ZyXEL
Firmware Release Note
ZyAIR G-2000PLUS v2
Release 3.60(AAF.1)C0
Date: June 15, 2006
Author: Watties Lin
360AAF1C0.RTF 1/10

ZyXEL Confidential
ZyXEL ZyAIR G-2000PLUS v2 Standard Version
release 3.60(AAF.1)C0
Release Note
Date: June 15, 2006
Supported Platforms:
ZyXEL ZyAIR G-2000PLUS v2
Versions:
ZyNOS Version: V3.60(AAF.1) | 06/15/2006 10:10:00
BootBase : V1.05 | 04/20/2004 10:36:26
Notes:
1. If Wireless Port Control (SMT Menu 23.4) is “Authentication Required”, G-2000PLUS v2 will enable
802.1x/WPA/WPA-PSK user authentication mechanism, a wireless user must associate G-2000PLUS v2
successfully before accessing network service. If Wireless Port Control is “No Authentication Required”,
G-2000PLUS v2 will allow all wireless users to access network service. If Wireless Port Control is “No
Access Allowed”, G-2000PLUS v2 will not allow wireless user to access network service.
2. If the Key Management Protocol is “WPA/WPA2”, then you have to configure RADIUS server and the
Authentication Databases will be “RADIUS only”.
3. G-2000PLUS v2 supports external and internal RADIUS server, both of them use the same setting page
(SMT Menu 23.2). The internal RADIUS server use EAP-PEAP/MS-CHAP-V2 to authenticate the client.
If internal RADIUS server is desired, the server address is “127.0.0.1”, and shared secret is “don’t care”.
“Don’t care” means whatever user key in, if server address is “127.0.0.1”, G-2000PLUS v2 will use
default shared secret “1234”. But leave blank is exception.
4. The Local User Database does not support key generation for 802.1x dynamic web key and WPA
pairwise/group key.
5. As a wireless client roams from one wireless AP to another, it must perform a full 802.1X authentication
with each wireless AP. WPA2 allows the wireless client and the wireless AP to cache the results of a full
802.1X authentication so that if a client roams back to a wireless AP with which it has previously
authenticated, the wireless client needs to perform only the 4-way handshake and determine new pairwise
transient keys. In the Association Request frame, the wireless client includes a PMK identifier that was
determined during the initial authentication and stored with both the wireless client and wireless AP's
PMK cache entries. PMK cache entries are stored for a finite amount of time, as configured on the
wireless client and the wireless AP. So wireless client may reconnect to AP with error user name or
password.
Known Issues:
360AAF1C0.RTF 2/10

ZyXEL Confidential
CI Command List
Features:
Modification in 3.60(AAF.1)C0 | 06/15/2006
1. [FEATURE CHANGED]
Convert to FCS version.
Modification in 3.60(AAF.0)C0 | 05/09/2006
1. [FEATURE CHANGED]
Convert to FCS version.
Modification in 3.60(AAF.0)b4 | 05/03/2006
1. [BUG FIXED]
Symptom: Wireless Power Saving issue.
Condition: When wireless station (G-162, Intel 2200BG or Conexant-3890) power saving enable, and
connect to G-2000plus v2 with no security mode, nothing to do (no ping no FTP no...), more than 20
minutes, the wireless station can't ping to DUT.
SPRID: 60424865
2. [BUG FIXED]
Symptom: Port change to check SNMP service works with Access setting (LAN & WAN / Disable /
LAN / WAN) works failed.
Condition: 1) Encapsulation is Ethernet, and disables Firewall.
2) Remote MGMT/ SNMP service access = all.
3) LAN & WAN host access G-2000plus v2 via SNMP port 161 successful.
4) Change port 161 to 1610.
5) LAN & WAN host access G-2000plus v2 via port 1610 failed.
SPRID: 60425015
3. [BUG FIXED]
Symptom: Spoof Mac addresses issue.
Condition: In wizard, whether you use Ethernet/PPPoE/PPTP to make IP address, if you choose ”spoof
Mac address”, the device will exception.
SPRID: 60425978
4. [BUG FIXED]
Symptom: Local database user account can pass the authentication when using RADIUS only.
Condition: 1) In eWC->Advanced->Wireless: choose security as “802.1X+NO WEP” and authentication
database as “RADIUS only”.
2) In eWC->Advanced->AUTH. Server->Trusted User: add one active user “1234”.
3) Wireless STA can use “1234” to pass the authentication.
SPRID: 060310888
5. [BUG FIXED]
Symptom: WPA2-PSK (WPA2) mixed mode with WPA-PSK (WPA) station issue. If G-2000plus v2
configure with WPA2-PSK (WPA2) mixed mode, and the station which configure with WPA2-PSK
(WPA2) connect to device first, then the other station that configure with WPA-PSK (WPA) will not
connection any more.
Condition: 1) Load default first.
360AAF1C0.RTF 3/10

ZyXEL Confidential
2) Configure device with WPA2-PSK (WPA2) mixed mode, and STA1 (Intel 2200BG) configure with
WPA2-PSK (WPA2) and connect to device first, then STA2 (Conexant wireless card) configure with
WPA-PSK (WPA) try to connect with device, but STA2 always can't connect.
SPRID: 60428284
6. [FEATURE ENHANCED]
Extend share secrets of authentication and accounting from length 31 to 128.
SPRID: 60426109
7. [FEATURE ENHANCED]
Add a rule of default server (0.0.0.0) in address mapping.
SPRID: 60427229
Modification in 3.60(AAF.0)b3 | 04/20/2006
1. [BUG FIXED]
Symptom: System crash when user telnet in and modify configuration.
Condition: Copy a long character string (ex: 12345678901234567890123456789012), telnet to
G-2000plus v2, then paste the string in any item (Ex System name or domain name), system will crash.
SPRID: 60414066
2. [BUG FIXED]
Symptom: Conexant chipset wireless client (Mixed mode) can’t associate to G-2000plus v2 (802.11b
only mode).
Condition: In eWC->Advanced->Wireless: change 802.11 mode to 802.11b only, Setting Conexant STA
802.11 mode as b/g mixed mode, then STA can’t associate to G-2000plus v2.
SPRID: 60418320
3. [BUG FIXED]
Symptom: Report function doesn’t work.
Condition: In eWC->Advanced->LOGS->Reports: press “Start Collection” to monitor “Web Site Hits”,
“LAN IP Address”, and “Protocol/Port”. Press “Refresh” to update the information, but nothing appears.
SPRID: 60418347
Modification in 3.60(AAF.0)b2 | 04/07/2006
1. [BUG FIXED]
Symptom: Mass 64 bytes packets will cause switch interrupt fail and doesn’t receive packets.
Condition: 1) Configure G-2000plus v2: NAT on, Firewall off, Quick Route 0x9bf2, Flow Control off.
2) Configure LAN to WAN performance test for SmartBits.
3) Under 64 bytes packets, Rx interrupt fail, and doesn’t receive packets.
SPRID: 060307557
2. [BUG FIXED]
Symptom: WAN MAC Address Spoof failed.
Condition: In eWC->Advanced->WAN->MAC: when choose “Spoof this computer's MAC Address - IP
Address” and press applies, an error messages”Can not get the WAN MAC Address” occurred.
SPRID: 060307559
3. [BUG FIXED]
Symptom: ZyAIR G-100 can’t associate with G-2000plus v2 when 802.11 mode is set to 802.11b only.
Condition: 1)In eWC->Advanced->wireless: choose “802.11 mode” as “802.11b only”.
2) Because preamble setting doesn’t match, some STA like “ZyAIR G-100” can’t associate successfully.
SPRID: 060309804
4. [BUG FIXED]
360AAF1C0.RTF 4/10

ZyXEL Confidential
Symptom: Local database user account can pass the authentication when using RADIUS only.
Condition: 1) In eWC->Advanced->Wireless: choose security as “802.1X+NO WEP” and authentication
database as “RADIUS only”.
2) In eWC->Advanced->AUTH. Server->Trusted User: add one active user “1234”.
3) Wireless STA can use “1234” to pass the authentication.
SPRID: 060310888
5. [BUG FIXED]
Symptom: system reboot many times after overnight stress test. (16 STAs run FTP+HTTP data
transmission)
Condition: The below two test cases can reproduce this issue.
1) Let 16 wireless clients associate to DUT at the same time, run the FTP and HTTP data transmission
between eSTA and all wireless clients. After overnight test, DUT reboot many times.
2).DUT reboot when run WLAN throughput test for 64 WEP\128 WEP and WPA-PSK\WPA2-PSK.
SPRID: 060311932
6. [BUG FIXED]
Symptom: STA using wrong password and CA can still pass the WPA2 authentication once STA passed
the WPA2 authentication before.
Condition: STA using wrong password and CA can still pass the WPA2 authentication once STA passed
the WPA2 authentication before.
SPRID: 060313945
7. [FEATURE CHANGED]
-USA(255), Taiwan(238), Philippine(216), India(214), Brazil(208) use 11 channels.
-Not Used(223, 251, 210), Morocco(239), Slovak(228), Slovenia(215), European CTR21(212),
ZyXEL(000) use 13 channels.
-Others (include Japan 234) use 13 channels.
Modification in 3.60(AAF.0)b1 | 02/22/2006
1. First firmware release
CI Command List
Command Class List Table
System Related Command Exit Command Ethernet Related Command
Wireless LAN Related Command IP Related Command Bridge Related Command
Radius Related Command 802.1x Related Command Certificates
Radserv
SystemRelatedCommand Home
Command Description
sys
Callhist
display display call history
remove <index> remove entry from call history
countrycode [countrycode] set country code
domainname display domain name
Edit <filename> edit a text file
extraphnum maintain extra phone numbers for outcalls
add <set 1-3> <1st phone num> [2nd
phone num] add extra phone numbers
360AAF1C0.RTF 5/10

ZyXEL Confidential
display display extra phone numbers
node <num> set all extend phone number to remote node <num>
remove <set 1-3> remove extra phone numbers
reset reset flag and mask
Feature display feature bit
Hostname [hostname] display system hostname
Logs
Clear clear log error
Display display log error
Syslog
active [0:no/1:yes]
display <FacilityNo> set/display syslog type flag
facility [Local ID(1-7)] set syslog facility
server [domainName/IP] set syslog server IP address
Rn
load <entry no.> load remote node information
disp <entry no.>(0:working buffer) display remote node information
nat <none|sua|full_feature> config remote node nat
nailup <no|yes> config remote node nailup
save [entry no.] save remote node information
Stdio [second] change terminal timeout value
Trcdisp parse, brief,
disp monitor packets
Trclog
Trcpacket
Version display RAS code and driver version
View <filename> view a text file
Wdog
switch [on|off] set on/off wdog
cnt [value] display watchdog counts value: 0-34463
Romreset restore default romfile
Socket display system socket information
Filter
netbios
roadrunner
debug <level> enable/disable roadrunner service
0: diable <default>
1: enable
display <iface name> display roadrunner information
iface-name: enif0, wanif0
restart <iface name> restart roadrunner
Ddns
debug <level> enable/disable ddns service
display <iface name> display ddns information
restart <iface name> restart ddns
logout <iface name> logout ddns
Cpu
display display CPU utilization
Firewall
acl
disp Display specific ACL set # rule #, or all ACLs.
delete Delete specific ACL set # rule #.
active <yes|no> Active firewall or deactivate firewall
clear Clear firewall log
cnt
360AAF1C0.RTF 6/10

ZyXEL Confidential
disp Display firewall log type and count.
clear Clear firewall log count.
debug Set firewall debug level.
tosctrl
destination Display TOS destination hash
incomplete Display TOS incomplete List.
dynamicrule
display Display firewall dynamic rules
tcprst
rst Set TCP reset sending on/off.
rst113 Set TCP reset sending for port 113 on/off.
display Display TCP reset sending setting.
dos
smtp Set SMTP DoS defender on/off
display Display SMTP DoS defender setting.
ignore Set if firewall ignore DoS in lan/wan/dmz/wlan
ignore
dos Set if firewall ignore DoS in lan/wan/dmz/wlan
triangle Set if firewall ignore triangle route in
lan/wan/dmz/wlan
ExitCommand Home
Command Description
exit exit smt menu
Ethernet Related Command Home
Command Description
ether
Config display LAN configuration information
Driver
cnt
disp <name> display ether driver counters
ioctl <ch_name> Useless in this stage.
status <ch_name> see LAN status
version see ethernet device type
edit
load <ether no.> load ether data from spt
save save ether data to spt
Wireless LAN Related Command Home
Command Description
wlan
active [on|off] set on/off wlan
association display association list
breathLED [0|1] Turn off/on breath LED
chid [channel id] set channel
chgmod <0: B+G, 1: B only, 3: G only>
essid [ess id] set ESS ID
hideessid <on, off>
intrabssblock <0: Disable, 1: Enable>
preamble <0: Dynamic, 1: Long>
removeSTA <MAC ADDRESS> Remove STA
reset Reset WLAN
version display WLAN version information
360AAF1C0.RTF 7/10

ZyXEL Confidential
IPRelatedCommand Home
Command Description
ip
address [addr] display host ip address
alias <iface> alias iface
aliasdis <0|1> disable alias
arp
status <iface> display ip arp status
dhcp <iface>
client
release release DHCP client IP
renew renew DHCP client IP
status [option] show dhcp status
dns
query
server <primary> [secondary] [third] set dns server
stats
default set default DNS server
httpd
icmp
status display icmp statistic counter
discovery <iface> [on|off] set icmp router discovery flag
ifconfig [iface] [ipaddr] [broadcast <addr> |mtu
<value>|dynamic] configure network interface
ping <hostid> ping remote host
route
status [if] display routing table
add <dest_addr|default>[/<bits>]
<gateway> [<metric>] add route
addiface <dest_addr|default>[/<bits>]
<gateway> [<metric>] add an entry to the routing table to iface
addprivate <dest_addr|default>[/<bits>]
<gateway> [<metric>] add private route
drop <host addr> [/<bits>] drop a route
status display ip statistic counters
udp
status display udp status
rip
tcp
status [tcb] [<interval>] display TCP statistic counters
telnet <host> [port] execute telnet clinet command
tftp
traceroute <host> [ttl] [wait] [queries] send probes to trace route of a remote host
xparent
join <iface1> [<iface2>] join iface2 to iface1 group
break <iface> break iface to leave ipxparent group
igmp
debug [level] set igmp debug level
forwardall [on|off] turn on/off igmp forward to all interfaces flag
querier [on|off] turn on/off igmp stop query flag
iface
<iface> grouptm <timeout> set igmp group timeout
<iface> interval <interval> set igmp query interval
<iface> join <group> join a group on iface
<iface> leave <group> leave a group on iface
360AAF1C0.RTF 8/10

ZyXEL Confidential
<iface> query send query on iface
<iface> rsptime [time] set igmp response time
<iface> start turn on of igmp on iface
<iface> stop turn off of igmp on iface
<iface> ttl <threshold> set ttl threshold
<iface> v1compat [on|off] turn on/off v1compat on iface
robustness <num> set igmp robustness variable
status dump igmp status
BridgeRelatedCommand Home
Command Description
Bridge
cnt related to bridge routing statistic table
Disp display bridge route counter
Clear clear bridge route counter
stat related to bridge packet statistic table
Disp display bridge route packet counter
Clear clear bridge route packet counter
RadiusRelatedCommand Home
Command Description
Radius
auth show current radius authentication server
configuration
acct show current radius accounting server configuration
802.1x Related Command Home
Command Description
8021x
debug Level [debug level] set ieee802.1x debug message level
Trace show all supplications in the supplication table
User [username] show the specified user status in the supplicant table
Certificates Related Command Home
Command Description
certific
ates
my_cert create Self-signed
request
Scep_enroll
Cmp_enroll
import Import certificate.
export <name> Export certificate.
view <name> View certificate content.
verify <name> [timeout] Verify certificate path.
delete <name> Delete the specific certificate.
list List all my certificate.
rename <old name> <new name> Rename the certificate.
def_self_signed Show the default self signed certificate name.
replace_factory Replace certificate to factory default.
ca-trusted Import <name> Import trust CA certificate.
Export <name> Export trust CA certificate
view <name> View trust CA certificate content
Verify <name> [timeout] Verify trust CA certificate path.
Delete <name> Delete the specific trust CA certificate.
List List all trust CA certificate.
360AAF1C0.RTF 9/10

ZyXEL Confidential
Rename <old name> <new name> Rename the trust CA certificate.
Crl_issuer <name> [on|off] Check the crl of trust CA.
Cert_manage
r Reinit Reinitialize the certificate manager.
Debug_tools Cm_reset Reset the certificate manager.
Radserv Related Command Home
Command Description
Radser
v
Time_out <value(ms)> Set radius server authenticate time out.
authenticator Set <entry_no active [ip secret]> Set trust AP.
remove <entry_no> Remove trust AP.
list List trust AP.
enable <1|0> Enable | disable internal RADIUS server.
360AAF1C0.RTF 10/10
