ZyXEL Communications VMG4005-B50B User manual

Default Login Details
User’s Guide
VMG4005-B50B
VDSL2 17a Bonding and 35b Single Line Bridge
Copyright © 2019 Zyxel Communications Corporation
LAN IP Address http://192.168.1.1
Login admin
Password See the Zyxel Device label
Version 5.13 Ed 1, 7/2019

VMG4005-B50B User’s Guide
2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from what you see due to differences in your
product firmware or your computer operating system. Every effort has been made to ensure that the
information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the VMG.
•MoreInformation
Go to support.zyxel.com to find other information on the VMG.

VMG4005-B50B User’s Guide
3
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this guide.
Warnings tell you about things that could harm you or your device.
Note: Notes tell you other important information (for example, other things you may need to
configure or helpful tips) or recommendations.
Syntax Conventions
• The VMG4005-B50B may be referred to as the ‘VMG’ in this guide.
• Product labels, screen names, field labels and field choices are all in bold font.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For example, Network Setting
> Home Networking >LAN Setup means you first click Network Setting in the navigation panel, then
the Home Networking sub menu and finally the LAN Setup tab to get to that screen.
Icons Used in Figures
Figures in this user guide may use the following generic icons. The VMG icon is not an exact
representation of your device.
VMG Generic Router Wireless Router / Access Point
Switch Telephone USB Storage Device
Server Cell Tower Printer
Telephone Jack Splitter
DSL

Table of Contents
VMG4005-B50B User’s Guide
4
Table of Contents
Document Conventions ......................................................................................................................3
Table of Contents.................................................................................................................................4
Part I: User’s Guide............................................................................................7
Chapter 1
VMG Introduction ................................................................................................................................8
1.1 Overview ........................................................................................................................................... 8
1.1.1 Internet Access ........................................................................................................................ 8
1.2 Ways to Manage the VMG ............................................................................................................. 8
1.3 Good Habits for Managing the VMG ............................................................................................ 9
1.4 Hardware ........................................................................................................................................... 9
1.4.1 Front Panel ............................................................................................................................... 9
1.4.2 LEDs (Lights) ........................................................................................................................... 10
1.4.3 Bottom Panel ......................................................................................................................... 10
1.4.4 RESET Button ........................................................................................................................... 10
1.4.5 Wall Mounting ....................................................................................................................... 11
Chapter 2
The Web Configurator........................................................................................................................13
2.1 Overview ......................................................................................................................................... 13
2.1.1 Access the Web Configurator ............................................................................................. 13
2.2 Web Configurator Layout .............................................................................................................. 15
2.2.1 Title Bar ................................................................................................................................... 15
2.2.2 Navigation Panel .................................................................................................................. 16
Part II: Technical Reference...........................................................................17
Chapter 3
Network Status....................................................................................................................................18
3.1 Overview ......................................................................................................................................... 18
3.2 Status ................................................................................................................................................ 18
Chapter 4
Home Networking..............................................................................................................................21

Table of Contents
VMG4005-B50B User’s Guide
5
4.1 Overview ......................................................................................................................................... 21
4.1.1 What You Can Do in this Chapter ....................................................................................... 21
4.1.2 What You Need To Know ..................................................................................................... 21
4.2 LAN Setup ........................................................................................................................................ 22
4.3 UPnP ................................................................................................................................................. 23
4.3.1 Turn on UPnP in Windows 7 Example .................................................................................. 24
4.3.2 Turn on UPnP in Windows 10 Example ................................................................................ 26
Chapter 5
Log ......................................................................................................................................................29
5.1 Overview ......................................................................................................................................... 29
5.1.1 What You Can Do in this Chapter ....................................................................................... 29
5.1.2 What You Need To Know ..................................................................................................... 29
5.2 System Log ...................................................................................................................................... 30
Chapter 6
Traffic Status .......................................................................................................................................31
6.1 Overview ......................................................................................................................................... 31
6.1.1 What You Can Do in this Chapter ....................................................................................... 31
6.2 WAN Status ...................................................................................................................................... 31
6.3 LAN Status ........................................................................................................................................ 32
Chapter 7
xDSL Statistics .....................................................................................................................................34
7.1 xDSL Statistics ................................................................................................................................... 34
Chapter 8
System.................................................................................................................................................37
8.1 Overview ......................................................................................................................................... 37
8.2 System .............................................................................................................................................. 37
Chapter 9
User Account......................................................................................................................................38
9.1 Overview ......................................................................................................................................... 38
9.2 User Account .................................................................................................................................. 38
9.2.1 User Account Add/Edit ........................................................................................................ 39
Chapter 10
Remote Management.......................................................................................................................41
10.1 Overview ....................................................................................................................................... 41
10.2 MGMT Services .............................................................................................................................. 41
10.3 Trust Domain .................................................................................................................................. 42
10.3.1 Add Trust Domain ................................................................................................................ 43

Table of Contents
VMG4005-B50B User’s Guide
6
Chapter 11
Time Settings.......................................................................................................................................44
11.1 Overview ....................................................................................................................................... 44
11.2 Time ................................................................................................................................................ 44
Chapter 12
Log Setting .........................................................................................................................................47
12.1 Overview ....................................................................................................................................... 47
12.2 Log Settings ................................................................................................................................... 47
Chapter 13
Firmware Upgrade.............................................................................................................................49
13.1 Overview ....................................................................................................................................... 49
13.2 Firmware ........................................................................................................................................ 49
Chapter 14
Backup/Restore .................................................................................................................................51
14.1 Overview ....................................................................................................................................... 51
14.2 Backup/Restore ............................................................................................................................ 51
14.3 Reboot ........................................................................................................................................... 53
Chapter 15
Diagnostic...........................................................................................................................................54
15.1 Overview ....................................................................................................................................... 54
15.1.1 What You Can Do in this Chapter ..................................................................................... 54
15.2 What You Need to Know ............................................................................................................. 54
15.3 Ping & TraceRoute & NsLookup .................................................................................................. 55
Chapter 16
Troubleshooting..................................................................................................................................56
16.1 Power, Hardware Connections, and LEDs ................................................................................. 56
16.2 VMG Access and Login ............................................................................................................... 57
16.3 Internet Access ............................................................................................................................. 58
16.4 UPnP ............................................................................................................................................... 59
Part III: Appendices........................................................................................60
Appendix A Customer Support ....................................................................................................... 61
Appendix B Legal Information......................................................................................................... 67
Index...................................................................................................................................................72

7
PART I
User’s Guide

VMG4005-B50B User’s Guide
8
CHAPTER 1
VMG Introduction
1.1 Overview
The VMG is a VDSL bridge, supporting IEEE 802.3az. VDSL provides fast Internet access over POTS (Plain
Old Telephone Service) analog telephone wires.
As a network bridge (or layer 2), the VMG functions as a switch. There is no IP routing or NAT between
networks, it simply extends the layer 2 domain. The “WAN” port of the router, and the “LAN” port of the
VMG, are all in the same LAN with no routing (or layer 3) network separation.
The VMG supports Zero Configuration Internet Access. Once you connect and turn on the VMG, it
automatically detects the Internet connection settings (such as the VCI/VPI numbers and the
encapsulation method) from the ISP and makes the necessary configuration changes.
1.1.1 Internet Access
Use the gray phone cable to connect the DSL port to a DSL splitter or directly to the telephone wall
outlet. You can have multiple WAN services over one ADSL or VDSL. The VMG cannot work in ADSL and
VDSL mode at the same time.
Note: The ADSL and VDSL lines share the same DSL interface in the VMG.
A computer, gateway, or router can connect to the VMG’s LAN port.
Figure 1 VMG’s Internet Access Application
1.2 Ways to Manage the VMG
Use any of the following methods to manage the VMG.
• Web Configurator. This is recommended for management of the VMG using a (supported) web
browser.
• Simple Network Management Protocol (SNMP). Use for collecting and organizing information about
the VMG and for modifying that information to change the VMG behavior.
• Secure Shell (SSH), Telnet. Use for troubleshooting the VMG by qualified personnel.

Chapter 1 VMG Introduction
VMG4005-B50B User’s Guide
9
• TR-069 management. Use for remotely managing the VMG.
1.3 Good Habits for Managing the VMG
Do the following things regularly to make the VMG more secure and to manage the VMG more
effectively.
• Change the Web Configurator password. Use a password that is not easy to guess and that consists of
different types of characters, such as numbers and letters. Refer to Section 9.2.1 on page 39 for details
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it). Restoring an earlier working
configuration may be useful if the device becomes unstable or even crashes. If you forget your
password, you will have to reset the VMG to its factory default settings. If you backed up an earlier
configuration file, you would not have to totally re-configure the VMG. You could simply restore your
last configuration. Refer to Section 14.2 on page 51 for details.
1.4 Hardware
1.4.1 Front Panel
The LED indicators are located on the front panel. The following graphic displays the front panel of the
VMG.
Figure 2 LEDs on the VMG

Chapter 1 VMG Introduction
VMG4005-B50B User’s Guide
10
1.4.2 LEDs (Lights)
The following table describes the LEDs.
None of the LEDs are on if the VMG is not receiving power.
1.4.3 Bottom Panel
The connection ports are located on the bottom panel. The following graphic display the bottom panel.
Figure 3 Bottom Panel
The following table describes the items on the bottom panel.
1.4.4 RESET Button
If you forget your password or cannot access the Web Configurator, you will need to use the RESET
button at the back of the device to reload the factory-default configuration file. This means that you will
Table 1 LED Descriptions
LED COLOR STATUS DESCRIPTION
Power
Green On The VMG is receiving power and ready for use.
Blinking The VMG is in the booting state and getting ready for use.
Red On The VMG detected an error while self-testing, or there is a device
malfunction.
Blinking The VMG is uploading firmware.
Off The VMG is not receiving power.
DSL1
DSL2
Green On The ADSL/VDSL line is up.
Blinking The VMG is initializing the ADSL/VDSL line.
Off The DSL line is down.
Ethernet
Green On The VMG has a successful 10/100/1000 Mbps Ethernet connection with a
device on the Local Area Network (LAN).
Blinking The VMG is sending or receiving data to/from the LAN at 10/100/1000
Mbps.
Off The VMG does not have an Ethernet connection with the LAN.
Bottom Panel Ports
LABEL DESCRIPTION
DSL Connect a RJ-11 cable to the DSL port for Internet access.
LAN Connect a router/gateway to the Ethernet port for Internet access.
Reset Press the button to return the VMG to the factory defaults.
Power Connect the power adapter and then can press the power button to start the VMG.

Chapter 1 VMG Introduction
VMG4005-B50B User’s Guide
11
lose all configurations that you had previously and the password will be reset to the factory default (see
the device label).
1Make sure the POWER LED is on (not blinking).
2To set the device back to the factory default settings, press the RESET button for more than five seconds
or until the POWER LED begins to blink and then release it.
When the POWER LED begins to blink, the defaults have been restored and the device restarts.
1.4.5 Wall Mounting
You may need screw anchors if mounting on a concrete or brick wall.
The following figure introduces the specifications of the screws and screws anchors for wall mounting.
Figure 4 Screws & Screw Anchors Specifications
1Select a position free of obstructions on a wall strong enough to hold the weight of the device.
Do NOT wall-mount the VMG over the height of 2 meters.
2Mark two holes on the wall at the appropriate distance apart for the screws.
Be careful to avoid damaging pipes or cables located inside the wall
when drilling holes for the screws.
Table 2 Wall Mounting Information
Distance between holes 80 mm
Screws Two
Screw anchors (optional) Two

Chapter 1 VMG Introduction
VMG4005-B50B User’s Guide
12
Figure 5 Distance Between Holes
3If using screw anchors, drill two holes for the screw anchors into the wall. Push the anchors into the full
depth of the holes, then insert the screws into the anchors. Do not insert the screws all the way in - leave
a small gap of about 0.5 cm.
If not using screw anchors, use a screwdriver to insert the screws into the wall. Do not insert the screws all
the way in - leave a gap of about 0.5 cm.
4Make sure the screws are fastened well enough to hold the weight of the VMG with the connection
cables.
5Align the holes on the back of the VMG with the screws on the wall. Hang the VMG on the screws.
Figure 6 Wall Mounting Example

VMG4005-B50B User’s Guide
13
CHAPTER 2
The Web Configurator
2.1 Overview
The Web Configurator is an HTML-based management interface that allows easy VMG setup and
management via Internet browser. Use Internet Explorer 11 and later versions or Mozilla Firefox 67.0.2 and
later versions or Safari 5.0 and later versions. The recommended screen resolution is 1024 by 768 pixels.
In order to use the Web Configurator you need to allow:
• Web browser pop-up windows from your VMG. Web pop-up blocking is enabled by default in
Windows 10.
• JavaScript (enabled by default).
• Java permissions (enabled by default).
2.1.1 Access the Web Configurator
1Make sure your VMG hardware is properly connected (refer to the Quick Start Guide).
2Launch your web browser. If the VMG does not automatically re-direct you to the login screen, go to
http://192.168.1.1.
3A password screen displays. To access the administrative Web Configurator and manage the VMG,
type the default username admin and password (in the VMG’s label) in the password screen and click
Login. If you have changed the password, enter your password and click Login.
Figure 7 Password Screen
4The following screen displays if you have not yet changed your password. Enter a new password, retype
it to confirm and click Apply.

Chapter 2 The Web Configurator
VMG4005-B50B User’s Guide
14
Figure 8 Change Password Screen
5The Status screen appears, where you can view the VMG’s interface and system information.

Chapter 2 The Web Configurator
VMG4005-B50B User’s Guide
15
2.2 Web Configurator Layout
Figure 9 Screen Layout
As illustrated above, the main screen is divided into these parts:
•A- title bar
•B- main window
•C- navigation panel
2.2.1 Title Bar
The title bar provides some icons in the upper right corner.
C
A
B

Chapter 2 The Web Configurator
VMG4005-B50B User’s Guide
16
The icons provide the following functions.
2.2.2 Navigation Panel
Use the menu items on the navigation panel to open screens to configure VMG features. The following
tables describe each menu item.
Table 3 Web Configurator Icons in the Title Bar
ICON DESCRIPTION
Language: Select the language you prefer.
Logout: Click this icon to log out of the Web Configurator.
Table 4 Navigation Panel Summary
LINK TAB FUNCTION
Connection Status This screen shows the network status of the VMG and computers/devices
connected to it.
Network Setting
Home
Networking LAN Setup Use this screen to configure the LAN IP address and subnet mask.
UPnP Use this screen to turn UPnP and UPnP NAT-T on or off.
System Monitor
Log System Log Use this screen to view the status of events that occurred to the VMG.
You can export or email the logs.
Traffic Status WAN Use this screen to view the status of all network traffic going through the
DSL port of the VMG.
LAN Use this screen to view the status of all network traffic going through the
LAN ports of the VMG.
xDSL Statistics xDSL Statistics Use this screen to view the VMG’s xDSL traffic statistics.
Maintenance
System System Use this screen to set Device name and Domain name.
User Account User Account Use this screen to change user password on the VMG.
Remote
Management MGMT Services Use this screen to enable specific traffic directions for network services.
Trust Domain Use this screen to view a list of public IP addresses which are allowed to
access the VMG through the services configured in the Maintenance >
Remote Management screen.
Time Time Use this screen to change your VMG’s time and date.
Log Setting Log Setting Use this screen to change your VMG’s log settings.
Firmware
Upgrade Firmware
Upgrade
Use this screen to upload firmware to your VMG.
Backup/Restore Backup/Restore Use this screen to backup and restore your VMG’s configuration
(settings) or reset the factory default settings.
Reboot Reboot Use this screen to reboot the VMG without turning the power off.
Diagnostic Ping&Traceroute
&Nslookup
Use this screen to identify problems with the DSL connection. You can
use Ping, TraceRoute, or Nslookup to help you identify problems.

17
PART II
Technical Reference

VMG4005-B50B User’s Guide
18
CHAPTER 3
Network Status
3.1 Overview
After you log into the Web Configurator, the Status screen appears. This shows the current status of the
VMG, system resources, and interfaces (LAN and DSL).
3.2 Status
Use this screen to view the network connection status of the device and its clients. A warning message
appears if there is a connection problem. You can configure how often you want the VMG to update
this screen in Refresh interval.

Chapter 3 Network Status
VMG4005-B50B User’s Guide
19
Figure 10 Status Screen
Each field is described in the following table.
Table 5 Status Screen
LABEL DESCRIPTION
Refresh Interval Select how often you want the VMG to update this screen.
Device Information
Host Name This field displays the VMG system name. It is used for identification.
Model Number This shows the model number of your VMG.
Serial Number This field displays the serial number of the VMG.
Firmware
Version This is the current version of the firmware inside the VMG.
WAN Information (These fields may display when you have a WAN connection.)
Encapsulation This field displays the current encapsulation method.

Chapter 3 Network Status
VMG4005-B50B User’s Guide
20
IP Address This field displays the current IP address of the VMG in the WAN.
IP Subnet Mask This field displays the current subnet mask in the WAN.
MAC Address This shows the WAN Ethernet adapter MAC (Media Access Control) address of your VMG.
Primary DNS
server This field displays the first DNS server address assigned by the ISP.
Secondary DNS
server This field displays the second DNS server address assigned by the ISP.
DHCP This field displays whether the WAN interface is using a DHCP IP address or a static IP address.
Choices are:
Client - The WAN interface can obtain an IP address from a DHCP server.
None - The WAN interface is using a static IP address.
LAN Information
IP Address This is the current IP address of the VMG in the LAN.
IP Subnet Mask This is the current subnet mask in the LAN.
IPv6 Link Local
Address This field displays the current link-local address of the VMG for the LAN interface.
MAC Address This shows the LAN Ethernet adapter MAC (Media Access Control) address of your VMG.
System Status
System Up Time This field displays how long the VMG has been running since it last started up. The VMG starts
up when you plug it in, when you restart it (Maintenance > Reboot), or when you reset it.
Current Date/
Time This field displays the current date and time in the VMG. You can change this in
Maintenance> Time Setting.
System Resource
CPU Usage This field displays what percentage of the VMG’s processing ability is currently used. When
this percentage is close to 100%, the VMG is running at full load, and the throughput is not
going to improve anymore. If you want some applications to have more throughput, you
should turn off other applications (for example, using QoS; see Chapter 7 on page 54).
Memory Usage This field displays what percentage of the VMG’s memory is currently used. Usually, this
percentage should not increase much. If memory usage does get close to 100%, the VMG is
probably becoming unstable, and you should restart the device. See Section 14.2 on page
51, or turn off the device (unplug the power) for a few seconds.
Interface Status
Interface This column displays each interface the VMG has.
Status This field indicates the interface’s use status.
For the LAN interface, this field displays Up when using the interface and NoLink when not
using the interface.
For the DSL interface, this field displays Down (line down), Up (line up or connected), Drop
(dropping a call) if you're using PPPoE encapsulation, and NoLink when not using the
interface.
Rate For the LAN interface, this displays the port speed and duplex setting.
For the DSL interface, it displays the downstream and upstream transmission rate.
Table 5 Status Screen (continued)
LABEL DESCRIPTION
