2 Save Energy OWL Z-Smart User manual

© 2 Save Energy Limited 2016 1
In-home display for Solar PV monitoring
IN THE BOX:
Getting started with
OWL Z-Smart Home Display
Z-Smart
2x AA Batteries

2 © 2 Save Energy Limited 2016
Introduction
This OWL Z-Smart display unit is a part of the OWL Intuition range of cloud connected
monitoring and control products. Its operation is dependant upon being paired to a
Network OWL as part of an Intuition -PV Installation (supplied separately - part number
TSE200-103).
This version of the Z-Smart is designed for monitoring electricity consumption and Solar PV
generation. It is suitable for domestic use and some light commercial premises.
The Z-Smart provides access to all of the energy generation, consumption and export data
normally accessible via the OWL Intuition online dashboard - but provides this in a concise
manner with at-a-glance accessibility.
This manual outlines the pairing process for your Z-Smart device and the primary functions
of the Z-Smart unit as a whole. To ensure a full understanding of what is being shown to
you in each viewing mode, and how to switch between these viewing modes, please make
sure you read the section “Using your OWL Z-Smart” contained in this manual.

© 2 Save Energy Limited 2016 3
Installation Instructions
BEFORE YOU START
The OWL Z-Smart will not work until a running Intuition -PV installation is present at your
property. If you do not have such an installation present, you will need one to continue
with the installation of the Z-Smart. In such a case, please contact one of our
recommended suppliers found at http://theowl.com/distributors/.
Once you have ensured a complete Intuition -PV installation has been congured at your
property, follow the steps on the next few pages to get your OWL Z-Smart up and running.

4 © 2 Save Energy Limited 2016
Step 1. Log Into the Online Dashboard
Open your preferred internet web browser and access the site www.owlintuition.com. Log
into your account, then click “Wizard” once logged in.
Please note, your OWL Intuition account should already be set up to monitor solar PV prior
to attempting to install the Z-Smart. Please consult the manuals supplied with the Intuition
-PV if this has not yet been done.
Step 2. Run through the Wizard
Upon starting the online Wizard, select “Z-Smart”. Click “Next”. It may be necessary to
update your network OWL - the wizard will prompt you to do so if this is the case.
Insert the batteries into the Z-Smart unit. Initially the unit should be in “Time/Date” mode
(indicated by a small clock icon showing on the left hand side). This will show the time to
be “00:00” and date to be “01/01” (the unit will receive correct date and time
information once paired).
The Wizard will ask you to press and hold and ▼ for 3 seconds to put the Z-Smart into
pairing mode; indicated by the “RX” symbol ashing. Do so, then click “Next”
Wait for the OWL Intuition Dashboard to notify you that pairing has been successful. Once
this has been displayed, simply click “Finish”, “Finish” again, and “OK”.

© 2 Save Energy Limited 2016 5
Step 3. Check the pairing was successful
Ensure your Z-Smart is now receiving data from the Network OWL; this can be determined
by looking at the display unit. Upon receiving its rst packet of information from the net-
work OWL, the date and time should update on-screen as it retrieves this from our servers.
This may take up to 60 seconds to take place.
If after 60 seconds the time and date are still being suggested as 00:00 and 01/01 respec-
tively, please perform the following actions on the online dashboard:
- Click on “devices”.
- If the Z-Smart is listed here, please click on this to bring up its information screen, and
click “delete device”.
- Once the unit has been successfully deleted, or if it has not appeared in the devices list,
please remove the batteries from the Z-Smart and attempt step 2 again.

6 © 2 Save Energy Limited 2016
Using your OWL Z-Smart
The OWL Z-Smart has four viewing modes:
- Time/Date
- Consumption/Generation
- Consumption/Cost
- Generation/Export
Each of these viewing modes show differing information, covered in the following pages.
At any time, these modes of operation can be cycled through via the ▲/▼buttons on the
right hand side of the unit.
Cycle viewing mode back (▲)
Cycle viewing mode forward (▼)

© 2 Save Energy Limited 2016 7
Time/Date
3
1
4
1. Date/Time Mode Indicator
2. Battery Status
3. Time - In the format HH:MM
4. Date - In the format DD.MM; year is not included.
2

8 © 2 Save Energy Limited 2016
Consumption/Generation
2
1
4
1. Consumption/Generation Mode Indicator
2. Live Energy Usage - updated every 20 seconds, this shows how much energy your home
is currently consuming.
3. Usage Scale - provides a visual representation of your current usage.
4. Live Generation - updated every 20 seconds, this shows how much energy your solar
panels are currently generating.
3

© 2 Save Energy Limited 2016 9
Consumption/Cost
3
2
5
1. Currency selection button - cycles through €, $ and £.
2. Consumption/Cost Mode Indicator
3. Live Energy Usage - updated every 20 seconds, this shows how much energy your home is
currently consuming.
4. Usage Scale - provides a visual representation of your current usage.
5. Live Cost - updated every 20 seconds, this shows how much your current usage is
costing you per hour.
4
1

10 © 2 Save Energy Limited 2016
Export/Generation
2
1
4
1. Generation/Export Mode Indicator
2. Live Export - updated every 20 seconds, this shows how much energy you are currently
exporting back to the grid.
3. Export Scale - provides a visual representation of your current level of Export.
4. Live Generation - updated every 20 seconds, this shows how much energy your solar pan-
els are currently generating.
3

© 2 Save Energy Limited 2016 11
System Icons
Battery Level: This icon will slowly deplete as the battery level in the unit gets
lower. Once the battery symbol is on its nal bar or is empty, the batteries should
be changed.
Transmission Indicators: The TX and RX icons will appear briey whenever the
Z-Smart receives or sends information to the Network OWL.
Export Indicator: Visible on every screen, this icon being present indicates that
you are currently generating more than you are consuming.
Send/Receive Indicator: Indicates that the Z-Smart is currently using its radio
to communicate with the Network OWL.
Signal Strength: Indicates the signal strength between the Z-Smart and Network
OWL.

12 © 2 Save Energy Limited 2016
Technical Specications
Power Supply 3 Volts DC, 2x AA batteries
Operating Temperature Range +0oC to +40oC
Storage Temperature Range -25oC to +65oC
Dimensions 134 x 87 x 26mm
Approx. Weight (batteries included) ~200g
Operating Range 50m
Operating Frequency 868MHz
Refresh Rate 20 seconds
Compliance
The CE marking certies that this product meets the main requirements of EU Directive
1999/5/EC (R&TTE) and EU Directive 2011/65/EU (RoHS2). A copy of the signed declara-
tion of Conformity is available on request. OWL Intuition products are manufactured to
ISO9001 Quality Assurance Standards.

© 2 Save Energy Limited 2016 13
Warranty Information
2 Save Energy Limited guarantees that OWL Intuition products will work for a minimum
period of 24 months from date of purchase and that it will be free from defects in materi-
als, workmanship or design. If during this limited 2 year period of guarantee, from date of
purchase, you nd that the equipment is not working properly, you may return it to us and
we will replace, or (at our discretion) repair it, free of charge.
2 Save Energy will not accept any liability for defects arising from fair wear and tear,
accidental or wilful damage, misuse or failure to follow product or safety instructions. If
you return any equipment as faulty, 2 Save Energy reserves the right to test the equipment
and if found to be in perfect working order, to return it to you. In this event, 2 Save Energy
Limited reserves the right to charge for any testing or postage costs incurred. This does
not affect your legal rights relating to equipment which if faulty. Warranty conditions only
apply where proof of purchase is provided.
To return your OWL Intuition product please submit a support ticket via our helpdesk at
https://theowl.zendesk.com to report the issue and your reason for wishing to return your
product. 2 Save Energy Limited will issue you an RMA number. You should ensure that the
returned product is clearly marked with the issued RMA number. Once we have received
the product and proof of purchase we will commence the returns process.

14 © 2 Save Energy Limited 2016
This page is intentionally left Blank

© 2 Save Energy Limited 2016 15
This page is intentionally left Blank

16 © 2 Save Energy Limited 2016
Customer Support
If you have any further questions please check our knowledge base at:
https://theowl.zendesk.com
You can also email us at: [email protected]
(please ensure you state your Network OWL MAC ID)
2 Save Energy Limited operate a policy of continuous development and improvement,
therefore the content of this document is subject to change without notice.
Document Version 1.0 - June 2016
