2gig Technologies PASSIVE INFRARED MOTION DETECTOR Configuration guide

PASSIVE INFRARED MOTION DETECTOR
FCC ID: WDQ-PIR1345
Industry Canada ID: 7794A-PIR1345
INSTALL INSTRUCTIONS
ThePassiveInfraredMotionDetectorisawall‐mountedunitwithwide
anglemotionprotection.WhensettoHighSensitivityMode,thePassive
InfraredMotionDetector(PIR)hasamaximumrangeof30feetdeepx50
feetwide.ThePIRispetimmuneupto55lbs.
Box Contents
•Detector
•3VLithiumbattery
•3screwsand2dowels
•Bracket
•Flatwallmount
•Cornermount
Programming
Thefollowingstepsdescribegeneralguidelinesforprogramming
(learning)thePIRintotheControlPanel.Scrollbetweenoptionsusingthe
←and→arrows.Movetothepreviousornextpromptbypressingthe↑
and↓arrows.
1SelectRFsensor#(01to48).AssignthePIRtoanewzone.
2SelectRFsensortype:
(04)interiorfollower
(10)interiorwithdelay
3SelectRFsensorequipmentcode.Enter0533forthePassiveInfrared
MotionDetector.
4SelectRFequipmenttype.
(2)motion
5EnterRFsensorserialnumber(7digits).
ManualEntry:Typeinthelast7digitsoftheTXIDthatisfound
outsideoftheboxoronthebackofthedevice.
AutoEntry:WiththepanelinLearn‐inmode,(pressShiftthenLearn)
pressthetamperswitch.ThecorrectTXIDshouldappear.Acceptthe
correctTXIDbypressingok.
Remembertopressthe↓arrowtocontinuegoingthroughthe
systemconfigurationprompts.
6SelectRFsensorequipmentage(0to1).
(0)new(productisnew)
(1)existing(productalreadyexists)
7SelectRFsensorloopnumber(1to3).
8SelectRFSensordialerdelay(0to1)
(0)disabled
(1)enabled
9ConstructRFsensorvoicedescriptor.PressInsertthenpressany
numberbetween002and255toaddaword.Repeatthisforeach
word.Forexample,ifyouwanttonamethisPIRasthe“master
bedroom,”pressInsertthenpress140formaster.PressInsertthen
press024forbedroom.
10 SelectRFsensorreports(0to1).
(0)disabled(PIRdoesnotreporttothecentralstation)
(1)enabled(PIRreportstothecentralstation)
11 SelectRFsensorsupervised(0to1)
(0)disabled(detectordoesnotreportlossofsupervision/lowbattery)
(1)enabled(detectorreportslossofsupervision/lowbattery)
12 SelectRFsensorchime(0to13).
(0)disabled(panelwillNOTchimewhenPIRisactivated)
(1‐13)enabled(selectsavoiceandchimetosoundonthepanelwhen
thePIRisactivated)
13 Toprogramanothersensorclicknext.
14 Toexitprogramming,clickskipthenendandexit.Uponexit,the
paneltakesaseveralsecondstoreboot.
Testing
Beforemountingthedetector,ensurethatthePIRmountinglocation
providesgoodRFcommunicationtothepanel.Toverify,dothefollowing:
1FromtheInstallerToolbox,selectwalktest.
2PlacetheamagnetoverthearrowontheleftsideofthePIR,(the
detector’sLEDindicatesthatamagnethasbeendetected)andthen
removethemagnet(amagnetisnotsupplied).
3PlacethePIRinthelocationthatyouplanonmountingit.
4MoveintheareathatistobecoveredbythePIRandmakesurethat
theLEDonthePIRflasheseverytimeyoumove.TheLEDflashing
continuesfor1minutesoyoucancheckthePIRbeamcoverage.
NOTE: Thereisa3‐seconddelaybetweenflashesontheLED.
IMPORTANT: Thefollowingcancauseafalsealarmwhentesting:
•Leavingthecoveroff
•Removingjumpers
• PositioningthePIRindirectsunlightorcloseproximitytoaheatingor
anairconditioningduct
5Exitinstallertoolbox.
Inserting and Replacing Batteries
IfasupervisedPIRbatteryislow,alowbatterynotificationisindicatedon
theControlPanel’stouchscreen.Ifindicated,replacethebattery
immediately.Useonlytherecommendedreplacementbatteries(See
Specifications).
•Removebackcoverbyunscrewingbottomscrewandpullbackcover
frombottomtotop.Observethepolarityofthebattery.SeeFigure2.
WARNING: Improperhandlingoflithiumbatteriesmayresultinheat
generation,explosionorfire,resultinginpersonalinjuries.
Replaceonlywiththesameorequivalenttypeofbatteryas
recommendedbythemanufacturer(seeSpecifications).
Batteriesmustnotberecharged,disassembledordisposedofinfire.
Disposalofusedbatteriesmustbemadeinaccordancewiththe
wasterecoveryandrecyclingregulationsinyourarea.KeepAway
FromSmallChildren.Ifbatteriesareswallowed,promptlyseek
medicalattention.
CaliforniaOnly:ThisPerchloratewarningappliesonlytoManganese
DioxideLithiumcellssoldordistributedONLYin/California,U.S.A.
PerchlorateMaterial‐specialhandlingmayapply.Seedtsc.ca.gov/
hazardouswaste/perchlorate.
Installing and Mounting
RemovethescrewfromthebottomofthecaseandopenthePIR(see
Figure1).
1Installthe3VLithiumbatteryfromthebox.
2Settheleftjumper(PETIMMUNITY)toeither33lbs.(15kg)or55lbs.
(25kg;default).(seeFigure2)
3Settherightjumper(SENSITIVITY)toeitherLO(default)orHI(see
Figure2).
4Pressandreleasethetamperswitchtobeginthepowerupprocess.
5Wait10secondsforthePIRtofullypowerup.

Mounting the PIR with the bracket (see Figure 2)
1UseshortPhillipsheadscrewstoscrewpartAintopartB.
2Selecteitherthecornermount(partC)orflatwallmount(partD).
3Mounttheselectedbracket(CorD)ataheightof7.5ft(2.3m).on
thewallusingthesuppliedlongscrewswithanchors.
4PlacetheassemblyofpartsAandBontheshaftofbracketCorD.
5ScrewaPhillipsheadscrewwithwasherintothetopofparBtohold
theassemblytotheshaftofbracketCorD.
6AttachthemainbodyofthePIRtothemountedbackwithascrewat
thebottomofthecase.
Mounting the PIR without bracket (see Figure 3)
1Forcornermountingusethesuppliedlongscrewswithanchorsand
mountthePIRcasebackusingeithertherighttwocornermount
screwholes(A)orthelefttwocornermountscrewholesandmount
thePIRbackataheightof7.5ft.(2.3m).Attachthemainbodyofthe
PIRtothemountedbackwiththescrewatthebottomofthePIR.
2FormountingthePIRonaflatwallusethe
suppliedlongscrewswithanchorsandmount
thePIRcasebackusingthe2wallmountscrew
holesinthecenterofthebackandmountthe
backataheightof7.5ft.(2.3m).Attachthe
mainbodyofthePIRtothemountedbackwith
thescrewatthebottomofthePIR.
Using the PIR with Pets
Totakefulladvantageofthepetimmunityfeatures,dothefollowing:
1EnsurethatthePIRismounted7.5‐8feetabovefloorlevel.
2Settherightjumper(SENSITIVITY)tolow(default).
3Ensurethattheleftjumper(PETIMMUNITY)issettoyourpet’s
weight.
4DonotaimthePIRatstairsorfurniturethatyourpetcouldclimbon.
NOTE: ThePIRprovidesimmunitytofalsealarmsforanindividual
animaloragroupofanimalswhosetotalweightisequaltoorless
than55poundswhentheroomtemperatureisabove50°Fand
below90°F.Ifyouusedtheoptionalmountingbracket,ensurethat
thePIRismountedwithNOtilt.
Environmental and other Useful Information
WhilethePIRisahighlyreliableintrusiondetectiondevice,itdoesnot
guaranteeagainstburglary.Anyintrusiondeviceissubjecttocompromiseof
failuretowarnforavarietyofreasons.Considerthefollowingwheninstalling
thePIRforthefirsttimeorwhenyouaretroubleshooting:
1ThisPIRhasbuilt‐inprotection,thatkeepsbugsfromgettingintothe
sensorareaandcausingfalsealarms.Thisdoesnotpreventinsects
fromcrawlingacrossthelensofthePIR,whichcouldtriggerthePIR.
2Infraredenergycanbereflectedoffanyglossysurfacessuchas
mirrors,windows,floorsorcountertopswithglossyfinish,andslick
finishedconcrete.Somesurfacesreflectlessthanothers.For
example,thePIRcanseeachangeininfraredenergyoffofreflective
surfaceseveniftheheatorcoldsourceisnotwithinthePIRdetection
pattern.
3Windowscannotonlyreflectinfraredenergy,buttheycanalsoallow
sunlightorlightsfromcarstopassthroughtothePIR.Forexample,a
PIRcandetectaquickchangeininfraredenergyifsunlightcomes
throughawindowandshinesonahardwoodfloor.Ifthechangein
infraredenergyisquickenoughonthehardwoodfloor,thePIRcan
triggeranalarm.ThesameappliesifthePIRareaincludesawindow,
eventhoughthepatternofprotectioncannot“see”throughglass.
Lightsfromapassingcarcanalsopassthroughthewindowatnight
anddirectlyinthelensofthePIR.
4Heatingandairconditioningductsarealsoimportantbecauseifthey
blowairontoanobjectwithinthefieldofthePIR’sview,the
temperatureofthatobjectcouldchangequicklyenoughforthe
detectorto“see”achangeininfraredenergy.PIR’sCANNOTseeair
current,onlythechangeintemperatureofaphysicalobject.
5ThePIRsenseschangeintemperature;however,astheambient
temperatureoftheprotectedareaapproachesthetemperature
rangeof95°to120°F,thedetectionperformanceofthePIR
decreases.
6EnsurethattheareayouwishthePIRtocoverisfreeofobstructions
(curtains,screens,plants,etc.)thatmayblockthepatternof
coverage.
7Anythingthatcanswayormoveduetoaircurrentcancauseachange
ininfraredenergywithinthefieldsofview.Draftsfromdoorsor
windowscancausethistohappen.Plants,balloons,curtainsand
hangingbasketsshouldneverbeleftinthePIR’sfieldofview.
8DonotmountthePIRonasurfacethatallowsforanyvibration.
VibrationsnotonlycausethePIRtomovealittle,butitalsocauses
thefieldsofviewinaroomtomovewithrespectthePIR.Alittle
vibrationcancausehavocwiththePIR’sfieldofview,thusthePIR
mayseeachangeinenergyandtriggerthealarm.
9AninstallationoftenrequiresthatthePIRisaimedatthedoor.The
PIRmaydetectdoormovementbeforethedoorcontactcaninitiate
anentrydelay,causingthealarmtotrigger.IfyouinstallthePIR
facingadoor,thenwhileprogrammingthePIR,chooseanentrydelay.
10 ThePIRONLYdetectsintrusionwithinthepatternofcoverage.
11 ThePIRdoesnotprovidevolumetricareaprotection.
12 ThePIRcreatesmultiplebeamsofprotection.Intrusioncanonlybe
detectedinunobstructedareascoveredbythosebeams.
13 ThePIRcannotdetectmotionorintrusionthatoccursbehindwalls,
ceilings,floors,closeddoors,partitions,glassdoorsorwindows.
14 Tamperingwith,masking,painting,orsprayingofanymaterialonthe
PIRlensoranypartoftheopticalsystemcanimpairdetectionability.
15 ThePIR,likeotherelectricaldevices,aresubjecttocomponent
failure.EventhoughthePIR2isdesignedtolastaslongas10years,
theelectroniccomponentsaresubjecttofailure.
Specifications
FCC Compliance Statement*
Notice:Unauthorizedchangesormodificationscouldvoidtheuser’sauthoritytooperatethe
equipment.
ThisdevicecomplieswithPart15oftheFCCRulesandIndustryCanadalicense‐exemptRSS
standard(s).Operatingissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperationofthedevice.
2GIG Copyright © 2013. All rights reserved.
For technical support in the USA and Canada
855-2GIG-TECH (855-244-4832)
For technical support outside of the USA and Canada
Contact your regional distributor
Visit 2gig.com for a list of distributors in your region
PN 187-0727 Rev. E
ACornermountingscrewholes
BFlatwallmountingscrewholes
CBracketscrewholes
WirelessSignalRange 350ft.,openair,with2GIGControlPanel
CodeOutputs Alarm;AlarmRestore;Tamper;TamperRestore;Supervisory;
LowBattery
TransmitterFrequency 345,000MHz(crystalcontrolled)
TransmitterFrequencyTo leran ce ±1 5kHz
TransmitterBandwidth 24kHz
ModulationType AmplitudeShiftKeying‐On/OffKeying(ASK‐OOK)
UniqueIDCodes Over1milliondifferentcodecombinations
SupervisoryInterval 70minutes
PeakFieldStrength Typical50,000uV/mat3m
SensorType Quadelement
Petimmunity Selectable:15kg(33lbs)or25kg(55lbs;default)
SensitivityJumper Selectable:HIghorLow(default)
SuggestedMountingHeight 7.5ft(2.3m)
SensorRange 30ft.(9.1m)x50ft.(15.2m)
Max.HorizontalSensingAngle 90°
Dimensions(LxWxH) 3.2x2.5x1.9in.(8.12x6.35x4.82cm)
Weight(inc.battery&bracket) 3.7oz.(104.9g)
HousingMaterial ABSplasticandpoly‐carbonate
Color White
OperatingTemperature 32°to120°F(0°to49°)
RelativeHumidity 5‐95%Non‐Condensing
Battery(included,notinstalled) 1PanasonicCR123A,orequivalentLithiumbattery
RegulatoryLIstings ETL,FCCPart15,IndustryCanada
Warranty* 2years
IncludedAccessories Mountingbrackets,2longPhillip’sheadscrews,2plasticwall
anchors
