3Com Switch 7750 Series
Command Reference Guide
www.3Com.com
Part Number: 10015463 Rev. AB
September 2006

Copyright © 2006, 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by
any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission
from 3Com Corporation.
3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without
obligation on the part of 3Com Corporation to provide notification of such revision or change.
3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed,
including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a
particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this
documentation at any time.
If there is any software on removable media described in this documentation, it is furnished under a license agreement included
with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named
LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software described herein are provided to you
subject to the following:
All technical data and computer software are commercial in nature and developed solely at private expense. Software is
delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as
defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for
the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR
52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any
licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in
other countries.
3Com, the 3Com logo, are registered trademarks of 3Com Corporation.
Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows NT are
registered trademarks of Microsoft Corporation. UNIX is a registered trademark in the United States and other countries, licensed
exclusively through X/Open Company, Ltd.
All other company and product names may be trademarks of the respective companies with which they are associated.
3Com Corporation
350 Campus Drive
Marlborough, MA
01752-3064

3Com Switch 7750 Series
Command Reference Guide – CLI Table of Contents
i
Table of Contents
Chapter 1 CLI Configuration Commands.................................................................................... 1-1
1.1 CLI Configuration Commands ...........................................................................................1-1
1.1.1 command-privilege level .........................................................................................1-1
1.1.2 display history-command ........................................................................................1-2
1.1.3 super ....................................................................................................................... 1-2
1.1.4 super password.......................................................................................................1-3

3Com Switch 7750 Series
Command Reference Guide – CLI Chapter 1 CLI Configuration Commands
1-1
Chapter 1 CLI Configuration Commands
1.1 CLI Configuration Commands
1.1.1 command-privilege level
Syntax
command-privilege level level view view command
undo command-privilege view view command
View
System view
Parameter
level: Command Level. This argument ranges from 0 to 3.
view: Command view. This argument can be any command view the switch supports.
command: Command to be specified.
Description
Use the command-privilege level command to set the level of the specified
command in a specified view.
Use the undo command-privilege view command to restore the level of the specified
command in the specified view to the default.
Commands fall into four command levels: visit, monitor, system, and manage, which
are identified as 0, 1, 2, and 3 respectively. The administrator can change the level of a
command to enable users of specific level to utilize the command.
By default, the ping, tracert, and telnet commands are at the visit level (level 0); the
display and debugging commands are at the monitor level (level 1); all configuration
commands are at the system level (level 2); and FTP/TFTP/XModem and file system
related commands are at the manage level (level 3).
Example
# Specify the interface command in system view to be of level 0.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] command-privilege level 0 view system interface

3Com Switch 7750 Series
Command Reference Guide – CLI Chapter 1 CLI Configuration Commands
1-2
1.1.2 display history-command
Syntax
display history-command
View
Any view
Parameter
None
Description
Use the display history-command command to display history commands. All the
history commands are saved in the history command cache. When the history
command cache is full, the old information in it will be overlaid.
Related command: history-command max-size.
Example
# Display history commands.
<3Com> display history-command
system-view
quit
display history-command
1.1.3 super
Syntax
super [ level ]
View
User view
Parameter
level: User level. This argument ranges from 0 to 3 and defaults to 3. If you execute
this command with the level argument not provided, this command switches the
current user level to level 3.
Description
Use the super command to switch the current user level to the one identified by the
level argument. If a password is previously set by using the super password [level
level ] { simple |cipher } password command, you need to provide the password as

3Com Switch 7750 Series
Command Reference Guide – CLI Chapter 1 CLI Configuration Commands
1-3
well to switch to the higher user level. You will remain in the original user level if you
fail to provide the correct password.
Note that:
zUsers logging into a switch also fall into four levels, each of which corresponding
to one of the command levels. Users at a specific level can only use the
commands at the same level and the commands at the lower levels.
zYou can specify an AUX user to provide a password when he switches from a
lower user level to a higher user level and specify the password by using the
super password [level level ] { simple |cipher } password command. With a
password configured, an AUX user remains in the original user level if the
password provided is incorrect when the AUX user attempts to switch to a higher
user level. If the password is not configured, an AUX user can switch to a higher
user level directly.
zA password is necessary for a VTY user to switch to a higher user level. You can
use the super password [level level ] { simple |cipher } password command to
set the password. With the password not configured, a VTY user is prompted the
message reading “Password is not set” and remains in the previous level.
zAn AUX user or a VTY user can switch to a lower user level directly regardless of
the password.
Related command: super password.
Example
# Switch to user level 3.
<3Com> super 3
Password:
1.1.4 super password
Syntax
super password [level level ] { simple |cipher } password
undo super password [ level level ]
View
System view
Parameter
level: User level. This argument ranges from 1 to 3 and defaults to 3. If you execute
this command with the level argument not provided, this command sets the password
to switch to level 3.
simple: Specifies to provide the password in plain text.
cipher: Specifies to provide the password in encrypted text.

3Com Switch 7750 Series
Command Reference Guide – CLI Chapter 1 CLI Configuration Commands
1-4
password: Password to be set. If you specify the simple keyword, provide this
argument in plain text. If you specify the cipher keyword, you can provide this
argument in either encrypted text or plain text. In this case, a password containing no
more than 16 characters (such as 123) is regarded to be in plain text and is converted
to the corresponding 24-character encrypted form (such as
7-CZB#/YX]KQ=^Q`MAF4<1!!) automatically. You can also provide a 24-character
encrypted password directly (such as 7-CZB#/YX]KQ=^Q`MAF4<1!!). In this case, you
must know its corresponding plain-text password is 123.
Description
Use the super password command to set the password for users to switch to a higher
user level. To prevent unauthorized accesses, you can use this command to require
users to provide the password when they switch to a higher user level. For security
purpose, the password a user enters when switching to a higher user level is not
displayed. A user will remain at the original user level if the user has tried three times
to enter the correct password but fails to do this.
Use the undo super password command to cancel the configuration.
Note that no matter what form of the password (plain text or encrypted text) is in, the
password entered for verification must be in plain text.
Example
# Set the password to switch from the current user level to user level 3 to “zbr”.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] super password level 3 simple zbr

3Com Switch 7750 Series
Command Reference Guide – Login Table of Contents
i
Table of Contents
Chapter 1 Login Commands ........................................................................................................ 1-1
1.1 Login Commands............................................................................................................... 1-1
1.1.1 authentication-mode................................................................................................ 1-1
1.1.2 auto-execute command........................................................................................... 1-2
1.1.3 databits....................................................................................................................1-3
1.1.4 display user-interface..............................................................................................1-3
1.1.5 display users ...........................................................................................................1-5
1.1.6 flow-control.............................................................................................................. 1-6
1.1.7 free user-interface................................................................................................... 1-7
1.1.8 header.....................................................................................................................1-8
1.1.9 history-command max-size................................................................................... 1-10
1.1.10 idle-timeout.......................................................................................................... 1-11
1.1.11 lock...................................................................................................................... 1-12
1.1.12 modem ................................................................................................................ 1-12
1.1.13 modem auto-answer ...........................................................................................1-13
1.1.14 modem timer answer........................................................................................... 1-14
1.1.15 parity.................................................................................................................... 1-14
1.1.16 protocol inbound..................................................................................................1-15
1.1.17 screen-length.......................................................................................................1-16
1.1.18 send..................................................................................................................... 1-16
1.1.19 service-type......................................................................................................... 1-17
1.1.20 set authentication password................................................................................1-19
1.1.21 shell.....................................................................................................................1-20
1.1.22 speed...................................................................................................................1-21
1.1.23 stopbits................................................................................................................1-21
1.1.24 sysname..............................................................................................................1-22
1.1.25 telnet.................................................................................................................... 1-23
1.1.26 user-interface ...................................................................................................... 1-23
1.1.27 user privilege level ..............................................................................................1-24
Chapter 2 Commands for User Control.......................................................................................2-1
2.1 Commands for Controlling Logging in Users.....................................................................2-1
2.1.1 acl............................................................................................................................2-1
2.1.2 snmp-agent community...........................................................................................2-1
2.1.3 snmp-agent group................................................................................................... 2-2
2.1.4 snmp-agent usm-user.............................................................................................2-4

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-1
Chapter 1 Login Commands
1.1 Login Commands
1.1.1 authentication-mode
Syntax
authentication-mode {password |scheme [ command-authorization ] | none }
View
User interface view
Parameter
password: Authenticates users using the local password.
scheme: Authenticates users locally or remotely using usernames and passwords.
command-authorization: Performs command authorization on TACACS
authentication server.
none: Does not authenticate users.
Description
Use the authentication-mode command to specify the authentication mode.
zIf you specify the password keyword to authenticate users using the local
password, remember to set the local password using the set authentication
password { cipher | simple } password command.
zIf you specify the scheme keyword to authenticate users locally or remotely
using usernames and passwords, the actual authentication mode, that is, local or
remote, depends on other related configuration.
zIf this command is executed with the command-authorization keywords
specified, authorization is performed on the TACACS server whenever you
attempt to execute a command, and the command can be executed only when
you pass the authorization. Normally, a TACACS server contains a list of the
commands available to different users.
If you specify to perform local authentication when a user logs in through the Console
port, a user can log into the switch with the password not configured. But for a VTY
user interface, a password is needed for a user to log into the switch through it under
the same circumstance.
By default, users logging in through the Console port are not authenticated, whereas
modem users and Telnet users are authenticated.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-2
Example
# Configure to authenticate users using the local password on the AUX interface.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface aux 0
[3Com-ui-aux0] authentication-mode password
1.1.2 auto-execute command
Syntax
auto-execute command text
undo auto-execute command
View
User interface view
Parameter
text: Command to be executed automatically.
Description
Use the auto-execute command command to set the command that is executed
automatically after a user logs in.
Use the undo auto-execute command command to disable the specified command
from being automatically executed.
Normally, the telnet command is specified to be executed automatically to enable the
user to Telnet to a specific network device automatically.
By default, no command is automatically executed.
Caution:
zThe auto-execute command command may cause you unable to perform
common configuration in the user interface, so use it with caution.
zBefore executing the auto-execute command command and save your
configuration, make sure you can log into the switch in other modes and cancel the
configuration.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-3
Example
# Configure the telnet 10.110.100.1 command to be executed automatically after
users log into VTY 0.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface vty 0
[3Com-ui-vty0] auto-execute command telnet 10.110.100.1
% This action will lead to configuration failure through ui-vty0. Are you
sure?[Y/N]y
1.1.3 databits
Syntax
databits { 7 |8 }
undo databits
View
User interface view
Parameter
7: Sets the data bits to 7.
8: Sets the data bits to 8.
Description
Use the databits command to set the databits for the user interface.
Use the undo databits command to revert to the default data bits.
Execute these two commands inAUX user interface view only.
The default data bits is 8.
Example
# Set the data bits to 7.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface aux 0
[3Com-ui-aux0] databits 7
1.1.4 display user-interface
Syntax
display user-interface [ type number | number ] [ summary ]

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-4
View
Any view
Parameter
type: User interface type.
number: User interface number.
summary: Displays the summary information about a user interface.
Description
Use the display user-interface command to display the information about a
specified user interface or all user interfaces. If the summary keyword is not specified,
this command displays user interface type, absolute/relative user interface number,
transmission speed, available command level, authentication mode, and physical
position. If the summary keyword is specified, this command displays the number
and type of the user interfaces, including those that are in use and those that are not
in use.
Example
# Display the information about user interface 0.
<3Com> display user-interface 0
Idx Type Tx/Rx Modem Privi Auth Int
F 0 AUX 0 9600 - 3 N -
+ : Current user-interface is active.
F : Current user-interface is active and work in async mode.
Idx : Absolute index of user-interface.
Type : Type and relative index of user-interface.
Privi: The privilege of user-interface.
Auth : The authentication mode of user-interface.
Int : The physical location of UIs.
A : Authenticate use AAA.
N : Current UI need not authentication.
P : Authenticate use current UI's password.
Table 1-1 Descriptions on the fields of the display user-interface command
Filed Description
+ The user interface is in use.
F The user interface operates in asynchronous mode.
Idx The absolute index of the user interface
Type User interface type and the relative index

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-5
Filed Description
Tx/Rx Transmission speed of the user interface
Modem Indicates whether or not a modem is used.
Privi Available command level
Auth Authentication mode
Int Physical position of the user interface
A The current user is authenticated by AAA.
N Users are not authenticated.
P Users need to provide passwords to pass the authentication.
# Display the summary information about the user interface.
<3Com>display user-interface summary
User interface type : [AUX]
0:UXXX XXXX
User interface type : [VTY]
8:UUUU X
5 character mode users. (U)
8 UI never used. (X)
5 total UI in use
1.1.5 display users
Syntax
display users [ all ]
View
Any view
Parameter
all: Displays the information about all user interfaces.
Description
Use the display users command to display the information about user interfaces. If
you do not specify the all keyword, only the information about the current user
interface is displayed.
Example
# Display the information about the current user interface.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-6
<3Com> display users
UI Delay Type Ipaddress Username Userlevel
F 0 AUX 0 00:00:00 3
1 VTY 0 00:06:08 TEL [phone]
+ : Current operation user.
F : Current operation user work in async mode.F 0 AUX 0 00:00:00
Table 1-2 Descriptions on the fields of the display users command
Field Description
F The information is about the current user interface, and the
current user interface operates in asynchronous mode.
UI The numbers in the left sub-column are the absolute user
interface indexes, and those in the right sub-column are the
relative user interface indexes.
Delay The period (in seconds) the user interface idles for.
Type User type
IPaddress The IP address form which the user logs in.
Username The login name of the user that logs into the user interface.
Userlevel The level of the commands available to the users logging into
the user interface
+ The user interface is in use.
1.1.6 flow-control
Syntax
flow-control { hardware | none | software }
undo flow-control
View
User interface view
Parameter
hardware: Performs hardware flow control.
none: Performs no flow control.
software: Performs software flow control.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-7
Description
Use the flow-control command to configure the flow control mode of the user
interface.
Use the undo flow-control command to restore the default flow control mode of the
user interface.
By default, flow control is not performed.
This command can only be executed in AUX user interface view.
Example
# Set flow control mode to software flow control.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface aux 0
[3Com-ui-aux0] flow-control software
1.1.7 free user-interface
Syntax
free user-interface [ type ]number
View
User view
Parameter
type: User interface type.
number: Index of the user interface. This argument can be an absolute user interface
index (if you do not provide the type argument) or a relative user interface index (if you
provide the type argument).
Description
Use the free user-interface command to release a specified user interface. If you
execute this command, the corresponding user interface will be disconnected.
Note that the current user interface cannot be released.
Example
# Release user interface VTY 0.
<3Com> free user-interface vty 0
Are you sure you want to free user-interface vty0 [Y/N]? y
[OK]

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-8
After you execute this command, user interface VTY 0 will be disconnected. The user
in it must log in again to connect to the switch.
1.1.8 header
Syntax
header [incoming |login |shell ]text
undo header {incoming |login |shell }
View
System view
Parameter
Incoming: Sets the login banner for users that log in through modems. If you specify
to authenticate login users, the banner appears after a user passes the authentication.
(The session does not appear in this case.)
login: Sets the login banner. The banner set by this keyword is valid only when users
are authenticated before they log into the switch and appears while the switch
prompts for user name and password.
shell: Sets the session banner, which appears after a session is established. If you
specify to authenticate login users, the banner appears after a user passes the
authentication.
text: Banner to be displayed. If no keyword is specified, this argument is the login
banner. You can provide this argument in two ways. One is to enter the banner in the
same line as the command (A command line can accept up to 255 characters.) The
other is to enter the banner in multiple lines (you can start a new line by pressing
<Enter>,) where you can enter a banner that can contain up to 2000 characters
(including the invisible characters). Note that the first character is the beginning
character and the end character of the banner. After entering the end character, you
can press <Enter> to exit the interaction.
Description
Use the header command to set the banners that are displayed when a user logs into
a switch. The login banner is displayed on the terminal when the connection is
established.And the session banner is displayed on the terminal if a user successfully
logs in.
Use the undo header command to disable displaying a specific banner or all
banners.
Note that if you specify any one of the three keywords without providing the text
argument, the specified keyword will be regarded as the login information.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-9
You can specify the banner in the following three ways, each of which requires that
the first character and the last character of the banner be the same.
zEnter the banner in multiple lines. If you only type onecharacter in the first line of
a banner, the character and the last character do not act as part of the banner.
The following gives an example of this way.
[3Com] header shell 0
Input banner text, and quit with the character '0'.
Welcome!0
When you log in the next time, “Welcome!” is displayed as the banner. The beginning
character and the end character (character 0) do not appear.
zEnter the banner in multiple lines. If you type multiple characters in the first line of
a banner and the beginning and the end characters of the banner in this line are
not the same, the beginning character is part of the banner. The following is an
example.
[3Com] header shell hello
Input banner text, and quit with the character 'h'.
my friend !
h
When you log in the next time, “hello” and “my friend !“ is displayed respectively in two
lines as the banner. The beginning character “h” appears in the banner.
zEnter the banner in a single line. You can also specify the banner in a single line.
In this case, the banner does contain the beginning and the end character. The
following is an example.
[3Com] header shell 0welcome,my friend!0
When you log in the next time, “welcome, my friend!” is displayed as the banner.
Example
# Set the session banner.
Option 1: Enter the banner in the same line as the command.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] header shell %SHELL: Hello! Welcome%
(Make sure the beginning and end characters of the banner are the same.)
When you log in the next time, the session banner appears on the terminal as the
following:
[3Com] quit
<3Com> quit
Please press ENTER
SHELL: Hello! Welcome

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-10
(The beginning and end characters of the banner are not displayed.)
<3Com>
Option 2: Enter the banner in multiple lines.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] header shell %SHELL:
(Following appears after you press <Enter>:)
Input banner text, and quit with the character '%'.
Continue entering the banner and end the banner with the character identical with the
beginning character of the banner.
Hello! Welcome %
(Press <Enter>.)
[3Com]
When you log in the next time, the session banner appears on the terminal as the
following:
[3Com] quit
<3Com> quit
Please press ENTER
%SHELL:
(Note that the beginning character of the banner appears.)
Hello! Welcome
<3Com>
1.1.9 history-command max-size
Syntax
history-command max-size value
undo history-command max-size
View
User interface view
Parameter
value: Size of the history command buffer. This argument ranges from 0 to 256 and
defaults to 10. That is, the history command buffer can store 10 commands by default.
Description
Use the history-command max-size command to set the size of the history
command buffer.

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-11
Use the undo history-command max-size command to revert to the default history
command buffer size.
Example
# Set the size of the history command buffer ofAUX 0 to 20 to enable it to store up to
20 commands.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface aux 0
[3Com-ui-aux0] history-command max-size 20
1.1.10 idle-timeout
Syntax
idle-timeout minutes [ seconds ]
undo idle-timeout
View
User interface view
Parameter
minutes: Number of minutes. This argument ranges from 0 to 35,791.
seconds: Number of seconds. This argument ranges from 0 to 59.
Description
Use the idle-timeout command to set the timeout time. The connection to a user
interface is terminated if no operation is performed in the user interface within the
timeout time.
Use the undo idle-timeout command to revert to the default timeout time.
You can use the idle-timeout 0 command to disable the timeout function.
The default timeout time is 10 minutes.
Example
# Set the timeout time of AUX 0 to 1 minute.
<3Com> system-view
System View: return to User View with Ctrl+Z.
[3Com] user-interface aux 0
[3Com-ui-aux0] idle-timeout 1 0

3Com Switch 7750 Series
Command Reference Guide – Login Chapter 1 Login Commands
1-12
1.1.11 lock
Syntax
lock
View
User view
Parameter
None
Description
Use the lock command to lock the current user interface to prevent unauthorized
operations in the user interface.
With the execution of this command, the system prompts to enter and confirm the
password, and then locks the user interface. You can set the password in the range of
1 to 16 characters.
Enter the correct password to cancel the lock. If your password contains more than 16
characters, the system will cancel the lock as long as the first 16 characters are
matched.
Example
# Lock the current user interface.
<3Com> lock
Password:
Again:
locked !
1.1.12 modem
Syntax
modem [ call-in |both ]
undo modem [ call-in | both ]
View
User interface view
Parameter
call-in: Permits call in.
both: Permits both call in and call out.
