WARNING
• All users must read and understand the instructions prior to using this system.
• If you have any questions or concerns on the usage, care, or suitability of this equipment, please contact 3M before using it.
•
This product is approved for use with retractable devices only with a MAXIMUM ARRESTING FORCE (M.A.F.)
RATING OF
900 lb (4 kN)
OR LESS.
• SYSTEM CAPACTITY 310 lb (141 kg) PER USER including tools, clothing, etc.
• Do not exceed the maximum number of users rating.
• Only one user allowed per anchor point.
• All three leveling jacks must be firmly contacting the ground prior to use. For soft terrain, jack support pads must be used.
• System must be level within 1° (side to side & front to back) prior to use.
• Do not exceed the recommended safe working radius of 6’
work within the safe working area may cause serious injury
or death.
See figure 1.
• Hazardous voltage will cause serios injury or death. Keep
mast and offset arms a minimum of 10’ (3 m) away from
power lines.
• Supporting structures for this system must be certified
and capable of supporting the entire weight of the
configured system in addition to any loads that could
potentially be introduced in the event of arresting a fall.
• Do not use this system if the lift winch brake wear
indicator is pointing in the red under load
(while raising system). See figure 2.
• Do not transport this system when in the raised position.
• Secondary mast lock must be engaged during use.
• Do not over extend the vertical mast assembly.
Over extension of the vertical mast assembly will cause
serious damage to the height adjustment mechansim.
9520789 REV B
APPROX. SYSTEM WEIGHT: 5,700 lbs. (2,585 kg)
SELF RETRACTING
LIFELINE (SRL)
6 FT MAX. WORKING
RADIUS FROM
ANCHOR POINT
30° MAX SAFE
WORKING
ANGLE FROM
TROLLEY
ANCHOR
POINT
SAFE
WORKING
CONE
THIS MAN-RATED SYSTEM IS DESIGNED
FOR A MAXIMUM OF
USER CAPACITY IN ACCORDANCE WITH
MANUFACTURER’S INSTRUCTIONS.
FAILURE TO COMPLY MAY RESULT IN
SERIOUS INJURY OR DEATH.
Max. Highway Speed: Rated for Posted Highway Speeds on Smooth Roads
Max. Offroad Speed: 10 mph (16 kph)
Minimum Required Overhead Clearance: 13’-6” (4.2 m)
Ground Clearance: 12” (305 mm)
PERSONS
2
IMPORTANT
FIGURE 2
Arrow should
be in green when
under load.
If arrow is pointing
in red remove
fromservice
immediately.
BRAKE WEAR
INDICATOR
8523327
Rev.C.
Arrow should
be in green when
under load.
If arrow is pointing
in red remove
fromservice
immediately.
BRAKE WEAR
INDICATOR
8523327
Rev.C.
TRAILER MOUNTED FALL ARREST SYSTEM
OSHA
MANUFACTURER CERTIFES
CONFORMANCE TO
APPLICABLE STANDARDS
FIGURE 1
