2gig Technologies 2GIG-DBELL1-345 Configuration guide

INSTALL INSTRUCTIONS
The2GIG‐DBELL1‐345isadualpurposedoorbellthatwillworkwithboththestandard
24Vwiringinthehouseandwirelesslywiththe2GIGControlPanel.Itfeaturesa
buttonthatisfullywater‐resistantandremainsilluminatedwhenthe24Vhouse
doorbellwiringisused.
Box Contents
•2woodscrews
•2machinescrews
• Doorbellsensor
•InstallInstructions
•O‐ring
Programming
Thefollowingstepsdescribegeneralguidelinesforprogramming(learning)thesensor
(2GIG‐DBELL1‐345)intothe2GIGpanel.Scrollbetweenoponsusingthe←and→
arrows.Movetothepreviousornextpromptbypressingthe↑and↓arrows.
1SelectRFsensor#(01to48).AssigntheDoorbelltoanewzone.
2SelectRFsensortype.
(23)noresponsetype(systemwillchimewhenthedoorbellispressed,butnottriggeralarm)
3SelectRFequipmenttype.
(1)contact
4SelectRFsensorequipmentcode.Enter1063fortheDBELL1‐3452GIGdoorbell.
5EnterRFsensorserialnumber(7digits).
ManualEntry:Typeinthelast7digitsoftheTXIDthatisfoundoutsideoftheboxoronthebackofthedevice.
AutoEntry:WiththepanelinLearn‐inmode(pressShiftthenLearn)pressthedoorbellbutton.ThecorrectTXIDshouldappear.Accept
thecorrectTXIDbypressingok.
Remember to press the ↓arrow to connue going through the 2GIG system configuraon prompts.
6SelectRFsensorequipmentage(0to1).
(0)new(productisnew)
(1)existing(productalreadyexists)
7SelectRFsensor1loopnumber(1to3).
(1)1
8SelectRFsensor1dialerdelay.
(0)disabled
9ConstructRFsensorvoicedescriptor.PressInsertthenpressanynumberbetween002and255toadda
word.Forexample,ifyouwantedtonamethisdoorbellas“frontdoor,”pressInsertthenpress098for
FRONT.PressInsertthenpress058forDOOR.Press↓toconnueconfiguringthesystem.
10 SelectRFsensorreports(0to1).
(0)disabled
(1)enabled
11 SelectRFsensorsupervised(0to1).
(0)disabled(sensordoesnotreportlossofsupervision)
(1)enabled(sensorreportslossofsupervision)
12 SelectRFsensorchime(0to13).
(0)disabled(panelwillNOTchimewhensensorisactivated)
(1‐13)enabled(selectsavoiceandchimetosoundwhensensorisactivated)
13 Toprogramanothersensorclicknext.
14 Toexitprogramming,clickskipthenendandexit.Uponexit,thepaneltakesaseveralsecondstoreboot.
Testing
Beforemountingthesensor,ensurethatthesensormountinglocationprovidesgoodRFcommunicationtothe
panel.Toverify,dothefollowing:
1FromtheInstallerToolbox,selectwalktest.
2Pressandreleasethedoorbellbuttonandlistenforchimeorkeypadbeepstodeterminetheappropriateresponse(refertothe2GIG
Control Panel Install Guide).
3ExittheInstallerToo l b ox.
4(OptionalafterInstallingandMounting)Verifythatthehousehold24VACconnectionisworkingbypressingthedoorbellbuttontoring
thedoorbell.
Installing and Mounting
Ifpossible,locatesensorswithin100ft(30m)ofthepanel.Whileatransmittermayhavearangeof350ft(106m)ormoreoutintheopen,the
environmentattheinstallationsitecanhaveasignificanteffectontransmitterrange.Althoughthedoorbellhasbeendesignedtowithstand
weather,avoidmountingitinareaswhereitwillbeexposedtoextrememoisture.
1Toremovethesensorcover,useyourfingertopressthetab.Thisdisengagestheclipholdingthecovertothebase.
2(Optional)Pulltheexistinghouse24ACwiringthroughtheholeifconnectingthedoorbelltoexisting24Vdoorbellwiring.
3Mountthe2GIG‐DBELL1‐345usingtheorientationshown.UsethesuppliedPhillipswoodscrewstoattachthebasetothemounting
surface.Ensurethattheorientationarrowsarepointedup(asshown).
4PlacethesuppliedO‐ringaroundtheperimeterofthebase.
5Ifavailable,attachtheexisting24VAChouseholddoorbellwiringtotheboardusingthemachinescrewsprovided.Ifthisstepisskipped,
thedoorbellwillworkonlywiththe2GIGControlPanelandtheLEDwillnotilluminate.
6Pullthebatterytaboutanddiscardtabproperly.
7Replacethesensorcover.Ensurethatthedrainholeisfacingdown.Ifthecoverdoesnotsnapinplace,itmaybeupsidedown.
FCCID:WDQ‐DBELL1345
IndustryCanadaID:7794A‐DBELL1345
DOORBELL

Inserting and Replacing Batteries
Ifasupervisedsensorbatteryislow,alowbatterynotificationwillbeindicatedonthecontrolpanelscreen.Whenthe2GIG
systemindicatesthatthesensorhasalowbattery,replacethebatteryimmediately.Useonlytherecommended
replacementbatteries(SeeSpecifications).
1Toremovethesensorcover,useyourfingertopressthetab.Thisdisengagestheclipholdingthecovertothebase.
2Placeasmallflatheadscrewdriverintheslotbetweenthemetalclipandbatteryandpushitouttakingcarenotto
scratchthebatteryterminal.
3Insertthereplacementbatterywiththe+signfacingout.
4VerifyprogrammingandRFcommunicationwiththecontrolpanel.
5Replacethesensorcovertothebase.
WARNING: Thepolarityofthebatterymustbeobserved,asshown.Improperhandlingoflithiumbatteriesmay
resultinheatgeneration,explosionorfire,resultinginpersonalinjuries.Replaceonlywiththesameor
equivalenttypeofbatteryasrecommendedbythemanufacturer(seeSpecifications).Batteriesmustnotbe
recharged,disassembledordisposedofinfire.Disposalofusedbatteriesmustbemadeinaccordancewiththe
wasterecoveryandrecyclingregulationsinyourarea.KeepAwayFromSmallChildren.Ifbatteriesareswallowed,
promptlyseekmedicalattention.
CaliforniaOnly:ThisPerchloratewarningappliesonlytoManganeseDioxideLithiumcellssoldordistributed
ONLYin/California,U.S.A.PerchlorateMaterial‐specialhandlingmayapply.Seedtsc.ca.gov/hazardouswaste/
perchlorate.
Specifications
FCC and Industry Canada Regulatory information
Notice:Unauthorizedchangesormodificationscouldvoidtheuser’sauthoritytooperatetheequipment.
ThisdevicecomplieswithPart15oftheFCCRulesandIndustryCanadalicense‐exemptRSSstandard(s).Operatingissubject
tothefollowingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany
interferencereceived,includinginterferencethatmaycauseundesiredoperationofthedevice.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBcomputingdevice,pursuanttoPart15of
FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyandifnotinstalledandusedin
accordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguarantee
thatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna
•Increasetheseparationbetweentheequipmentandthereceiver
•Consultthedealeroranexperiencedradio/televisiontechnicianforhelp
LIMITED WARRANTY
This2GIGTechnologiesproductiswarrantedagainstdefectsinmaterialandworkmanshipfor2years.Thiswarrantyextendsonlyto
wholesalecustomerswhobuydirectfrom2GIGTech no l og ies orthrough2GIGTechnologies’normaldistributionchannels.2GIG
Tech n ol o gi es doesnotwarrantthisproducttoconsumers.Consumersshouldinquirefromtheirsellingdealerastothenatureofthe
dealer’swarranty,ifany.
Therearenoobligationsorliabilitiesonthepartof2GIGTechnologiesforconsequentialdamagesarisingoutoforinconnection
withuseorperformanceofthisproductorotherindirectdamageswithrespecttolossofproperty,revenue,orprofit,orcostof
removal,installation,orreinstallation.Allimpliedwarrantiesforfunctionality,arevalidonlyuntilthewarrantyexpires.This2GIG
Tech n ol o gi es Warrantyisinlieuofallotherwarrantiesexpressorimplied.
AllproductsreturnedforwarrantyservicerequireaReturnProductAuthorizationNumber(RPA#).Contact2GIGTechnologiesat
1(866)670‐1591foranRPA#andotherimportantdetails.
Warrantyservicereturnaddress:
2GIGTec h n o l o g i e s , Inc.
2961WMapleLoopDrive
Lehi,Utah84043
TechnicalSupportContactInformation
1‐855-244‐4832
Email:[email protected]
Internet:dealer.2gig.com
PN77‐000004‐001RevF
2GIGCopyright©2012.Allrightsreserved.
WirelessSignalRange 350ft,openair,with2GIGWirelessControlPanel
CodeOutputs Alarm;AlarmRestore;Supervisory;LowBattery
TransmitterFrequency 345.000MHz(crystalcontrolled)
TransmitterFrequencyTolerance ±15kHz
TransmitterBandwidth 24kHz
ModulationTypeAmplitudeShiftKeying‐On/OffKeying(ASK‐OOK)
UniqueIDCodes Overonemilliondifferentcodecombinations
SupervisoryInterval 70minutes
ExternalInputSamplingCurrent 20uA
ExternalInput 24VACStandarddoorbellcircuit
SensorDimensions(HxD) 2.75x1.17x0.63in.(6.98x2.97x1.60cm)
Weight(includingbatteryandmagnet) 1.1oz.(31.2g)
HousingMaterial ABSplastic
Color White
OperatingTem p e rature Limits 14°to104°F(‐10°to40°C)
RelativeHumidity 5‐95%Non‐Condensing
Battery(installedwithpulltab) OnePanasonicCR2032orequivalentLithiumbatteries
IncludedAccessories FourPhillipsflat‐headscrews
