ZyXEL Communications ZyXEL Dimension ES-2108PWR Instruction Manual

ZyXEL ES-2108PWR V3.80(ABS.1)C0
Release Note/Manual Supplement
Date: July 11, 2007
This document describes the features in the ES-2108PWR product for its 3.80(ABS.1)C0
release.
Support Platforms:
ZyXEL ES-2108PWR V3.80(ABS.1)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.80(ABS.1) | 07/11/2007
BootBase Version: V1.02 | 11/27/2006
Default Bootbase Setting:
ZyNOS Version V3.80(ABS.1) | 07/11/2007 10:27:50
Bootbase Version V1.02 | 11/27/2006 13:33:38
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 0019CB000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version 48
RomFile Checksum ff38
ZyNOS Checksum 38bb
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
None
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Bug Fix:
1. When reboot with fiber port, the DUT will crash.

Limit of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
6. IGMP MVR entry 256
7. IGMP Filtering profile 256
8. Syslog server entry 4
9. IP source guard entry 128
10. MSTP MSTI 16
11. IGMP multicast VLAN entry 16
12. DHCP Entry 16
Change History:
V3.80(ABS.1) (07/11/2007)
fix bug
V3.80(ABS.0) (06/18/2007)
Support new features and fix bugs
V3.70(ABS.1)C1 (11/27/2006)
Change the prefix of MAC address.
V3.70(ABS.1)C0 (08/24/2006)
Change fan and temperature threshold.
V3.70(ABS.0)C0 (07/31/2006)
Support new features and fix bugs
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First public version.
ZyXEL ES-2108PWR V3.80(ABS.0)C0
Release Note/Manual Supplement
Date: June 18, 2007
This document describes the features in the ES-2108PWR product for its 3.80(ABS.0)C0
release.

Support Platforms:
ZyXEL ES-2108PWR V3.80(ABS.0)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.80(ABS.0) | 06/18/2007
BootBase Version: V1.02 | 11/27/2006
Default Bootbase Setting:
ZyNOS Version V3.80(ABS.0) | 06/18/2007 17:07:01
Bootbase Version V1.02 | 11/27/2006 13:33:38
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 0019CB000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version 48
RomFile Checksum ff38
ZyNOS Checksum ac48
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
1. 802.1s MSTP
2. 802.3ah OAM
3. SNMPv3
4. Multilevel CLI
5. SNMP trap group
6. configurable multicast VLAN
7. independent IGMP snooping and MVR setting
8. enlarge concurrent telnet session
9. IP source guard(Static binding, ARP inspection)
10. RADIUS accounting
11. TACACS+ authentication
12. TACACS+ accounting
13. IGMPv3 snooping
14. Loop guard
15. Daylight saving time
16. DHCP relay
17. IEEE 802.1X enhancement: add NAS-Port-Type attribute for Access-Request packet.
Known Issue:
3. For the same ports, LACP and RSTP cannot be activated at the same time.
4. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.

Bug Fix:
2. GVRP causes system crash in ring topology.
3. Show error messages when only use no command under config-interface mode.
4. Management traffic will flood to all ports.
5. CPU can’t be set or removed for egress ports via CLI.
6. Can't get correct static MAC forwarding value of the DUT with MIB browser.
7. When the DUT is set as a DHCP client, the DUT will generate a strange ip route entry
0.0.0.0
Limit of Settings:
13. VLAN 1Q static entry 256
14. Static MAC forwarding entry 256
15. MAC filtering entry 256
16. Cluster member 24
17. Management IP address 64
18. IGMP MVR entry 256
19. IGMP Filtering profile 256
20. Syslog server entry 4
21. IP source guard entry 128
22. MSTP MSTI 16
23. IGMP multicast VLAN entry 16
24. DHCP Entry 16
Change History:
V3.80(ABS.0) (06/18/2007)
Support new features and fix bugs
V3.70(ABS.1)C1 (11/27/2006)
Change the prefix of MAC address.
V3.70(ABS.1)C0 (08/24/2006)
Change fan and temperature threshold.
V3.70(ABS.0)C0 (07/31/2006)
Support new features and fix bugs
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First public version.

ZyXEL ES-2108PWR V3.70(ABS.1)C1
Release Note/Manual Supplement
Date: November 27, 2006
This document describes the features in the ES-2108PWR product for its 3.70(ABS.1)C1
release.
Support Platforms:
ZyXEL ES-2108PWR V3.70(ABS.1)C1 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.70(ABS.1) | 08/24/2006
BootBase Version: V1.02 | 11/27/2006
Default Bootbase Setting:
ZyNOS Version V3.70(ABS.1) | 08/24/2006 14:32:44
Bootbase Version V1.02 | 11/27/2006 13:33:38
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 0019CB000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version 42
RomFile Checksum 3831
ZyNOS Checksum 87ad
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
None
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.

Bug Fix:
None
Limit of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
6. IGMP MVR entry 256
7. IGMP Filtering profile 256
8. Syslog server entry 4
Change History:
V3.70(ABS.1)C1 (11/27/2006)
Change the prefix of MAC address.
V3.70(ABS.1)C0 (08/24/2006)
Change fan and temperature threshold.
V3.70(ABS.0)C0 (07/31/2006)
Support new features and fix bugs
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First public version.
ZyXEL ES-2108PWR V3.70(ABS.1)C0
Release Note/Manual Supplement
Date: August 24, 2006
This document describes the features in the ES-2108PWR product for its 3.70(ABS.1)C0
release.
Support Platforms:
ZyXEL ES-2108PWR V3.70(ABS.1)C0 supports models: ZyXEL ES-2108PWR

Version:
ZyNOS Version: V3.70(ABS.1) | 08/24/2006
BootBase Version: V1.01 | 01/05/2006
Default Bootbase Setting:
ZyNOS Version V3.70(ABS.1) | 08/24/2006 14:32:44
Bootbase Version V1.01 | 01/05/2006 09:19:25
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 001349000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version 42
RomFile Checksum 3831
ZyNOS Checksum 87ad
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
None
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Bug Fix:
None
Limit of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
6. IGMP MVR entry 256
7. IGMP Filtering profile 256
8. Syslog server entry 4
Change History:
V3.70(ABS.1)C0 (08/24/2006)
Change fan and temperature threshold.

V3.70(ABS.0)C0 (07/31/2006)
Support new features and fix bugs
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First public version.
ZyXEL ES-2108PWR V3.70(ABS.0)C0
Release Note/Manual Supplement
Date: July 31, 2006
This document describes the features in the ES-2108PWR product for its 3.70(ABS.0)C0
release.
Support Platforms:
ZyXEL ES-2108PWR V3.70(ABS.0)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.70(ABS.0) | 07/31/2006
BootBase Version: V1.01 | 01/05/2006
Default Bootbase Setting:
ZyNOS Version V3.70(ABS.0) | 07/31/2006 17:08:42
Bootbase Version V1.01 | 01/05/2006 09:19:25
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 001349000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version 20
RomFile Checksum e1fd
ZyNOS Checksum e8ef
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00

Enhanced Features:
1. Multicast
2. MVR
3. IGMP Filtering
4. Syslog
5. Administration user management
6. RADIUS enhancement(for 802.1X enhancement and multiple radius servers)
7. IGMP enhancement
8. Web enhancement (Select all, Clone)
9. TFTP server and TFTP client
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Bug Fix:
1. BPDU loop will make DUT unreachable.
2. The passwords of logins accounts are shown in config file.
3. When configuring force speed, DUT can’t link up with straight through cable.
4. BPDU packets are always tagged out.
5. Packets will be forwarded between VLANs after reboot.
6. PC can ping the IP of default management VLAN even not inside the VLAN domain.
7. The DUT will crash when scanned by MaxPatrol.
8. TCP session won’t be reset after restore configuration.
Limit of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
6. IGMP MVR entry 256
7. IGMP Filtering profile 256
8. Syslog server entry 4
Change History:
V3.70(ABS.0)C0 (07/31/2006)
Support new features and fix bugs
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First public version.

ZyXEL ES-2108PWR V3.60(ABS.2)C0
Release Note/Manual Supplement
Date: April 25, 2006
This document describes the features in the ES-2108PWR product for its 3.60(ABS.2)C0
release.
Support Platforms:
ZyXEL ES-2108PWR V3.60(ABS.2)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.60(ABS.2) | 04/25/2006
BootBase Version: V1.01 | 01/05/2006
Default Bootbase Setting:
ZyNOS Version V3.60(ABS.2) | 04/25/2006 19:36:57
Bootbase Version V1.01 | 01/05/2006 09:19:25
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 001349000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version DC
RomFile Checksum f53e
ZyNOS Checksum e2fb
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
None
Bug Fix:
None
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.

2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Limitation of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
Change History:
V3.60(ABS.2)C0 (04/25/2006)
Change the temperature high limit of hardware monitor.
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First Public Version
ZyXEL ES-2108PWR V3.60(ABS.1)C0
Release Note/Manual Supplement
Date: April 13, 2006
This document describes the features in the ES-2108PWR product for its 3.60(ABS.1)C0
release.
Support Platforms:
ZyXEL ES-2108PWR V3.60(ABS.1)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.60(ABS.1) | 04/12/2006
BootBase Version: V1.01 | 01/05/2006
Default Bootbase Setting:
ZyNOS Version V3.60(ABS.1) | 04/12/2006 19:04:13
Bootbase Version V1.01 | 01/05/2006 09:19:25
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 001349000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version DC

RomFile Checksum f53e
ZyNOS Checksum 7863
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Enhanced Features:
None
Bug Fix:
None
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Limitation of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
Change History:
V3.60(ABS.1)C0 (04/12/2006)
Support new revision of switch chip.
V3.60(ABS.0)C0 (02/09/2006)
First Public Version
ZyXEL ES-2108PWR V3.60(ABS.0)C0
Release Note/Manual Supplement
Date: February 9, 2006
This document describes the features in the ES-2108PWR product for its 3.60(ABS.0)C0
release.

Support Platforms:
ZyXEL ES-2108PWR V3.60(ABS.0)C0 supports models: ZyXEL ES-2108PWR
Version:
ZyNOS Version: V3.60(ABS.0) | 02/09/2006
BootBase Version: V1.01 | 01/05/2006
Default Bootbase Setting:
ZyNOS Version V3.60(ABS.0) | 02/09/2006 11:17:41
Bootbase Version V1.01 | 01/05/2006 09:19:25
Vendor Name ZyXEL
Product Model ES-2108PWR
ZyNOS Code Model ES2108PWR
HTP Code Model Unknown
ZyNOS ROM address bfc10000
System Type 8
MAC Address 001349000001
Default Country Code FF
Boot Module Debug Flag 01
RomFile Version DC
RomFile Checksum f53e
ZyNOS Checksum a201
SNMP MIB level & OID 060102030405060708091011121314151617181920
Main Feature Bits C0
Other Feature Bits
F4 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 00 13 00 00 00
Features:
1. MAC address learning
2. Support IEEE 802.1D transparent bridge
3. Support IEEE 802.1Q tagged VLAN
4. Support Port-based VLAN
5. Support IEEE 802.1X
6. Support IEEE 802.1W
7. Support IEEE 802.3AD
8. Support GVRP
9. IGMP snooping
10. Support IEEE 802.1p
11. Automatic age out
12. Specific MAC addresses forwarding per port
13. MAC Filtering
14. Port Trunking
15. Port Mirroring
16. Bandwidth Control
17. Broadcast Storm Control
18. Support Strict Priority and WRR queuing method
19. Static IP management or dynamic IP(DHCP client)
20. Multiple IP address management
21. Firmware upgrade and configuration backup/restore.
22. Remote manageable.
23. Cluster Management
24. WEB manageable
25. Support RFC-1213 MIB II
26. Support RFC-1493 Bridge MIB

27. Support RFC-1643 Ethernet MIB
28. Support RFC-1757 Four group of RMON
29. Support RFC-2674 VLAN MIB
30. NEW CLI supported
31. System configuration backup / restore in text-mode
32. Multiple login supported
33. Radius management authentication
34. SSH/SSL support
Known Issue:
1. For the same ports, LACP and RSTP cannot be activated at the same time.
2. The counter of packets whose length is between 1519 and 1522 (without VLAN tag but
including FCS) will be counted both in the range of 1024 to 1518 and Giant.
Limit of Settings:
1. VLAN 1Q static entry 256
2. Static MAC forwarding entry 256
3. MAC filtering entry 256
4. Cluster member 24
5. Management IP address 64
Change History:
V3.60(ABS.0)C0 (02/09/2006)
First Public version.
Firmware Upgrade:
The ES- 2108PWR uses FTP to upgrade firmware in run-time through its built-in FTP server.
You can use any FTP client (for example, ftp.exe in Windows) to upgrade ES-2108PWR. The
upgrade procedure is as follows:
Upgrade ES-2108PWR FW:
C:\> ftp <ES-2108PWR IP address>
User : <Enter>
Password: 1234
230 Logged in
ftp> put 360ABS0C0.bin ras
ftp> bye
Where
•User name : just press <Enter>
•Password : the management password, 1234 by default
•360ABS0C0.bin : the name of firmware file you want to upgrade
•ras : the internal firmware name in ES-2108PWR
Configuration Upgrade:

The ES-2108PWR uses FTP to upgrade configuration in run-time through its built-in FTP
server. You can use any FTP client (for example, ftp.exe in Windows) to upgrade ES-
2108PWR. The upgrade procedure is as follows:
Upgrade ES-2108PWR configuration:
C:\> ftp <ES-2108PWR IP address>
User : <Enter>
Password: 1234
230 Logged in
ftp> put 360ABS0C0.rom rom-0
ftp> bye
Where
•User name : just press <Enter>
•Password : the management password, 1234 by default
•360ABS0C0.rom : the name of configuration file you want to upgrade
•rom-0 : the internal configuration name in ES-2108PWR
