RELEASE NOTES
SUPERSTACK®II REMOTE ACCESS SYSTEM 1500
RELEASE 2.0
These Release Notes contain information that does not appear in the
SuperStack®II Remote Access System 1500 (RAS 1500), Release 2.0
documentation. It includes the following:
■New Features ........................................................................2
■Installation and Upgrade Information.....................................3
■Operational Information ........................................................3
Visit the RAS 1500 Web Site (http://www.3com.com/ras1500) for the
latest RAS 1500 product information, code, and documentation. On this
this site, you will also find a link to the 3Com Knowledgebase where you
will find useful product tips and information posted by other RAS 1500
users.
ISDN Assistance For assistance with ISDN services in the U.S., call the 3Com Access Plus
hot line, 1-800-343-3266.
When a similar service is available in Canada, information will be posted
on the 3Com Support Web Site (http://support.3com.com).
For assistance with ISDN services in Latin America, contact your local
phone company.

2RELEASE NOTES SUPERSTACK® II REMOTE ACCESS SYSTEM 1500 RELEASE 2.0
New Features The following are new features in this release:
Web Configuration
Interface
The Web Configuration Interface or Web Configurator is a browser-based
application for configuring features of your SuperStack®II Remote Access
System1500. This new tool provides a platform-independent solution to
set up your unit and only requires that you run a browser (such as,
Netscape Navigator or Microsoft Internet Explorer) that supports HTML
4.0, or higher, JavaScript, and style sheets on your PC or UNIX
workstation. Details for setting up basic features of your RAS 1500 are
described in the SuperStack®II Remote Access System 1500 Quick Setup
Guide that is packaged with your system. You can also find this guide by
clicking on “Documentation” on the Release 2.0 Resource CD.
Primary Rate Access
Unit (PAU)
The Primary Rate Access Unit (PAU) is an ISDN PRI T1 or E1 access unit
that connects to your Router Unit via a STACKNET™. Once the units are
connected to the base unit, the system serves as one network entity,
managed as one device, by a single network management application.
Dynamic Host
Configuration
Protocol (DHCP)
Dynamic Host Configuration Protocol (DHCP), acting as a server, proxy, or
relay is a new component for this release. The RAS 1500 can serve as the
central DHCP server for both LAN-based and remote users. In addition, it
can “proxy” or “relay” IP address requests to another central server. This
feature simplifies network administration and enhances the mobility of
both remote and local users. The three DHCP scenarios are described
below:
■Server - Acting as a DHCP server, the RAS 1500 receives and
processes requests for IP information from dial-in clients and provides
the IP information directly back to the client.
■Proxy - Acting as a DHCP proxy, the RAS 1500 initiates a DHCP
requests to a DHCP server on behalf of a DHCP dial-in client. The
DHCP server receives and processes the request and sends the IP
information back to the dial-in client via the RAS 1500.
■Relay - Acting as a DHCP relay, the RAS 1500 passes on a request for
IP information from LAN clients through a LAN-to-LAN connection to
a DHCP server.
PPP Over Serial WAN
Port
This release of the RAS 1500 supports a PPP connection over a leased line
on its serial port. A leased line is a dedicated line between two sites and is
a permanently installed rather than a dialed up connection. PPP over the

Installation and Upgrade Information 3
WAN port can connect to another RAS 1500 or any compatible device
that supports PPP. PPP over leased line offers the following benefits:
■Constant connection. Once the connection between the sites is
established, the link does not come down unless you issue a
command to do so.
■Simple configuration. To prepare a RAS 1500 for leased-line PPP
requires little configuration.
■Fast. The RAS 1500 supports speeds of 2.048 Mbps.
Installation and
Upgrade
Information
The following is installation and upgrade information in this release:
Primary Rate
Access Unit (PAU)
Firmware Upgrade
The Primary Rate Access Unit (PAU) is delivered with firmware
pre-installed. If you upgrade to future releases of the firmware, be aware
of the following information:
After issuing the download command for PAU firmware upgrade,
download pau_image pau_x.dmf from server <tftp server ip
address> command sdl_start, do not enter anything, even though the
RAS 1500 prompt is visible from the console. The PAU code is being
written to flash. Wait until the message, “PAU is Operational,” is
displayed. This takes approximately 15 minutes. When the PAU is
operational message is displayed, it is safe to issue commands from the
console.
Operational
Information
The following is operational information in this release:
Idle Timeout for
LAN-to-LAN
Configuration
The idle timeout default for LAN-to-LAN in the Web Configurator is 0 (or
no timeout).This default value cannot be changed in the Web
Configurator. If you want to change the idle timeout, and we recommend
you do, you must use the CLI. The command is as follows:

4RELEASE NOTES SUPERSTACK® II REMOTE ACCESS SYSTEM 1500 RELEASE 2.0
Set user <user name> Idle_timeout <idle timeout value>
IMPORTANT: Please be aware that if you do not change the idle timeout
default value, which is set at 0, on-demand configurations will not
timeout. This means that you could incur costly telco charges. Therefore,
we recommend that you change this default from the CLI.
NT NOS Application Before loading the RAS 1500 NT NOS Authentication application, be sure
to uninstall any previous versions of this or the AccessBuilder NOS
Authentication application that may have been used previously.
Use the following steps to install and configure NOS authentication
software on the Windows NT station:
1Insert the RAS 1500 Resource CD into the Windows NT station.
2Select Install Software from the Main Menu.
3Select NT NOS Security. The setup program will be executed.
4From the Windows NT desktop, click Start, then Programs, then RAS
1500 Security Client, then Enable Authentication.
5Follow the directions to enable the service on the NT platform. This
ensures the service starts each time the machine is rebooted.
6By default the NOS program is installed to authenticate users without
regard to time differences between the RAS 1500 and the NT system
running NT Security Client. If you do wish to use the NT Security Client to
check timestamps between the RAS 1500 and the NT system, change the
default time of 0 to 15 minutes.
7On the NT system, go to Start, Programs, RAS 1500 Security Client and
select Security Client Config. The encryption key is a password exchanged
between the NT system and the RAS 1500. 3Com recommends you do
not change this. If you do, you must change the secret password on the
RAS 1500 the Web Configurator or the CLI with the following command:
set authentication secondary_secret [password]
8By default, there is no timestamp checking (0). To check timestamps
between the RAS 1500 and the server, enter the allowable time
difference, for example, 15.
9It is very important to set the date, time, and time zone correctly on the
RAS 1500 when using the timestamp check feature of NT Security Client.
To do this, through the Web Configurator click Date & Time/Timezone

Operational Information 5
10 Under the selection pulldown menu, select Timezone and select your
time zone. Click Apply to enable these settings.
11 Click Daylight Savings Time, if applicable. Enter the appropriate time
information, if daylight-saving applies to your configuration. Click Apply
to enable those settings.
12 Click Date&Time/Timezone. Under the selection pulldown menu, select
Date&Time. Select the appropriate date and time information. Click
Apply to enable these settings.
The RAS 1500 does not support MS-CHAP authentication with Windows
NT NOS authentication.
Users must logon locally to allow the user to use Windows NT security
with the RAS 1500. For example, follow these steps:
1Log on to the NT Server as Administrator.
2Open the Administrative Tools Program Group.
3Double-click the User Manager for Domains Program Group icon. The
User Manager screen appears.
4Click the single or multiple users you want to assign remote-access rights.
5In the User Rights from Policies list, select “logon locally.”
6Click OK.
The table below shows NT event viewer messages that help when
troubleshooting the RAS 1500.

6RELEASE NOTES SUPERSTACK® II REMOTE ACCESS SYSTEM 1500 RELEASE 2.0
Table 1 Event Viewer Messages
Extra Blank Faceplate
Packed with the PAU
For this release of the software, an I/O card does not have to be present in
the Router Unit (however, if one is installed it must be installed in
rm0/slot:1). Although you do not have to install an I/O card in the Router
Unit, it is recommended that you cover the blank slot so that no slots are
left exposed. An extra face plate is provided when you purchase a PAU.
This face plate should be used to cover this empty slot in your Router
Unit. It can be easily attached to the unit by using the panel screws that
are provided.
PAU Delete Command Remove the STACKNET cable from the PAU before issuing a delete
command.
set imodem interface
command in the CLI
for the PAU
There is an undocumented set imodem interface command for saving
modem configurations on the PAU that is not displayed in the section
entitled, “Set Commands” in Chapter 4 of the SuperStack®II Remote
Access System 1500 System Reference Guide. Enter the following
command to save your PAU modem configuration:
set imodem interface <PAU interface name> at at&S
Restoring Router Unit
to Factory Defaults
When the Router Unit is restored to factory defaults, the IP address and
manage user(s) will be deleted. To begin using your RAS 1500, you must
reassign an IP address, either through the IP Wizard available from the 2.0
Resource CD if you are a PC user, or through the CLI Quick Setup if you
are a UNIX user. Refer to the SuperStack®II Remote Access System 1500
Quick Setup Guide for details on setting an IP address for your RAS 1500.
Message ID Message
1Security Service installed successfully
2Security Service disabled
3Security Service enabled successfully
with encryption key (key)
4Security Service stopped
5User successfully authenticated user
RAS 1500 IP Address
6User failed to authenticate user
RAS 1500 IP Address

Operational Information 7
Once you have reassigned an IP address for your RAS 1500, use the
default user name “Admin” and the default password “Password”
when you configure features through the Web Configurator. You are
prompted to enter this user name and password when you select the first
feature, from the menu of features, that you want to configure. Both the
default user name and password will be overwritten once you set your
own unique manager user name and password. The user name must be
between 1 and 32 alphanumeric, nonblank characters and is
case-sensitive. The password must be between 1 and 15 characters and is
not case-sensitive.
List Connections
Command in the CLI
Sometimes a list connections command from the CLI (Command Line
Interface) will scroll information. If this occurs, press <CTRL-C> to refresh
the screen.
Using Fractional PRI If you are using fractional PRI, obtain from your telco, information on the
PRI line and the channels that are associated with that line. Configure a
specific modem group to include only those PRI members. Do not use
modem group all.
Creating A Network
Service
Creating a network service automatically creates a modem group with
the same name as the network service. This could cause a problem if a
modem group already exists with the same name. The modem group will
be overwritten with new information.
Refreshing Web
Configuration
Interface Data
In order to ensure data between device and web browser is synchronized,
refresh the data in your web browser by clicking the reload or refresh
button. Do not leave the browser open on the desktop. When
configuration is complete exit out of the browser session.
Configuring Users To properly change a user’s configuration, follow these general steps:
1From the Web Configuration Interface, telnet to the CLI in the Router
Unit.
2Disable the user.
3Make the changes to the user’s configuration.
4Enable the user.

8RELEASE NOTES SUPERSTACK® II REMOTE ACCESS SYSTEM 1500 RELEASE 2.0
For example, to set an existing user, “john,” as a “network” type, enter
the following commands in the CLI:
1disable user john
A message appears.
2set user john type network
3enable user john
Installing 3CDaemon
and Adobe Acrobat
from the 2.0
Source CD
Before you install freeware applications, such as 3CDaemon and Adobe
Acrobat, from the 2.0 Resource CD, you must disable any antivirus
software that is running on your system (i.e., Norton Utilities). If you do
not, your system may fail and you may receive an operational failure
message, “ISSET_SE”. If after you disable antivirus software you still
receive an “ISSET_SE” after installing your freeware, go to the Microsoft
Support Web page and search on “ISSET_SE” for installation problems.
North American
Switch Types for
ISDN BRI calls
In rare situations, ISDN BRI calls using North American switch types, may
connect and then immediately disconnect. If this happens, while using
this release, issue the following commands for each of your BRI ISDN
interfaces on the Router Unit or Port Expansion Module (PEM):
set switched interface rm0/slot:1/mod:1 at at*B3=0
set switched interface rm0/slot:1/mod:2 at at*B3=0
set switched interface rm0/slot:1/mod:3 at at*B3=0
set switched interface rm0/slot:1/mod:4 at at*B3=0
set switched interface rm0/slot:2/mod:1 at at*B3=0
set switched interface rm0/slot:2/mod:2 at at*B3=0
set switched interface rm0/slot:2/mod:3 at at*B3=0
set switched interface rm0/slot:2/mod:4 at at*B3=0
Copyright © 2000, 3Com Corporation
3Com, the 3Com logo, and SuperStack are registered trademarks of 3Com Corporation.
Other brand and product names may be registered trademarks or trademarks of their respective holders.
