3One data IAP2300F-2N2-5T-PDP12 36 User manual

IAP2300F-2N2-5T-PDP12_36
2.4G wireless single-band AP
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Song Bai Road, Nanshan
District, Shenzhen, 518108, China
Website:
www.3onedata.com
Te l :
[phone]
Fax:
[phone]
【Package Checklist】
Please check whether the package and accessories are intact
while using the industrial wireless AP for the first time.
1.
Wireless AP x1
2.
WIFI antenna x2
3.
Warranty card
4.
Certification
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
The product is an industrial 2.4G wireless single-band AP. Its
model is IAP2300F-2N2-5T-PDP12_36 (2 WIFI IPEX-1
generation antenna pedestal + 4 100M LAN + 1 100M WAN +
1 12~36VDC power supply).
【Panel Design】
Front View
Rear View
Right view
Top view
1. 100M WAN port
2. 100M LAN port
3. System running indicator RUN
4. Power supply indicator PWR
5. 2.4G wireless indicator WIFI
6. Signal strength indicator Bridge
7. Reset button
8. Power supply input terminal block
9. WIFI IPEX-1 generation antenna pedestal
【Mounting Dimension】
Unit: mm
Notice before mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Power Supply Connection】
The device provides 1 DC power input, interface
is 3-pin 5.08mm pitch terminal blocks, power
supply supports anti-reverse connection and
1.5kV isolation protection. Voltage range: 24VDC
(12~36VDC). Its pin definitions are as follows:
PIN
1
2
3
Definition
V+
FG
V-
Notice:

Power ON operation: First insert the power supply
terminal block into the device power supply interface,
and then plug the power supply plug contact and power
on.
Power OFF operation: First, remove the power plug,
and then remove the wiring section of terminal block.
Please pay attention to the above operation sequence.
【Reset Button Setting】
This device provides 1 reset button, press the button
for 1-2S then release it to reboot the device; press the
button for 5S then release it to restore factory defaults.
【Checking LED Indicator】
The device provides LED indicators to monitor the device
working status with a comprehensive simplified
troubleshooting; the function of each LED is described in the
table as below:
LED
Indicate
Description
WIFI
ON
WIFI is running normally
OFF WIFI is running abnormally
or closed
RUN
ON The device is powered on
or the device is abnormal.
OFF The device is powered off
or the device is abnormal.
Blinking
The device is running
normally
PWR
ON
PWR is connected and
running normally
OFF PWR is disconnected and
running abnormally
Bridge
OFF
No bridging is established
ON
The strength of bridging
signal is 70~100dBm
1 time/1s Blinking
The strength of bridging
signal is 30~70dBm
1 time/2s Blinking
The strength of bridging
signal is 1~30dBm
【
Logging in to WEB Interface
】
This device supports WEB management and configuration.
Computer can access the device via LAN. The way of logging
in to device’s configuration interface via IE browser is shown
as below:
Step 1 Configure the IP addresses of computer and the
device to the same network segment, and the
network between them can be mutually accessed
Step 2 Enter device’s IP address in the address bar of the
computer browser.
Step 3 Enter device’s user name and password in the
login window as shown below.
Step 4 Click “Login” button to login to the WEB interface of
the device.
Note:
The default IP address of the device is “192.168.1.254”.
The default user name and password of the device is
“admin”.
If the user name or password is lost, user can restore it
to factory settings via restore button or management
software; all modified configurations will be cleared
after restoring to factory settings, so please backup
configuration file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Standard
Standard IEEE802.3、IEEE802.3u、
IEEE802.11b/g/n、
IEEE802.11i
、
IEEE802.11r
Panel
Copper Port 5 10/100Base-
T(X) RJ45
ports: 4 LAN + 1 WAN.
Antenna pedestal 2 WIFI IPEX-
1 generation
antenna pedestals, RP-SMA-K
type (Female), support 1.5kV
isolation protection
Indicator
Signal indicator, Running
indicator, Power supply
indicator, 2.4G wireless
indicator
WIFI Transmission Rate
802.11n
6.5~300Mbps
802.11b
11/5.5/2/1Mbps
802.11g
54/48/36/24/18/12/9/6Mbps
WIFI RF
Channel
2.412GHz~2.4835GHz
RF power output
23dBm
Modulation scheme DBPSK, DQPSK, CCK,
OFDM, 16-QAM, 64-QAM
WIFI Receiving
Sensitivity
802.11n_HT40 -82dBm@MCS0、
-64dBm@MCS7
802.11n_HT20 -85dBm@MCS0、
-67dBm@MCS7
802.11g -91dBm@6Mbps、
-72dBm@54Mbps
802.11b -93dBm@1Mbps、
-87dBm@11Mbps
WIFI Transmission

Power
802.11n_HT40 23dBm@MCS0、
20dBm@MCS7
802.11n_HT20 23dBm@MCS0、
20dBm@MCS7
802.11g 23dBm@6Mbps、
20dBm@54Mbps
802.11b 23dBm@1Mbps、
23dBm@11Mbps
Power Supply
Input power supply Support DC power input,
voltage range: 24VDC(12 ~
36VDC), support anti-reverse
connection, support 1.5KV
isolation protection
Access terminal block 3-
pin 5.08mm pitch terminal
block
Power Consumption
Power
≤4.6W@24VDC
Working Environment
Working temperature
-40~75
℃
Storage temperature
-40~85
℃
Working humidity
5%
～
95% (no condensation)
