V500_ReleaseNote 1/15
ZyXEL
Firmware Release Note
V500
Standard Version
Release 1.00(AOX.6)C0
Date: March 4, 2008
Author: HsiangHan Chan

V500_ReleaseNote 2/15
ZyXEL V500 Standard Version
Release 1.00(AOX.6)C0
Release Note
Date: March 4, 2008
Supported Platforms:
ZyXEL V500
Versions:
ZLD Version: V1.00(AOX.6) | 03/04/2008 16:32:11
Bootbase Version: V1.07 | 02/22/2008 17:12:41
Notes:
1. Firmware Version: 1.00(AOX.6)C0.
2. Auto provision default port is 8080.
3. If you upgrade firmware from V1.00(AOX.4)C0 (include before) to V1.00(AOX.5)b1 (include after). You have
to reset to default first, when upgrade firmware successfully.
4. This firmware is without TR069 function.
5. Change Bootbase Version from V1.06 to V1.07 for to add MXIC flash type.
6. Change version from b4 to C0.
Features:
Modification in V1.00(AOX.6) | 3/4/2008
[Modification]
1. Change version from b4 to C0.
Modification in V1.00(AOX.6)b4 | 2/28/2008
[Modification]
1. [SPR: 070330937] [bug 247] Sometimes device hang after setting phone book from web and after reboot device
all settings are set to default values.
2. [SPR: 070723519] [bug 289] WAN type still keep last type when key in error password in pppoe mode.
3. [SPR: 070911498] [bug 297] (V501-T1/V500-T1) Reset device to factory default it will not return to login page
after device reboot.
4. [SPR: 071214854] [bug 325] IF the V500's account 1~4 state all are Unused,press the speed Dial key will get
the LED light on ,BUT press again can't let LED light off. Hope to fix this question.
Modification in V1.00(AOX.6)b3 | 2/25/2008
[Modification]
1. [SPR: 080124257] [bug 341] Some of Parameters work failed.
2. [SPR: 080219578] [bug 345] When change password successfully, the password part will disappear. The web

V500_ReleaseNote 3/15
page must refresh to logout automatically.
3. [SPR: 080219581] [bug 346] When password over 8 numerals, the warning message is incorrect.
4. [SPR: 080219583] [bug 347] When password is 8 numerals, the Tools function will disappeared.
5. [SPR: 080219585] [bug 348] It cannot only modify password of "User level" in Password setup.
6. [SPR: 0080219587] [bug 349] When password is empty (default), it cannot login via User mode.
7. [SPR: 080219591] [bug 350] INVITE of V500-T1 send special type field (Content-Length).
8. Disable "Turbo Mode" of DSP.
9. Change Bootbase Version from V1.06 to V1.07 for to add MXIC flash type.
Modification in V1.00(AOX.6)b2 | 2/18/2008
[Modification]
10. [SPR: 070702050] [bug 283] Can't make VoIP call after run CERT conformance test.
11. [SPR: 080121028] [bug 339] It's not show any messages on webGUI while uploading rom file.
12. [SPR: 080121029] [bug 340] Daylight Savings function can't work.
13. [SPR: 080124257] [bug 341] Some of Parameters work failed.
14. [SPR: 080125327] [bug 342] The information is incorrect in "Device Status --> Device Summary". So some of
parameter can't be used. (Example: voice……).
15. [SPR: 080125328] [bug 343] Sometimes Periodicenable value will become to 16 or 40 or other numbers.
16. Changed Auto provision system file for the ZyStack issue of X6004.
Modification in V1.00(AOX.6)b1 | 1/18/2008
[Modification]
1. Implement new function: TR069.
Modification in V1.00(AOX.5) | 1/11/2008
[Modification]
1. Change version from b2 to C0.
Modification in V1.00(AOX.5)b2 | 1/7/2008
[Modification]
17. Implement new function of V500 UI and Web: 2-tire login. (1) In LCD menu, to use “Advanced Setting->SIP
Configuration” and “Advanced Setting->Auto Provision” have to enter the admin password. (2) In Web login
page, user has to enter “admin” or “user” username and password to login.
18. [SPR: 071210469] [bug 310] Some of Time Zone cannot work.
19. [SPR: 071211535] [bug 312] LCD menu setting the SIP number to 127 characters combined with "0~9"
characters will be crash.
20. [SPR: 071211536] [ bug 313] LCD menu can setting SIP's Port,User ID,Password,Server address and Account
name, auth password, voice mail, STUN server address, Outbound server address, backup 1 and 2's SIP service
address, Register service address characters range not match GUI SIP's range.
21. [SPR: 071211537] [bug 314] Suggested user can type password then press "Enter" key on keyboard to login
DUT.
22. [SPR: 071214860] [bug 316] SIP 2 ~ 4's “MusicOnHold Active” function has wrong behavior with X6004.
23. [SPR: 071213768] [bug 317] Paging don't working when enable RingBack Active, and MusicOnHold Active.
24. [SPR: 071213769] [bug 318] STUN function doesn’t work.

V500_ReleaseNote 4/15
25. [SPR: 071213748] [bug 319] V500 can't send the account 2, account 3 and account 4’s Voice mail number to
SIP server with [Voice mail] key.
26. [SPR: 071213756] [bug 321] GUI’s SIP Local Port, SIP Server Port and REGISTER Server Port‘s field type in
any characters except number to apply will change to 0.
27. [SPR: 071214852] [bug 324] V500 connect the P-334WT or ZyWall 2WG's Lan port, but LCD menu can't
display any IP address message.
28. [SPR: 071217950] [bug 327] The LCD menu can't display the LCD menu's Programmable Feature Key Settings
data or GUI’s Programmable Feature Key Settings data.
29. [SPR: 071218050] [bug 332] Auto firmware upgrade doesn’t work.
30. [SPR: 071218051] [bug 333] Call forward can't display correct status via auto provision.
31. [SPR: 071218999] [bug 334] If Speed Dial Key set 127 characters to dial will be crash.
32. [SPR: 071218036] [bug 335] If LCD menu's Contact List add a 127 characters account will be crash.
33. [SPR: 071218037] [bug 336] If Call forward's Specific Active table set item 1 for NoAnswer forward,item 2 for
Busy forward on the same Incoming Call Number,The Busy forward can't work.
34. [SPR: 071218039] [bug 338] After the CERT conformance test can't make call.
35. Change default “PBXIVR” configuration from **99 to ***01.
Modification in V1.00(AOX.5)b1 | 12/7/2007
[Modification]
1. Modified V500 architecture to new one.
2. Implement new function of V500 UI: Predial function. User can press phone number in idle status of V500 UI,
than press “Line key”, “Account key”, “Speaker key”, “Send key” or “Off hook” to dial out.
3. [SPR: 070315115][bug 234] Have to double click "Apply", then the Speed Dial phone number can save.
4. [SPR: 070315116][bug 235] Have to double click "Apply", then the Programmable Feature Key's value can
save.
5. [SPR: 070411516][bug 250] Change DHCP to PPPoE mode, V-500 is still keeping DHCP IP even if PPPoE get
IP already.
6. [SPR: 070412549][bug:251] [Web] In VoIP Statistics page, the duration in call statistics format is not correct.
7. [SPR: 070412551][bug 253] After doing call transfer, the line LED is still on.
8. [SPR: 070412552][bug 254] [Web] Active call forward show wrong status.
9. [SPR: 070625504][bug 266] [Web] sometime firmware upgrade from web tools "Browse…" button must press
3~5 times.
10. [SPR: 070627742][bug 269] [LCD] enable or disable any function then back to index page press speaker button
or offhook handset must wait 5 sec.
11. [SPR: 070629904][bug 282] V500-T1 display error message when upgrade incorrect file via Web.
12. [SPR: 070717924][bug 287] Daylight saving of Time Zone behavior is wrong.
13. [SPR: 071015777][bug 308] Please remove the item "Default" in DTMF Mode in every SIP account.
14. [SPR: 071016824][bug 309] sometimes DUT's respond time is too slowly after delete missed call.
Modification in V1.00(AOX.4) | 12/4/2007
[Modification]
2. Change version from b1 to C0.
Modification in V1.00(AOX.4)b1 | 12/4/2007
[Modification]

V500_ReleaseNote 5/15
1. Implement AEC function for half duplex mode.
2. Setup default “Featurekey” configuration. The “CallTRF” is *96. The “VoiceMail” is **.
Modification in V1.00(AOX.3) | 10/18/2007
[Modification]
1. Change version from b4 to C0.
Modification in V1.00(AOX.3)b4 | 10/9/2007
[Modification]
1. [SPR: 070717925] [bug 288] Callee have piercing voice when use ring tone (chirp1~10).
2. [SPR: 070724633] [bug 290] V500-T1 have interoperability problem about music on hold with X6004.
3. [SPR: 070911501] [bug 300] V500-B can't hear music when V500-A hold active VoIP call.
4. [SPR: 070928629] [bug 303] Restart device web via LAN PC (192.168.5.10), after device reboot finished,
refresh the webpage, device will reboot again.
5. [SPR: 070928630] [bug 304] System Name doesn’t support empty characters, but default system name: V500
Series.
6. [SPR: 071001042] [bug 307] Ring Style display wrong chirp on web when set ring style via LCD menu.
7. [SPR: 071001043] [bug 309] Lose voice in callee side.
8. Change default “Call Feature Mode” configuration from PBX mode to Local mode.
9. Modified CLI “hwtest dsp” function that can adjust DSP volume by user.
Modification in V1.00(AOX.3)b3 | 9/26/2007
[Modification]
1. [SPR: 070910446] [bug 293]DUT occur crash after press DND button many times.
2. [SPR: 070911497] [bug 296] Please change DNS SRV funcrion name in LCD menu from "DNS SRV / DNS" to
"DNS SRV".
3. Modified the ring type to extent from 10 to 12.
4. Modified the system name from "V500-T1" to "V500 Series".
5. Change the G.726 Endian from MSB to LSB to sync with X6004.
Modification in V1.00(AOX.3)b2 | 9/7/2007
[Modification]
1. Implement PBXIVR function.
2. Implement Paging Number function.
3. Implement IP-PHONE model name change function.
4. When DTMF type=SIPINFO then should not have dtmf tone in RTP inside.
5. Added Ring Download Restriction for Midi File.
6. Modified the behavior of DND Action.
7. Implement Function of Distinct Ring.
Modification in V1.00(AOX.3)b1 | 8/8/2007
[Modification]
1. Change auto provision configuration from inactive to active.

V500_ReleaseNote 6/15
2. Implement new function of V500 UI: Call Feature Mode.
3. Modify menu item save timing of V500 UI.
4. Add PBX User Agent String Control Mechanism.
5. Add Conference Key to Feature Key List.
6. Add Call Transfer Control Flag.
7. Modify SSDP Address.
Modification in V1.00(AOX.2) | 7/26/2007
[Modification]
2. Change version from b4 to C0.
3. Change configuration from SIP mode to Feature Key mode.
Modification in V1.00(AOX.2)b4 | 7/19/2007
[Modification]
1. [SPR: 070717923] [bug 286] PPPoE function don't work.
Modification in V1.00(AOX.2)b3 | 7/16/2007
[Modification]
1. [SPR: 070716869] [bug 285] V500-T1 don't display correct phone number in each Group.
Modification in V1.00(AOX.2)b2 | 7/13/2007
[Modification]
1. [SPR: 070627741] [bug 268] Settings static IP then get rom-t remote IP subnet mask error.
2. [SPR: 070627743] [bug 270] [LCD] Disable or enable caller ID don't work please remove.
3. [SPR: 070627745] [bug 271] [Web] Please add "SIP account name" to rom-t file settings.
4. [SPR: 070627746] [bug 272] [Web] The value of Contact list disappear when add 200 entry data in Contact list
UI happened error to lessen phone book.
5. [SPR: 070628829] [bug 273] Specific forward table display wrong data when add 10 entry
6. [SPR: 070629887] [bug 274] [LCD] Auto provision port error.
7. [SPR: 070629888] [bug 275] [LCD] Dial to line 2~3 number can't receive caller ID.
8. [SPR: 070629890] [bug 276] Upload ring midi file always show message " Ring is packing, please wait…"
9. [SPR: 070703100] [bug 284] DND LED don't show on when V500 syn personal profile table on the IP PBX
10. [SPR: 070705230] [bug 285] [Web][LCD] default ring volume too loud (volume 0~10).
Modification in V1.00(AOX.2)b1 | 6/22/2007
[Modification]
1. Implement V500 new phase 2 MMI.
2. Modify auto provision, SSDP, public phonebook, personal profile and feature code mechanism sync with PBX.
Modification in V1.00(AOX.1) | 6/14/2007
[Modification]
1. Change version from b2 to C0

V500_ReleaseNote 7/15
Modification in V1.00(AOX.1)b2 | 6/11/2007
[Modification]
1. [SPR: 070606230] Some function help page don't ready.
2. [SPR: 070606231] Sometimes V500-T1 occur reboot when press refresh button after reset factory default .
3. [SPR: 070606232] Date don't set up more than 2037 via web, please pop up error message.
4. [SPR: 070606292] V500-T1 can't get correct time and date from NTP time server : asia.pool.ntp.org.
5. [SPR: 070606291] Advanced setup table of specific forward will display error status .
Modification in V1.00(AOX.1)b1 | 5/16/2007
[Enhancement]
1. Add wideband codec G.722 and G.722.2 supporting.
2. Improve the rom-file verify, if rom-file format is not compatible with older rom-file , system will auto restore
default rom-file.
[Modification]
1. Modify the rom-file size to 64k fixed size.
2. Change G.726 RTP format from ITU to IETF mode.
Modification in V1.00(AOX.0) | 4/13/2007
Change V500 version from b8 to C0.
Modification in V1.00(AOX.0)b8 | 4/10/2007
1. [SPR: 061220214][ItemNo.:147] V-500 voice quality (G.711u G.711a G.729 G.723) failed.
2. Update DSP frequency to 100MHz, RD evaluate if possible this only effects voice quality.
Modification in V1.00(AOX.0)b7 | 4/9/2007
1. [SPR: 070315114][ItemNo.:233] "SIP Active" and "RingBack Active" show wrong status
2. [SPR: 070329844][ItemNo.:237] LCD missed call page please align "Delete" with soft key.
3. [SPR: 070329846][ItemNo.:238] LCD missed call and voice mail logo please align with soft key.
4. [SPR: 070329848][ItemNo.:240] Symptom: PPPoE mode unplug wan cable then plugin cable can't get IP.
5. [SPR:070330932][ItemNo.:241] V500 can't get correct time and date from NTP server(ex: time.windows.com or
time.nist.gov), and it will show error message.
6. [SPR: 070330934][ItemNo.:243] Please remove "<max xx>" strings form all web pages.
7. [SPR: 070330916][ItemNo.:244] [Web] When contact list table is full, press "clear all" button. After complete,
device cannot make call and all button cannot use.
8. [SPR: 070330935][ItemNo.:245] When click apply button in block list page, it will show strange strings on the
web page.
9. [SPR: 070330936][ItemNo.:246] Sometimes device cannot display IP address on Web and LCD.
10. [SPR: 070330939][ItemNo.:248] [Web] V500-T1 Phone book contact list can't delete the last item.
Modification in V1.00(AOX.0)b6 | 3/28/2007
1. [SPR: 070227355][ItemNo.:195]. LED of Voice mail don't blink when V500-T1 receive voice mail and change
codec
2. [SPR: 070227358][ItemNo.:198]. V500-T1 don't register SIP server when DUT located at behind the NAT

V500_ReleaseNote 8/15
Router and enable STUN function
3. [SPR: 070228425][ItemNo.:208]. [Web] There should have error message when Block list or DND white list are
full and user add a rule in contact list with enabled block or DND white.
4. [SPR: 070314021][ItemNo.:218] V500-T1 display wrong ip address "192.168.1.130" when WAN type is PPPoE
mode and unplug WAN cable than reboot DUT.
5. [SPR: 070314022][ItemNo.:219] DUT don't pop a small error page to remind user we don't support symbol when
input it into SIP user name in web, except input "-" "_"and "@".
6. [SPR: 070314023][ItemNo.:220] V500-T1 don't send Register packets to SIP server when enable VLAN Tag
7. [SPR: 070314024][ItemNo.:221] [Web] The contact list is full, Web occur hang up when entry into Group list, or
Block list, or DND whilt list web page, then entry into contact list.
8. [SPR: 070314025][ItemNo.:222] [Web] V500-T1 don't return login page when change WAN type from DHCP
to PPPoE by management PC
9. [SPR: 070314026][ItemNo.:224] [Web] The value of Contact list disappear when add 150 entry data in Contact
list by manual
10. [SPR: 070314027][ItemNo.:225] [Web] Can't set up "No answer Time" when set "No answer" of Specific
forward
11. [SPR: 070314028][ItemNo.:226] DUT can't return idle mode when auto Firmware upgrade but new Firmware no
found
12. [SPR: 070314029][ItemNo.:227] SIP2 ~SIP 4 don't register to SIP server when update parameter via provision
server
13. [SPR: 070314030][ItemNo.:228] Sometimes reset device or Upload Rom file in web via LAN PC
(192.168.5.100) , it don't return to login page after device reboot. but click "Refresh" button in IE, DUT occur
reboot.
14. [SPR: 070314031][ItemNo.:229] Web login's destination IP show wrong IP address when PC login web with
192.168.5.1
15. [SPR: 070314032][ItemNo.:230] When callee enable "RingBack" , make call , caller don't hear voice.
16. [SPR: 070314032][ItemNo.:231] Accept and Regject soft key disappear when test Call-Waiting function
17. [SPR: 070315113][ItemNo.:232] Caller play wrong ring type when configure Ring Style
18. [SPR: 070315117][ItemNo.:236] SIP web page is damage, when input specific character in SIP 2 phone number
Modification in V1.00(AOX.0)b5 | 3/12/2007
1. [SPR: 070117831][ItemNo.:175] Symptom: Change device Ethernet from DHCP to PPPoE mode from web, in
status page, the IP Address still shows the IP get from Ethernet.
2. [SPR: 070213155][ItemNo.:185] DNS SRV 's Priority and port don't work.
3. [SPR: 070214201][ItemNo.: 186] V500-T1 display wrong ip address "192.168.1.130" when reboot DUT and
unplug WAN cable.
4. [SPR: 070214202][ItemNo.: 187] WAN or LAN link status always show 10 Mbps in Web Interface status.
5. [SPR: 070214236][ItemNo.: 192] DUT don't pop a small error page to remind user we don't support when inputs
symbol into SIP server address, register address and domain , except "-" and "." in web.
6. [SPR: 070227353][ItemNo.:193]. The SIP Auth Password of LCD menu SIP setting can't accept to input "-_" ,
but LCD show user can input "-_"
7. [SPR: 070227354][ItemNo.:194]. The SIP Auth ID of LCD menu SIP setting can't accept to input
"!|#:;"/\?@%&.',+^=~-_()<>$*"
8. [SPR: 070227355][ItemNo.:195]. LED of Voice mail don't blink when V500-T1 receive voice mail and change
codec
9. [SPR: 070227356][ItemNo.:196]. WAN IP address keep IP when unplug WAN cable

V500_ReleaseNote 9/15
10. [SPR: 070227357][ItemNo.:197]. SIP number of LCD menu setting and Web setting can be accepted character
mode don't match
11. [SPR: 070227358][ItemNo.:198]. V500-T1 don't register SIP server when DUT located at behind the NAT
Router and enable STUN function
12. [SPR: 070227359][ItemNo.:199]. Management IP address don't work when WAN type is DHCP miode and
unplug WAN cable
13. [SPR: 070227331][ItemNo.:200]. Set phone number with full characters (max 50), when make call the callee
will see a wrong character on LCD monitor.
14. [SPR: 070227333][ItemNo.:201]. Enable voice mail number, after delete missong call list, console will display
error message, and disabled the SIP account the LED of voice mail will keep linked.
15. [SPR: 070227334][ItemNo.:202]. After inactived SIP account, the voice mail icon on LCD will not disappear.
16. [SPR: 070228440][ItemNo.:203]. The ring type of Default, Family, Business, Friend, and Other in web setting
don't configure it
17. [SPR: 070228441][ItemNo.:204]. Standard rings don't according to country code to play put 12 cadence of
default ring
18. [SPR: 070228442][ItemNo.:205]. Speed Dail don't dail special phone number [email protected]
19. [SPR: 070228443][ItemNo.:206]. DUT WAN can't IP address when enable VLAN Tag
20. [SPR: 070228424][ItemNo.:207]. After Blind transfer, caller's line1 will still link
21. [SPR: 070228425][ItemNo.:208]. [Web] There should have error message when Block list or DND white list are
full and user add a rule in contact list with enabled block or DND white.
22. [SPR: 070228426][ItemNo.:209]. [LCD] When contact list is full, user still can add from LCD.
23. [SPR: 070228427][ItemNo.:210]. [LCD] When contact list is full, edit phonebook from LCD. After finished the
setting and back, there will have a long time that all button cannot work. It should have some information or
message to tell user the phonebook is updating.
24. [SPR: 070301100][ItemNo.:211]. Hope the No Answer Time can be independent from Conditional Forward.
25. [SPR: 070301101][ItemNo.:212]. Some item don't update successful with AutoProvision by using TFTP or
HTTP
26. [SPR: 070301102][ItemNo.:213]. DUT can't return idle mode when auto Firmware upgrade but new Firmware
no found
27. [SPR: 070301103][ItemNo.:214]. Don't play auto upgrade firmware message after second goes offhook
28. [SPR: 070301047][ItemNo.:215]. [Web] Word error. In firmware upgrading page, the "complate" should be
"complete".
29. [SPR: 070301048][ItemNo.:216]. When network is not ready, offhook the phone then onhook, the busy tone
cannot stop.
30. [SPR: 070301049][ItemNo.:217]. Simultaneous many VoIP calls incoming, DUT will cannot make call. Try to
make call several times, DUT hang.
Modification in V1.00(AOX.0)b4 | 2/12/2007
1. [SPR: 061208632][ItemNo.:60]Symptom: Click web items, web show 304 and many pages are broken. (PC
enabled Kaspersky Antivirus 6.0.1.411)
2. [SPR: 061213822][ItemNo.:83]SIP1~SIP4's DNS SRV behavior is wrong.
3. [SPR: 061221244][ItemNo.:143] Hope LCD monitor display Missed Call information when it can't pick up VoIP
call.
4. [SPR: 070103137][ItemNo.:153] In Region settings list there is a "lssue sys default countrycode" item. It should

V500_ReleaseNote 10/15
be removed.
5. [SPR: 070104194][ItemNo.:157] Web click restore configuration upload (don't select upload file) than click back
to factory defaults "reset" can't work, still show message "please select upload file".
6. [SPR: 070116780][ItemNo.:163] Web Min-SE of SIP advanced setup please fix the range to 20-1800 sec.
7. [SPR: 070116781][ItemNo.:164] When Firmware upgrade via Web , it pop up message "226 Update Firmware
Successful, Please wait until device reboots ", Please remove "226" in this message.
8. [SPR: 070116793][ItemNo.:165] Programmable Feature key sent wrong character
9. [SPR: 070116794][ItemNo.:166] Programmable Feature key can't symbol characters
10. [SPR: 070116795][ItemNo.:167] SIP can't sent register packets when setup SIP setting then plug WAN cable
11. [SPR: 070116796][ItemNo.:168] WAN IP work wrong IP address when WAN type from PPPoE to static IP
12. [SPR: 070116797][ItemNo.:169] Some Device upgrade RAS code and Default rom file with Tera Term , Rom
file Chksum display wrong
13. [SPR: 070116798][ItemNo.:170] Don't IVR system to Record, Play, Delete, Clear all sound , so when enable
music on hold and acller ringback, we can't hear voice
14. [SPR: 070117827][ItemNo.:171] Symptom: Using web, it is hard to login to device
15. [SPR:070117828][ItemNo.:172] Symptom: CPU loading is too high even doing nothing.
16. [SPR: 070117829][ItemNo.:173] Symptom: Reset device to factory default from web, it will not return to login
page after device reboot.
17. [SPR: 070117830][ItemNo.:174] Symptom: Reset device to factory default from web, after device reboot
finished, refresh the webpage, device will reboot again.
18. [SPR: 070117831][ItemNo.:175] Symptom: Change device Ethernet from DHCP to PPPoE mode from web, in
status page, the IP Address still shows the IP get from Ethernet.
19. [SPR: 070117832][ItemNo.:176] Symptom: In web page, the View Log page the "Sourece" should be "Source".
20. [SPR: 070117833][ItemNo.:177] Symptom: In log page on web, the source of "web login" always shows
255.255.255.255:0
21. [SPR:070117834][ItemNo.:178] Symptom: In log page on web, click "#" to sort by descending but it will auto
refresh and back to ascending.
22. [SPR: 070117835][ItemNo.:179] Symptom: Audio codec not match still can make call.
23. [SPR: 070117840][ItemNo.:180] During 3-way conference to press line 1 & 2 button, V-500-T1 can't hear any
voice.
24. [SPR: 070118902][ItemNo.:181] Symptom: Set voice compression with 3 different types, but DUT only send
first 2 type in SDP.
25. [SPR: 070118903][ItemNo.:182] Symptom: In VoIP > Phone Book> Group List page, the "Contact List" will be
renamed as "Phone Book".
26. [SPR: 070118904][ItemNo.:183]When select "other" tone on ring setting page then return to main menu, it still
ringback tone .
27. [SPR: 070118905][ItemNo.:184]LCD select page to ring setting into default、family、business、friend or other
I don't click play button but DUT always auto play.
Modification in V1.00(AOX.0)b3 | 1/15/2007
[New Enhancement]
1. The hookswitch can work.
[Bug Fixed]
1. [SPR: 061207532][ItemNo.:8]Symptom: Many page will have error message from IE6. (ie, Time setting page,
block list page, DND whit list page, Firmware upgrade page….)

V500_ReleaseNote 11/15
2. [SPR: 061207553][ItemNo.:26]Symptom: Model name is wrong.
3. [SPR: 061208621][ItemNo.:49]Cannot set Ethernet via PPPoE from web. After apply, PPPoE will not be
actived.
4. [SPR: 061208627][ItemNo.:55]Use Firefox2.0 cannot show phone book table settings.
5. [SPR: 061208628][ItemNo.:56]Symptom: When one user configure from web, another user still can login from
web.
6. [SPR: 061208631][ItemNo.:59]Symptom: Backup SIP server function no work.
7. [SPR: 061208632][ItemNo.:60]Symptom: Click web items, web show 304 and many pages are broken. (PC
enabled Kaspersky Antivirus 6.0.1.411)
8. [SPR: 061211713][ItemNo.:65]Symptom: The Headset button don't match ES.
9. [SPR: 061211720][ItemNo.:68]Symptom: The 6 Programmable speed button don't match ES
10. [SPR: 061211726][ItemNo.:72]V500-T1 send DNS Query to 2nd DNS server .
11. [SPR:061211727][ItemNo.:73]V500-T1 still query previously DNS server when WAN type change from
Ethernet static IP to PPPoE DHCP mode.
12. [SPR: 061213820][ItemNo.:80] [ LCD menu setting] PPPoE function don't work.
13. [SPR: 061212793][ItemNo.:85]Phone Hold function change line 1~4 issue.
14. [SPR: 061213884][ItemNo.:86]SIP 1 and SIP2 don't sent register packets to SIP server when fill max. value in
SIP 2 every parameter.
15. [SPR: 061213892][ItemNo.:92]Symptom: Web VoIP volume control setting don't work.(Speaker & Phone &
Ring & Handset volume).
16. [SPR: 061214960][ItemNo.:108]Symptom: when use [soft key 1] to accept waiting call or [soft key 3] to reject
waiting call, the soft key's message of LCD screen and soft key button don't match
17. [SPR: 061214973][ItemNo.:114]V500-T1 don’t get dial tone when it dial another call during the 3 way
conference call.
18. [SPR: 061215005][ItemNo.:122]Web phone book name(max 20) & number(max 50) but LCD display max
29,wish LCD display can recombination.
19. [SPR: 061219130][ItemNo.:127] [LCD setting] Specific Forward of Call Forward don't work.
20. [SPR: 061220142][ItemNo.:135] [LCD & web setting]Outbound Proxy don't work
21. [SPR: 061220144][ItemNo.:137] [LCD & web setting]NAT keep Alive function don't work.
22. [SPR: 061220210][ItemNo.:139] [LCD setting] Dialplan don't work
23. [SPR:061221237][ItemNo.:141] [LCD setting] sometimes Menu setting show strange phenomenon.
24. [SPR: 061221241][ItemNo.:142]The version don't support Music on Hold , and Early Media.
25. [SPR: 061221246][ItemNo.:145] Auto-provision have to update SIP and WAN's parameter.
26. [SPR: 061220212][ItemNo.:146]Debug mode load RAS code use ATLC can't show error and can uplold
success.
27. [SPR: 070103139][ItemNo.:148] WAN show wrong information when the cable don't attach V500-T1's WAN
port.
28. [SPR: 070103141][ItemNo.:149] The rule of MWI expiration time is wrong .
29. [SPR: 070103142][ItemNo.:150] V500-T1 don't send DHCP Request when reboot successful, then attach cable
to WAN port.
30. [SPR: 070103143][ItemNo.:151] Time Zone will affect the Manual time.
31. [SPR: 070103136][ItemNo.:152] If SIP no register to server then all button can't be workable. It should
be ……….
32. [SPR: 070103137][ItemNo.:153] In Region settings list there is a "lssue sys default countrycode" item. It should
be removed.
33. [SPR: 070103138][ItemNo.:154] Web upgrade firmware DUT always show please wait… don't return to login
page, please setting can auto reboot after upgrade firmware via web.

V500_ReleaseNote 12/15
34. [SPR: 070103140][ItemNo.:155] [regression] LCD DND white list can't add of menu setting phonebook.
35. [SPR: 070104193][ItemNo.:156] Click hang up button on/off have a noise, please check the noise.
36. [SPR: 070104194][ItemNo.:157] Web click restore configuration upload (don't select upload file) than click
back to factory defaults "reset" can't work, still show message "please select upload file".
37. [SPR: 070104198][ItemNo.:158] Click hang up button on/off have a noise, please check the noise.
38. [SPR: 070104195][ItemNo.:159] Many page will have error message from firefox show Incorrect XML. (block
list page, DND whit list page….) (Web)
39. [SPR: 070104278][ItemNo.:160] [LCD setting] The parameter of SIP save to memory, the timing is too long.
40. [SPR: 070104279][ItemNo.:161] [LCD setting] Port parameter of SIP1 will affect port parameter of SIP2.
41. [SPR: 070104280][ItemNo.:162] V500-T1 sent strange DNS query.
Modification in V1.00(AOX.0)b2 | 12/29/2006
[Bug Fixed]
1. [SPR: 061207522][ItemNo.:1]Symptom: Set Ethernet as DHCP, IP Address and IP Subnet mask on device
information show ""
2. [SPR:061207523][ItemNo.:2]Symptom: In status page, VoIP status show error. Wrong registration status and
wrong URI.
3. [SPR: 061207524][ItemNo.:3]Symptom: In status page, VoIP Statistics detail link is failed.
4. [SPR: 061207526][ItemNo.:4]Symptom: Packet statistics page, the numbers are wrong.
5. [SPR: 061207527][ItemNo.:5]Symptom: Model name is wrong. Not "Prestige V501D".
6. [SPR: 061207529][ItemNo.:6]In main page, device icon is error. It still router's icon.
7. [SPR: 061207530][ItemNo.:7]Symptom: In login page, the description of device "router" is wrong.
8. [SPR: 061207533][ItemNo.:9]Symptom: In time setting page, current time/ date show nothing.
9. [SPR: 061207535][ItemNo.:11]Symptom: Reset from web is failed.
10. [SPR: 061207537][ItemNo.:12]Symptom: help button is no work.
11. [SPR: 061207538][ItemNo.:13]Symptom: Manual set time, after apply, web show empty.
12. [SPR: 061207539][ItemNo.:14]Symptom: In Time Zone list, there is a "Daytime (RFC-867)" item.
13. [SPR: 061207540][ItemNo.:15]Symptom: Change time zone, after apply, it still show "Daytime (RFC-867)".
14. [SPR: 061207541][ItemNo.:16]Symptom: Log is no work. There is no log display.
15. [SPR: 061207542][ItemNo.:17]Symptom: Background image error. (All pages except system page)
16. [SPR: 061207543][ItemNo.:18]Symptom: Page path is wrong. (ie, Mgnt Port page, Restart page, Configuration
page, Time settings page)
17. [SPR: 061207544][ItemNo.:19]Symptom: In system > general page, when change password and apply. It popup
an error message "Error: The DomainName can't be empty!"
18. [SPR: 061207545][ItemNo.:20]Symptom: In system > general page, domain name can't save.
19. [SPR: 061207546][ItemNo.:21]Symptom: Device still show enter new password page even the password is
changed.
20. [SPR: 061207547][ItemNo.:22]Backup current configuration and phone book is no work.
21. [SPR: 061207548][ItemNo.:23]Symptom: Set Ethernet as static IP, dhcp of device information show static.
22. [SPR: 061207549][ItemNo.:24]Symptom: When apply SIP1 setting, web will show a strange string
"====>[1]=====" on web page.
23. [SPR: 061207552][ItemNo.:25]By using console and telnet , the system use BusyBox as default shell. DUT
should enter ZySHELL when user use Console or TELNET or SSH management device.
24. [SPR: 061207554][ItemNo.:27]Symptom: DUT default setting don't match release notes's parameter
25. [SPR: 061207555][ItemNo.:28]Symptom: DUT's WAN setting should be "Get IP address automatically"

V500_ReleaseNote 13/15
26. [SPR: 061207556][ItemNo.:29]Symptom: The Management Port IP address (192.168.5.1) don't work
27. [SPR: 061207557][ItemNo.:30]Symptom: Click H/W reset buttom about 5 sec, DUT's system don't reset to
deafult setting
28. [SPR: 061208659][ItemNo.:31]Symptom: when upgrade firmware via Web, DUT should have "message page "
to remind user DUT is upgrading firmware, and the firmware upgrade successful, DUT don't return to login
page.
29. [SPR: 061208660][ItemNo.:32]Symptom: [Wish]When configure SIP [aramter of SIP setting via LCD monitor
successful , hope it can return to menu setting.
30. [SPR: 061208661][ItemNo.:33]Symptom: On zySHELL , when input the command "voice" on configure model ,
DUT show error message.
31. [SPR: 061208662][ItemNo.:34]DUT should sent one SUBSCRIBE packets to SIP server at three-second
intervals, when MWI's Expiration Time is 3 , but DUT will send two SUBSCRIBE packets to SIP server at
three-second intervals.
32. [SPR: 061208663][ItemNo.:35]Symptom: [Wish] Hope the paramter of MWI's Expiration Time is 60.
33. [SPR: 061208664][ItemNo.:36]Symptom: PC ftp to DUT, DUT show strange file , ex : 00.xmf ~ 18.xmf
34. [SPR: 061208665][ItemNo.:37]Symptom: Don't upload rom file to DUT via FTP
35. [SPR: 061208667][ItemNo.:38]Symptom: Can't get spt-gen configuration file via FTP
36. [SPR: 061208666][ItemNo.:39]Symptom: Don't upload ROM files and ackup configuration file and Restore
configuration file to DUT via TFTP.
37. [SPR: 061208668][ItemNo.:40]Symptom: DUT receive voice mail from SIP server.
38. [SPR: 061208669][ItemNo.:41]DUT don't dial tone after SIP1 receive voice mail.
39. [SPR: 061208669][ItemNo.:42]Symptom: Keypad don't work when DUT can't register SIP server , but DUT
have registered to SIP server once, don't this problem.
40. [SPR: 061208610][ItemNo.:43]Symptom: Set SIP account from web, device will not send register packet.
41. [SPR: 061208615][ItemNo.:44]Manual set time, after reboot device, the time will change to default time.
42. [SPR: 061208616][ItemNo.:45]Symptom: When device bootup, screen will display AAAAAAAAAA…..
43. [SPR: 061208618][ItemNo.:46]Symptom: Active 4 SIP accounts, after reboot device, sometimes there are only 3
or less SIP accounts are registered.
44. [SPR: 061208619][ItemNo.:47]Symptom: Active 2 or more SIP accounts, device cannot make call.
45. [SPR: 061208620][ItemNo.:48]Symptom: When active second SIP account from web, sometimes sipua process
will disappear.
46. [SPR: 061208622][ItemNo.:50]Symptom: In Voice compression, the "G.711ulaw" should be "G.711 u law", the
"G.711Alaw" should be "G.711 A law", and the "G729" should be "G.729"
47. [SPR: 061208623][ItemNo.:51]Symptom: NAT keep Alive should not be enabled by default.
48. [SPR: 061208624][ItemNo.:52]Symptom: Administrator Inactivity Timer is no work.
49. [SPR: 061208625][ItemNo.:53]Default region should not be Japan. Please set USA as default.
50. [SPR: 061208626][ItemNo.:54]Symptom: Custom Key, Key 9 cannot set, it will always show key 8's setting.
51. [SPR: 061208629][ItemNo.:57]Cannot enable allow anonymous call.
52. [SPR: 061208630][ItemNo.:58]Symptom: Enable DNS SRV will send wrong dns srv packet. Device will send
query srv 192.168.1.31
53. [SPR: 061211709][ItemNo.:61]Symptom: V500-T1 don’t support DECT function , Please remove the function
on LCD menu setting
54. [SPR: 061211710][ItemNo.:62]Symptom: The voice mail button don't match ES
55. [SPR: 061211711][ItemNo.:63]Symptom: V500-T1 can't resent register packet to SIP server when V500-T1
have registered SIP server, then change other account to register SIP server
56. [SPR: 061211712][ItemNo.:64]Symptom: The Speaker button don't match ES.
57. [SPR: 061211714][ItemNo.:66]Symptom: The Mute button don't match ES.

V500_ReleaseNote 14/15
58. [SPR: 061211716][ItemNo.:67]Symptom: The DND button don't match ES.
59. [SPR: 061211723][ItemNo.:69]Speaker LED's behavior is wrong.
60. [SPR: 061211724][ItemNo.:70]V500-T1 can't disconnect VoIP call with 4 Linekey.
61. [SPR: 061211725][ItemNo.:71]Symptom: The Volume button don't match ES.
62. [SPR: 061211703][ItemNo.:74]Symptom: SIP Expiration duration no work.
63. [SPR: 061211704][ItemNo.:75]Symptom: Register re-send timer not correct.
64. [SPR: 061211705][ItemNo.:76]Symptom: Devices cannot make call if the session expires timer smaller than
Min-SE timer.
65. [SPR: 061211706][ItemNo.:77]Symptom: Cannot set Voice compression from web. (Web)
66. [SPR: 061211707][ItemNo.:78]DTMF mode set as SIP Info. Send more DTMF keys, device can't make call.
67. [SPR: 061211708][ItemNo.:79]Symptom: In SIP setting page, the "apply","advanced setup","reset" buttons are
not align. (Web)
68. [SPR: 061213819][ItemNo.:81]Symptom: Hope add DNS server information on "System info > IP address"
when V500-T1 get IP address from DHCP server.
69. [SPR: 061213821][ItemNo.:82]Symptom: 1st and 2nd Codec Selection and SIP servie domain's value of LCD is
different from Web.
70. [SPR: 061213823][ItemNo.:84]V500-T1 sent SUBSCRIBE packets to SIP server at four-second intervals when
SIP can't register to SIP server .
71. [SPR: 061213885][ItemNo.:87]Symptom: V500-T1 don't make call when disanle Call ID.
72. [SPR: 061213887][ItemNo.:88]LCD display two Voice mail message when only SIP2 register to Asterisk SIP
server.
73. [SPR: 061213889][ItemNo.:89]when SIP1's register type change from success tp fail , it should sent unregister
packets to SIP server.
74. [SPR: 061213890][ItemNo.:90]LCD don't display Voice mail message when SIP register to SIP server from
OpenSER to Asterisk.
75. [SPR: 061213891][ItemNo.:91]LED of Voice mail still on when it change SIP register status from Asterisk to
OpenSER.
76. [SPR: 061213895][ItemNo.:93]Symptom: Web Voip custom key settings sequence error.
77. [SPR: 061213896][ItemNo.:94]Symptom: Web VoIP call forward setting failed.
78. [SPR: 061213897][ItemNo.:95]Web VoIP Phone book failed.
79. [SPR: 061213898][ItemNo.:96]Web VoIP Phone book wish.
80. [SPR: 061213899][ItemNo.:97]Web VoIP Phone book wish.
81. [SPR: 061213900][ItemNo.:98]Under GUI Phone book page button "clear page".
82. [SPR: 061213901][ItemNo.:99]Web phone book group list please remove group button.
83. [SPR: 061213903][ItemNo.:100]Web phone book DND white list find a blank space button and page1~20
button?
84. [SPR: 061213904][ItemNo.:101]Web DND white list wish.
85. [SPR: 061213905][ItemNo.:102]Web SIP settings advanced setup caller ringing don't work.
86. [SPR: 061213906][ItemNo.: 103]Web SIP settings advanced setup caller ringing wish.
87. [SPR: 061213907][ItemNo.:104]Web VoIP > Phone Book > Phone Book have the same name.
88. [SPR: 061214957][ItemNo.:105]Symptom: The scenario of Hold function don't match ES.
89. [SPR: 061214958][ItemNo.:106]Symptom: The Call waiting scenario don't match ES.
90. [SPR: 061214959][ItemNo.:107]Symptom: when use soft key to pick up the waiting call, then can't press [Hold]
button to swap original call and waiting call .
91. [SPR: 061214961][ItemNo.:109]Symptom: DUT-B don't get ringback when test Blind Transfer function
92. [SPR: 061214962][ItemNo.:110]Callee still show incoming call information when Caller have disconnected this
call1.

V500_ReleaseNote 15/15
93. [SPR: 061214963][ItemNo.:111][Wish] Suggest to modify the scenario about Blind Transfer function.
94. [SPR: 061214964][ItemNo.:112] [Wish] Hope Soft key row don't display "Please Invite" when press Linkey
95. [SPR: 061214969][ItemNo.:113]SIP2's account name disappear when SIP 1 fill max. value in SIP1's account
name.
96. [SPR: 061214943][ItemNo.:115]Symptom: Web status page find under top name is "Menu 1 > Sunmenu-1"
97. [SPR: 061215021][ItemNo.:116] [Wish] Hope Soft key row display "Conferencing" establish 3-way conference
call with different account and FXO.
98. [SPR: 061215022][ItemNo.:117]Callee don't display Caller ID when incoming call's SIP number is
"12345678901234567890123456789012345678901234567890"
99. [SPR: 061215023][ItemNo.:118]LCD show Busy when press [phonebook] button to dial the second call after
hold original call.
100.[SPR: 061215024][ItemNo.:119]SIP number don't accept 50 characters.
101.[SPR: 061215002][ItemNo.:120]Web Group can't rename and naming rule is Default, Family, Business, Friend,
other.
102.[SPR: 061215003][ItemNo.:121]Symptom: Add phone book via CLI cammand write more than 77 entry,DUT
will crash.
103.[SPR: 061215006][ItemNo.:123]Reset to defaults open Web setting SIP local port bug.
104.[SPR: 061219124][ItemNo.:124] Web VoIP phone settings cutom key settings have 1~9 but V-500 HW only
have 1~6 button.
105.[SPR: 061219126][ItemNo.:125] V-500 HW program key in web name is custom key please check this name.
106.[SPR: 061219128][ItemNo.:126] LCD Speed dial don't work and web can't find any speed settings function.
107.[SPR: 061219132][ItemNo.:128] LCD call forward unconditional forward sometime work.
108.[SPR: 061219134][ItemNo.:129] LCD call forward number (ex:152) change (ex:88888) still send 152 number.
109.[SPR: 061219136][ItemNo.:130] LCD and WEB enable uncondition forward than call V-500 forward must 35
second.
110.[SPR: 061219138][ItemNo.:131] LCD Advance setting SIP configuration have "call forward action" function ,
but WEB can't find this settings function.
111.[SPR: 061219139][ItemNo.:132] User need to login several times, then it can login successful after V-500 reset
to factory defaults
112.[SPR: 061220140][ItemNo.:133] 3-way Conference don't work after callee don't onhook.
113.[SPR: 061220141][ItemNo.:134] Sometimes "Call Forward Active" don't work.
114.[SPR: 061220143][ItemNo.:136] [LCD & web setting]STUN function don't work
115.[SPR: 061220211][ItemNo.:138] Sometimes the parameter of SIP configuration disappear
116.[SPR: 061220213][ItemNo.:140] [LCD setting] Auto Provision functiondon't work .
117.[SPR:061221246][ItemNo.:144] V500-T1 always sent IGMP packets to 224.0.23.1and 239.255.255.250.
