3D LabPrint LW Planes Series User manual

page 1
... print your plane | www.3DLabPrint.com
Fully 3d printable
VL Pyörremyrsky
scale 1:12, wingspan 850 mm / 33.5 inch
User Guide
rev. 2020/04

page 2
... print your plane | www.3DLabPrint.com
VL Pyörremyrsky
fully printable R/C plane for your desktop 3Dprinter
Fully 3D printable RC model of the finish attack plane, specially designed to meet ACES and
EPA aircombat requirements, but also as a cheap and easy to build RC model for everyday
flying. Many scale details such as armament, airframe plating or exhausts encourages to
create realistic paint jobs. This plane has been designed for printing from foaming LW-PLA
filament, that allow even the small printed planes to be as light as any other RC plane build-
ing technique. Get ready for battle with this great performing flying legend!
The first fully printable airplanes with files prepared for your 3Dprinter, with
flight characteristics, comparable or even supperior to classic build model airplane.
This is not a dream, now you can print this HI-TECH at home. Simply download and print
the whole plane or spare parts anytime you need just for a cost of filament only about $16
Extensive hi-tech 3d structural reinforcement making the model very
rigid while maintaining a lightweight airframe and exact airfoil even it’s just a plastic. This
perfect and exact 3d structure is possible only thanks to additive 3dprinting technology. So
welcome to the 21st century of model flying and be the first at your airfield.
Easy to assembly, you don’t need any extra tools or hardware, just glue printed
parts together and make pushrods for control surfaces. The rest of the assembly is very
easy. Simply add brushless motor, ESC, servos and radio system. Don’t worry, detailed step
by step PDF/VIDEO is included.
You’ll get a superb performing airplane with highly ecient powerplant capable of flying
7+ minutes at full throtle and speeds exceeding 80 kph. Low stall speed is achieved for easy
landing on the other hand.

page 3
... print your plane | www.3DLabPrint.com
General specifications (HP setup):
Wingspan: 850 mm / 33.5 inch
Lenght: 750 mm / 29.5 inch
Height: 170 mm / 6.7 inch
Wing area: 15,9 dm2 / 1.61 square foot
Wing loading: 31 g/dm2 / 15.3 oz/square foot
Center of gravity: 60 mm / 2.34 inch
from leading edge
Airfoil: LHK508 modified by 3DLabPrint
Print weight (LW PLA): 224 g / 7.90 oz
Empty weight (w/o battery): 380 g / 13.40 oz
Takeo weight (3s 1300 lipo): 500 g / 17.63 oz
Max takeo weight: 700 g / 24.70 oz
Never exceed speed, VNE: 100 km/h / 62 mph
Design maneuvering speed, VA: 50 km/h / 31 mph
Stall speed, VS: 15 km/h / 9.4 mph
Recommended setup
Motor: Leopard LC2830 980KV (for 3S setup)
ESC: Turnigy 20A / 3S or similar
Propeller: two blade GWS 9 x 7,5 (ugly orange)
Battery: LiPol 1300mAh / 3s
printed PET motor mount
Performance measurement
Max speed VH (level flight): 105 km/h – 56.7kn – 65.2mph with GWS 9x7,5
Rate of climb: 20 m/s (5 373 ft/min) with GWS 9x7,5
Flight time (3s 1300mAh/full): 7:30 with GWS 9x7,5

page 4
... print your plane | www.3DLabPrint.com
VL Pyörremyrsky (Wooden Messerschmitt), History
On 26 November 1942 the Finnish Air Force ordered two Pyörremyrsky prototypes to be built.
The aircraft were to be ready by May 1944. One prototype was later cancelled and only one
aircraft was ever built. The aircraft designation VMT Pyörremyrsky is also sometimes used,
as the factory had been formed into the State Metal Factories (Valtion Metallitehtaat) during
the construction of the aircraft. The Finnish Air Force airplane code letters PM gave the plane
nickname Puu-Mersu (Wooden Messerschmitt), but the plane was an independent design.
The use of wood in the construction of the aircraft was maximized due to the scarcity of metals.
The goal was to create a fighter with similar flight qualities to the German Messerschmitt
Bf 109G. The engine and the propeller were taken from the Bf 109G. The Pyörremyrsky
prototype PM-1 made its first flight on 21 November 1945 at Härmälä, piloted by Esko Halme.
The Pyörremyrsky design was considered quite successful. It could outclimb the Bf 109G-6
and it was very manoeuvrable. It was considered almost ready for mass production. Its only
major problem with the design was found to be the low-quality glue used in the joints.
The aircraft was still in the prototype stage when the war ended and this also meant that the
funds allocated for the project decreased. The Pyörremyrsky prototype was grounded after
only some 30 hours of flying and the programme terminated. The wing construction was
later used in another Finnish aircraft, the all-metal Valmet Vihuri trainer.

page 5
... print your plane | www.3DLabPrint.com
Included:
1. STL 3d files
Universal STL files designed to be used with desktop FDM 3d printers and slicer software
as Simplify3D (recommended), CURA or MatterControl (these STLs are not compatible with
Slic3r).
2. Factory files for Simplify3D slicer - preered
contains all the necessary settings to slice the models along with suggested bed layout. We‘re
using PRUSA i3 ORIGINAL printers so you may need to adjust the basic printing parameters
to match your printer or use these files as a start point for you. Please check the Simplify3D
3. Step By Step PDF/VIDEO userguides
Apart from this userguide, please see the Printing Guide to find some Tips and Advice for
airplane printing (Thin Wall Printing).
4. Gcodes
Basic Gcodes prepared for direct use, as universal as possible. Should work on i3 style printers,
Give it a try, but we can‘t guarantee it will work on your printer.

page 6
... print your plane | www.3DLabPrint.com
5. Slice on your own with CURA or MatterControl slicers
If you for any reason don‘t like Simplify3D, there is always option to use another free slicer
Please follow our Cura guide in the Help section of the website where you can find the basic
single-wall profile. Remember: We use 0 retraction with LW-PLA.
6. Scale markings PDF
You could cut this PDF in scale from thin self adhesive advertisement foil and place it on the
model as needed.

page 7
... print your plane | www.3DLabPrint.com
Lenght: 750 mm / 29.5 inch
Wing area: 15,9 dm2 / 1.61 square foot
VL Pyörremyrsky
Centre of Gravity
60 mm

page 8
... print your plane | www.3DLabPrint.com
Wing span: 850 mm / 33.5 inch

page 9
... print your plane | www.3DLabPrint.com
Step By Step PDF/VIDEO userguide
1.Choose airplane at www.3Dlabprint.com, visit our Facebook for latest info.
Basic requirments for VL Pyörremyrsky are 195/195/195
mm volume, nozzle 0.4mm recommended (0.35 or 0.5mm
alternativelly). Heated bed recommended. Designed to be
printed with LW PLA filament by Colorfabb.
Contact: [email protected]
2. Create account, download
You will receive download link to all the zipped files to your email (please check your spam
folder if not) or you can log in to your account and download directly from our websites.
3. Gcodes preparing
option A Gcodes:
if your printer is i3 comptatible you can use prepared gcodes directly. Just save them to the
SD card and let the 3d printer do it‘s job. HE temperature is set to 230°C so the layers fuse
together well, you can adjust speed and temperature only through your printer‘s LCD. If these
Gcodes does not work for you, please proceed to the next options.

page 10
... print your plane | www.3DLabPrint.com
option B Factory files Simplify3D (recommended):
We prepared all you need in these files (FFF process settings, parts layout on bed, etc...)
You can use these settings as a start point. Adjust according to your need (adapt for your
printer), print single parts and so on... Most 3d printers should work just with these settings,
but please go through the settings and amend if necessary, we are not liable for any damage
resulting from using our settings. If this still does not work for you, please proceed to the
next option.
option C Simplify3D manual setting (watch and learn):
Use our video guide 2 and check our Simplify3D reference guide for proper setting... this
is very good option and you will learn a lot about Simplify3D and become an 3d printing
expert. Remember: We use 0 retraction with LW-PLA.
AND... please watch our VideoGuides:
video 2 Simplify3D setting
video about Thin Wall Printing (normal PLA)

page 11
... print your plane | www.3DLabPrint.com
option D CURA or MatterControl
MatterControl and CURA are free and provide satisfactory results. The airframe is still strong
enough, but don‘t expect the best quality. Both slicers lacks some very useful features, and
finer settings, like multiple processes according to Z height, retraction options, layer start,
etc.
Please try to find the best extrusion multiplier and temperature for good weight and best
possible layer bonding. Look at parts weight list for proper multiplier settings.
As a starting point you can use our predefined CURA or MC slicer setting file - see below
(always adapt it for your printer, change build volume, filament diameter, etc...
according to your printer!!!)
Please check our CURA guide on the website for the latest basic profile. Please visualise our
presliced gcodes to see how the result should look like and try to achieve the same in your
slicer. Remember: We use 0 retraction with LW-PLA.
Please watch our VideoGuides...

page 12
... print your plane | www.3DLabPrint.com
4. Print it
Save the Gcodes to the SD card and insert into your printer. Prepare your printer and start
printing, we prefer to use SD card rather than direct USB connection. Scaling the model will
lead to unusable result!
you will need: LW PLA filament - (by ColorFabb)
3DLac, Strong hair spray, PEI or your favorite adhesive bed surface
Razor blade
AND... please watch our VideoGuides:
video printing guide
Basic Tips and Advice
While stadard PLA filament could be used, this plane has been designed to be printed from
foaming LW-PLA by ColorFabb that means about 50% weight reduction on printed parts.
Please Experiment with temperature and extrusion multiplier. Hotend temperature is very
important (220° up to 260° celsius). The temperature determines, how much the LW-PLA
foams while printing. Cranking up temperature means, you can go loweron multiplier as the
material will gain on volume. Turn OFF cooling fan for better layer adhesion (HE fan should be
ON). We dont need it for thin wall printing. Heated bed is very recommended, 55-60° Celsius
(to prevent warping ends).
Price of the LW-PLA may look a bit steep at first glance, but since we’re using 50% less material
thanks to the foaming feature, the cost dierence is not so high as it looks.
LW-PLA by ColorFabb comes in two colours. White and Black. We found no dierence in
printing of both colours, but the black colour will probably attract the sunrays more, causing
warping of the thin wall surface. There are many 3d printers on the market, most of them are
capable of printing our airplanes (specific thin wall printing...) suficient volume, heated bed,
0.4mm nozzle.
Please see the Printing Guide (FAQ):

page 13
... print your plane | www.3DLabPrint.com
Enjoy the fun together!
VL Pyörremyrsky is the first of new LW Planes
series designed for easy and cheap flying. The
build is simple even for a beginner. It’s very
low weight, easy assembly and fantastic flight
characteristics makes this model an ideal plane
for beginner RC pilots.
Very suitable for dads and kids. Children will learn
some modern building skills and technology and
most of all have fun. This is the reason, why every
dad should have a 3D printer at home.
This model has been completely designed with a
new LW PLA material by ColorFabb in mind.
Parts printed from this LW PLA are light, easily
sanded and glued together. This model requires
only about 220 g of this material, that means it’s a
very cheap build. In case of accident, parts can be
easily reprinted with just a filament cost.
We’ve been testing this material for half a year
before this plane was released... The material is
using an active foaming technology to achieve
lightweight, low density PLA parts. At around
230°C this material will start foaming, increasing
its volume by nearly 3 times.
All parts of this plane should be printed from LW-
PLA.
Possibly VL Pyörremyrsky can be printed from
normal PLA but the plane will be too heavy for
relaxed flying. Standard PLA printed model
therefore could not be recommended for
beginners. You should use heavyer battery also to
compensate Center of Gravity of the plane in this
case.
VL Pyörremyrsky
weights of printed parts
fuselage LW PLA
F1 24 g
F2 19,4 g
F3 12,5 g
F4 9,2 g
fuselage cover 1 4,2 g
fuselage cover 2 3 g
fuselage cover arm 2,8 g
wing
wing L1 29,3 g
wing L2 17 g
wing L3 2,7 g
wing R1 29,3 g
wing R2 17 g
wing R3 2,7 g
aileron L1 1,6 g
aileron L2 3,3 g
aileron L3 4,5 g
aileron R1 1,6 g
aileron R2 3,3 g
aileron R3 4,5 g
tail
stabiliser L1 4,6 g
stabiliser L2 1 g
stabiliser R1 4,6 g
stabiliser R2 1 g
elevator L1 4,8 g
elevator L2 0,5 g
elevator R1 4,8 g
elevator R2
elevator arm (PLA) 1,1 g
rudder 4,0 g
accessories
motor mount (PLA) 6,5 g
spinner (PLA) 4,8 g
all printed parts 224,8 g

page 14
... print your plane | www.3DLabPrint.com
How to print LW-PLA?
The basic print setup is almost the same as we use for standard
PLA. The only dierence is in extrusion multiplier set to 0.5 and
turning o the retractions completely.
This results in parts with half the weight and still suitable
mechanical properties, but expect some heavy stringing inside
and outside. Of course you can try to tweak the retractions for
less stringing inside the parts, but there‘s a high risk of clogging
the nozzle or throat. Increasing the retraction distance above
1 mm is not recommended at all and leads to nozzle clogs
caused by foaming. Cleaning the hairy, but functional parts
after printing with retractions completely disabled seems to be
more ecient method. The nozzle is permanently pressurized
and you don‘t need to worry about print failures. This method
works fine even for bowden printers.
Extrusion multiplier 0,5 has been tested for easy print with
massive weight saving around 50%. Feel free to experiment
with extrusion multiplier and temperatures at will for the best
results on your printer.
Cosmetic issues of the prints are easily fixed with snap knife or
sand paper, as the LW is easily sanded and cut.
See video guide #4.1 (clearing LW-PLA parts)
Ocial guide by ColorFab - How to print LW-PLA
colorFabb B.V.
The Netherlands
LW-PLA
shop:
https://colorfabb.com/
lw-pla-natural
email sales:
[email protected]
email support:
[email protected]
Video of print LW-PLA

page 15
... print your plane | www.3DLabPrint.com
5. Assembly of printed parts
5.1 Wing assembly VL Pyörremyrsky
Glue wing parts L1-L3 perfectly together. The new 3DLabPrint lock system will help you.
Repeat for the right side. Glue both halves of the wing together. Use the CA glue, (position
locks and wing pins will help you to align the parts), and use activator to speed up the glue
curing.
On a flat surface glue the ailerons L1-L3 and repeat for the right side. Use a suitable 0,8mm -
1,2mm carbon rod or wire as a hinge for the ailerons. Just slide it in, there‘s no need to glue
the hinge for easy aileron or servo replacement.
See video guide #4.2
you will need: CA Glue medium viscosity + activator
0,8 - 1,2 mm carbon, fiberglass or steel wire for aileron hinge
Snap knife, Some cloth for wiping CA glue...
wing L1
29,3g/1.03oz LW
wing pins
PLA
wing L2
17g/0.59oz LW
wing L3
2.7g/0.09oz LW
aileron L1
1,6g/0.06oz LW aileron L2
3,3g/0.11oz LW
aileron L3
4,5g/0.16oz LW
R wing
completed

page 16
... print your plane | www.3DLabPrint.com
5.2.1 Fuselage assembly VL Pyörremyrsky
You can use snap knife for cleaning the surface of printed parts, but mostly it is not necessary.
Glue fuselage parts F1-F4 with CA glue together. The new 3DLabPrint lock system will help you.
Zkontrolujte kolmost dílu F4 na uložení křídla dílů F1 a F2 před zalepením. Do not glue rudder
part before tail and elevator assembly. Use any hot tool to remove the unnecessary material
from F4 tail part for the elevator arm.
Insert two 90 mm long 3 mm diameter carbon rods making a rubber band wing holders. No
need to glue it for easy replacement.
For fuselage cover arm use a ball pen spring. Put it to the part 2 and glue with part 1 together.
NOTE: Don‘t glue the rudder tailpart yet !!! (proceed to the next step for elevator and stabilizer
assembly)
See video guide #4.3
you will need: CA Glue medium viscosity + activator
Snap knife or Sandpaper, Soldering Iron or any hot tool + hot glue
2x 90mm of 3mm carbon or fiberglass rod
F1
24g/0.84oz LW
F2
19,4g/0.68oz LW
F3
12,5g/0.44oz LW
F4
9,2g/0.32oz LW
ball pen spring
motor mount
6,5g/0.23oz PLA
spinner
4,8g/0.17oz PLA
cover 1
3g/0.10oz LW
cover arm
1g/0.03oz LW
2,8g/0.10oz PLA
cover 2
4,3g/0.15oz LW

page 17
... print your plane | www.3DLabPrint.com
5.2.2 Fuselage tail - elevator pushrods and servos
Glue L1 and L2 parts of the stabilizer and elevator. The profile is symmetric, so the left and
right sides are identical. Glue the stabilizers perfectly perpendicular to the fuselage. Assemble
both sides of the elevator with the elevator control lever on a flat surface. Make a Z bend on
the elevator 0,8 mm pushrod wire. Using hot tool cut loose the hinge of the elevator on the
F4 part of the fuselage and mount the elevator assembly to the stabilizer using the 0,8 - 1,2
mm carbon rod or steel wire. Elevator should move freely controlled by the pushrod and
servo. Check the functionality of the elevator assembly carefully and finally glue in the rear
rudder part.
you will need: CA Glue medium viscosity+ activator
0,8 - 1 mm steel wire for elevator pushrod
0,8 - 1 mm carbon or steel wire for aileron hinge
Snap knife, Soldering Iron or any hot tool
See video guide #4.4
stabiliser L1
4,6g/0.16oz LW
elevator L1
4,8g/0.17oz LW
elevator L2
0,5g/0.03oz LW
elevator arm
normal PLA!
1,1g/0.09oz
elevator arm
normal PLA!
stabiliser L2
1g/0.07oz LW
rudder
4,0g/0.14oz LW

page 18
... print your plane | www.3DLabPrint.com
6. Servo installation
Cut loose the servo holder ears on aileron servos. Install the prepared servos to wing servo
bays. Use a 1mm steel wire with Z bends as a linkage between the servos and aileron control
horns. Elevator servo will be fixed by servo holder or directly glued in the fuselage.
See video guide #5
you will need: 3x HXT900, or opt1, opt2, opt3
or any similar sized servos
23x12x26 mm / 0.74x0.42x0.78 inches
Snap knife, Z pliers
7. Motor & ESC & battery holder
Fix the battery by velcro tape and mount it in the front of the fuselage, find the perfect balance
and CG position by moving it. Mount the motor using 4x M3 screws and nuts to the printed
universal motor holder 16 x 19mm. For long motors you can flip the holder to the front (as at
picture). Glue universal motor mount with motor into the fuselage in right position.
See video guide #6
you will need:
4x M3 screws and nuts
LW planes setup
(230W)
Motor: any 2830 1000KV, opt1, opt2, opt3, opt4... or similar
ESC: any 20A/3s, opt1, opt2, opt3, opt4... or similar
Propeller: two blade GWS 9 x 7,5 (ugly orange) or opt1, opt2, opt3
Battery: 1300mAh/3s, opt1, opt2, opt3, opt4, opt5
Batt. connector: XT60 or Gold Conn
printed PLA mount 16 x 19 mm

page 19
... print your plane | www.3DLabPrint.com
8. Painting/marking and Final assembly/setting
See video guide #7
Refer to your R/C system userguide for setup information.
See video guide #8
you will need: Your own Rx/Tx system
Install your reciever, connect battery, setup servos and etc. with your trasmitter, check servo
position, then install propeller, the supplied spinner guarantees proper cooling of the motor
and mount.
Make sure the battery is positioned properly and secured with wing battery holder, if battery
moves during flight it can shift the center of gravity backwards and aircraft will become
uncontrollable! Never set ESC with propeller installed, this could be very dangerous!
9. Go flying
Pre-flight check center of gravity is very important (move it 5mm forward for the first flights),
battery properly charged, ailerons and elevator deflection check, your own flying skills or RC
simulator training ...
Flyght video of VL Pyörremyrsky
aileron elevator
+15mm +15mm
-12mm -15mm

page 20
... print your plane | www.3DLabPrint.com
10. Pilots Please Attention!
For the first flights we recommend setting the center of gravity to around 5 mm forward of
the CG tag - nose heavy, this increases the stability (you can use heavier battery). Increasing
expo settings on your transmitter for elevator and ailerons to 80 % calms response from your
stick inputs. Also you can decrease elevator and ailerons deflection to calm down the plane.
Make sure the battery is well fixed in proper possition. If it moves during flight it will cause
shifting of CoG aft and will result in uncontrolable flight behavior.
After gaining some confidence you can balance the plane to the Center of Gravity marks and
set Expos to 60 % as shown in the video/instructions... this gains back extra maneuverability.
Never fly aft positioned Center of gravity.
Please, use these files only for your own purpose, do not
redistribute or publish. Thank you very much.
Enjoy your flight.
