ZyXEL Communications NBG-4615 User manual

Quick Start Guide
www.zyxel.com
NBG4615 v2
Wireless N300 Gigabit NetUSB Router
Version 1.00
Edition 1, 09/2012
Copyright © 2012 ZyXEL Communications Corporation
User’s Guide
Default Login Details
LAN IP Address http://192.168.1.1
Password 1234

NBG4615 v2 User’s Guide2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from your product due to differences in
your product firmware or your computer operating system. Every effort has been made to ensure
that the information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the NBG4615 v2 and access the Web Configurator
wizards. It contains information on setting up your network and configuring for Internet access.
