ZyXEL Communications GS1100-16 - EDITION 1 User manual

The ZyXEL Switch 1100 Series is positioned to deliver a solution that requires no switch
management for office environments demanding silent operation and green technology.
It provides plug-and-play simplicity for high-bandwidth connectivity.
The ZyXEL Switch 1100 Series consists of two unmanaged switches: the GS1100-16 and
GS1100-24.The GS1100-16 is a 16-port 10/100/1000 switch, and the GS1100-24 is a 24-port
10/100/1000 switch with 24 10/100/1000 ports and 2 Gigabit open SFP slots.The Switch 1100
Series protects your existing network investments while providing you with a straightforward
migration path to faster Gigabit speeds.
Enterprise LAN
Switches
Switch 1100 Series
Enterprise LAN
Switches
Switch 1100 Series
Key Features
Ł
Non-blocking, wire-speed
transmission
Ł
Auto MDI/MDI-X support
Ł
IEEE 802.3az compliant
Ł
Fanless design for silent running
Ł
IEEE 802.3x flow control
supported
Ł
IEEE 802.1p CoS supported
Ł
Jumbo frame supported up to
9K bytes
Ł
ZyXEL GS1100-16, 16 ports,
desktop design
Ł
ZyXEL GS1100-24, 26 ports,
rack mount format
Key Benefits
IEEE Energy-Efficient-Ethernet (EEE) compliance
The Switch 1100 Series offers environmental efficiency with Gigabit Ethernet speeds critical for
next-generation network applications.To comply with the IEEE 802.3az standard,the Switch 1100
Series provides power saving functions to reduce energy consumption to help business save cost.
Inactive link detection
The power usage adjustment feature automatically reduces power usage when any shut down
network device or inactive link is detected.That is, power consumption of the Series can be adjusted
according to the link status or the number of active network devices when possible.
Cable length detection
The devices equipped with this green feature can automatically detect the length of connected
Ethernet cables and adjust power usage accordingly.The shorter the cable length, the less power it
consumes.
Fanless design
Since the fanless design ensures quiet operation in small office spaces, the Switch 1100 Series is the
perfect solution for small business and SOHO office deployments.
Gigabit to the desktop
The ZyXEL Switch 1100 Series comprises of unmanaged Gigabit switches that provide an
inexpensive desktop Gigabit solution for significant performance boost thanks to the higher
network bandwidth. In addition, the Switch 1100 Series is equipped with two SFP slots: the 24-port
model provides fibre optics connection while the 16-port model offers copper lines (SFP only
available at GS1100-24).The 16-port model comes in desktop,wall-mountable or rack-mountable
enclosure design.
The flexible connection options (copper lines or fibre optics) enable the switches to easily fit
different applications and environments.The Switch 1100 Series is an ideal solution for
bandwidth-intensive applications such as high-resolution photo transmission,video/audio
streaming and downloading as well as server farm connections.

65-100-110002B 07/10
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2010 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
Power-packed delivery
With the non-blocking switching architecture, the Switch 1100 Series filters and forwards packets at wire speed for maximum throughput. Features
such as Address learning and aging, 802.3x flow control adjust traffic congestion and ensure reliable data transmission.The Switch 1100 Series also
supports jumbo frames of up to 9k bytes for extra large transfers.
Easy installation
The Switch 1100 Series offers plug-and-play connectivity and easy installation. With the Auto MDI/MDI-X feature,it eliminates the need for crossover
cables when connecting to another switch or hub; the Auto-negotiation feature senses the link speed of a network device and intelligently adjusts
for compatibility and optimal performance.
Specifications
Standard Compliance
• IEEE 802.3 10Base-T Ethernet
• IEEE 802.3u 100 Base-Tx Ethernet
• IEEE 802.3ab 1000 Base-T Ethernet
• IEEE 802.3az EEE support
• IEEE 802.3x flow control
• IEEE 802.3z 1000 Base-X (GS1100-24 only)
• IEEE 802.1p CoS
Safety Agency Certification
• UL 60950-1*
• CSA 60950-1*
• EN 60950-1
• IEC 60950-1*
• EU RoHS compliant
* will be available in future releases.
Enterprise LAN
Switches
Switch 1100 Series
Enterprise LAN
Switches
Switch 1100 Series
Model GS1100-16 GS1100-24
Product Picture
Port Density
1000Base-T 16 24
Open SFP Slot (GbE) - 2
Performance
Switching Capacity, Gbps 32 52
Switching Forwarding Rate, Mpps 23.8 38.7
Packet Buffer, Bytes 256K 448K
MAC Address 8K 8K
Auto MDI/MDI-X Yes Yes
802.1p CoS Yes Yes
Broadcast Storm Control Yes Yes
VLAN Packet Pass Through Yes Yes
Power Requirement
Input Voltage 100 - 240 V AC, 50/60 Hz
Maximum Power Consumption,Watt 6.4 16.2
Environmental Specification
Operating Temperature 0°C to 50°C
Storage Temperature -40°C to 70°C
Operating Humidity 10% to 95% (non-condensing)
Physical Feature
Dimensions, (W) x (D) x (H) mm 215 x 133 x 42 441 x 131 x 44
Weight, kg 1 2
