Zykronix ZIP10-KSC User manual

www.Zykronix.com
User Manual
Installation and Programming
Door Access Control
VoIP Interface
IP Door Phones
IP ZIP1X Series

www.zykronix.com
Notification
Notification is hereby given that Zykronix International Inc. reserves the right to modify, change, update or revise
this document from time to time as required without the prior obligation to notify any person, company or
organization. Further, Zykronix International Inc. makes no warranty or representation, either express or implied,
with respect to merchantability, or fitness of its products for a particular purpose.
© 2015 Zykronix International Inc.
This document or any parts thereof are not to be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying, recording, or information storage and retrieval systems for any purpose
whatsoever without the express written permission of Zykronix International Inc.

www.Zykronix.com
Table of Contents
1Introduction ................................................................................................................................................................1
1.1 List of Available Models...................................................................................................................................2
2Product Overview.......................................................................................................................................................3
3IP Door Phone Package Content...............................................................................................................................4
“What’s In The Box” ..........................................................................................................................................................4
4IP Door Phone Front Panel........................................................................................................................................5
5IP Door Phone Main Functionality.............................................................................................................................6
6Installation..................................................................................................................................................................7
6.1 Mounting..........................................................................................................................................................7
6.2 Connections.....................................................................................................................................................9
6.3 Reset Device to Factory Default Configuration .............................................................................................12
7Programming ...........................................................................................................................................................14
7.1 Access to Web Management Interface..........................................................................................................14
7.2 Home Screen.................................................................................................................................................15
7.3 Network Parameters......................................................................................................................................17
7.3.1 Network Configuration Parameters...........................................................................................................17
7.3.2 Network -> HTTPS Activation....................................................................................................................18
7.3.3 Network / NAT Traversal...........................................................................................................................19
7.3.4 Auto Provision ...........................................................................................................................................20
7.4 SIP Parameters..............................................................................................................................................21
7.4.1 SIP Account Screen ..................................................................................................................................21
7.4.2 SIP / Port Settings.....................................................................................................................................21
7.4.3 SIP Audio Codecs .....................................................................................................................................22
7.4.4 SIP Video Codecs .....................................................................................................................................22
7.4.5 SIP Advanced Settings..............................................................................................................................23
7.5 Telephony......................................................................................................................................................24
7.5.1 Telephony Parameters..............................................................................................................................24
7.5.2 Day and Night Settings..............................................................................................................................25
7.5.3 Speed Dial and System Subscribers Table...............................................................................................26
7.6 Door Functions...............................................................................................................................................27
7.6.1 Door Functions / Parameters ....................................................................................................................27
7.6.2 Door Access Codes...................................................................................................................................28
7.6.3 Sensor .......................................................................................................................................................29
7.6.3.1 Sensor Door Status Control..............................................................................................................30
7.6.4 LED Display Settings.................................................................................................................................32
7.7 System Parameters .......................................................................................................................................33
7.7.1 Volumes.....................................................................................................................................................33
7.7.2 NTP and Time (System Time Configuration) ............................................................................................33
7.7.3 Camera......................................................................................................................................................35

www.Zykronix.com
7.8 Administration Parameters ............................................................................................................................36
7.8.1 Save Configuration File / IP Door Phone Backup .....................................................................................36
7.8.2 Restore Configuration ...............................................................................................................................37
7.8.3 Firmware Update.......................................................................................................................................38
7.8.4 Firmware Local Update .............................................................................................................................41
7.8.5 Set to Default.............................................................................................................................................42
7.8.6 Restart / Cold Reset..................................................................................................................................42
7.8.7 Web-Management Credentials..................................................................................................................43
7.8.7.1 Change WEB Administrator Login Credentials.................................................................................43
7.8.7.2 Change WEB User Login Credentials ..............................................................................................44
7.8.8 Syslog Server Settings..............................................................................................................................44
7.8.9 Ping Test ...................................................................................................................................................46
8User Operations.......................................................................................................................................................47
8.1 Access by using the ‘Door Access Code’ ......................................................................................................47
8.2 Door Opening by Using the External Switch Button......................................................................................48
8.3 The Door Status Sensor / Serial Doors Opening...........................................................................................48
8.3.1 Serial Door Opening..................................................................................................................................48
8.4 Call to the Day / Night Operator.....................................................................................................................49
8.4.1 Peer-to-Peer Calls.....................................................................................................................................49
8.5 Direct Call to Destination Number .................................................................................................................50
8.6 Dialing by Using Speed Dial Destinations .....................................................................................................50
8.6.1 Speed Dialing by Using the SPD Code.....................................................................................................51
8.6.2 Speed Dialing by Using the LED Display Search......................................................................................51
8.7 Door Opening from IP Extension by Using the Extension’s Door Opening Code .........................................51
8.8 Setting the Maximum Conversation Time......................................................................................................52
8.9 Case Opening Alarm .....................................................................................................................................53
8.10 Door Opening Report in the Syslog Server ...................................................................................................53
9Technical Specification............................................................................................................................................56

1
www.Zykronix.com
1Introduction
The ZIP10 Series IP Door Phones offer a wide range of options for both indoor / outdoor access control and door
entry options, based on industry standard SIP protocol.
The ZIP10 IP Door Phones are standalone SIP phones, which enhance the functionality of a VoIP network by
providing entrance door connectivity, access control, video monitoring and more.
The ZIP1 Series are designed using cutting edge technology, incorporating a high quality full duplex speakerphone
with microphone and speaker volume settings for optimum environmental performance as well as a built in
electromagnetic lock controller.
All models are simple to set up, have modern aesthetics and are made of durable construction and provide “plug and
play” installation.
Model Nomenclature:
ZIP10-KC/SB
ZIP10 –This is the ZIP10 Series Model
K/S –Model Number –“K” Keypad / “S” Single Call Button
S –Piezo Faceplate
B - Acrylic Faceplate
C - Camera
ZIP10-KSC
ZIP10-KS
ZIP10-SSC
ZIP10-SS

2
www.Zykronix.com
1.1 List of Available Models
Model
Description
ZIP10-KCS
IP Door Phone, Piezo Keypad, Integrated Internal Video Camera
ZIP10-KS
IP Door Phone, Piezo Keypad
ZIP10-SSC
IP Door Phone, Piezo Single Button, Integrated Internal Video Camera
ZIP10-SS
IP Door Phone, Piezo Single Button
ZIP10-KBC
IP Door Phone, Touch Keypad, Integrated Internal Video Camera
ZIP10-KB
IP Door Phone, Touch Keypad
ZIP10-SBC
IP Door Phone, Touch Single Button, Integrated Internal Video Camera
ZIP10-SB
IP Door Phone, Touch Single Button
ZIP10-SBC
ZIP10-KBC
ZIP10-KB
ZIP10-SB

3
www.Zykronix.com
2Product Overview
Zykronix IP ZIP10-x Door Phones are smart, surface mounted access control devices connected to an IP network
allowing door entry control and monitoring. They are designed for both indoor and outdoor use and are constructed in
an aluminum case with piezo or touch keypads.
The Zykronix IP Keypad and Single Button versions support the following features:
Feature
Keypad
Single
Button
Multiple door access codes
V
X
Door opening from any extension
V
V
Programmable day and night destinations
V
V
Integration with local LAN and VoIP networks
V
V
Network Configuration: DHCP or Static
V
V
Authorized registration with existing VoIP switching system (SIP Proxy)
V
V
Automatic busy & disconnect detection
V
V
99 Speed Dialing Memories
V
X
Up to 99 System accounts
V
X
Destination No answer call forwarding
V
V
Day and Night weekly time profiles
V
V
Separate Day & Night destinations
V
V
Informative Display
V
V
Speed dial memory scrolling
V
X
External buttons
V
V
Two separate doors control
V
V
POE-Power over Ethernet
V
V
High quality speakerphone with WEB volume control
V
V
High quality Video over IP
V
V
Web Management interface
V
V
Web GUI password protection
V
V
Software upgrade capabilities
V
V
Integral Card reader ( * Optional)
V
V
Door Status Detectors ( * Optional)
V
V
Backlit keypad with stylish design ( * Indoor Touch keypad)
V
V
Weather resistant and anti-vandal PIEZO keypad
V
V
Case Opening Alarm
V
V

4
www.Zykronix.com
3IP Door Phone Package Content
“What’s In The Box”
IP Door phone unit
Metal rear cover
Rear rubber mat
Set of connectors
Hex key wrench for security screw
Note:
1. If POE equipment is not available, it is possible to use External Power Supply (not supplied).
External Power Supply shall be:
Input: 100 –240 V AC
Output: 5VDC; 2A
2. 5VDC Power Supply shall be connected to IP Door Phone in accordance with the required polarity.
3. The External Power Supply does not include in standard ZIP10-x package.
4. The 5 VDC source is connected to the unit via a terminal block. Observe polarity on the PCB where the
terminal block is located.

5
www.Zykronix.com
4IP Door Phone Front Panel
Figure 4-1 The IP Door Phone Unit Front Panel
▲▼ –scroll a speed dial directory.
–enter the programming mode or use as a “Backspace”
–dial predefined day/night extensions and hang up a call.

6
www.Zykronix.com
5IP Door Phone Main Functionality
The IP Door Phone unit can be integrated with IP PBX (Server / SIP-Proxy) as a SIP extension.
IP Door Phone can be connected to IP PBX directly or via IP router, HUB or Switch.
The unit dials to predefined ‘Day’ and ‘Night’ extensions via IP PBX.
The unit dials to local extensions or external destinations.
The unit dials pre-programmed destinations using Speed Dial directory.
The unit opens doors from local extension or remote conversation party.
The unit opens doors using External Switch buttons.
The unit management is handled by Web Management interface.
Figure 5-1 The IP Door Unit Schematic Setup
Figure 5-1the unit schematic setup.
Remote IP Extensions
Remote IP Extensions
