10L0L Front Inner Storage Basket User manual

3/8 inch (10mm)3/8 inch (10mm)1/2 inch (13mm)
10mm Wrench......................................1
13mm Wrench......................................1
10mm Sleeve.......................................1
13mm Sleeve.......................................1
Socket..................................................1
Screw..................................................12
Screw Nut............................................ 8
Gasket.................................................16
Plastic Buckle.......................................1
Metal Buckle........................................ 4
Basket...................................................1
Socket 1/2 inch (13mm)
Front Inner Storage Basket for
Golf Cart Club Car DS and Precedent 1. Fasten the buckle in middle.
See figure 1
2. Prepare screws and bolts.
See figure 2
3. Tighten the screws with No.
13 sleeve & wrench.
See figure 3
4. Fix the screws well.
See figure 4
We are striving to build an reliable brand of golf carts parts and accessories.
Hope this manual can assist you to easier install.
For more technical support, please reach us via
Website : www.10l0l.com
Email : [email protected]
Facebook : zhong zaiyang
Youtube : 10L0L
Installation Tools Qty
Installation Tools
Installation Steps
International Smart Production, Global Direct Supply International Smart Production, Global Direct Supply

5. Drilling on the tube.
See figure 5
6. As shown.
See figure 6
7. Align the holes.
See figure 7
8. Insert screws.
See figure 8
9. Tighten the screws with No.
10 sleeve & wrench.
See figure 9
10. As shown.
See figure 10
11 Installation finished.
See figure 11
9
10
11
