ZyXEL
Vantage CNM
3.0.00.61.00
Upgrade Notes
Elven Cao
[email protected]
ZyXEL Communications
CONFIDENTIALITY STATEMENT
The information presented in this document is strictly confidential and supplied on the
understanding that it will be handled as confidential material. Disclosure of any part of this
document to third parties, without the prior written consent from the author, is prohibited.

www.zyxel.com
Document Information
Revision History
Date Version Author Document
7/19/2007 1.0 Elven Initiated
Related Documents
Version Name Author Comment
- 2 -
Z
y
XEL Confidential

www.zyxel.com
Content
Introduction................................................................................................ - 4 -
Upgrade Notes ............................................................................................ - 4 -
Upgrade procedure ...................................................................................... - 6 -
Before upgrade ...................................................................................... - 6 -
After upgrade .......................................................................................- 12 -
New installation......................................................................................... - 12 -
- 3 -
Z
y
XEL Confidential

www.zyxel.com
Introduction
This upgrade notes is to help Vantage CNM users who have already installed Vantage
CNM 2.3 version.
We assume that Vantage CNM 3.0 software is available for the reader who is reading
this document. If not, please get the software, Vantage CNM 3.0.00.61.00.exe from
the Vantage CNM 3.0 CD or 3.0.00.61.00 package from ZyXEL website>>Support &
Downloads>>Software
http://www.zyxel.com/web/support_download_list.php.
For those people who are using older version (e.g. Vantage CNM 2.0, 2.1 or 2.2), we
recommend to conduct new installation and migrate your existing license from
previous installation to the new installation from myZyXEL.com; please see the “New
Installation” section in this document and refer to the Quick Start Guide document.
Upgrade Notes
¾Support upgrade from Vantage CNM 2.3.00.61.00/01.
¾Data which will be migrated:
zDevice list.
If the device type and firmware version is in default full supported list of CNM
3.0, then these devices will be migrated as full supported in CNM 3.0. See the
following default full supported device list of CNM 3.0.
Device Type Firmware Version
ZyWALL 5 / 35 / 70 / 2 Plus 4.00 / 4.01 / 4.02 / 4.03
ZyWALL 2WG 4.02 / 4.03
ZyWALL 2 3.62
- 4 -
Z
y
XEL Confidential

www.zyxel.com
P-662H(W)-D1 3.40
Prestige 662H(W)-61 3.40
Prestige 662HW-63 3.40
Prestige 653HWI-17 3.40
ZyWALL 1050 2.01
ZyWALL USG 300 / 1000 2.01
Others that are supported in CNM 2.3 but not in the full supported list will be
migrated as basically support (registration, firmware upgrade, configuration
file backup and restore, log and alarm). See following list.
Device Type Firmware Version
ZyWALLP1 3.64
ZyWALL 5 / 35 3.64
ZyWALL 70 3.65
ZyWALL 10W 3.62
ZyWALL 1050 2.00 and before
zDevice configuration data.
The configuration data of devices will not be migrated by program but will be
synchronized from devices when they are online. The device synchronization
is only for the devices that are full supported by CNM 3.0 (see full supported
list above).
zDevice topology structure
zAdministrators
CNM 3.0 UAM (User Account Management) is completely different from CNM
2.3 (please reference to User Guide for detail).
The “root” account in CNM 2.3:
The “root” account will be in “super” group in CNM 3.0 after migration.
Other accounts in CNM 2.3:
The migration will create a special group called “custom” in CNM 3.0 for those
accounts with minimum privileges including:
Folder None
- 5 -
Z
y
XEL Confidential

www.zyxel.com
Device Management (Add/Delete/Edit Devices/Folders) Disabled
Device Operation & VPN Management Disabled
Monitor Disabled
Log & Report Disabled
For UAM detail definition in CNM 3.0, please reference to User Guide.
All administrators in “Normal” and “Custom” group in CNM 2.3 will be migrated
to this “custom” group in CNM 3.0. So these users can do nothing except
modifying his/her privileges by super uses after migration.
zAddress Book
The Address Book in CNM 2.3 will be migrated as Device Owner in CNM 3.0.
The relationship with devices will also be migrated.
zLicense
CNM license will be migrated from CNM 2.3 to CNM 3.0 automatically.
zSSL Certificate
CNM certificate will be migrated.
zSystem Configurations
System configuration will be migrated including Server Configurations, User
Access and VRPT server list.
¾Data which will NOT be migrated.
zDevice alarms
zCNM logs
zSystem backup files
zBuilding Block
zSignature profiles
zVPN tunnels created in One-Click VPN
zPending tasks such as device configurations.
Upgrade procedure
Before upgrade
- 6 -
Z
y
XEL Confidential

www.zyxel.com
¾If you are using Vantage CNM 2.2 version or Vantage CNM 2.3 LITE version, you
need to upgrade your CNM to 2.3 version, 2.3.00.61.00. The upgrade step is:
2.2.00.61.00 Æ2.2.00.61.01 Æ2.2.00.61.02 Æ2.2.00.61.03 Æ2.3.00.61.00
Or
2.3.49.61.00 Æ2.3.49.61.01 Æ2.3.00.61.00
For detail upgrade procedure, please reference to the Upgrade Notes in CNM 2.3
release package.
¾If you are not sure about the version of your Vantage CNM, please go to
System>>About.
¾Suggest making a maintenance backup of CNM 2.3 to local computer before
migration. Please go to System>>Maintenance>>Backup and choose “To your
Computer”.
¾Check system environment for uprade.
zIf your Vantage CNM is running, please shutdown it first.
zPlease make sure the ports 1864, 11864, 8080, 443, 3306, 3305 in your
system is not occupied.
zPlease make sure there is more than 600MB available free disk space in the
disk where previous CNM 2.3 is installed.
zInternet access is available and http://www.myZyXEL.com is reachable.
CNM 3.0 installer will double check the above conditions. If anyone of them is not
satisfied, the upgrade process will not continue.
During upgrade
1. Run the install package “Vantage CNM 3.0.00.61.00.exe” to do the migration.
- 7 -
Z
y
XEL Confidential

www.zyxel.com
2. Installation wizard will check the migration condition to make sure everything is
available.
3. Confirm the check result.
- 8 -
Z
y
XEL Confidential

www.zyxel.com
If checking fail, the process will be terminated. Please check your system status
about current CNM version, ports occupy status and free disk space.
4. The program will install CNM 2.3 first.
- 9 -
Z
y
XEL Confidential

www.zyxel.com
5. The program will check whether www.myZyXEL.com is reachable for CNM license
migration.
6. The migration will start after check successfully. You will see command prompt
windows during migration. Just simple allow it to execute and it will close
automatically.
7. If migrate successfully from CNM 2.3, you will be asked to restart you computer.
- 10 -
Z
y
XEL Confidential

www.zyxel.com
8. If the migration is failed, there will be a warning message. You can read the
upgrade log in directory “upgradeLog” in your boot disk. Forward the upgradeLog
to your support contact.
- 11 -
Z
y
XEL Confidential

www.zyxel.com
When the migration failed, the program will cancel the migration and rollback. The
pervious CNM can work well.
After upgrade
¾If your previous external FTP server for CNM 2.2 or 2.3 is installed in the same
machine that your CNM installed, please shutdown it and disabled further CNM
3.0 running, because CNM 3.0 embed FTP server inside its software.
If CNM 3.0 is behind NAT router, please configure that router to make sure FTP
ports (20, 21) are available to devices.
¾Because UAM is completely different from CNM 2.3, so the user accounts
migrated from CNM 2.3 should be re-organized.
zCreate user groups with specified privileges.
zAssociate user accounts to specified groups.
Please reference to User Guide for detail about UAM.
¾CNM 3.0 uses VRPT 3.1 for CNM version as its reporting module. So your VRPT
servers need to be upgraded to 3.1 for CNM version. You can get VRPT 3.1 for
CNM install package in CNM 3.0 release package.
Please reference to the upgrade notes of VRPT 3.1 for detail.
New installation
If you have never installed CNM before, just run the file “Vantage CNM
2.3.00.61.00.exe” and follow the wizard to install the CNM.
¾Double click “Vantage CNM 2.3.00.61.00.exe”.
¾Confirm license agreement
- 12 -
Z
y
XEL Confidential

www.zyxel.com
¾Fill user information
¾Choose the install destination that has enough space (more than 600MB).
- 13 -
Z
y
XEL Confidential

www.zyxel.com
¾When you confirm the information, you can start the installation.
- 14 -
Z
y
XEL Confidential

www.zyxel.com
¾After install, please restart your computer. CNM will start automatically after your
system boot up.
