DATA SHEET
High-performance,
affordable, copper
and fiber Gigabit
switching
XRN Technology
3Com XRN™(eXpandable Resilient
Networking) technology allows
implementation of high availability
configurations using two interconnected
3Com® SuperStack®3 Switch 4900s or
Switch 4900 SXs, scaling the backbone
to 24 wirespeed Gigabit Layer 3
switching ports.
Performance
Wirespeed, non-blocking Gigabit Ethernet
switching across all ports delivers maxi-
mum performance for heavily utilized
networks. The use of XRN Technology
intelligent forwarding can scale the
performance of two units to 48 Gbps.
Affordability
The SuperStack 3 Switch 4900 family of
fixed configuration managed switches
provides unmatched value and industry
leading performance without compromise,
enhanced further with the pay-as-you-
grow capabilities of XRN technology.
High Availability
Robust availability features include
link aggregation, support for Rapid
Spanning Tree,Redundant Power
Supply system, and e-mail or pager
status notification, ensuring maximum
uptime for critical applications.
Prioritize Business Critical Traffic
Advanced Class of Service support
including support for four queues per
port, 802.1p, and multilayer packet
classification capabilities to allow
prioritization of critical traffic.
Layer 3 Switching
Layer 3 switching capabilities such as
support for IP unicast routing using
static routes, OSPF*, RIP/RIPv2, CIDR,
and UDP Helper, enhance perfor-
mance, provide network control and
security, and enable logical network seg-
mentation.
Advanced Security Capabilities
Security features such as RADIUS client
support and Routed Access Control
Lists ensure authorized user access to
network resources.
Powerful Management
3Com Network Supervisor application
(trial copy included) with discovery,
mapping, monitoring, and alerting for
easy network administration. Intuitive
interface speeds network-wide set-up of
switch traffic prioritization.
The 3Com SuperStack 3 Switch 4900
delivers high performance, feature-rich
Gigabit Ethernet switching in a simple,
affordable platform, making it an excel-
lent solution for small-to-medium-size
networks with growing bandwidth
requirements. It’s also perfect for large
enterprises that require low cost yet high
functionality Gigabit Ethernet switching
across their data center and the server
farm or wiring closet.
Both switches support 3Com Gigabit
Multilayer Switching (GMS) software,
offering advanced Layer 2 switching
features such as traffic prioritization,
VLANs, multicast filtering, and RMON,
as well as Layer 3 switching features,
including support for unicast IP routing
supporting static routes, RIP/RIP2 and
OSPF* and Access Control Lists. Their
Class of Service capabilities are ideal for
key business applications, such as mul-
timedia, LAN telephony, database and
inventory/purchase applications.
3Com® SuperStack®3 Switch 4900
and SuperStack 3 Switch 4900 SX
Key Benefits
* With purchase of optional Advanced Feature License, 3C1770V40

3COM®SUPERSTACK®3 SWITCH 4900 AND SUPERSTACK 3 SWITCH 4900 SX DATA SHEET
3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough MA 01752-3064.
To learn more about 3Com solutions, visit www.3com.com. 3Com Corporation is publicly traded on NASDAQ under the
symbol COMS.
Copyright© 2004 3Com Corporation. All rights reserved. 3Com, the 3Com logo, and SuperStack are registered trademarks
and XRN is a trademark of 3Com Corporation. All other company and product names may be trademarks of their respective
companies. While every effort is made to ensure the given information is accurate, 3Com does not accept liability for any errors
or mistakes which may arise. Specifications and other information in this document may be subject to change without
notice. 400632-011 08/04
Connectors
3C17700: 12 auto-negotiating
100BASE-TX/ 1000BASE-T ports
configured as Auto-MDIX
(cross-over).
3C17702: 12 1000BASE-SX ports
using MT-RJ connectors.
3C17710: Switch 4900 series
expansion module supporting
4 1000BASE-SX ports using
MT-RJ connectors
3C17711: Switch 4900 series
expansion module supporting
4 x 1000BASE-T ports using
RJ-45 connectors configured as
Auto-MDIX
3C17712: Switch 4900 series
expansion module supporting
4 x 1000BASE-LX ports using
MT-RJ connectors
3C17714: Switch 4900 series
expansion module supporting
4 x GBIC ports
Dimensions
Height: 6.6 cm (2.6 in)
Width: 44 cm (17.3 in)
Depth: 37 cm (14.5 in)
Weight: 6.5 kg (13 lb)
Performance
23 million packets per second
Reliability
MTBF @ 40°C: 326,000 hours
Environmental Requirements
Operating temperature: 0° to
40°C (32° to 104°F)
Storage Temperature: -40° to
+70°C (-40° to +158°F)
Operating Humidity: 10%
to 90% relative humidity
non-condensing
Standards: EN60068 (IEC68)
Safety Agency Certifications
UL1950, EN60950, CSA22.2 No.
950, IEC 60950
Emissions
EN55022 Class A, FCC Part 15
Subpart B Class A, ICES-003
Class A, VCCI Class A, AS/NZS
3548 Class A, CNS 13438 Class A
Immunity: EN55024
Heat Dissipation: 50 W maxi-
mum (168 BTU/hr maximum)
Power Supply
AC Line Frequency 50/60 Hz
Input Voltage Options 90-240
VAC
Current Rating 4.5A maximum
Switching
Features/Functionality
802.1D
802.1Q VLAN Support
IGMP Snooping
Link Aggregation
SNMP Standards
SNMP Protocol (RFC 1157)
MIB-II (RFC 1213)
Bridge MIB (RFC 1493)
RMON MIB II (RFC2021)
Remote Monitoring MIB
(RFC 1757)
Interface MIB (2233)
MAU MIB (RFC 2668)
Administration
UDP (RFC 768)
IP (RFC 791)
ICMP (RFC 792)
TCP (RFC 793)
ARP (RFC 826)
TFTP (RFC 783)
TELNET (RFC854)
BOOTP/DHCP (RFC1542)
HTTP (RFC2068)
Routing Protocols
RFC 1058 RIP
RFC 1519 CIDR
RFC 1723 RIP v2
RFC 2131 BootP/DHCP Relay
RFC 2328 OSPF Version 2*
RFC 1850 OSPF Version 2 MIB*
Warranty
3 Year hardware warranty. See
www.3com.com/warranty for
details.
90 day software warranty
Management
3Com Network Supervisor (trial
copy provided on accompanying
CD)
Web interface
Command line interface
management
SNMP compatibility
Specifications
Ordering Information 3Com SuperStack 3 Switch 4900 3C17700
3Com SuperStack 3 Switch 4900 SX 3C17702
Optional Modules and Accessories
3Com XRN Interconnect Kit 3C17715
3Com 5m XRN Interconnect Cable 3C17722
3Com GMS v4.0 Advanced Feature License 3C1770V40
3Com SuperStack 3 Switch 4900
1000BASE-SX Module 3C17710
3Com SuperStack 3 Switch 4900
4-port 1000BASE-T Module 3C17711
3Com SuperStack 3 Switch 4900
4-port 1000BASE-LX module 3C17712
3Com SuperStack 3 Switch 4900
4-Port GBIC Module 3C17714
Optional Modules and Accessories, continued
3Com 1000BASE-SX GBIC 3CGBIC91
3Com 1000BASE-LX GBIC 3CGBIC92
3Com 1000BASE-T GBIC 3CGBIC93A
3Com 1000BASE-LH70 GBIC
(up to 70km) 3CGBIC97
3Com SuperStack Advanced
Redundant Power System Chassis 3C16071B
3Com SuperStack Advanced
Redundant Power System Type 3 325W 3C16075
Optional Network Management Packages
3Com Network Supervisor
Advanced Package 3C15201
3Com Integration Kit for HP OpenView 3C15300
* With purchase of optional Advanced Feature License
The twelve-port switch is available in
two configurations, to support multi-
mode fiber optic cabling or traditional
Category 5 cabling. Mix and match both
fiber and copper Gigabit media, leverag-
ing optional Gigabit switching modules
for cost-effective performance in a
simple, integrated platform.
