3Com 3CR990 User manual

3Com
®
Embedded Firewall
Software for the 3CR990
Network Interface Card (NIC) Family
Quick Start Guide
http://www.3com.com/
http://www.3com.com/registration/frontpg.pl
09-2110-000
Published December 2001

3Com Corporation ■ 5400 Bayfront Plaza ■ Santa Clara, California ■ 95052-8145 ■ U.S.A.
Copyright © 2001 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any
form or by any means or used to make any derivative work (such as translation, transformation, or adaptation)
without written permission from 3Com Corporation.
3Com, EtherCD, and EtherLink are registered trademarks and the 3Com logo is a trademark of 3Com Corporation.
Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be
registered in other countries.
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
All other company and product names may be trademarks of the respective companies with which they are associated.
3Com Corporation reserves the right to revise this documentation and to make changes in content from time to
time without obligation on the part of 3Com Corporation to provide notification of such revision or change.
3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or
expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory
quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or
the program(s) described in this documentation at any time.
If there is any software on removable media described in this documentation, it is furnished under a license
agreement included with the product as a separate document, in the hard copy documentation, or on the
removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please
contact 3Com and a copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software described herein are
provided to you subject to the following:
All technical data and computer software are commercial in nature and developed solely at private expense.
Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a
“commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in
3Com’s standard commercial license for the software. Technical data is provided with limited rights only as
provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not
to remove or deface any portion of any legend provided on any licensed program or documentation contained in,
or delivered to you in conjunction with, this user guide.
EXPORT RESTRICTIONS
This 3Com product and/or software contains encryption and may require U.S. and/or local government
authorization prior to export or import to another country.

Contents
What You Will Need 1
Installing EFW Policy Server and
Management Console Software 2
Initializing the Policy Server 3
Starting the Management Console and
connecting to the Policy Server 4
Setting up License-activation Keys 4
Creating and retaining a recovery diskette 5
Importing the “No sniffing, no spoofing” pre-defined Policy and
Assigning it to the Default Device Set 6
Installing and Registering an EFW NIC 7
Verifying NIC Registration 8
Changing the Policy for an EFW NIC 8
Importing the “Windows 2000 Standard” Rule Set 9
Creating a Policy 9
Creating a Sample Device Set 11
Moving the EFW NIC to the New Device Set 12
Testing Policy Enforcement and Viewing Audit Data 12
Expanding Your EFW Configuration 13

1
Quick Start Guide
This quick start guide assists you in installing and configuring a basic EFW
system that you can use as a starting point to tailor the system to your
organization’s security needs.
After completing the steps in this guide, you will have a basic EFW system
setup that includes:
■
An operational Policy Server and Management Console
■
A single embedded firewall (EFW) NIC
■ An understanding of how to import and create policies
■
An understanding of how to change the policy for a NIC
The final section in this guide points you to key sections in the 3Com
Embedded Firewall Administration Guide that provide detailed information
for expanding your EFW system to best suit your security needs.
What You Will Need
Before you install the EFW software, you will need:
■
A computer to host the Policy Server and Management Console that
meets the following requirements:
■ Operating system: Microsoft Windows 2000 or Windows NT 4-SP4
■ CPU: 600 Mhz or higher (recommended)
■ RAM: 128 MB
■ Disk space 150 MB
■ Monitor/video: 256 colors or higher, screen area set to 600 x 800 or
higher
■ System with a static IP address
■
A second computer to host an embedded firewall that meets the
following requirements:
■ Operating system: Microsoft Windows 2000, Windows XP Professional,
Windows NT 4-SP3, or Windows 98
■ CPU: No minimum requirement
■ RAM: 16 MB
■ Web browser with access to the Internet (for testing purposes)
■ 3CR990 NIC with factory drivers installed and operational in
the network

Quick Start Guide
2
■
Network connectivity between the two systems listed above
■ Capability to move file folders larger than a diskette between the two
systems (for example, a zip drive on each system, file compression
software and FTP on both systems, a shared drive, etc.)
■
One 3.5” diskette for creating a recovery diskette
■
Administrative privileges on both systems (required to install and run EFW
software as instructed here)
You should also become familiar with the 3Com Embedded Firewall
Administration Guide . If you encounter problems during installation, refer
to Appendix B, “Troubleshooting,” in that guide. It offers a list of common
problems you may encounter and offers suggestions for solving these
problems. If you have any further questions, contact 3Com technical support
as described in the administration guide.
Installing EFW Policy Server and
Management Console Software
The steps below provide instructions for installing a Policy Server and
Management Console on a single system using the Typical installation method.
1 Insert the 3Com product CD in the appropriate drive; the Installation
wizard launches automatically, and a Welcome window appears.
2 Click Next . The License Agreement window appears.
3 Read the terms of the license agreement, and select I accept the terms
in the license agreement . Click Next . The Customer Information
window appears.
4 Type your user name and organization name in the appropriate fields.
Click Next . The Installation Type window appears.
5 Select Typical Centralized Management . This selection installs the Policy
Server software and Management Console software.
6 Click Next . In the EFW Domain Association window, select Create a new
EFW domain .
7 Click Next . The Ready to Install the Program window appears.
8 Click Install . The Installation wizard installs the features you selected.
A status bar appears, allowing you to monitor the installation progress.
9 When the Installation wizard is complete, the InstallShield Wizard
Completed window appears.

Initializing the Policy Server
3
10 Click Finish to complete the installation process.
11 When the window appears asking if you want to start the Policy Server
now, click Yes .
Initializing the Policy Server
The first time you start the Policy Server, the Join Existing EFW Domain or
Create EFW Domain window appears. Follow the steps below.
1 Select the host name or IP address for the new Policy Server from the
list displayed.
If all EFW NICs and Policy Server hosts in your EFW domain will reside on
one network, select the host name.
Otherwise, select an IP address such that:
■ the NICs to belong to this EFW domain can resolve this address
■ traffic originating at the Policy Server machine and going to the EFW
NICs in this domain is routed through the network card on the Policy
Server machine corresponding to this address.
In most cases only one IP address is offered on this screen.
2 Select Confirm Create New Domain .
3 Enter a domain name in the Domain Name field.
The domain name is used only as a reference to assist you in identifying a
particular domain, if multiple domains are created.
4 Click OK . A Policy Server Startup window appears, displaying the status of
the various Policy Server components.
When “Policy Server Initialized” appears at the bottom of the window, the
Policy Server is fully operational. To close this window, click the X in the
upper right corner of the window. (This window is informational only and
may be left open or closed at any time without affecting the Policy Server.)
NOTE: Under some network configurations, you may successfully
select the host name option here, even if your EFW domain is spread
across several networks. If you are interested in examining this option
in detail now, refer to the section “Joining a New Policy Server to a
Domain” in the 3Com Embedded Firewall Administration Guide.
NOTE: After first start-up, the Policy Server automatically starts when
the system is rebooted.

Quick Start Guide
4
Starting the Management Console and
Connecting to the Policy Server
The Management Console is the administrative interface to the Policy Server.
You can configure the system and view data using the Management Console.
To start the Management Console, follow the steps below.
1 From the Windows Start menu, select Programs -> 3Com Embedded
Firewall Management . One of the following two options appears:
■ 3Com Embedded Firewall Management Console— If this option
appears, select it to open the 3Com Embedded Firewall Login window.
■ 3Com MMC Embedded Firewall Management Console — If this option
appears, select it to open the 3Com MMC Embedded Firewall
Management Console, and then double-click Embedded Firewall
Management Console . The 3Com Embedded Firewall Login window
appears.
2 Enter your EFW login name and password in the appropriate fields.
The default EFW login and password for a new system are as follows:
■ Login: admin
■ Password: admin
3 Select the Policy Server that you just created from the Policy Server list.
4 Click Connect . The Embedded Firewall Management Console window
appears, and the Policy Server to which you are connected is listed in
the tree-view frame of the Server tab.
Setting up License-activation Keys
License-activation key numbers are provided with the EFW software. The first
time you log in to the system, you must enter these keys to enable all of the
EFW functionality. Three types of licenses exist: Policy Server licenses, EFW
server NIC licenses, and EFW desktop NIC licenses. To complete the steps in
this quick start guide, you need to add an activation key for the Policy Server
you created, and for the EFW NIC you will be adding in a later section of
this guide.
NOTE: An information window appears the first time you connect to
the Management Console, notifying you that no Policy Server or NIC
licenses currently exist. You will learn how to add license-activation
keys in the following section of this guide. Click OK to close the License
Warning window.

Creating and retaining a recovery diskette
5
To add the activation keys, follow the steps below.
1 In the Management Console Tools menu, select License Manager .
The License Summary window appears.
2 Click Add Keys . The Add Activation Key window appears. Enter the
activation key and click Add for each activation key that you want to add.
3 When you have finished adding activation keys, click Close to close the
Add Activation Key window.
4 Click Close to close the License Summary window. All EFW system
functionality is now available.
For more information on license-activation keys, refer to the section “Licensing
Overview” in the 3Com Embedded Firewall Administration Guide.
Creating and retaining a recovery diskette
Communication is encrypted between EFW devices and the Policy Server,
between the Management Console and the Policy Server, and between Policy
Servers. Policy Servers identify themselves to each other, to the Management
Console, and to their EFW devices (NICs) using two public/private key pairs
generated upon creation of a new EFW domain.
After installing your first policy server in an EFW domain, it is critical to make a
copy of the files named public.key and server.keystore from your installation.
Save this data indefinitely in a safe, secure location.
In the unlikely event of a disaster, such as a disk crash on all of your policy
server machines and a simultaneous loss of all disk backups for these
machines, this recovery diskette allows you to “clone” your policy server and
regain management control of your NICs. A clean installation of the policy
server cannot communicate with your EFW NICs (which is the intended design,
for security reasons).
If you do not create a recovery diskette and you lose all policy server
installation data, you will not be able to recover your NICs. They
continue to enforce the fallback mode specified in their last EFW policy,
indefinitely. These NICs must be replaced in order to obtain a different policy.
To create a recovery diskette, follow the steps below.
1Insert a formatted 3.5” diskette into the a: drive of the computer hosting
the Policy Server.
2Save the public.key and server.keystore files to diskette. (These files are
located in Program Files -> 3Com Corporation -> 3Com EFW.)

Quick Start Guide
6
3Remove and label the diskette, and store it in a secure location for as long
as any EFW NIC remains in the domain for this Policy Server.
Importing the “No sniffing, no spoofing” Pre-defined
Policy and Assigning it to the Default Device Set
After you have added the appropriate license-activation keys, you can import
or create policies to assign to your EFW NICs. In this section you will import a
single pre-defined policy (the “No sniffing, no spoofing” policy) and assign it
to the existing default device set. After this policy is assigned to the default
device set, any NICs that automatically register with the Policy Server receive
the “No sniffing, no spoofing” policy because these NICs are automatically
placed in the default device set upon registration.
To import the “No sniffing, no spoofing” pre-defined policy, follow the
steps below.
1From the Main menu, select Import Policy/Rule set. The Import Policy/Rule
Set window appears.
2Select Policy and click Next.
3Click Browse and navigate to Program Files -> 3Com Corporation -> 3Com
EFW -> predefined-policies-rulesets.xml. Click Next. A list of the policies
contained in the file appears.
4Select the No sniffing, no spoofing pre-defined policy and click Next.
A summary window appears, showing the policy you selected.
5Click Import. A message appears indicating whether the import was
successful.
6Click Finish.
After you have imported the “No sniffing, no spoofing” policy, you can assign
it to the default device set by following the steps below.
1In the Management Console, click the Device Sets tab in the bottom left
portion of the window.
2Click Default Device Set in the tree-view frame. An information window
for the default device set appears in the working frame.
3Click the Policy drop-down list, and select No sniffing, no spoofing policy.
4Click Save.

Installing and Registering an EFW NIC
7
Installing and Registering an EFW NIC
You are now ready to install and register an EFW NIC using the network
installation method.
1In the Management Console Tools menu, select Create NIC Installation.
The EFW NIC Install Package wizard launches automatically.
2Select Network as the installation package type and click Next.
3From the drop-down list, select the first contact Policy Server for the NIC
installation when prompted. (This Policy Server is the one that you created
during the installation process earlier in this guide.) Click Next.
4Choose the location to which you want to save the installation
information. (A network installation package does not fit on a 3.5”
diskette.) Click Next.
5Review the information you entered, and click Create to create the
installation package for the network. When prompted, click Finish.
6Manually copy the contents of the folder specified in Step 4 to a
temporary directory on the computer that will receive the EFW NIC
installation (on a computer on which a 3Com 3CR990 NIC is installed).
NOTE: You may assign any policy to the default device set. The “No
sniffing, no spoofing” policy is generally a good choice, since it
increases network security and blocks few legitimate activities on the
network. If you have a system that requires sniffing, spoofing, or both
capabilities, you can manually register it and assign it to a device set
with a different policy, or you can allow it to register with the system
to the default device set and then move it to a different device set.
NOTE: If diagnostics are desired for a NIC installation, install them first
from the 3Com EtherCD®before installing EFW. Installing them over
EFW may make the card inoperable.
NOTE: After installation of EFW on a card, installing any non-EFW
firmware over this EFW installation may render the card inoperable.
If you wish to install non-EFW firmware on an EFW NIC, you must
first successfully delete the NIC from its EFW domain using the
Management Console, as noted in the section “Uninstalling an EFW
NIC” in the 3Com Embedded Firewall Administration Guide.

Quick Start Guide
8
7On the computer receiving the EFW NIC installation, run the setup.exe file
located in the temporary directory that was copied in Step 6. (For larger
installations of multiple NICs, you can simply run the installation from a
login script or other installation utility.)
Verifying NIC Registration
The NIC automatically registers with the Policy Server on the final reboot
that is required by the installation process. When the computer has finished
rebooting, the EFW NIC is displayed in the Management Console. To verify
that the EFW NIC registered correctly, follow the steps below.
1In the Management Console, click the Device Sets tab in the lower left
corner of the window.
2Select Edit -> Refresh.
3Click on the Default Device Set in the tree-view frame. The NIC should be
listed in the default device set.
4If desired, remove the temporary directory created for the NIC installation
package.
For information on other installation methods, refer to the section
“Distributing and Installing the EFW NIC Firmware” in the 3Com Embedded
Firewall Administration Guide.
Changing the Policy for an EFW NIC
You can allow all EFW NICs to register with the default device set, and then
move them to a different device set at a later time. To demonstrate this move,
you will:
■create a rule set,
■create a policy and add the new rule set,
■assign the new policy to a device set, and
■move the EFW NIC to the device set.
NOTE: Before you change the policy for the EFW NIC, test your Internet
access to ensure that the system hosting the EFW NIC can navigate
to the 3Com Web site, by connecting to www.3com.com. In a later
section, you will attempt to access the same Web site, which at that
point should be denied by the policy being enforced.

Changing the Policy for an EFW NIC
9
Importing the “Windows 2000 Standard” Rule Set
Before you create the sample policy, you need to import the Windows 2000
Standard rule set, which will be added to the sample policy in the next section.
To import the Windows 2000 Standard rule set, follow the steps below.
1From the Main menu, select Import Policy/Rule set. The Import Policy/Rule
Set window appears.
2Select Rule Set and click Next.
3Click Browse and navigate to Program Files -> 3Com Corporation -> 3Com
EFW -> predefined-policies-rulesets.xml. Click Next. A list of the rule sets
contained in the file is displayed.
4Select the Windows 2000 Standard pre-defined rule set and click Next.
A summary window appears, showing the rule set you selected.
5Click Import. A message appears indicating whether the import was
successful.
6Click Finish.
After you have imported the Windows 2000 Standard rule set, you can create
a sample policy by following the steps in the section below.
Creating a Policy
In this section you will create a sample policy (called the “No IP Initiation”
policy) that can be used on a system where the security goal is to minimize
the threat to your network if the machine is taken over by a hostile external
or internal agent. To achieve this goal, you will create a policy that:
■Allows the system to boot up as a member of a Windows domain
(achieved by implementing the Windows 2000 Standard rule set in
step 6 on the next page).
■Does not allow the system to initiate any TCP communication beyond
that allowed to boot up and connect to the network domain, etc. This
disallowance prevents a hostile agent from using this machine as a
launching point for an attack on the network (achieved by the rule
created in step 7 on the next page).
This type of policy would normally be used for a server machine. It is not
appropriate for an end-user workstation because it would not allow the user
to initiate any network traffic.

Quick Start Guide
10
To create the “No IP Initiation” policy, follow the steps below.
1In the Management Console Main menu, select New -> Policy. The Create
a New Policy window appears.
2Type No IP Initiation in the Policy field and click OK. The new policy
information appears in the working frame.
3Select the following policy-setting check boxes:
■No Sniffing
■No Spoofing, No Routing
■Allow non-IP Traffic
■Allow Fragmented IP Packets
■Allow IP Options
4Select Allow All Traffic in the Fallback Mode drop-down list. A fallback
policy is used by a NIC if it is unable to reach the Policy Server on boot-up.
5Type a description of the policy in the Description field, if desired. This field
is optional and exists solely to assist an administrator in assigning policies.
You can include information about what the policy does, or when to use
it (for example, the bulleted information provided at the beginning of
this section).
6The access control list (ACL) initially contains only the default rule. Add the
Windows 2000 Standard rule set as follows:
aIn the Policy menu, select Rule Set (or click the icon). The Rule Set
Manager window appears.
bClick on the Windows 2000 Standard Rule Set (that you imported in
step 4 on page 9) to select it, and then click Add To Policy.
cClick Close. The rule set should appear in the ACL.
7Create a “Deny outbound TCP SYN” rule as follows:
aIn the Policy menu, select Add Rule (or click the icon). A new rule
appears in the ACL.
bClick in the Rule Name cell, and type Deny outbound TCP SYN.
cClick in the Action cell, and select Deny from the drop-down list.
dClick in the Source IP Address cell, and select EFW Device IP from the
drop-down list.
eClick in the IP Protocol cell, and select tcp (6) init from the
drop-down list.

Changing the Policy for an EFW NIC
11
fClick in the Direction cell, and select Out from the drop-down list.
gClick the check box in the Audit cell to enable audit.
You now have an effective “Deny outbound TCP SYN” rule. This rule
should directly follow the Windows Standard 2000 rule set you added
in step 6. If it does not, highlight the Deny outbound TCP SYN rule
row, and use the arrow buttons to position it directly after the
Windows 2000 Standard rule set.
8Click Save to save the new policy information.
For more information on creating policies, refer to the section “Creating
Policies and Rules” in the 3Com Embedded Firewall Administration Guide.
Creating a Sample Device Set
Next you will create a sample device set that enforces the policy you created
in the previous section. A device set is a collection of EFW devices that are
associated with a specific policy. You can define any number of device sets and
assign EFW devices to any one of those device sets.
To create the sample device set, follow the steps below.
1From the Main menu, select New -> Device Set. The New Device Set
window appears.
2Type Sample in the Device Set Name field.
3Select the No IP Initiation policy, which you created in the previous section,
from the Policy for the New Device Set box.
4Click OK. The device set information appears in the working frame.
5Select a heartbeat interval of 15 minutes from the Heartbeat drop-down
list. (The heartbeat determines how often the EFW devices issue a
heartbeat, or status update, to the Policy Server.)
6Type Sample device set enforcing the No IP Initiation policy in the
Description field. This field is optional and exists solely to assist an
administrator in identifying the contents of the device set.
7Click Save.

Quick Start Guide
12
Moving the EFW NIC to the New Device Set
Now that you have multiple device sets, you can move the EFW NIC from
the default device set to the No IP Initiation device set that you created in
the previous section by following the steps below.
1In the Management Console, click the Device Sets tab in the
tree-view frame.
2Click Default Device Set. This device set contains the EFW NIC that you
added earlier in this guide.
3In the Device box, highlight the EFW device, and then click Move.
4A list of alternative device sets appears. Select the Sample device set that
you created in the previous section, and click OK. You will see a feedback
window indicating that the new policy has been distributed to the
embedded firewall. The EFW device is moved to the new device set and
now enforces the new policy.
Testing Policy Enforcement and Viewing Audit Data
At this point you should have an EFW NIC enforcing the No IP Initiation policy.
To ensure that the policy is functioning as expected, the following steps
attempt to connect to the Internet by initiating the TCP protocol HTTP, which
should be denied by the policy being enforced. You will then view the audit
generated by the failed attempt.
1On the machine hosting the EFW NIC, attempt to connect to
www.3com.com. If you were denied access to the site, the EFW NIC
is correctly enforcing the “No IP Initiation” policy. If you were able to
connect to the site, go back to the “Creating a Policy” section in this
guide and verify that you correctly set up the policy rules.
2To view the audit generated by this access attempt using the Management
Console, follow the steps below:
aIn the Audit menu, select Audit Browser (or click the icon).
bIn the Query menu, select New (or click the icon). The Query Editor
window appears.
cType All Recent Audit Records in the Query Name field.
dIn the Rule tab, select the All Devices check box in the For area, and the
All rule matches check box in the Show area.
eIn the Policy tab, select the All Policies check box in the For area, and
the All policy eventscheck box in the Show area.

Expanding Your EFW Configuration
13
fIn the Administrator tab, select the All administrator components check
box in the For area, and the All administrator events check box in the
Show area.
gClick OK.
hIn the Audit Browser window in the List of Queries, click on the All
Recent Audit Records query you just created. In the Query menu, select
Execute (or click the icon).
Double-click on any event in the table to see detailed information for
that event.
The audit results should appear in table format. For information on
viewing audit results, refer to the section “Audit Information” in the
3Com Embedded Firewall Administration Guide.
Expanding Your EFW Configuration
Now that you have a basic EFW system configured and running, you can
expand your configuration as needed to best suit your organization’s security
needs. The following list provides some sectional references to the 3Com
Embedded Firewall Administration Guide that will assist you in expanding
your configuration.
■To add additional EFW NICs to your system, refer to”Distributing and
Installing the EFW NIC Firmware.”
■To create additional policies, refer to “Creating Policies and Rules.”
■To add additional Policy Servers for redundancy, refer to “Configuring
Policy Servers for Redundancy.”
■To install additional remote Management Consoles, refer to “Installing and
Uninstalling EFW Software.”
■For an overview of EFW and its basic components, concepts, and
operations, refer to Chapter 1, “Planning and Overview.”
