Limitation of Warranty
1. The foregoing warranty shall apply only when:
•The product has not been abused, misused, or improperly or inadequately maintained by
the Buyer; and
•The defect has not been caused by normal wear and tear; and
•The defect is not the result of voltage surges or brownouts, lightning, water damage or
flooding, fire, explosion, earthquakes, tornadoes, acts of aggression or war, or by any
similar phenomenon; and
•All interconnected software or hardware has been either supplied by Zultys or approved
for use by Zultys in writing prior to its use; and
•There has been no unauthorized modification of the product; and
•The product has not been operated outside of the environmental or other specifications;
and
•There was proper site preparation, installation, and maintenance; and
•The defect is reported by the original purchaser of the product.
2. Zultys assumes no responsibility for the use or reliability of interconnected equipment that
is not furnished by Zultys.
3. THE WARRANTY SET FORTH ABOVE IS EXCLUSIVE AND NO OTHER WARRANTY,
WHETHER WRITTEN OR ORAL, IS EXPRESSED OR IMPLIED. ZULTYS SPECIFICALLY
DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
2.3.3 Extended Warranty for Products Sold in the USA to USA Customers
You can extend your warranty for additional periods, each of two years. The price for this
extension is different depending on whether you purchase the extended warranty at the time you
place your order for the system, during a period of coverage, or at a time when you no longer
have coverage. Contact your Zultys sales representative for current pricing.
2.3.4 Products Sold Outside of the USA
If you have purchased your product from a distributor of Zultys’ products outside the USA,
Canada, the UK, China, and Australia, that distributor provides you with warranty on the
product. The terms of the warranty under which your product was purchased may differ from

8
BPS12 Hardware Manual
the terms in section 2.3.2 on page 6. Zultys requires that its distributors provide warranty terms
to you that are similar to the terms outlined in this section, and that comply with the local laws
and expectations of the country in which you reside.
Contact your Zultys sales representative for the details of the warranty that covers your product.
2.3.5 Repairs to the Hardware
2.3.5.1 Verification
Contact your Zultys sales or service representative if you believe that your BPS12 hardware is
faulty. In the USA and Canada, you may need to contact Zultys’ technical support to confirm that
the equipment is faulty. Follow the procedures in section 2.4.3 on page 9 before calling.
If Zultys’ sales or service representative determines that there may be a problem with your
hardware, you will be issued an RMA number.
2.3.5.2 Warranty Repairs
If your hardware is covered under a warranty, see section 2.3 on page 6 for details of the terms of
the repair.
2.3.5.3 Out of Warranty Repairs
If the equipment is no longer covered by warranty, and if you do not have a maintenance
contract, you will have to pay for the repairs. Contact your Zultys sales or service representative
to obtain the current repair prices and payment terms. Outside the USA, contact the distributor
responsible for your territory.
2.3.5.4 Returning to Zultys
See section 3.4.6 on page 13 for details on returning equipment to Zultys.
2.4 Support
2.4.1 Resources
This section suggests ways to save yourself time by checking for answers yourself and ruling out
common problems.
If you have a question about the way the BPS12 works, the best way to get an accurate, immediate
answer is to try one or all of these approaches first.
•Check the index or table of contents of this manual for the topic you need.
•See the BPS12 technical support information on Zultys’ World Wide Web site.
If you take these steps and still cannot find the answer, contact your sales representative,
distributor, or Zultys.

2. Warranty, Service, and Support
9
2.4.2 Contacting your Reseller
If you bought your product from a reseller and not directly from Zultys, you should contact them
first about questions related to the product. The reseller that sold the product to you has charged
you money for this support and you should therefore expect that they will assist you.
Often, a reseller will provide you a maintenance contract as part of your purchase, so that the
reseller will support you for a period of time after you receive the product. Verify with your
purchasing department that you have a support contract for your BPS12.
If the reseller is unable or unwilling to assist you, or if you bought the product directly from
Zultys, contact Zultys’ technical support directly.
2.4.3 Using Zultys’ Technical Support
Zultys provides you with 30 days free technical support with the purchase of a system. The period
of technical support starts on the first day that you make a call to technical support and ends on
the 30th calendar day from the first time that you called.
2.4.3.1 Technical Support by Web
Zultys offers support through a web incident tracking system. You can use this system to report
and track your support cases. You can log into the system at anytime create a case or view the
status of the resolution for your case. To log into the web incident tracking system, access:
www.Zultys-support.com
2.4.3.2 Technical Support by E-Mail
If possible, Zultys’ technical support will resolve your problem efficiently by e-mail. Send the
serial number of your BPS12 along with a description of your problem to:
[e-mail]
If the problem cannot be resolved by e-mail, Zultys’ technical support will call you or wait for
your call.
2.4.3.3 Calling Technical Support
Be prepared when you call. When you call to speak to Zultys technical support, you are likely to
get an immediate resolution to your problem if you are ready with certain types of information:
1. E-mail a problem report in advance of calling. Allow Zultys technical support at least four
hours to review your e-mail. In your e-mail, state what it is that you think is wrong.
2. When you call, be at your computer, with your system connected to the BPS12 hardware.
3. Ensure that your surrounding area is quiet and that you can hear the technical support
person.
4. Zultys’ technical support can assist you best if you are ready to describe the sequence that
led to the problem.
5. Know exactly what you did before the problem occurred.
6. Have a pen or pencil and paper ready to take notes.

10
BPS12 Hardware Manual
Use Zultys’ technical support to solve problems that you have tried diligently to solve by yourself.
You may contact Zultys’ technical support at the following number. You must pay for any phone
charges:
[phone]

11
Chapter 3
Receiving the Equipment
3.1 Initial Inspection
When the shipment of your BPS12 arrives, inspect the shipping boxes for external damages, and
record any discrepancies. Save the boxes and packing material in case you need to ship the system
to another facility. Always retain the packing materials if you suspect that part of the shipment is
damaged — the carrier may need to inspect them.
Warning Do not attempt to use the equipment if it appears damaged. Immediately report
the damages to Zultys or a local Zultys sales representative.
3.2 Shipment Contents
3.2.1 Verify Contents
There are few hardware options for the BPS12. Upon delivery of your system, inspect the packing
list, and confirm that all items listed on that note were received. Compare the packing slip with
your purchase order. Your BPS12 is usually shipped with an ac power cord, one battery power
cable, rack mount brackets, and sufficient screws to securely mount the power supply to your
equipment rack.
Ensure that there are no discrepancies before you start installing the device as described in
chapter 5, starting on page 21.
Important If you suspect that there are discrepancies or that the equipment is not fully
functional, contact Zultys or your Zultys sales representative immediately.
Retain all packing materials and the shipping note for Zultys or its representative
to inspect. ZULTYS CANNOT BE HELD RESPONSIBLE IF YOU CLAIM THAT
AN ITEM IS MISSING, AND YOU HAVE NOT INFORMED ZULTYS WITHIN
THREE DAYS OF RECEIPT, OR IF YOU HAVE NOT RETAINED ALL PACKING
MATERIALS FOR INSPECTION.

12
BPS12 Hardware Manual
3.2.2 Serial Numbers
Verify the serial numbers of each item and compare them with the serial numbers on the packing
lists. The serial number is a five digit alphanumeric code printed on a white barcode label.
3.3 In Case of Damage or Malfunction
Notify your Zultys sales or service representative under any of the following conditions:
•the shipping container or any of the contents appear damaged
•an item is missing
•there is a discrepancy between the packing slip and the equipment received
•the equipment does not function correctly
Your local Zultys sales representative will arrange for repair or replacement, at Zultys’s
discretion. In certain cases, Zultys may require a claim settlement.
3.4 Returning Items for Repair or Replacement
3.4.1 Warranty Coverage
Before returning merchandise to Zultys for repair or replacement, you must ensure that the items
are under warranty. Read chapter 2, starting on page 5, for details on the warranty of Zultys’s
products. If you are unsure about the warranty of your merchandise, call your local Zultys sales
representative for clarification. You must obtain an RMA before returning any merchandise from
Zultys; this includes equipment covered under warranty.
For merchandise not under warranty, Zultys offers extended warranty. Call your local Zultys
sales representative for pricing on extended warranty for your merchandise.
3.4.2 Obtaining RMA Number
If you believe that something is wrong with the equipment, call Zultys’s inside sales department
to obtain a return merchandise authorization (RMA) number. If the problem is technical in
nature, Zultys may first try to diagnose the problem over the telephone. If the problem cannot be
resolved over the telephone, Zultys will issue an RMA number and give you specific instructions
for the return of the merchandise to Zultys’s facilities.
If you have purchased Zultys’s products through a distributor outside the US, contact the
distributor for specific instructions. Zultys issues RMA numbers for customers who buy its
products directly from Zultys. Distributors will offer their own service and support for Zultys’s
products.
3.4.3 Describing the Problem
If you are returning equipment to Zultys for service, attach a tag or sheet of paper to the
equipment giving the following details:
•your company or institution’s name, address, and phone number

3. Receiving the Equipment
13
•the main person to contact, an alternative contact, and their phone numbers if different from
the main phone number
•the return shipping address and any special shipping instructions
•the model number and serial number of the equipment being returned
•a description of the failure (If failure is intermittent, describe its frequency and special
condition that initiate the failure.)
•any additional comments
3.4.4 Accessories
Do not return any of the accessories with the equipment unless you suspect that one of them is
faulty. If you return an accessory, place a tag on it that clearly identifies it as yours, and briefly
explain the problem.
3.4.5 Packing
Wherever possible, use the original packing materials to ship the equipment. If these are not
available, containers and cushioning material similar to those originally used are available from
Zultys.
If it is inconvenient to obtain supplies from Zultys, use a strong, triple-walled shipping carton.
Place about 70 mm (3 in) of cushioning material around all sides of the equipment.
Zultys is not responsible for any damage that occurs during shipment back to the factory.
3.4.6 Shipping
Obtain from your nearest Zultys sales or service representative the correct address to which you
should return the equipment. Clearly mark the container with Zultys’s address and your own
address. Ship the package prepaid and insured to Zultys.
The method of shipment which Zultys will return repaired merchandise back to your facility will
be the same method by which you shipped the merchandise to Zultys. For example, if you
shipped merchandise to Zultys by ground shipment, Zultys will return the merchandise to you
by ground shipment. If the merchandise must be repaired and returned to you as soon as
possible, you must arrange for the merchandise to be shipped to Zultys by overnight shipment.
3.4.7 Correspondence
In any correspondence subsequent to the return of equipment, always refer to the equipment by
model number and serial number.

14
BPS12 Hardware Manual

15
Chapter 4
Hardware Description
4.1 Introduction
This chapter describes the BPS12 hardware and the status indicators located on the device.
4.2 Panel Descriptions
4.2.1 Front Side of the BPS12
The front side of the BPS12, shown in figure 4-1, displays the BPS12 label on the right side of the
panel and features three LEDs in the upper left corner. This side contains no wiring connectors.
The numbers in the figure correspond to the following descriptions:
1. Power LED – See section 4.3.1 on page 17 for a description of the Power LED.
2. Load LED – See section 4.3.2 on page 17 for a description of the Load LED.
3. Status LED – See section 4.3.3 on page 18 for a description of the Status LED.
Figure 4-1 Front Side of BPS12
BPS12
Battery Power Supply
123

16
BPS12 Hardware Manual
4.2.2 Rear Side of BPS12
The rear side of the BPS12, shown in figure 4-2, is the side that has the power connectors, fuses,
and standby switch. The numbers in the figure correspond to the following descriptions:
1. Master output fuse – This 16 A, 5 x 20 mm, quick acting, high current fuse is in series with the
–48VDC that is supplied to the output. This fuse protects all six dc power outputs. Replace
this fuse only with a fuse, obtained from Zultys, of the same rating.
2. Individual output fuse – One fuse is provided for each dc power output. Each fuse is a 10 A
5 x 20 mm quick acting, high current fuse. Fuses are in series with their dc power output.
Replace this fuse only with a fuse, obtained from Zultys, of the same rating.
3. dc power output – The BPS12 provides six DC power outputs of –48 Vdc. You can connect each
output to an MX250 or an MX1200. You may also connect this output to other BPS12 power
supply power outputs when connecting multiple BPS12 units in parallel. When connecting
the dc power output to these devices, you must only use the battery power cable supplied
by Zultys.
4. ac input – Provides a universal fused input for ac power. You can insert 100 Vac to 240 Vac at
47 Hz to 63 Hz.
5. Power LED – See section 4.3.1 on page 17 for a description of the Power LED.
6. Load LED – See section 4.3.2 on page 17 for a description of the Load LED.
7. Status LED – See section 4.3.3 on page 18 for a description of the Status LED.
8. Standby Switch – The standby switch connects the dc power source to the dc power outputs.
When the switch is turned off, the BPS12 does not provide power through any of the dc
power outputs. The BPS12 provides power through all dc power outputs when the switch is
turned on.
9. Serial Number – This is the serial number that identifies the BPS12 chassis. Refer to this
number when identifying the system to a technical support representative or when
returning the BPS12 for repair or replacement.
Figure 4-2 Rear Side of BPS12
BPS12
Part 89-05000
Serial No.
T16 AH, 250V
T10 AH, 250V
WARNING
No operator serviceable parts inside. Refer
servicing to service trained personnel.
–48 V
T10 AH, 250V –48 V
1
2
3
4
2
2
2
2
2
3
3
3
3
3
6
57 8
9
