3am Systems LineScope User manual

014.10
:. Quickstart guide

014.10
1. Wiringup
ConnecttheLineCouplerin
serieswith thetelephone
lineyouwant tomonitor.
Connectthetrailing3.5mm audiojack fromtheLineCouplerto
theMicrophoneinput onyour PC, whichisusually pink.
Ifyoucomputerhasa single4-polemulti-purposejack,youwill
alsoneed tousethesupplied whiteTRRSsplittercable.
2. Checksystem readiness
Haveyoueverusedyour PCtorecordaudiobefore?
Beforeusing LineScope, ensurethattheaudiorecording
subsystem onyour computerisworkingproperly.
Ifyourunintoproblems, reviewthefollowing:
§Download thelatest audiodrivers
§Disablethird-partyaudioenhancements
Beforeblaming LineScope, test your
system with a different audiorecording
application.Werecommend Audacity,a
freewareaudioeditor.

014.10
3. Set therecordinglevel
OpenLineScope, starta recording, andclick onthe
MixericoninLineScopetolaunchthemixerapplet.
SelecttheMicrophoneasthe
recording source, andinitiallysetthe
recording levelhalfway.
Ifthereisan‘Advanced’ button, click
it, and thendisabletheAGCfeatureif
shown.
inXP mixer
Recording level indicator
on the LineScope status bar
Settherecordinglevelsothatthelevel
indicatorisatroughly70% whena dial
toneordatacarriers arepresent.
4. What shouldrecordings looklike?
Your recordingsshould
look and soundlikethe
demonstrationWAV files
intheSamplesfolder.
Spectrogram
aveform envelope Constellation

014.10
5. WindowsVista/7/8audio
InWindows Vista/7/8, important features
related toaudiorecordingarea littledifferent
from Windows XP.
Sound applet in Vista
Innewerversions of Windows,
whenyouclick theMixericonin
LineScope, youwillsee theSound
applet.
Selectthe ecording tab,
highlight theMicrophonedevice,
click Set Default ifneeded, and
then, click Properties button.
Usethe Levels tab toadjust
theinput level.
Ifpresent, usethe Listen tab
toenablemonitoring.
Disableany Enhancements.
Microphone Properties in Vista
Pleasevisitour website
www.3amSystems.com
formoreinformation.
